Ignis CEI310 User manual

INSTRUCTIONS FOR USE
GB
DIAGRAM OF THE APPLIANCE (Fig. 1)
A. Handle.
B. Safety lock (if provided).
C. Gasket.
D. Separator (if provided).
E. Defrost water drain plug.
F. Control panel.
G. Side motor cooling grille.
DIAGRAM OF THE CONTROL PANEL (Fig. 2)
1. Red light: when flashing, indicates an alarm condition
(see paragraph "TROUBLESHOOTING GUIDE").
2. Blue light: when lit, indicates that the "
Eco Intelligent "
function is active (see paragraph " Eco Intelligent "
function).
3. Green lights: indicate that the product is running and
the temperature has been set.
4. Set temperature button: to adjust the set
temperature and to activate/deactivate fast freeze
procedures.
BEFORE USING THE APPLIANCE
Your new appliance is designed to be used in the
household and similar applications such as:
- kitchen areas in shops, offices and other working
environments
- farm houses
- by clients in hotels, motels, residences, bed &
breakfasts.
The product must only be used to store frozen food, to
freeze fresh food and to make ice.
Regulations require the appliance to be earthed.
The manufacturer declines all liability for injury to
persons or animals and for damage to property
resulting from failure to observe the above
procedures and reminders.
1. After unpacking, make sure that the appliance is
undamaged and that the door closes perfectly, with the
gasket remaining intact. Any damage must be reported
to your retailer within 24 hours after delivery of the
appliance.
2. Wait at least two hours before switching the appliance
on in order to ensure the refrigerant circuit is fully
efficient.
3. Installation and electrical connection must be carried
out by a qualified technician, according to the
manufacturer's instructions and local safety regulations.
4. Clean the inside of the appliance before using it.
• Before connecting the appliance to the mains supply,
ensure that the voltage corresponds to that given on
the rating plate located on the rear of the appliance.
• Electrical connections must be made in
accordance with local regulations.
INSTALLATION
• Unpack the appliance.
• Remove the 4 spacers inserted between the door
and the appliance. (Fig 3)
•Make sure the defrost water drain plug (if provided) is
correctly positioned (E).
• For optimum appliance operation and to avoid damage
when the door is opened, leave a space of at least 7 cm
from the rear wall and 7 cm at the sides. (Fig 4)
• Fit the accessories (if provided).
SWITCHING ON THE APPLIANCE
•Plug in the appliance.
• The green LED lights up ("Normal").
• The blu LED lights up (" Eco Intelligent ").
• The red LED flashes to indicate that the temperature
inside the appliance is not yet sufficiently low for food
storage. The red LED will normally switch off within
the first six hours after the appliance is switched on.
• Place food inside the product only when the red LED
has switched off.
• The blue LED, " Eco Intelligent " (2), stays on until the
set temperature is reached.
Note: Thanks to the efficient lid seal, the appliance lid will
not re-open easily immediately after closing. Wait a few
minutes before re-opening the lid of the appliance.
TEMPERATURE ADJUSTMENT
Use the key (4) to select the desired temperature.
To adjust the internal temperature, proceed as follows:
• Repeatedly press the key (4). Each time the key is
pressed, the set temperature is updated, displaying the
"Normal",
"Min" and "Intensive" values in succession.
• Select "Intensive" for a colder storage temperature.
• With partial loads "Min" is recommended: this setting
will optimize energy consumption.
Note: The settings will be saved in the memory even if a
power cut occurs. The time needed for the temperature
inside the freezer to reach the set value, can vary
depending on climatic conditions and the set temperature
itself.
"ECO INTELLIGENT" FUNCTION
This function will activate automatically in the following
cases:
• door opening
This function activates every time the opening of the
door changes the internal temperature of the appliance.
The function remains active for the time needed to
reinstate optimum operating conditions.
• storing food inside the freezer
This function activates every time significant quantities
of food are introduced. It remains active for the time
needed to reinstate optimum freezing conditions of the
food introduced, ensuring the best compromise
between the quality of the freezing process and energy
consumption.
