Implicit Audio 1x12 Cabinet User manual

1x12 Cabinet Assembly
1x12 Cabinet
Assembly Instructions
www.implicitaudio.ca
@implicit.audio
Implicit Audio
Built for the craft

Thank you for purchasing an Implicit Audio guitar cabinet kit. Whether you’re
new to woodworking or you're a seasoned veteran, this kit serves as a foundation
to build a piece of gear that is truly unique.
As with any wood working project, we encourage you to follow all health and
safety warnings as outlined by the tools and products you use. This assembly
does require a few tools which we’ve outlined on the next page along with a few
helpful suggestions.
One more thing!
We want to see your build!
Send us a photo of your finished cabinet or a video of you playing through your
new rig for a chance to be featured in one of our Maker Profiles where we show-
case exceptional quality and craftsmanship.
Questions and build pictures can be sent to [email protected]
Thank You.
1x12 Cabinet Assembly
www.implicitaudio.ca
@implicit.audio
Implicit Audio
Built for the craft

Dry fit everything before glueing to ensure that all pieces fit together.
Try to complete the entire assembly within the working time of the glue.
Make sure that all connections are properly seated.
Clamps x4 (minimum)
Wood glue
Philips screwdriver
Robinson #1 screwdriver
Hammer
Fabrication Tips
Required Tools
1x12 Cabinet Assembly
www.implicitaudio.ca
@implicit.audio
Implicit Audio
Built for the craft

Top Bottom
Horizontal Blocking x2
Vertical Blocking x2
Top Back
1. Back Screw x8
2. Speaker Screws x4
3. Feet Screws x4
4. Handle Screws x4
5. Jack Plate Screws x3
6. Tee Nut x8
Bottom Back
Screen
Side x2
Bae
1x12 Cabinet Assembly
www.implicitaudio.ca
@implicit.audio
Implicit Audio
Built for the craft
Cabinet Parts
Fasteners

1x12 Cabinet Assembly
www.implicitaudio.ca
@implicit.audio
Implicit Audio
Built for the craft
Step 1
Lay the Bae flat and hammer the Tee Nuts into the 4 holes provided.
It’s important to do this first on a solid surface.
Step 2
Lay the Top piece flat and hammer the Tee Nuts into the 4 holes
provided on the INSIDE of the part.

1x12 Cabinet Assembly
www.implicitaudio.ca
@implicit.audio
Implicit Audio
Built for the craft
Step 3
Lay the Bottom piece flat with the grooves facing up.
Step 4
Join one of the Side pieces with the Bottom.
Note: Both side pieces are exactly the same.

1x12 Cabinet Assembly
www.implicitaudio.ca
@implicit.audio
Implicit Audio
Built for the craft
Step 5
Slot the Bae into the Bottom and Side. Ensure that the Bae is
properly seated.
Note: The Tee Nuts from Step 1 should be on the OUTSIDE of
the cabinet.
Step 6
Join the other side piece with the Bottom and Bae.

1x12 Cabinet Assembly
www.implicitaudio.ca
@implicit.audio
Implicit Audio
Built for the craft
Step 7
Before putting on the Top piece, slot in the Right, Left, and Bottom
Blocking pieces.
Step 8
Join the Top piece to the Cabinet. When finished, insert the
remaining Blocking piece.

1x12 Cabinet Assembly
www.implicitaudio.ca
@implicit.audio
Implicit Audio
Built for the craft
Step 9
Attach the two Back pieces with the screws provided.
Note:
Space has been left between the Back and Sides to allow
for Tolex.
Hardware Installation
1. Install your speaker from the INSIDE of the cabinet using the screws provided.
2. Install the handle using the screws provided.
3. Attach the 1/4” jack to the jackplate using the nut & washer assembly provided on the jack.
4. Install the feet on the bottom of the cabinet using the screws provided.
