1 Device description
1.1 The device
Fig. 2: Description of the extractor hood
1 Cooking eld suction
2 Induction cooking eld
3 Engine box
4 Circulation fan box (special accessories)
1.2 Operating unit
Fig. 3: Touch control LED electronics
1 Unlocking 3 LED display
2 Decrease exhaust air fan power level 4 Increase exhaust air fan power level
5 Delayed shut-o󰀨 automatic
2

1.3 Scope of delivery
Control electronics housing
Extractor hood body
Engine box
1 Electronics box
1 Glass cover
2 Stainless steel cover
3 Cooking eld suction
1 Engine box
2 Assembling the accessories
3

Fig. 4:Scope of delivery
1 Cooking eld suction
2 Electronics box
3 Engine
4 Metric
5 Washers
6 Screws
7 Screws
8 Operation manual
4

2 For your Safety
2.1 Symbols in these instructions
Safety instructions
Tips and recommendations
Special safety instructions
Safety instructions are labelled with symbols in this manual.
The safety instructions are introduced by signal words that
express the extent of the hazard.
To draw attention to special dangers, the following symbols
are used in safety instructions:
DANGER!
This combination of symbol and signal word
indicates an immediately dangerous situation
which will lead to death or serious injuries if not
avoided.
WARNING!
This combination of symbol and signal word
indicates a possibly dangerous situation which
may lead to death or serious injuries if not avoid-
ed.
CAUTION!
This combination of symbol and signal word
indicates a possibly dangerous situation which
may lead to minor or light injuries if not avoided
will.
PLEASE NOTE!
This combination of symbol and signal word
indicates a possibly dangerous situation which
may lead to material damage if not avoided.
This symbol highlights useful tips and recom-
mendations as well as information for ecient
and trouble-free operation.
5


Safety instructions within
handling instructions
Further tags and labelling
Safety instructions may in particular refer to certain han-
dling instructions. Such safety instructions are embedded
in the handling instructions to avoid distraction while pre-
paring and performing the required steps and actions. The
above-described signal words will be used.
Beispiel:
1. Loosen the screw.
2.
Close the lid carefully.
3. Tighten the screw.
The following signs and highlighting are used for identifying
handling instructions, result descriptions, bullet lists, refer-
ences, and other elements in these operating instructions:
CAUTION!
If not handled correctly the lid might get
jammed!
Warning signs Type of danger or hazard
Warning - Danger caused by
electrical voltage
Warning of highly combustible
substances.
Warning of a danger zone
Labelling Explanation
Step-by-step handling instructions
Results of handling instructions
Reference to sections of this manual and
other relevant documents
Bullet lists without a determined order
6

2.2 Intended use
2.3 Children and persons with reduced physical, sensory, or
mental capabilities
2.4 Fire hazard!
The extractor hood is intended for suctioning of any vapour
and steam caused by cooking or frying or preparing other-
wise food on an electric or gas range in private households.
The device is not intended for any commercial usage or any
outdoor usage.
Any di󰀨ering usage is deemed deviating from the intended
purpose and therefore prohibited. We accept no liability for
any damages incurred by any usage that deviates from the
intended purpose.
Specically, the following shall be prohibited:
• Outdoor usage or usage in any commercial context
• Any arbitrary modications or repairing of the device
• Operation without metal grease lter
• Flambéing of food beneath the hood
• Exhaust air fan operation without window ip switch
while simultaneously using any replace, furnace, or
oven operated with ambient air
• Usage for air condition/ventilation purposes, in partic-
ular using the device in non-stop operation instead of a
ventilating fan or appropriately and regularly airing the
concerned room
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory, or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction by a person
responsible for their safety concerning the use of the appli-
ance in a safe way and understand the hazards involved.
Children must not play with the device.
• Do not allow children to play the with packaging ma-
terials. Danger of su󰀨ocation.
• Cleaning and user maintenance may not be per-
formed by children, unless they are older than 8 years
and supervised by a person responsible for their safety.
• Keep the appliance and the power cable out of reach
of children that are 8 years or younger.
• Keep children away from the device’s lamps until these
have cooled down. Danger of burning and serious injuries.
• Do not ambé any food beneath the device.
• Deep frying of any food requires your constant monitor-
ing.
• Clean the device surface regularly, to remove any fat
residues.
7

