ILVE IVDFI400 Manual

IVDFI400
Dishwasher Operating
& Installation Manual

Thank you for choosing this product.
This User Manual contains important information on safety and instructions intended to
assist you in the operation and maintenance of your appliance.
Please take the time to read this User Manual before using your appliance and keep this
book for future reference.
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Fire risk
CAUTION Injury or property damage risk
IMPORTANT / NOTE Operating the system correctly

CONTENTS
1.SAFETY INSTRUCTIONS ................................................................................................ 1
1.1. General Safety Warnings ..............................................................................................1
1.2. Installation Warnings .....................................................................................................1
1.3. During Use.....................................................................................................................2
2.INSTALLATION ................................................................................................................. 6
2.1. Machine Positioning .....................................................................................................6
2.2. Water Connection ..........................................................................................................6
2.3. Water Inlet Hose ............................................................................................................6
2.4. Drain Hose.....................................................................................................................6
2.5. Electrical Connection ....................................................................................................7
2.6. Fitting the Machine Undercounter .................................................................................7
3.TECHNICAL SPECIFICATIONS ....................................................................................... 8
3.1. General Appearance......................................................................................................8
3.2. Technical Specifications ................................................................................................8
4.BEFORE USING THE APPLIANCE ................................................................................. 9
4.1. Setting ...................................................................................................................10
4.2. Detergent Usage .........................................................................................................10
4.3. Filling the Detergent .................................................................................................... 11
4.4. Using Combined Detergents ....................................................................................... 11
4.5. Rinse-aid Usage .......................................................................................................... 11
4.6. Filling the Rinse-aid and Setting .................................................................................. 11
5.LOADING YOUR DISHWASHER ....................................................................................11
5.1. Recommendations....................................................................................................... 11
5.2. Alternative Basket Loads .............................................................................................13
6.PROGRAMME TABLE .................................................................................................... 14
7.THE CONTROL PANEL .................................................................................................. 15
7.1. Changing a Programme ..............................................................................................15
7.2. Cancelling a Programme .............................................................................................16
7.3. Switching the Machine Off ...........................................................................................16

8.CLEANING AND MAINTENANCE ................................................................................. 17
8.1. Cleaning the Machine and Filters ................................................................................17
8.2. Spray Arms ..................................................................................................................17
9.TROUBLESHOOTING .................................................................................................... 18
10.PRACTICAL INFORMATION ........................................................................................ 20
11.THE PRODUCT FICHE ................................................................................................. 21

EN - 1
1. SAFETY INSTRUCTIONS
1.1. General Safety Warnings
• Read these instructions carefully before using your
appliance and keep this manual for future reference.
Please check the packaging of your machine
before installation and the outer surface of the
machine once the packaging has been removed. Do
not operate the machine if it appears damaged or if
the packaging has been opened.
• Packaging materials protect your machine from any
damage that might occur during transportation. The
packaging materials are environmentally friendly
as they are recyclable. Use of recycled material
reduces raw material consumption and decreases
waste production.
This appliance can be used by children aged from
8 years and above, and by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning the use of the
appliance in a safe way and understand hazards
involved. Children should not be allowed to play with
the appliance.
Remove packaging and keep it out of reach of
children.
Keep children away from detergents and rinse
aids.
There may be some residue left in the machine
after washing. Keep children away from the machine
when it is open.

EN - 2
1.2. Installation Warnings
• Choose a suitable and safe place to install your
machine.
• Only original spare parts should be used with the
machine.
Unplug the machine before installation.
Your machine must only be installed by an
authorised service agent. Installation by anyone other
than an authorised agent may cause your warranty to
be void.
Check that the indoor electrical fuse system is
connected in line with safety regulations.
All electrical connections must match the values on
the plate.
Ensure the machine does not stand on the
electrical supply cable.
Never use an extension cord or a multiple socket
connection.
The plug should be accessible after the machine is
installed.
• After installation, run your machine unloaded for the
first time.
The machine must not be plugged in during
positioning.
Always use the coated plug supplied with your
machine.
If the electrical cable is damaged, it should only
be replaced by a qualified electrician.
1.3. During Use
• This machine is for domestic use only; do not use

