IFM EIO344 User manual

Operating instructions EN
Bluetooth Mesh adapter
EIO344
80298783 / 00 08 / 2021

EIO344
Bluetooth Mesh adapter
2
Contents
1Preliminary note.............................................................................................................................. 3
1.1 Symbols used....................................................................................................................... 3
1.2 Warnings used ..................................................................................................................... 3
1.3 Safety symbols on the unit ................................................................................................... 3
1.4 Change history ..................................................................................................................... 3
2Safety instructions .......................................................................................................................... 4
2.1 Cyber security ...................................................................................................................... 4
3Intended use ................................................................................................................................... 5
4Connection possibilities .................................................................................................................. 6
4.1 IO-Link connection and outputs ........................................................................................... 6
4.2 Bluetooth .............................................................................................................................. 6
4.3 Bluetooth Mesh .................................................................................................................... 6
5Electrical connection....................................................................................................................... 7
5.1 Mounting the connector........................................................................................................ 8
5.2 Removing the connector ...................................................................................................... 8
5.3 UL application area .............................................................................................................. 8
5.4 Cable length ......................................................................................................................... 8
6Display elements, output response and troubleshooting ............................................................... 9
6.1 RGB indicators ..................................................................................................................... 9
6.2 RGB status indicator, output response and troubleshooting................................................ 9
7Parameter setting ......................................................................................................................... 10
7.1 Parameter setting via IO-Link using a PC: ......................................................................... 10
7.2 Parameter setting by means of a mobile device via Bluetooth .......................................... 10
7.3 Data storage on sensor side via M12 socket with moneo|blue .......................................... 11
7.3.1 Note: Device validation and data storage .................................................................. 11
8Parameters and commands ......................................................................................................... 12
8.1 Parameters and commands via IO-Link............................................................................. 12
8.2 Bluetooth parameters and commands ............................................................................... 13
9Set-up of the moneo configure application................................................................................... 15
9.1 Function moneo configure.................................................................................................. 15
9.2 System requirements ......................................................................................................... 15
9.3 Installation of moneo configure .......................................................................................... 15
9.4 Connection with a PC......................................................................................................... 15
10 Set-up of the moneo|blue application ........................................................................................... 16
10.1 moneo|blue’s functions....................................................................................................... 16
10.2 System requirements ......................................................................................................... 16
10.3 Installation of moneo|blue .................................................................................................. 16
10.4 Connect a mobile device .................................................................................................... 16
11 Copyright and trademarks ............................................................................................................ 17
12 Approvals and certificates ............................................................................................................ 18
13 Maintenance, repair and disposal ................................................................................................ 19

Bluetooth Mesh adapter
EIO344
3
1 Preliminary note
You will find instructions, technical data, approvals and further information using the QR code on
the unit / packaging or at www.ifm.com.
1.1 Symbols used
Requirement
Instruction
Reaction, result
[...] Designation of keys, buttons or indications
Cross-reference
Important note
Non-compliance may result in malfunction or interference
Information
Supplementary note
1.2 Warnings used
1.3 Safety symbols on the unit
Observe instructions in chapter Electrical connection!
1.4 Change history
Version
Subject
Date
00
New creation of the document
11/2021
NOTE
Warning of damage to property
CAUTION
Warning of personal injury
Slight reversible injuries may result.
WARNING
Warning of serious personal injury
Death or serious irreversible injuries may result.

EIO344
Bluetooth Mesh adapter
4
2 Safety instructions
•The unit described is a subcomponent for integration into a system.
–The system architect is responsible for the safety of the system.
–The system architect undertakes to perform a risk assessment and to create documentation
in accordance with legal and normative requirements to be provided to the operator and
user of the system. This documentation must contain all necessary information and safety
instructions for the operator, the user and, if applicable, for any service personnel
authorised by the architect of the system.
•Read this document before setting up the product and keep it during the entire service life.
•The product must be suitable for the corresponding applications and
environmental conditions without any restrictions.
•Only use the product for its intended purpose ( Intended use).
•If the operating instructions or the technical data are not adhered to, personal injury and/or
damage to property may occur.
•The manufacturer assumes no liability or warranty for any consequences caused by tampering
with the product or incorrect use by the operator.
•Installation, electrical connection, set-up, operation and maintenance of the product must be
carried out by qualified personnel authorised by the machine operator.
•Protect units and cables against damage.
•Replace damaged units, otherwise the technical data and safety will be impaired.
2.1 Cyber security
NOTE
If the unit is operated in an unprotected network environment
Unauthorised read or write access to data is possible.
Unauthorised manipulation of the device function is possible.
Restrict access to authorised users (e.g. password-protected access).
Assign a new password for the Bluetooth access.