Note: The duration of the "
Eco Intelligent " function is set
automatically, and may vary depending on the way the
product is used.
FREEZING FOOD
Preparation of fresh food for freezing
• Before freezing, wrap and seal fresh food in: aluminium
foil, cling film, air and water-tight plastic bags,
polyethylene containers with lids, provided they are

suitable for freezing foods.
• Food must be fresh, mature and of prime quality in
order to obtain high quality frozen food.
• Fresh vegetables and fruit should preferably be frozen
as soon as they are picked to maintain the full original
nutritional value, consistency, colour and flavour.
• Always leave hot food to cool before placing in the
appliance.
Freezing fresh food
• Place foods to be frozen in direct contact with the walls
of appliance:
A) - foods to be frozen,
B) - foods already frozen.
• Avoid placing foods to be frozen in direct contact with
food already frozen.
• For best and fastest freezing, foods should be split into
small portions; this will also be useful when the frozen
items are to be used.
• If minimum quantities of food are introduced (up to 1/4
of the maximum freezing power stated on the rating
plate), the operation of the appliance will be controlled
automatically by the "
Eco Intelligent " function without
any need for intervention from the user.
• When freezing higher quantities of food, up to the
maximum freezing capacity of the appliance, indicated
on the rating plated, proceed as follows:
1. At least 24 hours before storing fresh foods inside
the product for freezing, activate the fast freezing
function ("Shopping") by pressing (4) for
approximately 3 seconds. The green LEDS (3) flash
in sequence.
2. Introduce the food to freeze inside the appliance,
and keep the door of the appliance closed for 24
hours. After this period the food will be frozen.
The fast freezing function ("Shopping") can be deactivated
manually by pressing (4).
If the fast freeze function is not manually deactivated, it
will be automatically deactivated by the appliance after 50
hours.
FOOD STORAGE
Refer to the table on the appliance.
Classification of frozen foods
Load and classify the frozen foods; it is advisable to
indicate the storage date on the packs, to ensure
consumption before the expiry dates listed in months in
fig. 6 for each type of food.
Advice for storing frozen food
When buying frozen food, make sure that:
• The packaging is intact (food in damaged containers
may have deteriorated). If a package is swollen or has
damp patches, the product may not have been stored
in optimum conditions and therefore undergone partial
defrosting.
• When shopping, leave frozen food purchases until last
and carry them in a thermally insulated bag.
• On arriving home, immediately place the frozen food in
the appliance.
• Avoid or minimise temperature variations. Observe the
expiry date on the packaging.
• Always follow the storage instructions on frozen food
packages.
Note:
•Eat fully or partially defrosted foods immediately.
Do not refreeze unless the food is cooked after it
has thawed. Once cooked, the food can be
refrozen.
•In case of a prolonged power failure:
Do not open the appliance door, except to place
ice packs (if provided) over the frozen foods on
the right and left side of the appliance. This will
slow down the rise in temperature.
PRECAUTIONS AND SUGGESTIONS
• During installation, make sure the appliance does
not damage the power cable.
• Do not store glass containers with liquids inside the
product as they may break.
• Do not eat ice cubes or ice lollies immediately after
taking them out of the appliance as they may cause cold
burns.
• Before carrying out any maintenance or cleaning, always
unplug the appliance or disconnect the power supply.
• Do not install the appliance in places exposed to direct
sunlight or near heat sources in order to avoid
increasing power consumption.
• Do not put aerosol spray cans or recipients containing
propellants or flammable substances in the appliance.
• Do not store or use gasoline or other flammable liquids
and gases in the vicinity of this or any other domestic
appliance. The fumes can create a fire hazard or
explosion.
• Install the appliance in a perfectly horizontal position, on
a floor strong enough to take its weight and in an area
suitable for its size and use.
• Install the appliance in a dry, well-ventilated place. The
appliance is set for operation at specific ambient
temperature ranges, according to the climatic class
indicated on the data plate located at the rear of the
product (Fig. 7). The appliance may not work properly
if it is left for a long time at a temperature outside the
specified range.
