Indaux IndaMatic EUROPA 2 User manual

Smart Simplicity
EUROPA 2
Compact multi-modular
double-walled drawer
425













The EUROPA-2 drawer has an
extensive range to help solve
all your bathroom and kitchen
organisational needs: high and low
drawers; drawer with enclosures,
with tubes, modular cutlery
holders, pan holders, dividers for
organising space, dish holders...
The EUROPA-2 drawer is available
in: coated steel, stainless
steel or plastic (which can be
personalised).
A pre-asssembled functional
drawer easy to fit, available in
12 sizes and 3 depths (270,480,
600mm).
range
The whole
427

1
300 678.430.104 678.430.314
10
350 678.435.100 678.435.310
400 678.440.103 678.440.313
450 678.445.106 678.445.316
500 678.450.102 678.450.312
300 678.530.101 678.530.311
10
350 678.535.104 678.535.314
400 678.540.100 678.540.310
450 678.545.103 678.545.313
500 678.550.106 678.550.316
600 678.560.105 678.560.315
700 678.570.104 678.570.314
800 678.580.103 678.580.313
5
900 678.590.102 678.590.312
1000 678.591.104 678.591.314
1200 678.599.106 678.599.316
600 678.660.102 678.660.312
5900 678.690.106 678.690.316
1200 678.699.103 678.699.313
300 686.630.103 686.630.313
1
350 686.635.106 686.635.316
400 686.640.102 686.640.312
450 686.645.105 686.645.315
500 686.650.101 686.650.311
600 686.660.100 686.660.310
800 686.680.105 686.680.315
300 686.130.141
20
700 686.170.144
20
350 686.135.144 800 686.180.143
400 686.140.140 900 686.190.144
450 686.145.143 1000 686.191.144
500 686.150.146 1200 686.199.146
600 686.160.145
Drawer: Stainless steel and plastic coated steel
COMPONENTS
270mm deep steel drawer.
Module Stainless steel Grey
480mm deep steel drawer.
Module Stainless steel Grey
600mm deep steel drawer.
Module Stainless steel Grey
480mm steel drawer in KIT-5.
Module Stainless steel Grey
Each box contains 5 drawers with their corresponding runners, front fixing brackets and
screws.
Drawer: Stainless steel and plastic coated steel
COMPONENTS
480mm steel drawer in KIT-1.
Module Grey Module Grey
Each box contains 1 drawer with their corresponding runners, front fixing brackets and
screws, and a assembly instructions template.
EUROPA-2 drawer
> CH.7 DRAWERS
428 CATALOGUE 2017

300 689.430.000 689.430.313
20
350 689.435.003 689.435.316
400 689.440.006 689.440.312
450 689.445.002 689.445.315
500 689.450.005 689.450.311
600 689.460.004 689.460.310
900 689.490.001 689.490.314 10
300 689.530.004 689.530.310
1
350 689.535.000 689.535.313
400 689.540.003 689.540.316
450 689.545.006 689.545.312
500 689.550.002 689.550.315
600 689.560.001 689.560.314
900 689.590.005 689.590.311
300 689.630.001 689.630.314
1
350 689.635.004 689.635.310
400 689.640.000 689.640.313
450 689.645.003 689.645.316
500 689.650.006 689.650.312
600 689.660.005 689.660.311
900 689.690.002 689.690.315
Drawer: Plastic molded
480mm plastic molded drawer.
Module White RAL 9001 Grey RAL 7040
480mm plastic molded drawer KIT-4.
Module White RAL 9001 Grey RAL 7040
Each box contains 4 drawers with their corresponding runners, front fixing brackets and
screws.
480mm plastic molded drawer KIT-5.
Module White RAL 9001 Grey RAL 7040
Each box contains 4 drawers with their corresponding runners, front fixing brackets and
screws.
Drawer: Plastic molded
COMPONENTS
EUROPA-2 drawer
> CH.7 DRAWERS
429

15÷16mm. 18÷19mm.
270 664.727.033 664.827.030
480 664.748.033 664.848.030 10
600 664.760.036 664.860.033

 



 




   



748.700.315 10
3
12
Length
Runner range: Full extension
Full extension with self-closing.
Length Ref. Side Ref. Side
Plastic molded
drawer
Steel drawer
Runner range: Full extension
COMPONENTS
Runner support bracket.
Length 480 / 600
Grey RAL 7040
Assembly
Lean the support against the mobile rail. Press the support to clip it into the runner. Slide the support till the front metal bracket.
Clamps
Runner support bracket
Note
Increases the load
capacity of the
runner from 30 to
45kg.
EUROPA-2 drawer
> CH.7 DRAWERS
430 CATALOGUE 2017

16mm.
480 663.848.032 10
520 663.852.033
6,75
39
6
Min.22mm
22
22
12
863
37
L
224 32
256
6
6,75
39
6
Min.22mm
22
22
13.5
863
480 485
520 520
 