Bluetooth Mesh adapter
EIO344
5
3 Intended use
The EIO344 communicates via IO-Link with a sensor. Using Bluetooth and an APP, the
connected sensor can be read and written.
All available functions can be accessed via moneo|blue. The APP is available for Android
and IOS in the App Store.
The EIO344 also features a data storage function. This allows a defective sensor to be
replaced quickly.
In addition, the adapter loops through the switching or analogue output on pin 2 of the
sensor; the output can still be used as a control signal.
The switching output at pin 4 of the sensor is replicated automatically or manually by the
EIO344.
Several adapters can be connected to each other via the EIO404 base station.
See chapter 4.3.
Fig. 1: Application example
1: Power supply
2: PLC with voltage supply
3: EIO344 adapter
4: Mobile device with Bluetooth LE
5: Base station EIO404 with Bluetooth Mesh
6: Example sensor
The unit is not suited for environments with particular requirements on mechanical stability
(e.g. shock/vibration).
The unit is intended for indoor use only.
► Observe the operating conditions (Technical data at www.ifm.com).
The process data received via Bluetooth are used for plant monitoring
DE

EIO344
Bluetooth Mesh adapter
6
4Connection possibilities
The EIO344 offers several connection options which include, among others, various
functions.
4.1 IO-Link connection and outputs
This unit has two IO-Link communication interfaces.
M12 connector:
•Power supply
•Output pin 2 (looped through from sensor) and digital output pin 4
•Pin 4 for parameter setting with an IO-Link software for the device side (reset, Ou1, events, history)
M12 socket
•Input for interaction with an IO-Link device.
IO-Link is an internationally standardised IO technology (IEC 61131-9) for communicating with
sensors and actuators.
General information about IO-Link can be found at io-link.ifm.
IO Device Description (IODD) with all parameters and process data of the unit can be
found at documentation.ifm.com.
4.2 Bluetooth
Using a mobile device the following functions are supported:
•Parameter setting of the M12 socket to the IO-Link device
•Parameter setting of the IO-Link device
•Input for parameter setting with an IO-Link software for the device side
M12 socket:
•Input for interaction with an IO-Link device
4.3 Bluetooth Mesh
After setting up the Bluetooth Mesh, the EIO344 independently establishes the connection
to a base station (EIO404). The connection can be made directly to the base station or via
several EIO344 Bluetooth Mesh adapters.
Cyclical process data is transmitted to the base station at a time interval of 2-4s. With
moneo on a PC or notebook, this process data can be read at the base station and the plant
can be monitored.
See operating instructions EIO404 www.ifm.com.

Bluetooth Mesh adapter
EIO344
7
5 Electrical connection
The unit must be connected by a qualified electrician.
Observe the national and international regulations for the installation of electrical equipment.
Voltage supply according to EN 50178, SELV, PELV.
► Disconnect power.
► Connect the unit as follows:
1: 4-pole M12 connector
•Power supply
•OUT2 (white, looped through)
•OUT1 (black, replicated)
•Input for IO-Link parameter setting
2: 5-pole M12 socket
•Input for IO-Link signals of the sensor
Fig. 3: Electrical connection
Pin
Output in operation
Input for IO-Link parameter setting
1:
L+
-(supply voltage EIO344 + sensor)
L+
2:
OUT2 setting of sensor
Not used
4:
OUT1 digital
IO
-Link (parameter setting)
3:
L-
(supply voltage EIO344 + sensor)
L-
Tab. 1: M12 connector pin assignment
Pin
Input for IO-Link signals of the sensor
1:
L+ (supply
voltage of the sensor)
2:
OUT2 (of the sensor)
4:
IO
-Link
3:
L-
(supply voltage of the sensor)
5:
Not used
Tab. 2: M12 socket pin assignment
The unit must not be externally supplied via the 5-pole M12 input socket (2). Pin 1, pin 2 and
pin 3 are each looped through.
Connect the sensors to the Bluetooth Mesh adapter using the connection cables provided (
Accessories at www.ifm.com).
2 1
1
3 4
1 2
2
5
4 3
DE
CAUTION
Input current is not limited.
No fire protection.
Protect circuits.

