Indesit G75C User manual

Tumble dryer
Instructions for installation and use
G75C

Contents
Safety Advice
Electrical Requirements
Features - Get to know the main parts of your Dryer
Where to put your Dryer
How to use your Dryer
The Controls
Sorting your laundry
Items not suitable for drying
Items requiring special attention
Emptying the Water Container
Guide to Drying Times
Caring for your Dryer
If something goes wrong
If it still won’t work
3 - 4
5
6
7
8
9
10
11
12
13
14
15
16
17
Retention of this Instruction Book
This Instruction Book must be kept handy for reference as it contains important
details on the safe and proper use of the appliance.
If you sell or pass the appliance to someone else, or move house and leave it
behind, make sure this Book is also provided so the new owner can become
familiar with the appliance and safety warnings.
Register your purchase now
Simply complete and return the Registration Form supplied with the appliance
documents.
2

3
For your safety
NEVER ● Allow children to play with or otherwise interfere with the dryer.
NEVER ● Allow the air inlet at the front of the dryer or the air outlet at the back
to be obstructed.
NEVER ● Switch the machine off leaving a hot load in the drum.
NEVER ● Tumble dry without the Filter, Water Container or Condenser in
position.
NEVER ● Exceed the maximum load capacity recommended or place
dripping wet items in the drum.
NEVER ● Allow lint to collect around the dryer.
NEVER ● Add liquid fabric conditioner to the dryer, use liquid conditioner in the
final rinse of your wash.
NEVER ●Use the dryer for commercial drying, the dryer is only suitable for
domestic use.
NEVER ●Dry Acrylics or synthetics on the high heat setting.
NEVER ● Tumble dry articles that have NOT been well washed in water and
detergent then well rinsed and spun.
NEVER ●Tumble dry articles that have had chemicals used for cleaning.
NEVER ●Dry articles that are contaminated with flammable substances such
as: petrol, oil, paint, hair lacquer, creams, cooking fat or oil.
NEVER ●Tumble dry: rubber, foam rubber, plastic, plastic foam, nappy pants
or liners, polythene or paper.
Large, very bulky items including duvets and sleeping bags.
NEVER ●Attempt to stand on top of your dryer, it is not designed for
such use and you could injure yourself or damage the dryer by such
abuse.
NEVER ●Switch electricity On or Off with wet hands.
IMPORTANT
Using your Tumble Dryer is easy.
Nevertheless, for your own safety and to get the best results it is important to know your
Dryer by reading right through this handbook before using your dryer for the first time.
A CHILD COULD CLIMB INTO OR TAMPER WITH AN UNATTENDED
TUMBLE DRYER.
WHEN THE MACHINE IS NOT IN USE SWITCH OFF, REMOVE THE PLUG AND
CLOSE THE DOOR.
IMPORTANT

4
For your safety
ALWAYS ●Empty the Water Container after EACH drying cycle.
ALWAYS ●Finish every programme with the cool tumble cycle provided on
the control.
ALWAYS ●Clean the filter, it is essential that the filter is kept clear of fluff
after EACH drying cycle.
ALWAYS ●Ensure Condenser is free of fluff, regular cleaning is recommended.
ALWAYS ●When the dryer is not in use, switch off, remove plug and close the
door.
ALWAYS ●Comply with the specified electrical requirements.
ALWAYS ●Ensure that your dryer is installed correctly and has adequate
ventilation. (see, "Where to put your dryer.")
ALWAYS ●Observe the rules for drying garments:
In particular woollen articles should not be dried in a
tumble dryer unless they are labelled ‘Superwash’,
‘Machine washable’ or have the ‘May be tumble dried’
symbol:
If in any doubt do not dry wool in the machine.
Unlike other materials, the mechanism of wool
shrinkage is irreversible, i.e. it will not stretch back to
the original size and shape.
ALWAYS ●Buy genuine accessories and spares.
CAUTION:
When the dryer is in use avoid touching the
rear of the dryer as it may be hot!

