Iluv i151 User manual

Bluetooth Transmitter for
your iPod
Instruction Manual
i151
Please read this manual carefully before operating and save it
for future reference.
Have a question? Please visit http://www.i-Luv.com

Bluetooth Transmitter V10M10_IM_EN_08032007
www.i-Luv.com
-1-
USER SAFETY GUIDE
Instructions on Environmental Protection
Do not dispose of this product in the usual
household garbage at the end of its life cycle;
bring it to a collection point for the recycling of
electrical and electronic appliances. This symbol
on the product means the instructions for use or
the packing will inform about the methods for disposal. The
materials are recyclable as mentioned in its marking. By
recycling, material recycling, or other forms of re-utilization of old
appliances, you make an important contribution to protect the
environment. Please inquire at your local community
administration for the authorized disposal location.
Important Safety Warnings
1. FCC regulations state that any change or modification to
the equipment, not expressly approved by the maker or its
authorized parties, could void user’s authority to operate
this equipment.
2. To prevent fire or electric shock, do not expose the unit to
rain or moisture.
3. Never attempt to open the cabinet. Always refer servicing to
a qualified technician.

Bluetooth Transmitter V10M10_IM_EN_08032007
www.i-Luv.com
-2-
USER SAFETY GUIDE
Important Safety Instructions
1. READ INSTRUCTIONS - All safety and operating
instructions should be read before the appliance is
operated.
2. RETAIN INSTRUCTIONS - The safety and operating
instructions should be retained in a secure place for future
reference.
3. HEED WARNINGS - All warnings on the appliance and in
the operating instructions should be observed.
4. FOLLOW INSTRUCTIONS - All operating and use
instructions should be followed.
5. WATER AND MOISTURE - The appliance should not be
used near water. For example: near a bathtub, kitchen sink,
laundry tub, and/or swimming pool.
6. HEAT - The appliance should be situated away from heat
sources such as radiators, heat registers, stoves, or other
appliances (including amplifiers) that produce heat.
7. POWER SOURCES - The appliance should be connected
to a power supply only of the type described in the
operating instructions or as marked on the appliance.
8. CLEANING - The appliance should only be cleaned with a
dry cloth.
9. OBJECT AND LIQUID ENTRY - Care should be taken so
that objects do not fall and liquids are not spilled into the
device’s openings.
10. CARTS AND STANDS - The appliance
should be used only with a cart or stand that
is recommended by the manufacturer. An
appliance and cart combination should be
moved with care. Quick stops, excessive
force, and uneven surfaces may cause the appliance and
cart combination to overturn causing possible injury to the
user and/or damage to the unit.

Bluetooth Transmitter V10M10_IM_EN_08032007
www.i-Luv.com
-3-
USER SAFETY GUIDE
Important Safety Instructions – Continued
11. DAMAGE REQUIRING SERVICE - The appliance should
be serviced by qualified service professional when:
a. Objects have fallen into, or liquid has been spilled into
the appliance’s apertures.
b. The appliance has been exposed to rain.
c. The appliance has been dropped and suffered damage.
d. The appliance does not appear to operate normally, or
exhibits a change in performance.
12. SERVICING - The user should not attempt to service the
appliance beyond what is described in the user's operating
instructions. All other servicing should be referred to
qualified service professional.
13. LEAD AND MERCURY - This product may contain lead
and/or mercury. Disposal of these materials may be
regulated by your local authorities due to environmental
considerations. For more detailed disposal or recycling
information, please contact your local authorities or the EIA
(Electronic Industries Alliance) – http://www.eiae.org
Additional Safety Instructions
•When not in use, keep your device in a safe place where it
will not be bent or crushed.
•Do not listen to music with high volume while driving.
Warning horn sounds may not be heard which could result
in a traffic accident.
NOTE: Changes or modifications not expressly approved by
the party responsible for compliance could void the user’s
authority to operate the equipment. Refer to 47 CFR Sec.
15.21.

Bluetooth Transmitter V10M10_IM_EN_08032007
www.i-Luv.com
-4-
USER SAFETY GUIDE
About Electromagnetic Interference (EMI)
This device is designed and manufactured not to exceed the
exposure limit for radio frequency energy, which is set by the
Federal Communications Commission of the U.S government.
The term “EMI” is short for the electromagnetic interference
caused by the electromagnetic field generated by electronic
devices. In fact, most electrical appliances and devices emit
electric and magnetic fields, and most of modern electronic
devices are susceptible to electromagnetic interference (EMI) if
they are inadequately shielded or designed.
•If you use any personal medical device, such as a
pacemaker, please consult the manufacturer of the device
to determine if it is adequately shielded from
electromagnetic interference. Your physician may assist
you in obtaining this information.
•Please turn off this device if you are instructed to do so,
especially on an airplane and in a hospital.
•Please keep away from the medical instruments in a
hospital or medical unit while using this device.
FCC Notice to U.S. Users
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation. Refer to 47 CFR Sec. 15.19.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.