Fig. 5: Fireplace, furnace, or
oven operated with ambient air
Fig. 6: Using a window ip switch
• Clean the metal grease lter at least every other week to
prevent the built-up of fat residues on the metal grease
lter. These residues may catch re or ignites sponta-
neously. Replace the metal grease lter regularly and/or
if needed.
• To avoid generating excessive heat, do never operate
any cooking zone without a pot or pan or other cookware
on it.
• Never use open re near the devise.
• Never leave hot oil or fat unattended. Do never use wa-
ter when trying to extinguish any re caused by oil or fat.
Simultaneously using the device in the exhaust air fan
operation modus while operating any replace, furnace, or
oven operated with ambient air (such as heating applianc-
es red by gas, oil, wood or coal, instant-on water heat-
ers, water boilers or chimneys), consumes the ambient air
of the kitchen and the adjoining rooms (Fig. 5). This may
cause toxic combustion gases from the chimney or the
exhaust air shaft to ow back into the living areas inside
the apartment. Danger of su󰀨ocation.
Therefore, you must in particular make sure of:
Employing a window ip switch to allow fresh air owing
in from the outside (Fig. 6).
A fresh air/ exhaust air wall sleeve does not provide su󰀩-
cient air supply. Please consult your competent chimney
sweeper who will evaluate the air supply and consumption
in your apartment.
The underpressure inside the room where the replace,
furnace, or oven is located must not be less than 4 Pa.
When using the device in the circulation fan operation mo-
dus, you do not need pay any particular attention to the air
supply and consumption in your apartment.
The device is powered by electricity; therefore, the danger of
an electric shock persists. Therefore, you must in particular
make sure of that:
• If an additional socket is required to connect the device,
you need to engage a professional electrician to perform
the respective installation.
• You will never touch the plug with wet hands.
• You will pay special attention to prevent the bending or
jamming of the power cable.
8

2.7 Transportation
2.8 Defect
2.9 Cleaning
• You will pull the mains plug out of the socket in order to
disconnect the device.
• You will only operate the device, if the voltage value stat-
ed on the nameplate coincides with the voltage available
at your socket. The inappropriate voltage may severely
damage the appliance. If you have any questions, please
consult a professional electrician.
• While transporting the device in your car, make sure that
is properly secured to protect all passengers from harm
or injury.
• Use the original packaging, when transporting the de-
vice. Retain the packaging for such situations.
• If the device is faulty or damaged, do not attempt to re-
pair it yourself.
• Any faulty or damaged power cable or plug must be
replaced to prevent any risk of electric shock. Call the
customer service department (see numbers “Hotline (for
Germany, Austria, and Benelux)” on page 3).
• In order to prevent the danger of electric shock, do never
turn a faulty or damaged device on.Pull out the mains
plug from the socket or switch o󰀨 the fuse inside the fuse
box. Call the customer service department (see numbers
“Hotline (for Germany, Austria, and Benelux)” on page 3).
• Always replace defect lamps to prevent overloading the
remaining lamps.
• Do not you any aggressive or abrasive cleaning agents,
since those may damage the device surface.
• For stainless steel surfaces, use a stainless steel clean-
er. Always clean along the sanding direction of the mate-
rial.
• Do not you any sharp or pointed object, since those may
scratch the device surface.
• Do not use a high pressure or steam cleaner, since the
penetrating humidity may cause an electric shock.
• Observe the cleaning intervals for metal grease lters
indicated in this operating manual. Otherwise, the risk of
re hazard will occur.
9