Electrical Requirements
Supply
Changing
the fuse
Moulded plug
Changing
the plug
Rewirable plug
Changing the
mains cable
WARNING:This appliance must be earthed!
REFER TO THE RATING PLATE FOR VOLTAGE AND CURRENT
REQUIREMENTS. (see diagram for location.)
The flexible mains lead is supplied fitted with a BS1363 plug and
with a 13 amp BS1362 fuse.
The plug should be connected to the mains supply via a suitable
switched socket which is accessible after installing your dryer.
If it is necessary to fit a replacement fuse, it must be a 13 amp
ASTA approved to BS1362 type.
If a replacement fuse holder/cover is required, it must be of the
same colour coding or wording as shown on the base of the plug.
Replacements are available from your Spares stockist.
The wires in the mains lead are coloured in accordance with the
following:
GREEN/YELLOW - EARTH
BLUE - NEUTRAL
BROWN - LIVE
If a replacement plug is to be fitted, the appropriate wire must be
connected to the correct terminal,as follows:
Connect:
Green/Yellow to terminal marked Earth or Green or
Blue to terminal marked Neutral or N or Black
Brown to terminal marked Live or L or Red.
If the plug being replaced is a non-rewirable type then the cut-off
plug must be disposed of safely. DO NOT leave where it can be
inserted into a socket and create a shock hazard.
Should the mains lead ever require replacing at any time please
contact your nearest Service Centre. A charge will be made for the
replacement of the mains lead or if you require a longer lead.
The mains lead must only be replaced by a specially prepared
cable obtainable from your Spares Stockist and fitted by a
qualified electrician.
WARNING:The plug must not be used without a fuse cover.
NOTE: IF IN DOUBT ABOUT ANY OF THE ABOVE CONSULT A
QUALIFIED ELECTRICIAN.
GREEN &
YELLOW TO
EARTH
13 AMP
FUSE
BROWN
TO LIVE
CORD
CLAMP
BLUE TO
NEUTRAL
5

6
Features - Get to know the main parts of your dryer
Push here to
open door
NOTE: If your
dryer is new wipe
out the inside of
the drum before
you first use it
to remove any
dust which may
have accumulated
during transit.
Water Container
(Empty after Each Load)
Air intake
grille
Plinth Moulding
(Not fitted to all models)
Serial & Model
numbers
Fluff filter
CLEAN AFTER
EACH LOAD
Door
catch
Rating Plate
Condenser
(Keep clear of fluff)
Clean periodically
Door latch
see "The Controls"

7
HINGE
HINGE
DOOR
LATCH
DOOR
CATCH
Your Tumble Dryer should NOT be located adjacent to a gas hob,
cooker, heater or eye level grill as flames from the burners could
cause damage to your machine.. When the dryer is fitted under a
work surface, allow space for air to exit the rear grille, a 15mm gap
each side of the dryer is recommended. This airflow is essential to
condense the water produced drying the washing, the dryer will not
operate efficiently in an enclosed space or cupboard.
If using your dryer in a small or cold room some condensation could
be experienced.
DO NOT use 2-way adaptors or extension leads.
The door of your Dryer is reversible and can easily be changed.
Exchange diagonally hinge brackets and blanking plugs. Exchange
door latch and catch with their opposite blanking plates. See diagram
above.
Door Reversal
Instructions
Where to put your dryer

8
How to use your dryer
1. Plug in, switch
on electricity. 2. Sort your laun- dry (see section
“Sorting Your
Laundry”)
3. Open the door
by pressing and
releasing the front
panel in the position
shown.
4. Always check
the following:
5. Load the dryer
placing the
clothes carefully in
the drum pushing
them well towards
the back and
away from the
door seal. Close
the door.
6. Select the rele-
vant heat setting
(see section “The
Controls”)
7. Select the
required programme
or drying time. (see
section “The
Controls”)
8. Press the START
switch to commence
the drying pro-
gramme.
9. When finished
open the door and
take out the laun-
dry. Clean and
replace the fluff fil-
ter, and empty the
water container.
10.Switch off elec-
tricity and remove
plug from socket.
WARNING: WHEN
SWITCHING ON
OR OFF, PLEASE
ENSURE THAT
YOUR HANDS
ARE DRY
WARNING: WHEN
SWITCHING ON
OR OFF, PLEASE
ENSURE THAT
YOUR HANDS
ARE DRY
FLUFF FILTER
is clean and in place
WATER CONTAINER
is empty and in place
CONDENSER
is clean and in place
The ‘Cool Tumble’
phase
About 10 minutes before the programme is completed, the heating
elements will be switched off and the programme enters the final
‘Cool Tumble’ phase. During this phase the fabric is cooled. You
should always allow the dryer to complete this phase.
By opening the door you can check the dryness of the load as often
as you wish and if you want to remove some items before they are
fully dry. (This is particularly useful for a mixed load where you want
to iron some items, but others are to be fully dried.) You will need
to press the start button after closing the door to re-start the
programme. See section ‘The Controls’.