300 224
350 274
400 324
450 374
500 424
600 524
700 624
800 724
900 824
1000 924
1200 1124
A B B
56.5 18 12
58 19.5 13.5
Partial extension with self-closing.
Length Ref. Side
Runner range: Partial extension
Steel drawer
Plastic molded
drawer
Depth L
MI = Inner cabinet width
Module Module F
NOTE:
Extension “F” is the same for all the sides
15/16 and 18/19mm of the module.
It is compensated by the runners.
Full ext. Partial ext.
Steel drawer
Plastic molded drawer
Runner range: Partial extension
COMPONENTS
EUROPA-2 drawer
> CH.7 DRAWERS
431

674.000.316 100
270 733.927.316
480 733.948.316 10
600 733.960.312
2
L
300 191 747.130.311
10
350 241 747.135.314
400 291 747.140.310
450 341 747.145.313
500 391 747.150.316
600 491 747.160.315
700 591 747.170.314
800 691 747.180.313
900 791 747.190.312
1000 891 747.191.314
1200 1091 747.199.316
±1.25mm
±2mm
Front fixing brackets
Adjustable front fixing brackets.
Grey RAL 7040
Each reference consists of a complete set of fixing brackets.
ACCESSORIES
Side rail Back rail
Side rail.
Depth Grey RAL 7040
Each reference is made of 1 set of side rails, 1 set of back supports and 1 set of upper
brackets. All unassembled.
Back rail.
Module Grey RAL 7040
Tubes needed for different sides.
Accessories for tubular high front drawers
Single pan divider
Side rail
Back supports
Upper brackets
ACCESSORIES
Front fixing brackets, accessories for tubular high front drawers
Back rail
Front Fixing brackets
Quick-Fix
(Tool-free)
Double pan divider
EUROPA-2 drawer
> CH.7 DRAWERS
432 CATALOGUE 2017

270 648.327.105 648.327.315
10480 648.348.105 648.348.315
600 648.360.101 648.360.311
658.900.141
300 367648.430.101 648.430.311
350 369648.435.104 648.435.314
400 369648.440.100 648.440.310
450 369648.445.103 648.445.313
500 248648.450.106 648.450.316 10
600 248648.460.105 648.460.315
700 248648.470.104 648.470.314
800 2 4 12 648.480.103 648.480.313
900 2 4 12 648.490.102 648.490.312
1000 2 4 16 648.491.104 648.491.314
1200 2 4 16 648.499.106 648.499.316
Accessories for high front drawers with dividers
Side divider.
Depth Stainless steel Grey RAL 7040
Each reference is made up of 2 dividers with fixing brackets and 1 set of back
supports. Back supports are unassembled.
Double divider for tubular front drawers.
Metal grey
ACCESSORIES
Base connector
Side divider Back divider
Single pan divider Cross divider
Back adapter
Connector
Accessories for high front drawers with dividers
Connector
Cross Divider
Divider
Cross divider
divider
Screw
Connector
Single divider for tubular high front drawers
Module Stainless steel Grey RAL 7040
Every ref. has transversal enclosures, connectors, dividers and screws. Everything
unassembled.
*10 sets in separate boxes. Each box A contains 10 bags with plastic accessories and a
bag of screws. The transversal enclosures are available in boxes of 10 units.
Accessories for tubular high front drawers
Double pan divider
EUROPA-2 drawer
> CH.7 DRAWERS
433

658.100.100 100
658.150.102 100
658.900.141
L
300 198 648.230.100 648.230.310
10
350 248 648.235.103 648.235.313
400 298 648.240.106 648.240.316
450 348 648.245.102 648.245.312
500 398 648.250.105 648.250.315
600 498 648.260.104 648.260.314
700 598 648.270.103 648.270.313
800 698 648.280.102 648.280.312
900 798 648.290.101 648.290.311
1000 898 648.291.103 648.291.313
1200 1098 648.299.105 648.299.315
300 367648.630.102 648.630.312
10*
350 369648.635.105 648.635.315
400 369648.640.101 648.640.311
450 369648.645.104 648.645.314
500 248648.650.100 648.650.310
600 248648.660.106 648.660.316
700 248648.670.105 648.670.315
800 2 4 12 648.680.104 648.680.314
900 2 4 12 648.690.103 648.690.313
1000 2 4 16 648.691.105 648.691.315
1200 2 4 16 648.699.100 648.699.310
Accessories for high front drawers with dividers
Double walled rail front bracket. Quick assembly.
1 set
Each reference consists of 2 brackets with expand dowels.
Double walled rail front bracket. Screw mounting.
1 set
Each reference consists of 2 brackets.
Double divider for front drawers with dividers.
Metal grey
Back divider.
Module Stainless steel Grey RAL 7040
Back divider
ACCESSORIES
Accessories for high front drawers with dividers
PLEASE NOTE
These accessories are ideal for the storing
of pots and pans, as well as storage jars.
Cross divider connector
Cross divider
Lateral divide
Single: Cooking utensils & provisions for dividers.
Cabinet width Stainless steel Grey RAL 7040
Each reference consists of 1 set of cross divider + connectors + lateral dividers. All
unassembled.
*10 sets in 2 boxes:
Box a: 10 sets connectors & lateral dividers
Box b: 10 sets of cross dividers
Joining bracket
Sides
Divider
EUROPA-2 drawer
> CH.7 DRAWERS
434 CATALOGUE 2017

