Imagilights Ball 35 User manual

USER MANUAL
©2011IMAGILIGHTS®
56 LED, as used in the following models:
Ball 35/50
Flat ball
Half ball
Teardrop
Egg big
Lantern
Byblos
Diamond
Viggo
Champagne
Might-e (4x)
Cube 40
Samoa Seat
Barelo
Tube
Marilyn

Thank you
for having selected an IMAGILIGHTS® lamp
Your multicolour ambiance LED lamp is rechargeable, waterproof and highly
resistant to shock. Your lamp may be used inside, outdoors, floating on water and
even hanging somewhere.
Pack contents
- Lamp
- Induction charger
- Electrical adapter
- Infrared remote
- Textile lanyard to hang your lamp (depending on model)
Usage precautions
Carefully read this guide before using your device. We recommend keeping it handy for
future use. Always use your lamp in conformity with the utilization precautions. Failure to
do so will void any warranty. IMAGILIGHTS® disclaims any responsibility for incorrect use of
the product or the transformer in combination with another product which could be
defective, dangerous or inappropriate.
Recycling
Do not throw this device away with your regular Household garbage. Contact the
appropriate service within your community to learn the best way to dispose of the device.
Electrical products contain substances harmful to human health and the environment so
must be adequately recycled.

The internal battery does not have a charge accumulator and will require 5 or 6
complete charges/discharges before reaching optimal charge capacity.
1. Connect the charger
2. Fully charge your lamp's battery by placing the lamp on the charger for at least
12 hours. A RED charge indicator appears on the charger when charging. A GREEN
luminous indicator indicates the lamp is fully charged.
To guarantee the maximum autonomy of your product, please
conform to the precautions:
First usage
The light automatically turns off
when placed on the Induction
charger plate. This to protect the
long life of the battery and to
assure that charging and
discharging is not done
simultaneously.
It is recommended to empty (discharge) the full capacity of the battery, before
recharging fully.
Once fully charged and a green luminous indicator is shown on the induction charger
plate, please remove the unit from the plate.

Choosebetweenoneofour
24pre-programmedcolours.
Starta160.000colourmixmodewhich
willtakeapproximately14minutes,and
willcontinuewithoutinterruption.Tofixa
colour,pressthebuttonagain.Tocontinue
thecycleusethissamebutton.
Shiftthroughfourlightintensitymodes.
Usethemetalringtohangyourlamp.
Starta160.000colourmixmodewhichwilltake
approximately14minutes,andwillcontinuewithout
interruption.Tofixacolour,pressthebuttonagain.Tocontinue
thecycleusethissamebutton.
2White+colours(RGB)
3Colours(RGB)
1Choosebetweenoneofour24pre-programmedcolours.
4Startthecandleeffect(yellowororange)
5Shiftthroughfourlightintensitymodes.
1
1
2
32
4 45 5
_______________________
__________________
__________
______________
Models starting from code IL45

1. Natural white
2. Galactic white
3. Candle mode light
4. Candle mode dark
5. Dark red
6. Light red
7. Light orange
8. Dark orange
9. Yellow
10. White/Green
11. Light green
12. Dark green
13. Turquoise light
14. Blue/Turquoise
15. Blue/Green
16. Purple/Blue
17. Dark blue
18. Light pink
19. Medium pink
20. Dark pink
21. Salmon
22. Light purple
23. Dark purple
24. Pink/Purple
Our pre-programmed colours
Hours of light
(approximately)
High intensity White - 14hrs
Low intensity White - 60hrs
Colour mix - 18hrs
Colour fix - 37hrs
Candle effect - 21hrs
(=colour demanding the most battery power)

- Use near a heat source or expose to fire.
- Touch the charger or charger base while charging.
- Try to open, in case of faultiness please return it to your vendor.
- Keep it plugged in after charging.
- Use outdoors
- Store in humid area
- Keep in reach of young children.
DO NOT...
Charger
LAMP
- Use near a heat source or expose to fire.
- Try to open or dismount the lamp to avoid any risk of Electrical shock or altering
its waterproofing; failure to comply will cancel your warranty.
- Connect the lamp's base to another device.
- Try to charge the lamp with a charger other than the one supplied in your pack.
- Place your lamp for extended periods in water or bright sunshine. This to avoid
dirty water markings on the level of the waterline.
- Remove the LED module unless it is broken, this to avoid dirty fingerprints on the
inside of your lamp and to maintain waterproofness.
Technical specifications
- Waterproof module : Class IP68
- Charging time: 12hrs
- Charger: Input 100-240V AC~50/60Hz - Output DC 7.5V 1.5A
- Battery: Li-Polymer 4000 mAh
- Battery remote: Lithium battery CR2025 3V
- Watt consumption: 3,36
- Polyethylene plastic diffuser, resistant to UV and shocks
- Lamp's ideal operating temperature range: 10°C to 45°C
LED MODULE

Legal information
IMAGILIGHTS® Wireless Lamps are covered by
Design Registration, Copyright and Patent Pending.
All rights reserved. All shapes and models are
registred. Patented LED module and patented
wireless Induction charger. Any tampering with or
repairing the unit voids the warranty. The unit is
equipped with special labels to avoid tampering.
[email protected]
www.imagilights.com
Warranty
Manufacturer's warranty of 1 year.
(European regulation regarding low voltage lighting)