9
The Controls
Heat Selection Switch
Start switch Empty water light
Timer
Control
The drying time for both heat settings is controlled by the timer. All you
have to do is turn the Timer Control clockwise until the required time
appears in line with the indicator.
NEVER WIND THE TIMER CONTROL ANTI-CLOCKWISE.
The “Guide to Drying Times” section will tell you how much time you’ll
need for various loads.
To select high heat (Cottons), the Heat Selection switch must be IN.
To select Low heat (Acrylics and Synthetics) the Heat Selection switch
must be OUT.
See section “Guide to Drying Times”.
Press and release the START button to commence a drying program
(The drying time must have been selected first).
This light will glow when the water container is full.
You should not wait for this light to glow before emptying the water
container, but empty it after each load (see section “Emptying the
Water Container”).
NOTE: When the light glows you must stop the dryer and empty the
water container.
If the water light glows during a drying cycle the timer will advance to
the Cool Tumble Phase without drying the load.
The light will take approximately 10 seconds to go out after replacing
the empty container.
Setting the timer
Selecting the
required Heat
Setting
Starting the Dryer
Empty Water
Light
NOTE: If the door is opened during a programme the
Dryer will automatically stop.
To continue the programme after closing the door, the
START button must be pressed.

10
Sorting your laundry
1. Always separate laundry into the correct fabric groups before
washing and drying.
2. See that all zips are closed, hooks and eyes are fastened and
belt, strings etc. are tied loosely in bows, you will normally have
done this for each item before the washing stage.
3. It is important to extract as much water as possible from each
item before drying. This saves you time and money.
4. Make sure that the items to be dried are suitable for tumble
drying, or are not of a type requiring ‘special attention’ (see“Wash
Care Labels” section).
Your dryer will hold a load of 6kg (13lb) dry weight of natural fabrics.
if you are drying items of man-made fibres (synthetic or acrylics), the
maximum load should not exceed 3kg (6.6lb) dry weight.
This difference is that man-made fibres require more space to tumble-
dry without creasing.
To help you estimate how many items it takes to make up a drying
load, the charts below show the approximate weights of some every-
day washing items.
If you group small cotton or terry-towelling items with a synthetic
fabric load they could be damp at the end of the drying cycle. If this
happens simply give them an additional short period of drying to
finish them off.
Maximum
load size
Typical load
WARNING: CLOTHES SHOULD NEVER BE LOADED
DRIPPING WET
WARNING: DO NOT OVERLOAD AS THIS COULD RESULT IN
REDUCED DRYING PERFORMANCE AND A POSSIBLE FIRE
HAZARD.
Clothes
Blouse Cotton 150g 5oz
Other 100g 31/2oz
Dress Cotton 500g 1lb 2oz
Other 350g 12oz
Jeans 700g 1lb 6oz
10 Nappies 1000g 2lb 3oz
Shirt Cotton 300g 101/2oz
Other 200g 7oz
T-Shirt 125g 41/2oz
Household Items
Duvet cover Cotton 1500g 3lb 5oz
(Double) Other 1000g 2lb 3oz
Large Tablecloth 700g 1lb 6oz
Small Tablecloth 250g 9oz
Tea Towel 100g 31/2oz
Bath Towel 700g 1lb 8oz
Hand Towel 350g 12oz
Double Sheet 500g 1lb 2oz
Single Sheet 350g 12oz

11
Wash Care Labels
Most of today’s fabrics can be tumble dried in your Dryer with no
trouble at all, but there are certain fabric finishes which should be
dried away from direct heat.
The majority of garments now have wash-care labels on them, giving
full washing and drying instructions. These should always be followed
carefully especially when you are drying something for the first time.
Typical symbols are:
May be tumble dried
Do not tumble dry
Or:
Tumble dry at high heat setting
Tumble dry at low heat setting
• Those containing foam rubber or rubber-like materials or plastic
film (e.g. pillows, cushions, PVC rainwear), or any other articles
which are inflammable or contain inflammable substances (e.g.
towels contaminated with hair lacquer
• Fibreglass (e.g. some types of curtains)
• Items which have been dry cleaned
• Woollens. Woollen items need as much care in drying as they do
in washing. The movement of the tumble-drying action causes the
woollen fibre to shrink and distort.
• Garments with the ITCL Code (see ‘Items Requiring Special
Attention’).
Do not tumble dry.
• Large bulky items e.g. continental quilts, sleeping bags, pillows,
cushions, double blankets and large bedspreads. These expand
when drying and would prevent airflow through the Dryer.
WARNING: THE DRYER IS INTENDED FOR USE ONLY
WHERE WATER SOLUTION IS USED FOR THE CLEANING
PROCESS. MISUSE OF A TUMBLE DRYER MAY CREATE A
FIRE HAZARD.
Items not suitable for tumble drying