EIO344
Bluetooth Mesh adapter
8
5.1 Mounting the connector
To achieve the protection rating indicated in the data sheet, the following has to be observed:
► Use IO-Link cable with IP class.
► Connect the connector with the unit. The arrow indicates the position of the coding.
► Tighten the coupling nut.
•Minimum tightening torque: 0.6 Nm (tightening by hand)
•Maximum tightening torque: 1.5 Nm (using a torque wrench).
5.2 Removing the connector
► Loosen the coupling nut and simultaneously press the connector against the unit.
5.3 UL application area
For use in the USA and Canada:
► For connecting the unit and the IO-Link sensor, use UL-certified cables of category CYJV
2/7/8 having suitable ratings.
5.4 Cable length
•Maximum cable length on the input and output side (IO-Link): 20 m.
•Maximum cable length on the output side (analogue signal): no recommendation, depending on
the receiver.
► Provide all input and output side cables with a strain relief approx. 200 mm behind
the connectors.

Bluetooth Mesh adapter
EIO344
9
6 Display elements, output response and troubleshooting
The indicator shows the current status of the unit with an RGB LED.
6.1 RGB indicators
Fig. 4: RGB indicator
6.2 RGB status indicator, output response and troubleshooting
The unit features self-diagnostic options.
Faults are indicated by the red LED.
Type
Description
RGB status
Output response
Troubleshooting
0
The unit works correctly
Green, on
---
---
1
IO
-Link optical identification
Green, double flash
---
---
2
Voltage too low
Off
Off
Check AS
-i voltage supply
2
Electronics too cold
Red, 1 Hz
---
2
Electronics too hot
Red, 1 Hz
---
2
Faulty IO
-
Link device process data
Green, on
FOU
3
Switching output short
-circuited
Red, 1 Hz
Short
-circuit c
locking
Check wiring
3
No IO
-Link device connected
Green, on
Off
Check IO
-Link wiring and IO-Link
sensor
3
Output configuration invalid
Red, 1 Hz
FOU
Check configuration
4
Hardware failure
Red, on
FOU
Unit
s defective, please replace
---
No connection BT Mesh
Red, 1 Hz
---
Check the
distance to the next
receiver
---
Bluetooth is active
Blue, on
---
---
---
Bluetooth
Mesh is active
Green, on
---
---
---
Device update
Green, flashing
(200ms on, 800ms
off)
---
Wait until the update is complete
Tab. 4: Troubleshooting; 1: Warning, 2: Fault, 3: Note
Colour
Designation
R
ed
Interference indication
G
reen
Operation indication
Blue
Bluetooth
DE

EIO344
Bluetooth Mesh adapter
10
7 Parameter setting
The parameters of this unit can be set via 2 interfaces. You can use IO-Link or Bluetooth to read
information and make changes. Assigned information and changes are possible for each interface.
For IO-Link, connect the M12 connector to a hardware for parameter setting. The connection is
established via Bluetooth with an app.
The parameter setting can be carried out with or without a sensor connected.
Information on suitable parameter setting software at www.ifm.com.
7.1 Parameter setting via IO-Link using a PC:
► Connect the Bluetooth Mesh adapter to the PC via the USB interface using the M12 connector:
Fig. 5: Parameter setting with a PC
► If the device is not detected, update the device catalogue for the parameter setting
software via the internet.
► Change the parameter settings in the software.
► Transfer the parameter settings to the device.
7.2 Parameter setting by means of a mobile device via Bluetooth
► Power the Bluetooth Mesh adapter
► The Bluetooth Mesh adapter is searched for and connected via an app
Fig. 6: Parameter setting with a mobile device
► If the device is not detected, update the device catalogue for the parameter setting
software via the internet.
► Change the parameter settings in the software.
► Transfer the parameter settings to the device.
► If a sensor is connected, it can also be reached via Bluetooth.