Bluetooth Transmitter V10M10_IM_EN_08032007
www.i-Luv.com
-5-
USER SAFETY GUIDE
FCC Notice to U.S. Users-continued
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications, which can be determined by turning the
equipment off and on, the user is encouraged to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
receiver.
•Connect the equipment to an outlet on a circuit different
from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician
for help.
Industry Canada Notice to Canadian Users
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation of the device. Refer to IC
RSS 210 Sec. 5.11. The term “IC” before the certification or
registration number only means that the registration was
performed based on a Declaration of Conformity and that
Industry Canada technical specifications were met. It does not
imply that Industry Canada (IC) approved this equipment. Refer
to Self-Marking 6(f) and RSP 100 Sec. 4.

Bluetooth Transmitter V10M10_IM_EN_08032007
www.i-Luv.com
-6-
GETTING STARTED
Thank you for purchasing the i151. Unpack the unit and make
sure all the accessories are put aside so they will not be lost.
Bluetooth Stereo Transmitter
•Controls your iPod wirelessly with Bluetooth remote control
function if your Bluetooth device supports AVRCP
•Detachable adapter for use with case or skin
•Bluetooth Core: Version 2.0
•Bluetooth Profile: AVRCP, A2DP
•Communication Range: Up to 33ft (10m)
What’s Included?
•Main Unit
•Instruction manual
•Warranty card

Bluetooth Transmitter V10M10_IM_EN_08032007
www.i-Luv.com
-7-
GETTING STARTED
Location of Controls
1. 30-pin connector
2. Pairing/Power button
Turning the i151 On/Off
•Press and hold the Pairing/Power button for
approximately three (3) seconds until the LED flashes
Blue. Power is now ON. Release the button.
•Press and hold the Pairing/Power button for
approximately five (5) seconds until the LED flashes Red.
Power is now OFF. Release the button.
Note: The i151 has an audio auto detect function. Once
connected to your iPod , it will power on automatically when an
audio signal is detected. If your iPod is turned off, the i151 will
also be turned off.
1 2

Bluetooth Transmitter V10M10_IM_EN_08032007
www.i-Luv.com
-8-
OPERATING INSTRUCTIONS
Pairing the i151
In order to function properly, the i151 must be paired with a
Bluetooth headset or other device with Bluetooth wireless
technology. Follow the instructions below.
1. Set your Bluetooth device into its pairing mode following
the instructions in the instruction manual for the
connected device.
2. With the i151 switched OFF, press and hold the
Pairing/Power button for approximately five (5) seconds,
3. With the i151 switched ON, press and hold the
Pairing/Power button for approximately three (3) seconds
4. When the LED flashes Blue and Red alternatively, the
i151 is in Pairing mode.
5. The i151 will find the Bluetooth device and pair with it
automatically when placed near the device.
6. Once fully and properly paired, the LED will flash Blue at
three (3) second intervals.
Using the i151
Once the i151 is paired, the functions of your iPod can now be
sent wirelessly to the paired device.
When the device or headphone supports Bluetooth Remote
Control Profile (AVRCP), all control functions of your iPod can be
used wirelessly, including:
•Play
•Pause
•Stop (turn off iPod)
•Track Forward
•Track Backward

Bluetooth Transmitter V10M10_IM_EN_08032007
www.i-Luv.com
-9-
OPERATING INSTRUCTIONS
LED Status Indicator
Mode LED Indicators
Power ON Blue light blinks
Power OFF Red light blinks
Pairing Blue and Red lights blink alternatively
Standby (Paired) Blue light blinks twice every three (3)
seconds
Standby (Not
Paired
Blue light blinks once every three (3)
seconds
Streaming Music Blue light blinks three times every three (3)
seconds.
Troubleshooting
No sound from Bluetooth device
•Your iPod is not inserted into the i151 properly. Insert again.
•Your iPod is not turned on. Turn on your iPod.
•The i151 is not turned on. Turn on i151.
•The connected device or i151 is not properly paired.
Bluetooth remote control functions do not work
•In order for the remote control functions of the i151, the
paired device must support Bluetooth Remote Control
Profile (AVCRP) profile. Check the profile of the connected
headphone or other Bluetooth device.

Bluetooth Transmitter V10M10_IM_EN_08032007
www.i-Luv.com
- 10 -
SPECIFICATIONS
• Detachable adapter for use with case or skin
• Bluetooth Core: Version V2.0
• Bluetooth Profile: AVRCP, A2DP
• Communication Range: Up to 33ft (10m)
* Features and specifications are subject to change without prior
notification. The unit dimensions and weights are approximate.

iLuv is a trademark of jWIN Electronics Corp. iPod is a trademark
of Apple Inc. All logos and brands are property of their respective
owners. iPod is not included in this package. Features and
specifications are subject to change without prior notification.
© 2007 jWIN Electronics Corp. All rights reserved. No portion of
this printed material or product enclosed herewith including
design, shape and graphics, may be reproduced or transmitted
in any form without the expressed written consent of jWIN
Electronics Corp. by any means, electronic or mechanical,
including photocopying, recording or use of an information
storage and retrieval system. Any unauthorized distribution or
reproduction of this printed material or product, or any portion
thereof, will be prosecuted to the fullest possible extent of the
law. iPod is not included with this product.
TEL: [phone]
FAX: [phone]
Website: www.i-Luv.com
E-mail: [e-mail]