EN - 3
• it for other purposes. Commercial use will void the
guarantee.
Do not stand, sit or place loads on the open door of
the dishwasher.
Only use detergents and rinse aids produced
specifically for dishwashers. Our company is not
responsible for any damage that may occur due to
misuse.
Do not drink water from the machine.
Due to the danger of explosion, do not place any
chemical dissolving agents into the machine’s washing
section.
• Check the heat-resistance of plastic items before
washing them in the machine.
Only put items in the machine which are suitable for
dishwashing, and take care not to overfill the baskets.
Do not open the door while the machine is in
operation, hot water may spill out. Safety devices
ensure the machine stops if the door is opened.
The machine door should not be left open. It may
cause accidents.
Place knives and other sharp objects in the cutlery
basket in a blade-down position.
In the case of a malfunction, repair should only
be performed by an authorised service company,
otherwise the warranty will be void.

EN - 4
Before repair work, the machine should be
disconnected from the mains. Do not pull the cable to
unplug the machine. Switch off the water tap.
Operation at a low voltage will cause a decline in
performance levels.
For safety, disconnect the plug once a program has
finished.
To avoid an electric shock, do not unplug the
machine with wet hands.
Pull the plug to disconnect the machine from the
mains, never pull on the cord.
RECYCLING
• Some machine components and packaging consist of recyclable materials.
• Plastics are marked with the international abbreviations:(>PE<, >PP<, etc. )
• The cardboard parts consist of recycled paper. They can be put into waste paper
containers for recycling.
• Material unsuitable for domestic waste must be disposed of at recycling centres.
• Contact your local recycling centre to obtain information about disposal of different
materials.
PACKAGING AND THE ENVIRONMENT
• Packaging materials protect your machine from damage that may occur during
transportation. The packaging materials are environmentally friendly as they are
recyclable. The use of recycled material reduces raw material consumption and
therefore decreases waste production.

CE Declaration of Conformity
We declare that our products meet the applicable European Directives, Decisions and
Regulations and the requirements listed in the standards referenced.
Disposal of your old machine
The symbol on the product or on its packaging indicates that this product
may not be treated as household waste. Instead, it shall be handed over to
the applicable collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this product,
please contact your local city office, your household waste disposal service or the shop
where the product was purchased.
EN - 5

EN - 6
2. INSTALLATION
2.1. Machine positioning
When positioning the machine, place it in
an area where dishes can be easily loaded
and unloaded. Do not put the machine in an
area where the ambient temperature falls
below 0°C.
Read all warnings located on the packaging
before removing the packaging and
positioning the machine.
Place the machine close to a water tap
and drain. Take into consideration that the
connections will not be altered once the
machine is in position.
Do not hold the machine by its door or
panel.
Leave an adequate distance around the
machine to allow ease of movement when
cleaning.
Ensure the water inlet and outlet
hoses are not squeezed or trapped and that
the machine does not stand on the electrical
cable while positioning.
Adjust the feet so the machine is level and
balanced. The machine should be placed
on flat ground otherwise it will be unstable
and the door of the machine will not close
properly.
2.2. Water connection
We recommend fitting a filter to your water
inlet supply in order to prevent damage to
your machine due to contamination (sand,
rust, etc.) from indoor plumbing. This will
also help prevent yellowing and deposit
formation after washing.
2.3. Water inlet hose
WARNING: Use the new water inlet
hose supplied with your machine, do not
use an old machine’s hose.
WARNING: Run water through the
new hose before connecting.
WARNING: Connect the hose directly
to the water inlet tap. The pressure
supplied by the tap should be a minimum
of 0.03 MPa and a maximum of 1 MPa. If
the pressure exceeds 1 MPa, a pressure
relief valve must be fitted between the
connection.
WARNING: After the connections are
made, turn the tap on fully and check
for water leaks. Always turn off the
water inlet tap after a wash program has
finished.
An Aquastop water spout is available
with some models. Do not damage it or
allow it to become kinked or twisted.
2.4. Drain Hose
Connect the water drain hose directly to
the water drain hole or to the sink outlet spigot.
This connection should be minimum 50 cm
and maximum 110 cm from the floor.
IMPORTANT: Items will not wash
properly if a drain hose longer than 4 m is
used.