• It is advisable to leave the appliance connected if left
empty even for short periods.
• Be careful not to damage the floors when you move the
appliance (e.g. parquet). To facilitate product handling, it
is advisable to empty it beforehand, if possible.
Note: The appliance must be handled and installed by two
or more persons.
• Do not use mechanical devices or any means other than
those recommended and/or supplied by the
manufacturer to speed up the defrosting process.
• Do not use electrical appliances inside the product,
unless such appliances are specifically recommended by
the manufacturer.
•This appliance must not be used by children under
8 years of age, or by people with limited physical,
sensory or mental abilities or without experience
and knowledge of it, unless instructed in its use by
those responsible for their safety.
• Do not allow children to play or hide inside the
product: risk of becoming trapped inside and
suffocating.
• Power cable modification or replacement must

only be carried out by qualified personnel or
After-sales Service.
• Do not use extension leads or adapters.
• Electrical disconnection must be possible either by
unplugging the appliance or by means of a double-
pole switch located upline from the socket.
• Ensure that the voltage indicated on the appliance
data plate corresponds to the domestic supply
voltage.
• Do not ingest the contents (non-toxic) of the ice
packs (if provided).
• Restrict the number of times you open the door.
• This appliance features "skin condenser"
technology: the condensing unit is integrated into
the walls of the freezer. For this reason the side
and front walls of the product may become hot
while the product is running. This is entirely
normal and also reduces the risk of condensation
forming in particularly critical environmental
conditions (see paragraph "Troubleshooting
guide").
APPLIANCE DEFROSTING
The appliance should be defrosted when the thickness of
ice on the walls reaches 5-6 mm.
• Disconnect the appliance from the power supply.
• Remove food from the appliance and put it in a very
cool place or a thermally insulated bag.
• Leave the appliance door open.
• Remove the internal defrost water drain plug
(depending on model) (Fig. 8).
• Remove the external defrost water drain plug
(depending on model) and reposition it as shown in
figure 8.
• Use the separator (depending on model) inside the
product as a recipient for any remaining water, (D) as
shown in fig. 8. If there is no separator, use a shallow
container.
• Defrosting can be sped up by using a spatula to detach
the frost from the appliance walls.
• Remove the frost from the bottom of the appliance.
•In order to avoid permanent damage to the
appliance interior, do not use pointed or sharp
metal instruments to remove the ice.
• Do not use abrasive products or heat up the
interior artificially.
• Dry the inside of the appliance thoroughly.
• Refit the plug after defrosting.
CLEANING AND MAINTENANCE
• Remove the frost from the upper edges (see
Troubleshooting Guide).
• Clean the inside after defrosting, using a sponge
dampened with warm water and/or mild detergent.
• Clean the side vent (if provided).
Unplug the appliance before carrying out
maintenance operations. Do not use abrasive
products, scourers or stain-removers (e.g. acetone,
trichloroethylene) to clean the appliance.
To obtain the best results from your appliance, carry
out cleaning and maintenance at least once a year.
CHANGING THE LID LIGHT BULB (if provided)
• Disconnect the appliance from the mains power supply.
• Remove the diffuser by following the sequence of steps
shown in the figure.
• Unscrew the light bulb and replace it with an identical
bulb of the same wattage and voltage.
• Refit the diffuser and plug in the appliance.
TROUBLESHOOTING GUIDE
1. The red LED flashes.
• Is there a power failure?
• Is a defrosting operation in progress?
• Has fresh food recently been introduced?
• Is the appliance lid properly closed?
• Is the appliance placed near a heat source?
• Are the ventilation grille and condenser clean?
2. All LEDs flash at the same time.
• Contact the After-Sales Service.
3. The appliance is too noisy.
• Is the appliance perfectly horizontal?
• Is the appliance in contact with other furniture or
objects that may cause vibrations?
• Has the packaging been removed from under the
appliance?