3 Operating
3.1 Ensuring safe control and operation
3.2 Turning on/o󰀨 the fan
3.2.1 About the control unit
Switching on the fan
Turn the fan on when you start cooking and wait
10-15 after you nished, before turning o the
device.
This will ensure the best possible removal of
cooking vapours.
WARNING!
Risk of injury due to improper operation!
Improper operation will cause the danger of seri-
ous injuries and property damage.
– Check the device before every use. A faulty or
damaged device must not be used.
– Do not place any objects on the device, since
they may fall down.
– Do never operate the device without the metal
grease lter. Risk of re hazard.
– Switch the device always on, to prevent corro-
sion damages caused by condensation.
Fig. 7: Fan On/O
You may turn the fan on/o󰀨 using the control unit or the re-
mote control.
1. While not in operation, the device digital display re
mains in standby and appears as a dot. As soon as any
button is pressed, a ashing “L” (i.e. lock) appears 3x on
the digital display.
2. After that, press and hold down the timer button until
“0’” appears on the digital display (Fig. 7/1).
The fan has been unlocked
3. After unlocking the fan, you may complete the setup
using the “+/-” button for adjustment the operation speed
(Fig. 7/2,4).
Now setting up the fan operation speed is completed.
10

3.3 Changing the fan power level
3.3.1 About the control unit
3.4 Turning the delayed shut-o󰀨 automatic on/o󰀨
Turning the delayed
shut-o󰀨 automatic on
Turning the delayed
shut-o󰀨 automatic o󰀨
To turn o the fan, press the button until “0”
appears on the digital display.
If for 10 minutes, no button has been pressed, the
device will switch into the standby mode and get
locked.
When the delayed shut-o automatic has
been activated, the speed value on the
digital display will start ashing.
Fig. 8: Multi-level switch for the fan
Fig. 9: Turning the delayed shut-o
automatic on/o
You may change the fan power level and set up the desired
level by using the control unit or the remote control.
2. You may increase the fan level by pressing the button
(Fig. + 8/4).
The fan now runs on a increased power level.
3. Reduce the fan power level by pressing the button
(Fig. 8/2).
The fan now runs on a lower power level.
If while the device is running on any level, the button is
pressed, the 15 minutes timer will be activated. As soon as
the timer starts counting down, the speed value on the digital
display will start ashing. After 15 minutes, all functions that
were activated prior to the timer, will shut down.
1. Press the timer button (Fig. 9/5).
Delayed shut-o󰀨 automatic has been activated. The
engine will automatically shut down after 15 minutes.
2. Press the sensor button again (Fig. 9/5).
Delayed shut-o󰀨 automatic has been deactivated.
11

3.5 Deleting the lter cleaning message
When indicated on the digital screen, the metal grease l-
ter must be cleaned (Fig.10). To delete the metal grease lter
cleaning prompt, proceed as follows:
After the cleaning has been completed (g. 10/2),
press the button, until “E” appears on the screen.
Now the metal grease lter cleaning prompt has
been deleted.
Fig. 10: Deleting the metal grease
lter cleaning prompt warning
12

PLEASE NOTE!
The device performance will be negatively
impacted by any non-compliance with the
maintenance intervals!
In case of overlong use, the metal grease l-
ter as well as the activated carbon lter will be
clogged with fat and dirt particles, which will
negatively impact the device performance.
– Please observe all maintenance intervals
specied in this manual.
DANGER!
Danger to life due to high voltage!
There is an immediate risk of fatal injury in case of
contact with live parts of the device.
– Pull out the mains plug from the socket or
switch o󰀨 the fuse inside the fuse box, before
initiating any maintenance or cleaning work.
4 Maintenance, cleaning, and care
4.1 Maintenance
Electrical voltage
Maintenance intervals
4.1.1 Maintenance intervals
Interval
after assembling and in case of heavy
contamination
Maintenance task
after cleaning the extractor hood
every other week or when the grease lter
prompt appears
every 3 Monat or is case of decreasing
performance
Outside cleaning of the device.
Servicing the device.
Cleaning the metal grease lter.
Cleaning or replacing the activated carbon lter (for circulation fan
operation only).
13