EN - 7
2.5. Electrical connection
WARNING: Your machine is set to
operate at 220-240 V. If the mains voltage
supply to your machine is 110 V, connect a
transformer of 110/220 V and 3000 W
between the electrical connection.
The earthed plug of the
machine must be connected to an
earthed outlet supplied by suitable
voltage and current.
In the absence of earthing
installation, an authorised
electrician should carry out an
earthing installation. In the case of use
without earthing installed, we will not be
responsible for any loss of use that may
occur.
The indoor fuse current value
should be 10-16 A.

EN - 8
3. TECHNICAL SPECIFICATIONS
11
3.1. General appearance
1. Upper basket with racks
2. Upper spray arm
3. Lower basket
4. Lower spray arm
5. Filters
6. Rating plate
7. Control panel
8. Detergent and rinse-aid dispenser
9. Cutlery basket
10. Upper Cutlery Basket
11. Super Active Drying Unit: This system
provides better drying performance for
your dishes.
3.2. Technical specifications
Capacity 13 place
settings
Dimensions
Height
Width
Depth
850(mm)
598(mm)
598(mm)
Net weight 38kg
Operating
voltage /
frequency
220-240V
50 Hz,
Total current
(A) 10(A)
Total power
(W) 1900(W)
Water supply
pressure
Maximum:
1 (Mpa)
Minimum:
0.03 (Mpa)
6
1
2
3
4
5
7
8
9
1
0

EN - 9
4.1. Detergent usage
Only use detergents specifically designed for domestic dishwashers.
Add the recommended amount of detergent for the selected programme to ensure the best
performance.
Keep your detergents in cool, dry places out of reach of children.
See the detergent manufacturer’s instructions for a further information.

EN - 10
4.2 Filling the detergent
Push the latch to open the dispenser and
pour in the detergent.
Close the lid and press it until it locks in
place. The dispenser should be refilled just
before the start of each programme. If the
dishes are heavily soiled, place additional
detergent in the pre-wash detergent
chamber.
DETERGENT
4.3. Using combined detergents
These products should be used according
to the manufacturer’s instructions.
Never put combined detergents into the
interior section or the cutlery basket.
Combined detergents contain not only
the detergent but also rinse-aid,
replacement substances and additional
components depending on the combination.
We recommend you do not use combined
detergents in short programmes.
Please use powder detergents in such
programmes.
If you encounter problems when using
combined detergents, please contact the
detergent manufacturer.
When you stop using combined detergents,
make sure that rinse
aid setting set to correct level.
4.4. Rinse-aid usage
Rinse-aid makes dishes sparkle and helps
them to dry without spotting. Rinse-aid is
required for stain-free utensils and clear
glasses. Use only rinse-aid for domestic
dishwashers.
4.5 Filling the rinse-aid and setting
To fill the rinse aid compartment, open
the rinse-aid compartment cap. Fill the
compartment with rinse aid to the MA level
and then close the cap. Be careful not to
overfill the rinse aid compartment and wipe
up any spills.
In order to change the rinse aid level,
follow the below steps before turning on
the machine:
• Touch the programme button and hold
it down.
• Turn on the machine.
• Hold down the programme button until
rA disappears.
• The machine will display the current
setting.
• Set the level by touching the programme
button.
• Switch off the machine to save the
setting.
The factory setting is 4.
If the dishes are not drying properly or are
spotted, increase the level. If blue stains
form on your dishes, decrease the level.
Level Brightener Dose Indicator
1 Rinse-aid not
dispensed
r1 is shown on the
display
2 1 dose is
dispensed
r2 is shown on the
display
3 2 doses are
dispensed
r3 is shown on the
display.
4 3 doses are
dispensed
r4 is shown on the
display.
5 4 doses are
dispensed
r5 is shown on the
display.

