IDW G-6-C23EB User manual

G-Series Cooler
Instruction Manual
G-6c/GCG-6c
BEVERAGE COOLER
Manual is for the following models:
G-6-C23EB
GCG-6-C23EB,
G-6-CB23EB,
GCG-6-CB23EB

Innovative DisplayWorks
G-6c
GCG-6c
Instruction Manual
Manual is for the following models:
G-6-C23EB
GCG-6-C23EB,
G-6-CB23EB,
GCG-6-CB23EB

Innovative DisplayWorks
G-6c/GCG-6c
FOR YOUR FUTURE REFERENCE
• This easy-to-use manual will guide you in getting the best use of your cooler.
• Remember to record the model number and the serial number. This information can be found on the
inside of your cooler.
• Keep your receipt with this manual for future warranty service.
Model #:
Serial #:
Date of Purchase: TABLE OF CONTENTS
Parts and Identication ......................................... 2
Safety Instructions................................................. 3
Installation ........................................................... 3
Electric Connection ................................................ 3
Start ..................................................................... 3
Light Control ......................................................... 3
Maintenance......................................................... 4
Cleaning ............................................................... 4
Condenser Maintenance ........................................ 4
Light Replacement................................................. 4
Power Failure........................................................ 4
Moving the cooler.................................................. 4
Drip Pan ............................................................... 4
Troubleshooting .................................................... 5
Refrigerant ........................................................... 5
Switch Function..................................................... 6
Flammable R600a Warnings ................................. 6
Circuit Diagram..................................................... 7
1

Instruction Manual
Innovative DisplayWorks
2
SAFETY INSTRUCTIONS
To reduce the risk of  re, electric shocks, or injury when using your cooler, please note the following basic precautions:
• Never clean appliance parts with fl ammable fl uids.
• Do not store or use gasoline or any other fl ammable vapors and liquids in the vicinity of this or any other appliance.
The fumes can cause a  re or explosion.
• As with all electrical appliances, please consult a licensed repair technician for any repairs.
INSTALLATION
• Keep cooler in an upright position for 1-hour prior to use. This is essential for proper operation. If the cooler is
transported in the horizontal position, the cooler must be returned to the upright position and not plugged in for 1
hour.
• Remove all the packing material before using your cooler.
• Clean the interior surface with a soft cloth and lukewarm water.
• If the cooler is transported in the horizontal position, check the drain pan and ensure that it is properly positioned
above the compressor.
• For proper operation, place the cooler on a dry, level surface.
• Place the cooler at least 4” away from any walls. Otherwise, this could cause damage to the electrical cord and block
the air circulation to the appliance.
• Do not block the air intake that ventilates the condenser unit.
ELECTRIC CONNECTION
• This model operates with an 115V/60Hz power supply. Check the electrical outlet for proper voltage.
• Warning: Plug unit directly into wall outlet. Do not use an extension cord or any other multiple connectors. Do not
use an extension cord or any other multiple connectors, this could cause compressor failure.
• For your safety, plug the unit into a grounded wall outlet.
START
• Plug the cooler into the electrical outlet. For optimum performance, run cooler for 3 hours prior to use.
• Temperature Control: Do not adjust the temperature control. The temperature control is factory set to provide
maximum performance. If really necessary, you can turn the thermostat by screw driver clockwise to have lower
temperature inside the cooler
LIGHT CONTROL
• The inside light is controlled by the magnetic switch.
BEFORE USING, PLEASE READ ALL INSTRUCTIONS
Innovative DisplayWorks
offi ce 909.447.8254 • fax [phone] • toll free 877.307.2665 • www.idw.global
1. Cabinet
2. Leveling Leg (4)
3. Lockpin
4. Evaporator
5. Return Pipe
6. Evaporator Fan
7. Evaporator Fan Grill
8. Evaporator Plate
9. Large Shelf
10. Shelf (2)
11. Pilasters (4)
12. Shelf Clips (12)
13. Door Gasket
14. Glass Door
15. Lock
16. Key
17. Bottom Hinge Washer
18. Bottom Hinge Board
19. Top Hinge
20. Light Cover
21. Canopy Bottom Frame
22. Fan Switch
23. Canopy Right Side
24. Fixation Board for Light
25. LED Light (4)
26. Canopy Top Frame
27. Canopy Left Side
28. Fixation of Inner Lampshade (2)
29. Interior Light Bracket
30. Top Board Bracket
31. Cabinet Top Cover
32. Compressor
33. Compressor Base
34. Power Cord
35. Thermostat Box Cover
36. Thermostat Box
37 Light Switch (G-6c: 1) (GCG-6c: 2)
38. Thermostat
39. Thermostat Label
40. Filter Drier
41. Filter Drier Bracket
42. Thermostat Box (Small)
43. Evaporator Fan Transformer
44. Power Supply Board
45. Power Supply Board Bracket
46. Transformer Box (Large)
47. Transformer
48. Power Cord Holder
49. Junction Box
50. Condenser
51. Condenser Bracket (4)
52. Connecting Pipe
53. Drip Pan
54. Drip Pan Bracket
55. Rear Grill
PARTS & IDENTIFICATION
Last Revised: July 23, 2015 1:06 PM
G-6c & GCG-6c