4.1.2 Cleaning the metal grease lter
Removing the metal grease lter
WARNING!
Fire hazard due to grease and fat residues
inside the metal grease lter!
There is a risk of re hazard due to grease and
fat residues inside the metal grease lter!
– Clean the metal grease lter as soon as the
lter cleaning prompt appears on the device
display or at least every other week.
– Do never operate the extractor hood without
the metal grease lter.
The metal grease lter retains solid particles from kitchen
and cooking vapours (such as oil or dust) and prevent the
excessive clogging and contamination of the extractor hood.
1. Remove the metal lid on the fresh air duct of you hood
box (Fig. 11).
2. Remove the metal grease lter by pushing it towards the
direction indicated by the arrow.Make sure that the metal
grease lter can not fall down.
3. Pull the metal grease lter forwards and take it out
(Fig. 12).
4. You may rinse the metal grease lter by hand or inside
the dishwasher.
Fig. 11: Removing the metal cover
1 Cover
2 Extractor hood box
Fig. 12: Removing the metal grease
lter
1 metal grease lter
14

Manual Cleaning
Cleaning in the dishwasher
After cleaning
Inserting the metal grease lter
Fig. 13: Inserting the metal grease
lter
Let the metal grease lter soak in warm soap water and
clean it using a soft brush.
6. 6. Rinse with water the metal grease lter with warm
water.
7. Place the metal grease lter loosely and vertically
without adding other tableware into the dishwasher.
8. Start any program with a temperature of no higher than
55°C.
9. Put the metal grease lter on a humidity-absorbing
surface and let it dry.
10. Please move the metal grease lter in the direction
towards the arrow and insert it into the air extraction duct
(g. 13).
11. Deleting the metal grease lter cleaning warning
(Fig. 13).
12. Close the metal grease lter lid of the extractor hood.
PLEASE NOTE!
Financial loss due to unsuitable cleaning
agents!
5.
Due to the cleaning in the dishwasher, the
lter parts may experience slight changes in
their colour.
This does not aect function or performance
to the metal grease lter.
If the activated carbon lter had been re-
moved as well, but it now back in to the metal
grease lter.
15

Cleaning the collection tray
4.1.3 Cleaning or replacing the activated carbon lter (for circulation
fan operation only)
The hood box may be clean in the
dishwasher.
1
2
Fig. 14
1 Extractor hood box
2 Device slot
Fig. 15
1 Activated carbon lter housing
2 Activated carbon lter with framework
Fig. 16
13. To retain water and solid particles, the hood box has a
slot inside (Fig. 14/2).
This is how you clean the inner box
Within the device slot, pull it up (Fig. 14).
After cleaning, you re-insert the inner box into the hood.
1. Take out the activated carbon lter (Fig. 15/2) by moving
it towards the arrow.(is secured by a magnet) (Fig. 15).
CAUTION!
Put the housing on a plane and stable sur-
face, then press down gently the lter and
take it out.
2. Put on and tighten the connecting screw (Fig. 16/1)
(Fig. 16).
16

PLEASE NOTE!
Property damage due to unsuitable cleaning
procedures!
Unsuitable cleaning procedures may result in
property damages.
– Always use the cleaning agents/devices spec-
ied in this operating manual only.
– Do not use a high pressure or steam cleaner.
– Never use aggressive and abrasive cleaning
agents or sharp and pointed objects.
– Before you start cleaning, take o󰀨 any jewel-
lery, to prevent scratching the surfaces.
Fig. 17
1 Connecting screw
2 Activated carbon lter
For the di󰀨erent surface type, please use the in following
specied cleaning agents/devices:
3. Take the activated carbon lter, as shown in (Fig. 17),
out of the lter framework.
4. Allow the activated carbon lter to regenerate for one
hour inside the baking oven at about 200°C. After
cooling down, re-insert the lter into the hood.
This procedure may be repeated not more than 10
times, after that lter must be replaced by a new one.
5. Re-insert the activated carbon lter by performing the
previous steps in reverse order.
Inserting the activated
carbon lter
4.2 Cleaning and maintenance
4.2.1 Cleaning agents/devices
17