EN - 11
5. LOADING YOUR DISHWASHER
For best results, follow these loading
guidelines.
We recommend that you place large items
(pots, pans, lids, plates and bowls) which
are heavily soiled in the lower basket.
The upper basket is designed for delicate
and lighter dishware such as glasses,
coffee and tea cups and saucers. Position
the dishes so that they will not get moved
by the spray of water.
Cutlery should be placed in the cutlery
basket. Items should be loaded individually
into the appropriate slots with their handles
downwards. Long utensils should be placed
horizontally on the baskets.
WARNING: Take care not to obstruct
the rotation of spray arms.
5.1. Recommendations
Remove any coarse residue on dishes
before placing the dishes in the machine.
Start the machine with full load.
Do not overload the drawers or place
dishes in the wrong basket.
WARNING: Always place sharp
utensils with the sharp point down and open
utensils with their openings down.
Upper Basket
The upper basket includes a mechanism
which enables the height of the basket to be
adjusted up (1) or down (2) without having
to remove the basket. Hold the basket on
both sides and pull it up or push it down,
ensuring both sides of the upper basket are
in the same position.
Height Adjustable Rack (peg type)
The height adjustable racks enable glasses
and cups to be placed on or under the
racks. The racks can be adjusted to 2
different heights. Cutlery and utensils can
also be placed on the racks horizontally.
1
2

EN - 12
5.2. Alternative Basket Loads
Lower Basket
Top basket
Incorrect loads

EN - 13
6. PROGRAMME TABLE
Programme Duration
(min) Description
Mini 14’ 14 Fastest programme for lightly soiled and recently used dishes. Suitable for 4 place
settings.
uick 30’ 30 For lightly soiled dishes and a quick wash.
Eco (Reference) 143 Standard programme for normally soiled, daily-used dishes.
Super 50’ 50 For normally soiled, daily-used dishes with a faster programme.
Hygiene 154 High-temperature, disinfecting programme for heavily soiled dishes.
Intensive
(Model
Depending)
Auto Intensive
(Model
Depending)
115
115-91
For heavily soiled dishes.
Automatic programme for heavily soiled dishes.
*If your model has turbidity sensor it has Auto Intensive program instead of Intensive program.
NOTE: THE PROGRAMME DURATION MAY CHANGE ACCORDING TO THE
AMOUNT OF DISHES, THE WATER TEMPERATURE, THE AMBIENT TEMPERATURE
AND SELECTED ADDITIONAL FUNCTIONS.
• Only use powder detergent for short programmes.
• Short programmes do not include drying.
• To assist drying, we recommend slightly opening the door after a cycle is complete.