Innovative DisplayWorks
G-6c/GCG-6c
3
SAFETY INSTRUCTIONS
To reduce the risk of  re, electric shocks, or injury when using your cooler, please note the following basic precautions:
• Never clean appliance parts with fl ammable fl uids.
• Do not store or use gasoline or any other fl ammable vapors and liquids in the vicinity of this or any other appliance.
The fumes can cause a  re or explosion.
• As with all electrical appliances, please consult a licensed repair technician for any repairs.
INSTALLATION
• Keep cooler in an upright position for 1-hour prior to use. This is essential for proper operation. If the cooler is
transported in the horizontal position, the cooler must be returned to the upright position and not plugged in for 1
hour.
• Remove all the packing material before using your cooler.
• Clean the interior surface with a soft cloth and lukewarm water.
• If the cooler is transported in the horizontal position, check the drain pan and ensure that it is properly positioned
above the compressor.
• For proper operation, place the cooler on a dry, level surface.
• Place the cooler at least 4” away from any walls. Otherwise, this could cause damage to the electrical cord and block
the air circulation to the appliance.
• Do not block the air intake that ventilates the condenser unit.
ELECTRIC CONNECTION
• This model operates with an 115V/60Hz power supply. Check the electrical outlet for proper voltage.
• Warning: Plug unit directly into wall outlet. Do not use an extension cord or any other multiple connectors. Do not
use an extension cord or any other multiple connectors, this could cause compressor failure.
• For your safety, plug the unit into a grounded wall outlet.
START
• Plug the cooler into the electrical outlet. For optimum performance, run cooler for 3 hours prior to use.
• Temperature Control: Do not adjust the temperature control. The temperature control is factory set to provide
maximum performance. If really necessary, you can turn the thermostat by screw driver clockwise to have lower
temperature inside the cooler
LIGHT CONTROL
• The inside light is controlled by the magnetic switch.
BEFORE USING, PLEASE READ ALL INSTRUCTIONS

