Indesit IDE 100 Quick start guide

IDE 100
Dishwasher
Installation and use
Geschirrspüler
Installation und Gebrauch

2
GB
Safety Is a Good Habit to Get Into
NOTICE
Carefully read the instructions contained in this manual, as they
provideimportantinformationwhichisessentialtosafeandproper
installation, use and maintenance of the appliance.
Thisappliancecomplieswiththe followingEEC directives:
-73/23/EEC of 19/02/73 (LowVoltage)and subsequent
modifications;
- 89/336/EEC of 03/05/89 (Electromagnetic Compatibility)
and subsequent modifications.
- 97/17/EEC Labelling
1.Carefully dispose of the packing material.
2.Afterremovingthepacking,checktomakesurethattheappliance
is not damaged. If in doubt, contact a qualified professional.
3.The dishwasher must only be used by adults for the washing of
household dishes and cooking utensils.
4.Fundamental rules to follow when using the appliance:
- Never touch the dishwasher when barefoot or with wet hands or
feet;
- We discourage the use of extension cords and multiple sockets;
-Duringinstallation,thepowersupplycordmustnotbeexcessively
or dangerously bent or flattened;
- If the appliance is not operating properly or maintenance must
be performed, disconnect the appliance from the power supply.
Close-up View (control panel)
5.Keep detergents out of the reach of children, who must also be
kept away from the dishwasher when it is open.
6.This appliance cannot be installed outdoors, not even if the areain
which it is installed is covered by a roof; it is also very dangerous to
leave it exposed to the rain and elements.
7.Do not touch the heating element during or after a wash cycle.
8.Donotleanorsitonthedoorwhen itisopen,asthis couldoverturn
the dishwasher.
9.Iftheappliancemalfunctions,turnoffwatersupplytotheappliance
and disconnect the plug from the wall socket. Then, consult the
section entitled, "Troubleshooting." If you cannot resolve the
problem, contact a service centre.
10.Appliances which are no longer being used must be made
inoperable by cutting the power supply cord and removing the door
lock.
A: ON-OFF button
C: Door handle
D: Cycle selection knob
H: Display
E: "Extra drying" button
F: "Half load" button
P: Delayed start select button
R: Start/Reset Button
IN
S
TL
G
H
G: "Extra drying" indicator light
H: Cycle phase indicator lights
L: Alphanumeric indicator
N: Half load indicator light
S: Low salt indicator light
T: Low rinse aid indicator light
I: Delayed start indicator light
To maintain the EFFICIENCY and SAFETY of this
appliance, we recommend:
lcall only the Service Centers authorized
by the manufacturer
lalways use original Spare Parts
C
A
D
PF
HR
E

3GB
Close-up View (Interior)
UpperRack
Top Sprayer Arm
Rack Height Adjustor
Lower Rack
Bottom Sprayer Arm
Salt Container Cap
Washing Filter
Detergent and Rinse Aid Dispenser
7HFKQLFDO FKDUDFWHULVWLFV
:LGWK FP
'HSWK FP
+HLJKW FP
&DSDFLW\ VWDQGDUGSODFHVHWWLQJV
0DLQVZDWHUSUHVVXUH SVLSVL.3D·03D·EDU
3RZHUYROWDJH 6HHGDWDSODWH
7RWDODEVRUEHUSRZHU 6HHGDWDSODWH
)XVH 6HHGDWDSODWH

4
GB
Salt ......
Salt
The hardness of the water varies from place to place. If
hard water is used in the dishwasher, deposits will form on
the dishes and utensils.
The appliance is equipped with a special softener that uses
a salt specifically designed to eliminate lime and minerals
from the water.
Loading the Salt into the Softener
Always use salt intended
foruse withdishwashers.
The salt container is
located beneath the
lowerrack and shouldbe
filled as follows:
1.Remove thelower rack
and then unscrew and
remove the cap from the
salt container;
2. If you are filling the
container for the first
time, fill it with water;
3. Place the end of the funnel (supplied) into the hole and
introduceabout 2 kg ofsalt. It is normal fora small amount
of water to come out of the salt container.
4. Carefully screw the cap back on.
The salt container should be filled up when the low
salt indicator light "S" flashes.
Once you have loaded the salt for the first time, it is normal
that the low salt indicator light stays on or flashes for about
5 consecutive cycles.
Warning: To prevent rust from forming, we advise you to
load the salt before starting a wash cycle.
Adjusting Salt Consumption
The dishwasher is designed to allow for adjusting the
amountofsalt consumedbased
on the harness of the water
used. This is intended to
optimize and customize the
levelofsalt consumptionsothat
it remains at a minimum.
Your Local Water Board can
supply the degree of hardness
of the water
in your area.
Toadjust salt consumption,pro-
ceed as follows:
1) Unscrew the cap from the salt container.
2) There is a ring on the container with an arrow on it (see
figure to the side), if necessary, rotate the ring in the anti-
clockwise direction from the "_" setting towards the "+"
sign, based on the hardness of the water being used.
It is recommended that adjustments be made in accord-
ance with the following schema:
Water Hardness
Clarke
degrees °fH mmol/l Selector
position
Salt
consu-
mption
(grams/-
cycle)
Autono-
my
(cycles\2-
kg)
0 - 14 0 - 17 0 -1,7 / 0 /
14 - 36 18 - 44 1,8 - 4,4 "-" 20 60
36 - 71 45 - 89 4,5 - 8,9 MED 40 40
>71 > 89 > 8,9 "+" 60 25

5GB
Detergent and Rinse Aid ....
Detergent
Detergent specifically intended for use with dishwashers
must be used. The dispenser must be refilled before the
startofeach washcyclefollowingthe instructionsprovided
in the "Wash Cycle Table." The detergent dispenser is
located on the inside panel of the door.
Loading the detergent
Toopen lid "A",pressbutton"B".Thecleaning detergent
should be introduced into the two containers "C"and
"D" up to the rim.
After pouring in the detergent, replace the lid, pressing
down until it clicks.
Dishwasher detergent in tablets is now available on the
market, in which case you should place one tablet into
container "D" and replace the lid.
Notice: To facilitate closing the cover, remove any
excess detergent on the edges of the dispenser.
Rinse Aid
This product makes dishes sparkle more as it improves their
drying. The rinse aid container is situated on the inside of
the appliance door; you should refill it when the low rinse
aid indicator light "T" flashes.
Loading the Rinse Aid
Toopen the dispenser, turn the"C" cap inthe anti-clockwise
direction and then pour in the rinse aid, making sure not to
overfill. The amount of rinse aid used for each cycle can be
regulatedby turning the"F" dose adjustor, locatedbeneath
the "C" cap, with a screwdriver. There are 6 different
settings; the normal dosage setting is 4.
Important:
Proper dosage of the rinse aid improves drying.
If drops of water remain on the dishes or spotting occurs,
the dosage adjustor should be turned to a higher setting. If
the dishes have white streaks, turn the dosage adjustor to
a lower setting.
BDC
A
F
C
Warning
Three-in-one dishwasher tablets are now available on the market, and combine detergent, salt and rinse aid all in one.
If the water in your area is hard or very hard, we still recommend you pour extra salt into the relevant dispenser to prevent the
formation of white streaks on your dishes or on the interior of the appliance.
Using a three-in-one product means it is no longer necessary to put rinse aid into the relevant container.
If you want to achieve perfectly dry dishes, you may add rinse aid as long as the dosage adjuster is set to no.2.
In any case, please read the manufacturer's instructions on the packet.
If you use only these products, it is normal for the salt and rinse aid indicator lights to flash permanently after a certain number
of cycles.