748.600.311 50


300 3 0 664.930.140
10
350 2 2 664.935.143
400 2 2 664.940.146
450 3 2 664.945.142
500 3 2 664.950.145
600 4 2 664.960.144
800 9 4 664.980.142
900 9 4 664.990.141
1000 9 4 664.991.143
1200 12 5664.999.145
Support. metal drawer front fixing bracket.
Grey RAL 7040
It is recommended to use this bracket for curved front surfaces in case of
curved fronts.
480mm deep cutlery tray with dividers.
Cabinet width Short divider Long divider Metal grey
Each reference consists of 1 cutlery tray and a bag of dividers.
Cutlery tray
Support
ACCESSORIES
Cutlery tray / Support
EUROPA-2 drawer
> CH.7 DRAWERS
435

480mm. 600mm.
800 650.780.314 650.880.311
900 650.790.313 650.890.310 10
1000 650.791.315 650.891.312
1200 650.799.310 650.899.314




56


1
34
2
ACCESSORIES
Drawer stabiliser
The Drawer stabiliser device neutralizes lateral movement common to all large drawers.
Advisable for use in 800mm cabinets width and more.
Available for 480 and 600mm depths for lower front drawers and pan drawers.
The assistance runner has 2 pivots each side, which fit in the main runner fix rail as a template, providing the correct position.
Stabiliser.
Grey
Cabinet width
Each ref. is made up of 1 rod, 2 racks, 2 gear sets and 4 lateral supports.
*10 units in 2 boxes:
box a: 10 rods and 20 racks.
box b: 20 gear sets and 40 lateral supports.
Box B is common to all the references and will include one
label indicating said references.
Gear set
Swivel rod
Rack
Lateral support
Adjust the gear with the assistance runner and adjust the movable
support to secure it.
Assemble the gear set into rod by matching the flat sections.
Assemble the lateral supports to the rails of the runner.
Close the runners.
1- Open the runners. 2- Insert the gear set with the rod into the
cavity. 3- Adjust the gear with the assistance runner.
Insert the assistance runner onto the lateral supports.
Assembly
Drawer stabiliser
EUROPA-2 drawer
> CH.7 DRAWERS
436 CATALOGUE 2017



















 
3
A B
56.5 18
58 19.5
A B B
56.5 18 12
58 19.5 13.5
C
96
90
High front drawers with dividers
Tubular high front drawers
TECHNICAL INFORMATION
Drawer front drilling template
Steel drawer
Plastic molded drawer
Cabinet
Cabinet
Drawer front drilling template
ACCESSORIES
Full ext. Partial ext.
Steel drawer
Plastic molded drawer
Full extension
Partial extension
EUROPA-2 drawer
> CH.7 DRAWERS
437



TECHNICAL INFORMATION
Drawer assembly / Front alignment
Drawer assembly
Front alignment
Quick and easy manual assembly.
1- Completely extend runners.
2- Insert the front brackets into the runners.
3- Turn the levers upwards to fix the front to the runners.
4- Place the drawer on the runners by opening the drawer sides and clip-on to the runners.
EUROPA-2 drawer
> CH.7 DRAWERS
438 CATALOGUE 2017

2
3
1














1- Assemble the front brackets in the tube
thread.
2- Assemble the lateral tubes by appying
pressure to the back adapters and lining
up the tube hole with the adaptor.
3- Assemble the side tubes and adaptors
in the back tube.
4- Insert the back adapters to the drawer
wings.
5- Rotate the lateral tubes until they are
assembled in the screws.
6- Move the caps towards the drawer front.
7- Move the caps to regulate the drawer front.
Assembly for tubular high front drawers
TECHNICAL INFORMATION
Assembly for tubular high front drawers
EUROPA-2 drawer
> CH.7 DRAWERS
439

1
2
3










High drawer assembly with dividers
1- Assemble the side dividers into the back
adapters.
2- Screw the adapter to the side dividers.
3- Join the side dividers to the back divider.
4- Insert the rear adapters to the drawer
wings.
5- Turn the side dividers until they fit into the
front brachets.
6- Turn the wheel to adjust the drawer front.
TECHNICAL INFORMATION
High drawer assembly with dividers
EUROPA-2 drawer
> CH.7 DRAWERS
440 CATALOGUE 2017