EN - 14
7.THE CONTROL PANEL
Press the On/Off touch button (1) for 1
second to switch the machine on. Two
dashes will appear on the Programme
Display.
Select the programme most suitable for
your dishes using the Programme touch
button (2). The selected programme will
show on the Programme Display (3), from
P1 to P6. The selected programme will
show for 3 seconds, then its duration will
show for 1 second, alternately.
Additional functions can also be selected.
The programme will start automatically
when the door is closed.
NOTE: Press the Tablet Detergent
button (5) when using combined detergents
that contain and rinse aid.
NOTE: Press the Half Load button (6)
to reduce the duration of a programme, and
therefore decrease your energy and water
consumption.
NOTE: If your dishwasher includes an
InfoLED function, the InfoLED will indicate
the status of the programme in operation.
During operation, the InfoLED will be on,
when the programme is complete the
InfoLED will switch off.
NOTE: If you decide not to start the
selected programme, please see the
Changing a Programme and Cancelling a
Programme sections.
NOTE: When there is insufficient rinse
aid, the Rinse Aid Lack Warning Indicator
(7) will iluminate to indicate the rinse aid
chamber needs filling.
Delaying a Programme
Press the Delay Start touch button to delay
the start time of a programme for 1 hour
up to 19 hours. Pressing the button once
will delay the start time for 1 hour, and
continuing to press will increase the delay
time. The programme can be selected first
and the delay duration after, or vice versa.
To cancel the delayed start, either set the
delay timer to 0h, or press and hold the
Programme touch button for 3 seconds.
The display will show a countdown of how
many seconds to hold the button for, 3-2-
1, in order to cancel the delay.
NOTE: Press and hold the Delay touch
button to change the delay time faster. The
rate of change is proportional to how long
the button is held for. Pressing the Delay
Start touch button for a long period of time
will stop the counter at h:00.
7.1.Changing a Programme
Follow the steps below to change the
programme while in operation.
1- Open the door and press the
Programme touch button (2) to select a
new programme. If the door is opened
during operation, the time remaining of the
programme will show on the display (3).
2- After the door is closed, the newly
selected programme will resume the course
of the old programme.
NOTE: Open the door slightly at first
to stop a wash programme before it is
complete in order to avoid water spillage.
7.2.Cancelling a Programme
Follow the steps below to cancel a
programme while in operation or in standby
mode.
1- After the door is closed, the water
discharge process will start and continue
(1) (2) (3) (4) (5) (6)
(7)

EN - 15
for 30 seconds. A buzzer will sound 5 times
when the programme is cancelled.
NOTE: When the door is opened after
a programme is complete, the buzzer sound
will stop and 0’ will show on the display (3).
Switching the Machine Off
A buzzer will sound 5 times when a
programme is complete. You can then
switch your machine off using the Power
On/Off touch button (1).
NOTE: Do not open the door before a
programme is complete.
NOTE: Leave the door of your
machine open slightly at the end of a wash
programme, or select the Energy Save
function before starting a programme, in
order to speed up drying.
NOTE: If the door of the machine
is opened or the power is cut during
operation, the programme will restart when
the door is closed or the power returns.
OPTIONAL
PROGRAMS
Delayed
Start
Half
Load
Tablet
Mini 14
uick 30
40°C
Eco
Express 50
65°C
Hygiene 60°C
Intensive
65° C
- Function cannot be selected
 Function can be selected.
Compatibility between Options
OPTIONS Delayed
Start
Half
Load
Tablet
Delayed Start
Half Load
Tablet

EN - 16
8. CLEANING AND
MAINTENANCE
Cleaning your Dishwasher is important
to maintain the machine’s service life.
Oil and limescale may build up in your
Dishwasher over time. If this occurs:
• Fill the detergent compartment
but do not load any dishes. Select
a programme which runs at high
temperature and run the Dishwasher
empty. If this does not clean your
Dishwasher sufficiently, use a
cleaning agent designed for use with
dishwashers.
•Wipe the door seals regularly
with a damp cloth to remove any
accumulated residue.
8.1. Cleaning machine and filters
Clean the filters and spray arms at least
once a week. If any food waste remains on
the coarse and fine filters, remove them and
clean them thoroughly with water.
a) Micro Filter b) Coarse Filter
c) Metal Filter
2
b
a
1
34
c
To remove and clean the filter combination,
turn it counter clockwise and remove it by
lifting it upwards (1).Pull the coarse filter out
of the micro filter (2).Then pull and remove
the metal filter (3).Rinse the filter with lots of
water until it is free of residue. Reassemble
the filters. Replace the filter insert, and
rotate it clockwise (4).
• Never use your Dishwasher without a
filter.
• Incorrect fitting of the filter will reduce
the washing effectiveness.
• Clean filters are necessary for proper
running of the machine.
8.2. Spray arms
Make sure that the spray holes are not
clogged and that no food waste is stuck
to the spray arms. If there is any clogging,
remove the spray arms and clean them
under water. To remove the upper spray
arm undo the nut holding it in position
by turning it clockwise and pulling it
downwards. Make sure that the nut is
properly tightened when refitting the upper
spray arm.
