In The Ditch ITD1613 User manual

TM
ITD1613 Slide Out Drawer Operations Manual
ITEM# QUANTITY DESCRIPTION PART #
1 1 Slide Out Drawer (Complete Assembly) ITD1613
2 1 Slide Out Drawer Bracket ITD1614
3 1 Slide Out Tray ITD1615
4 2 Drawer Dividers ITD1616
1
4
2
3
ITD0473208-587-7960 www.intheditch.com
TM

ITD1613 Slide Out Drawer Operations Manual
TM
DESCRIPTION QUANTITY
1/4” - 20 X 1” Carriage Bolt
( Front of Shelf ) 2
1/4” - 20 X 3/4” Carriage Bolt
( Back of Shelf ) 2
1/4” Nylock Nuts 4
1/4” Flat Washers 4 Mounting Hardware Included
Install Drawer Dividers into the
slide out tray slots. Bend the
tab over to secure the drawer
divider into place.
Place the Slide Out Tray into
Slide Out Drawer Bracket by
inserting the back of the
Slide Out Tray at an angle that
will clear the mounting bolt.
The front mounting bolt can also
be used as a stop for the Slide
Out Tray, this will allow the user
easier access to the tray.
ITD1613 Slide Out Drawer has a
20lbs. Load Limit
1
2
3
1/4” - 20 X 1” Carriage Bolt
1/4” - 20 X 1” Carriage Bolt