4.2.2 Outside cleaning of the device
4.2.3 Servicing the device
Surface Cleaning agent Cleaning implement
Stainless steel  Stainless steel cleaning product  soft cloth
 soft sponge
Glass  Glass cleaning product
 warm soap water
 soft cloth
Lacquered surfaces  warm soap water  soft cloth
 soft sponge
1. Apply the respective cleaning agent (stainless steel or
glass) with a soft cloth.
2. Wipe the device thoroughly dry using a soft cloth.
3. Service and clean the device regularly.
1. Apply with a soft cloth the stainless steel care spray in
a very thin layer on the stainless steel parts of the
device.
2. Lacquered surfaces do not require any additional care
(do never apply any stainless steel care spray on such
surfaces)
To prevent the fast re-soling of the stainless steel parts, the
treatment with a stainless steel care spray is necessary.
18

5 Error messages
5.1 Correct handling of errors
5.2 Error table
Inappropriately performed repairs will void the
manufacturer’s warranty.
WARNING!
Danger of injuries due to using a defective
device!
A defective device may cause serious injuries.
– Do never use a defective device.
– Pull out the mains plug from the socket or
switch o󰀨 the fuse inside the fuse box, before
searching for possible errors.
The following rule always applies:
Always perform the repair steps specied in this operating
manual only.
Call the customer service department (see numbers “Ho-
tline (for Germany, Austria, and Benelux)” on page 3).
In all technical devices, errors might occur. These represent
not always necessarily a defect of the device.
Therefore, you should consult the following table and check
whether you can x the error yourself.
Error description Cause Solution/remedy
Device does not function No connection to the mains
power supply
Connect the device to the mains power supply.
Defective fuse Check the fuse inside your fuse box.
Power failure Check the function of other electric equipment.
Loss of performance e󰀩-
ciency / increased operating
noise
Dirtied metal grease lters Clean the metal grease lters
Dirtied activated carbon lter
pad (for circulation fan only)
Clean the activated carbon lter pad or replace
it with a new one.
Exhaust air duct cross-section
too small; (less than Ø 150 mm)
Ask a professional technician to check the
exhaust air duct cross-section size.
19
If you cannot solve the issue usin the present
tale call the customer service department see
numers  otline for ermany ustria and
enelu on pae .
 ccessories and spare parts
.1 rdering accessories and spare parts
.2 ccessories
.2.1 ccessories circulation/ehaust air fan control
Purchase any spare parts or accessories either through your
retail dealer or the service department (see numbers o
tline for ermany ustria and enelu on pae ).
he use of not authorised spare parts and acces
sories authorised will void the warranty ranted y
the manufacturer.
or more information please visit
www.silverline.de.
WARNING!
Danger of injury through the use of unsuit
able accessories or spare parts!
sing unsuitable or faulty accessories or spare
parts may compromise your safety and cause
you damage, malfunctions or complete failure of
the device.
– se only original spare parts of the manufac-
turer or spare parts and accessories autho-
rised by the manufacturer.
– In case of any uncertainties, always call the
customer service department (see numbers
“otline for ermany ustria and enelu
on pae ).
0

CODE
DESCRIPTION
YM131.343.416 Replacement Stainless for Extractor
YM804.3413.03 Glass for Extractor
YM974.3413.03
Carbon Filter Bed (not including filter)
YM974.3413.04
Carbon Filter (for recircilation)
FLOW-IN PARTS
If you cannot solve the issue using the present
table, call the customer service department (see
numbers “ Hotline (for Germany, Austria, and
Benelux)” on page 3).
6 Accessories and spare parts
6.1 Ordering accessories and spare parts
6.2 Accessories
6.2.1 Accessories circulation/exhaust air fan control
Purchase any spare parts or accessories either through your
retail dealer or the service department (see numbers “Ho-
tline (for Germany, Austria, and Benelux)” on page 3).
The use of not authorised spare parts and acces-
sories authorised will void the warranty granted by
the manufacturer.
For more information, please visit
www.silverline24.de.
WARNING!
Danger of injury through the use of unsuit-
able accessories or spare parts!
Using unsuitable or faulty accessories or spare
parts may compromise your safety and cause
you damage, malfunctions or complete failure of
the device.
– Use only original spare parts of the manufac-
turer or spare parts and accessories autho-
rised by the manufacturer.
– In case of any uncertainties, always call the
customer service department (see numbers
“Hotline (for Germany, Austria, and Benelux)”
on page 3).
20