12
Items requiring special attention
The drying requirements of blankets and bedspreads will, of course,
vary tremendously according to size and weight. Some, however are
simply too big. if you have difficulty getting them into the Dryer, the
machine will have difficulty drying them properly. Blankets (and
Garments) made from Acrylic fibres (e.g. Acilan, Courtelle, Orion and
Dralon) must be dried with special care on Low heat setting.
Overdrying should be avoided to ensure heat creasing does not
occur.
Your dryer will cope with such clothes very well, but you should
always read the manufacturer’s drying instructions attached to the
garment before you begin.
Starched articles should be dried together in the same load to avoid
the distribution of starch to non-starched items. You should use a
slightly heavier starch solution than you would when drying the items
on the washing line. Make sure that as much of the solution is
removed from the load as possible before placing it in the Dryer.
Remove the items from the dryer as soon as they reach ironing
dampness. If they are overdried the starch will powder, leaving the
fabric limp - which rather defeats the purpose of the exercise!
To make sure all your tumble dried clothes come out really fresh and
soft we recommend you use a liquid fabric conditioner in the final
rinse of your wash. A liquid fabric conditioner restores bounce and
softness and helps eliminate static cling.
Garments with the ITCL Code may be cleaned using one of the
Home Dry Cleaning Kits available.
The instructions supplied with the Home Dry Cleaning Kit must be
strictly followed.
Blankets and
Bedspreads
Permanently
pleated or creased
garments
Starched articles
Fabric conditioner
Home Dry
Cleaning
WARNING: ON NO ACCOUNT SHOULD LIQUID FABRIC
CONDITIONER BE ADDED TO THE DRYER ITSELF.

13
Emptying the Water Container
Remove plinth (where fitted) by slightly lifting and sliding to the left.
Pull the container out of the dryer and empty it into a sink or other
suitable drain).
Empty the water container after EVERY programme.
Failure to do this will result in the water container
becoming full and the load will not dry.
Water
Container
Plinth
Moulding
(not fitted to
all models)
Sink
Water
Container
To Empty Water
Container

14
Guide to drying times
Please note that the drying times stated below and on appliance
control panel; are a GUIDE only and drying times are affected by:-
Items such as towelling retain a lot of water after spinning, also the
suggested wash programme for small items such as T-Shirts may
sometimes incorporate a low spin speed which has the same effect.
Your drying load may contain the same type of fabric but of different
thicknesses. Thinner items will take less time to dry. Some fabrics,
such as those used for jeans are of closer texture than others and
although light when dry will be heavy after washing and spinning.
Single items of clothes or small loads may take disproportionally
longer to dry. It is more energy efficient to dry larger loads.
As it takes longer to fully dry clothes than to have them ready for
ironing, you may wish to remove some clothes when they are slightly
damp, ready for ironing and then continue to dry the remainder until
they are fully dry.
The label on the garment should tell you the correct heat setting to
select. See ‘Wash Care Labels’.
If the room in which the dryer is situated is cold, your clothes will take
longer to dry than if the room is warm.
Some bulky items such as padded jackets can be dried, with care, and
we do advise that you remove these items several times, shake them
and return them to the dryer.
THERE ARE HOWEVER SOME ITEMS THAT WE DO NOT ADVISE
YOU TO DRY. SEE ‘ITEMS NOT SUITABLE FOR TUMBLE DRYING’
All fabrics contain a little natural moisture even when ‘dry’ and this nat-
ural moisture should not be lost if the clothes are to remain soft and
fluffy.
Clothes that are dried for too long tend to wrinkle and will need more
ironing than usual, giving you extra work that the Dryer was designed
to remove.
The amount of
water remaining
in the clothes
after spinning
The type of
fabric
The quantity of
clothes to be
dried
How dry you
want the
clothes
The heat setting
you have
selected
The temperature
of the room
Bulky items
Be careful not
to overdry
Drying Guide -approximate drying time in minutes (weights specified are when dry)
COTTONS SYNTHETICS ACRYLICS
Drying times 800 - 1000rpm in
washing machine Drying times on reduced spin in washing machine Drying times on
reduced spin in
washing machine
1 kg
30 - 40
2 kg
40 - 55
Half
load
3 kg
55 - 70
4 kg
70 - 80
5 kg
80 - 90
Full
load
6 kg
95 - 120
1 kg
40 - 50
Half
load
2 kg
50 - 70
Full
load
3 kg
70 - 90
Half
load
1 kg
40 - 60
Full
load
2 kg
55 - 75

