Ignite Coffee A400 Configuration guide


01 02

03 04


05
06
01 02 04 03 05

  

Cleaning Instructions - Weekly cleaning
Perform daily cleaning. (See: "Daily cleaning")
WEEKLY CLEANING OF THE A400/A600/A800/A1000
Cleaning the brewing module
Insert the brewing module.
Clean the brewing module.Remove the brewing module.Release the brewing module lock
in counterclockwise direction.
Open the door.
Cleaning the steam wand
Lock the brewing module in
clockwise direction.
Empty the container
Wipe the steam wand with a cloth.
Empty the container.
Fill the container with cold water
and place under the steam wand.
Select Autosteam/Steam.
The steam wand is rinsed.
Select Autosteam/Steam.
The steam wand is cleaned.
Fill container to approx. 5cm
with cold water and 30 ml of
clean solution.
Place under the steam wand for
approx. 1 minute.


01 02

03
04 05 06 07
10
!
09
  


11


08
Created: 7/2017 TD-107434 1C346366/Version 0
NOTICE
Impairment of function
If the bean hopper and powder
container are not locked correctly,
this may impair both the function
of the coffee machine and the
product quality.
• Push the locking slide all the
way in.
Cutting injuries/crushing
The powder container's conveyor
mechanism can cause cuts or
crushing injuries.
• Exercise care when cleaning
the powder container.
Attach the powder container.
CAUTION
Clean the powder container
with a cloth. Use detergent if
necessary. Rub down the pow-
der container with a dry cloth.
Close the door.Push the locking slide all the
way in.
Lift the powder container towards
the top.
Empty the powder container.
Attach the bean hopper.
Rub down the bean hopper with
a dry cloth.
Lift the bean hopper towards
the top.
Empty the bean hopper.
NOTICE
Soiling, formation of mildew
The bean hopper dries slowly and can continue to release moisture
during fitting.
• Do not bring the bean hopper into direct contact with water.
• Use only a damp cloth for cleaning.
• Remove detergent residue.
Pull the locking slide all the way
to the front.
Open the door.
Cleaning the bean hopper and powder container
Clean the powder chute with a
brush.

i
IV
 
III
 
II V
I
 
01 02 03
i
Starting the automatic cleaning on the screen for the A400/A600/A800 with EasyClean
Clean the Flavor Station
Wipe protection
Prepare the syrup system
Prepare the milk system
Rinse the coffee machine
ERROR LOG files
Data transfer and individua-
lization
Cleaning and maintenance Follow the instructions on the operating interface and confirm with "Continue".
The machine guides you to the next step.
After the cleaning cycle, the machine switches back to either the mainte-
nance level or the energy saver mode.
Your service technician can set the desired option for you.
Select and confirm "Clean Cof-
fee Machine" or "Clean Flavor
Station".
Select "Cleaning and maintenance".
Switch to the Maintenance level.
Authenticate with the PIN code
if necessary.
The factory-set PIN code is 1111.
Clean the Coffee Machine
Symbol for cleaning
DAILY CLEANING OF THE A400/A600/A800/A1000
Cleaning Instructions - Daily cleaning
Accessories required:
• Cleaning tablets
• Microfiber cloth
• Brush set
• Cleaning agent for milk systems (depending on design version)
Your responsibility for the perfect coffee experience.
The perfect coffee experience depends on a perfectly cleaned coffee machine. Increase
the quality of your products!
Clean your coffee machine at least once a day and more frequently if necessary.
Follow the 5-step method for all removable parts.
Please observe the warnings on the screen.
5-step method for removable parts
Dry the parts.Soak the parts in water with a
mild detergent for 60 seconds.
Clean the milk hose inside with
the brush.
Wash the parts.Remove coarse dirt with a
brush or paint brush.
Rinse the parts thoroughly.


01

01

i
i
04
02 03 05
i

02 03
Created: 7/2017 TD-107434 1C346366/Version 0
The machine switches over
automatically to cleaning mode.
Press "Yes" to start the cleaning
process.
Changing cleaning agents for the CleanMaster
Unscrew the lid.
Slide the cartridge without the lid
all the way in.
The seal is punctured automatically.
Slide the cleaning container in.Open the door.
Remove the milk container
and store the milk in a cool
location.
Starting automatic cleaning on the cooling unit with CleanMaster for the SU05
Follow the instructions on the operating interface and confirm with "Continue". The machine guides you to the next step.
After the cleaning cycle, the machine switches back to either the maintenance level or the energy saver mode.
Your service technician can set the desired option for you.
YesNo
Would you like to clean the coffee
machine now?
Clean the Coffee Machine
The machine switches over
automatically to cleaning mode.
Press "Yes" to start the cleaning
process.
Slide the milk container all the
way in.
Rotate the cleaning lever to the
"Cleaning" position.
Pull the reversible adapter towards
the top from the suction fitting.
Turn the reversible adapter 180°.
Place the reversible adapter on
the suction fitting.
Open the door.
Pull the milk container to the front.
The symbols indicate the correct
position of the reversible adapter
for milk delivery and cleaning.
Starting automatic cleaning on the cooling unit with CleanMaster for the SU12 and A1000
Follow the instructions on the operating interface and
confirm with "Continue". The machine guides you to the
next step.
After the cleaning cycle, the machine switches back to eit-
her the maintenance level or the energy saver mode. Your
service technician can set the desired option for you.
Would you like to clean the coffee
machine now?
Clean the Coffee Machine
YesNo