Instruction Manual
Innovative DisplayWorks
MAINTENANCE
Cleaning
• Before cleaning the appliance, always remember to unplug it.
• Unplug the cooler at the electrical outlet; never pull the service cord.
• Do not use sharp or pointed objects for cleaning.
• Clean the inside cabinet of the cooler with a clean damp cloth. Avoid damage by using non-abrasive and non-
fl ammable cleaning products.
• Clean the condenser at least once a month with a vacuum cleaner or a brush to
eliminate the dust accumulation.
Light Replacement
• Unplug the cooler before removing the LED light strip.
• Remove the screws.
• Remove the light cover gently.
• Take out the LED light strip.
• Replace the used strip with new equivalent light strip.
• Install the light cover and tighten the screws.
• Plug in the cooler.
Power Failure
• Please minimize the frequency of opening the door during a power failure.
• If your cooler is unused for an extended period of time, unplug, empty, and clean your cooler and keep the door open
to avoid condensation, formation of mold, or odors.
Moving The Cooler
• Empty the unit.
• Secure all loose parts inside the cooler.
• Tape the door shut.
• During transportation, make sure that the cooler is in an upright position.
Drip pan
• During normal compressor cycle, water will drain into the drain pan and evaporate.
• To clean, gently pull the drain pan towards you and remove. Slowly reinstall it after cleaning.
TROUBLESHOOTING
If your cooler is not working properly:
• Check the electrical outlet for power, and that the plug is properly inserted.
• Check to see if the circuit breaker is tripped or the fuse is blown.
• Check the condenser for proper cleaning.
If your cooler is making noise:
• Check that the cooler is level and on a fl at surface.
If the compressor turns on and off frequently:
• The room temperature is higher than normal.
• The door is not closed completely.
• The door gasket is not sealed well.
• There is insuf cient clearance around the cooler.
• The temperature is not set properly.
• The cycling frequency will reduce when all of the cans reach the set temperature.
The following is not a malfunction:
• It is normal to hear gurgling sounds caused by the fl ow of refrigerant when each cooling cycle ends.
REFRIGERANT
• The cooler utilizes R600a refrigerant.
SPECIFICATIONS
Model:
Power Supply (V/Hz):
Dimension (W x D x H):
Box Dimension (W x D x H):
Maximum Load Per Shelf:
NSF-7 Standard: This equipment is intended for the storage and display of non-potentially
hazardous bottled or canned products only.
4

Innovative DisplayWorks
G-6c/GCG-6c
TROUBLESHOOTING
If your cooler is not working properly:
• Check the electrical outlet for power, and that the plug is properly inserted.
• Check to see if the circuit breaker is tripped or the fuse is blown.
• Check the condenser for proper cleaning.
If your cooler is making noise:
• Check that the cooler is level and on a fl at surface.
If the compressor turns on and off frequently:
• The room temperature is higher than normal.
• The door is not closed completely.
• The door gasket is not sealed well.
• There is insuf cient clearance around the cooler.
• The temperature is not set properly.
• The cycling frequency will reduce when all of the cans reach the set temperature.
The following is not a malfunction:
• It is normal to hear gurgling sounds caused by the fl ow of refrigerant when each cooling cycle ends.
REFRIGERANT
• The cooler utilizes R600a refrigerant.
SPECIFICATIONS
Model:
Power Supply (V/Hz):
Dimension (W x D x H):
Box Dimension (W x D x H):
Maximum Load Per Shelf:
NSF-7 Standard: This equipment is intended for the storage and display of non-potentially
hazardous bottled or canned products only.
5
G-6c/GCG-6c
G-6c/GCG-6c Beverage Cooler
110V/60Hz
22.25” x 21.5” x 36.25”
25.5” x 232” x 38.25”
55 lbs.