Note: Gurgling noises from the refrigerating circuit after
the compressor cuts out are perfectly normal.
4. All LEDs are off and the product is not working.
• Is there a power failure?
• Is the plug properly inserted in the socket?
• Is the electric cable intact?
5. All LEDs are off and the product is working.
• Contact the After-Sales Service.
6. The compressor runs continuously.
• Have hot foods been put in the appliance?
• Has the appliance lid been left open for a long time?
• Is the appliance placed in a very warm room or near
heat sources?
• Has the fast freeze function
("Shopping") been
activated? (the green LEDS flash alternatively)
7. Too much ice on the upper edge.
• Are the defrost water drainage plugs correctly
positioned?
• Is the appliance lid properly closed?
• Is the appliance lid seal damaged or deformed? (See
chapter "Installation")
• Have the 4 protection pieces been removed? (See
chapter "Installation")
8. Formation of condensate on the external walls of
the appliance.
• It is normal for condensation to form under certain
atmospheric conditions (humidity above 85%) or if
the appliance is located in a damp or poorly
ventilated room. The performance of the appliance is
in no way affected.
9. The layer of ice on the internal walls of the
appliance is not uniform.
• This phenomenon is quite normal.
SAFEGUARDING THE ENVIRONMENT
1. Packing
The packing material is 100% recyclable and bears the
recycling symbol. For disposal, comply with the local

regulations. Keep the packing materials (plastic bags,
polystyrene parts, etc.) out of the reach of children, as
they are a potential source of danger.
2. Scrapping/Disposal
The appliance is manufactured using recyclable material.
This appliance is marked in compliance with European
Directive 2002/96/EC on Waste Electrical and Electronic
Equipment (WEEE). By ensuring the correct disposal of
this appliance, you can help prevent potentially negative
consequences for the environment and the health of
persons.
The symbol on the appliance, or on the accompanying
documents, indicates that this appliance should not be
treated as domestic waste but must be taken to a special
collection centre for the recycling of electrical and
electronic equipment.
When scrapping the appliance, make it unusable by cutting
off the power cable and removing the doors and shelves
so that children cannot easily climb inside and become
trapped.
Scrap the appliance in compliance with local regulations
on waste disposal, taking it to a special collection centre;
do not leave the appliance unattended even for a few
days, since it is a potential source of danger for children.
For further information on the treatment, recovery and
recycling of this product, contact your competent local
office, the household waste collection service or the shop
where you purchased the appliance.
Information:
This appliance does not contain CFCs. The refrigerant
circuit contains R134a (HFC) or R600a (HC) (see the
rating plate inside the appliance).
Appliances with Isobutane (R600a): isobutane is a natural
gas without environmental impact, but is flammable.
Therefore, make sure the refrigerant circuit pipes are not
damaged.
This product may contain Fluorinated Greenhouse Gases
covered by the Kyoto Protocol; the refrigerant gas is
inside a hermetically sealed system.
Refrigerant gas: R134a has a Global Warming Potential of
(GWP) 1300.
Declaration of conformity
• This appliance has been designed for preserving food
and is manufactured in compliance with Regulation (CE)
No. 1935/2004.
• This appliance has been designed, manufactured and
marketed in compliance with:
- safety objectives of the "Low Voltage" Directive
2006/95/CE (which replaces 73/23/CEE and
subsequent amendments);
- the protection requirements of Directive "EMC"
2004/108/EC.
Electrical safety of the appliance can only be guaranteed if
it is correctly connected to an approved earthing system.
AFTER-SALES SERVICE
Before contacting After-Sales Service:
1. See if you can solve the problem yourself.
2. Switch the appliance on again to see if the problem has
been solved. If it has not, disconnect the appliance from
the power supply and wait for about an hour before
switching on again.
3. If the problem persists after this course of action,
contact After-Sales Service.
Specify:
• the nature of the fault,
• the model,
• the service number (the number after the word
SERVICE on the rating plate on the rear of the
appliance)
• your full address,
• your telephone number and area code.