15
Caring for your Dryer
Your Tumble Dryer needs very little attention. The following simple
steps will keep it performing well.
Switch off electricity and remove plug. Ensure hands are dry.
Always clean the filter, by rinsing under the tap or using a vacuum
cleaner. Turn the dryer by hand to check that small items like hand-
kerchiefs do not get missed. Always empty the water container.
Wipe the drum and seal with a damp cloth.
Remove condenser unit and clean any build up of fluff from between
the plates by rinsing it under the tap with cold water. This should be
done with cold water from the rear of the condenser. Refit with the
handle at the front.
Every 6 months vacuum the front air intake grille and Vents at the rear
of the dryer, to remove the build up of fluff, lint or dust.
To remove accumulation of fluff from the door, front of condenser and
filter areas, clean occasionally with a vacuum cleaner.
Abrasive cleaners, scouring agents, acids, chlorine bleach or metal
polish to clean any part of the machine. These could damage the
machine.
Your tumble dryer uses special bearing components. Lubrication by
the user is not necessary and must not be attempted.
We strongly recommend that all appliances are regularly checked for
electrical and mechanical safety.
Fluff filter
Condenser
Front
Rear
Tap
When finished
After each load
Every Week
Every Month
Cleaning
Do not use
Lubrication

16
If something goes wrong
First, don’t panic! There may be nothing wrong at all. Look for your
problem below, then check the things we suggest. More often than
not, this will give you the answer to your problem, and you’ll be able to
carry on without having to telephone your Service Office.
If after this you still cannot get your machine to work, follow the advice
given on the next page.
Check these things first
1. Is the machine plugged in and switched on at the socket?
2. Is the timer control set to required time?
3. Is the door securely closed?
4. Has the start button been pressed hard enough? Try pressing
again.
5. Has the fuse blown? (Try plugging in another appliance to check)
6. Have you used an extension lead? Many are not suitable. Try
plugging the dryer directly into a socket to check.
1. Have you forgotten to clean the filter? It should be cleaned after
each load.
2. Does the water container need emptying? Is the Empty water
light glowing? The bottle should be emptied after every load.
3. Does the condenser need cleaning? It should be cleaned every
month.
4. Have you selected the correct Heat setting for the type of fabric
you are drying?
5. Have the air intake grille or rear vents of the Dryer been
obstructed?
6. Were the clothes ‘excessively wet’ when they were put in?
7. Was the correct time selected?
8. Have you overloaded the dryer?
Have you re-read this instruction book?
Problem
‘It won’t start’
‘It is taking a long
time to dry’
Any other
problem

17
If it still won’t work...
Spare parts
Disposal of your product
if something is still wrong with your machine after you’ve been
through the check-list on the previous page:
1. Switch off and unplug your machine from the mains.
2. Call your nearest Service Office or local importer
on the telephone number provided on the guarantee card.
When you contact us we will want to know the following:
1. Your name, address and postcode.
2. Your telephone number.
3. Clear and concise details of the fault.
4. The model number and the serial number of your dryer.
5. The date of purchase enter the date here.
...................................................................
Please make sure you have all these details ready when you call.
Please remember your new appliance is a complex piece of
equipment.
‘DIY” repairs or unqualified and untrained service people may put you
in danger, could damage the appliance, and might mean you lose
cover under the Parts Guarantee.
If you do experience a problem with the appliance don’t take risks,
call in our Service Engineer. Our Spare Parts are designed
exclusively to fit your appliance. Do not use them for any other
purpose as you may create a safety hazard.
To minimise the risk of injury to children please dispose of your
product safely. The door and lid should be removed and mains cable
cut off flush with the appliance ensuring that the mains plug can no
longer be plugged into a mains socket. The items must then be
disposed of safely.
This appliance conforms to the following EEC Directives.
Low Voltage Equipment
72/23/EEC
93/68/EEC
Electromagnetic Compatibility
89/336/EEC
92/31/EEC
93/68/EEC
Contact the Service Office (0870 6070805)

PRINTED BY SIMLEX .FOUR ASHES, WOLVERHAMPTON May 2003 Part number 0766200116-01