Instruction Manual
Innovative DisplayWorks
6
SWITCH FUNCTION
For GCG-6c Models Only
Switch Status Inner LED Switch Door Logo Switch Remarks
I / I ON ON Illuminated fascia always remains On
I / O ON OFF Illuminated fascia always remains On
O / I OFF ON Illuminated fascia always remains On
O / O OFF OFF Illuminated fascia always remains On
FEATURES
• Designed with an elegant shape and quick refrigeration speed, this commercial-grade product is an ideal choice for
shopping malls, supermarkets, hotels, etc.
•Transparent glass doors are built with hollow, toughened glass that provides a high level of heat insulation. Clear
doors allow for high product visibility.
•The forced air system allows for fast cooling speeds, which helps maintain a consistent temperature.
• Adjustable shelves allow for a wide variety of products to be stocked.
•A built-in lock offers the ability to secure products.
•The refrigeration unit is designed for easy access, allowing for fast and simple repairs.
• This equipment is intended for storage and display of non-hazardous packaged product.
CAUTION FLAMMABLE REFRIGERANT
• DANGER – Risk Of Fire Or Explosion. Flammable Refrigerant Used. To Be Repaired Only By Trained Service
Personnel. Do Not Puncture Refrigerant Tubing.
• CAUTION – Risk Of Fire Or Explosion. Flammable Refrigerant Used. Consult Repair Manual/Ownerʼs Guide
Before Attempting To Install or Service This Product. All Safety Precautions Must be Followed.
• CAUTION – Risk Of Fire Or Explosion. Dispose Of Properly In Accordance With Federal Or Local Regulations.
Flammable Refrigerant Used.
• CAUTION – Risk Of Fire Or Explosion Due To Puncture Of Refrigerant Tubing; Follow Handling Instructions
Carefully. Flammable Refrigerant Used.
INSTRUCTIONS
Ambient Environment
•Place cooler on an even surface to reduce vibration and noise.
•To transport, do not tilt the cooler beyond a 45 degree angle.
•Do not place cooler in direct sunlight or near any heat sources.
• Do not place cooler in environment temperatures that exceed 109°F.
•Do not place cooler in below normal temperatures.
• Do not place cooler in extreme humid environments, this may cause components to rust.
•Do not place cooler near constant running or splattering water, this may cause immediate damage to refrigeration
system.
•Must allow at least 2” between rear of cooler and wall for proper ventilation and heat dissipation of cooler.
•Do not place furniture or other articles with sharp edges near the cooler in order to prevent damage to the glass door.
DANGER – Risk Of Fire Or Explosion. Flammable Refrigerant Used. To Be
Repaired By Trained Service Personnel Only. Do Not Puncture Refrigerant Tubing.
CAUTION – Risk Of Fire Or Explosion. Flammable Refrigerant Used. Consult
Repair Manual/Owner’s Guide Before Attempting To Service This Product. All
Safety Precautions Must be Followed.
CAUTION – Risk Of Fire Or Explosion. Dispose Of Property In Accordance With
Federal Or Local Regulations. Flammable Refrigerant Used.
CAUTION – Risk Of Fire Or Explosion Due To Puncture Of Refrigerant Tubing;
Follow Handling Instructions Carefully. Flammable Refrigerant Used.
CAUTION FLAMMABLE - R600a Refrigerant
DANGER - Risque d'incendie ou d'explosion. Réfrigérant inflammable utilisé.
Pour être réparé que par un personnel de maintenance qualifié. Ne pas percer
réfrigérant Tubing.
ATTENTION - Risque d'incendie ou d'explosion. Réfrigérant inflammable utilisé.
Consultez manuel / guide de l 'utilisateur de réparation avant de tenter de
réparer ce produit. Toutes les précautions de sécurité doivent être respectées.
ATTENTION - Risque d'incendie ou d'explosion. Aliéner des biens conformé-
ment à la réglementation fédérales ou locales. Réfrigérant inflammable utilisé.
ATTENTION - Risque d'incendie ou une explosion due à la perforation de
tuyaux de réfrigérant; suivre les instructions de manipulation avec précaution.
Réfrigérant inflammable utilisé.
PRUDENCE INFLAMMABLE - R600a Réfrigérant

Innovative DisplayWorks
G-6c/GCG-6c
CIRCUIT DIAGRAM
G-6c Models
GCG-6c Models
7

Innovative DisplayWorks, Inc.
To locate the distributor in your area go to: http://www.idw.global/contact/#distributors
G-Series Cooler
Instruction Manual
