Indesit WIDXL 126 S User manual

1
GB
English,1
Contents
Installation, 2-3-4-5
Unpacking and levelling
Electric and water connections
The first wash cycle
Technical details
Washer-dryer description, 6-7
Control panel
Leds
tarting and Programmes, 8
Briefly: how to start a programme
Programme table
Personalisations, 9
Setting the temperat re
Setting the drying cycle
F nctions
Detergents and laundry, 10
Detergent dispenser
Preparing yo r la ndry
Special items
Precautions and advice, 11
General safety
Disposal
Saving energy and respecting the environment
Care and maintenance, 12
C tting off the water or electricity s pply
Cleaning yo r appliance
Cleaning the detergent dispenser
Caring for yo r appliance door and dr m
Cleaning the p mp
Checking the water inlet hose
Troubleshooting, 13
ervice, 14
Before calling for Assistance
WA HER-DRYER
WIDXL 126
Instructions for use
GB
AR
,15
Downloaded From WashingMachine-Manual.com Manuals

2
GB
Installation
Keep this instr ction man al in a safe place for
f t re reference. Sho ld the appliance be sold,
transferred or moved, make s re the instr ction
man al accompanies the washer-dryer to inform the
new owner as to its operation and feat res.
Read these instr ctions caref lly: they contain vital
information on installation, se and safety.
Unpacking and levelling
Unpacking
1. Unpack the washer-dryer.
2. Check whether the washer-dryer has been
damaged d ring transport. If this is the case, do not
install it and contact yo r retailer.
3. Remove the fo r
protective screws and
the r bber b sh with the
respective spacer,
sit ated on the rear of
the appliance (see also
the installation leaflet).
NB:The plastic spacers
may fall down inside the
machine once the bolt
has been removed, and will not interfere with the
operation of the machine.
4. Seal the gaps sing the plastic pl gs provided.
5. Keep all the parts: yo will need them again if the
washing machine needs to be moved to another
location.
Packaging materials are not children's toys.
Levelling
Yo r machine may make a considerable amo nt of noise
if the two front feet have not been adj sted correctly.
1. Install the washer-dryer on a flat st rdy floor,
witho t resting it p against walls, f rnit re cabinets
or other.
2. If the floor is not
perfectly level, compen-
sate for any nevenness
by tightening or
loosening the adj stable
front feet (see figure);
the angle of inclination,
meas red according to
the worktop, m st not
exceed 2°.
Levelling yo r appliance correctly will provide it with
stability and avoid any vibrations, noise and shifting
d ring operation. If it is placed on a fitted or loose
carpet, adj st the feet in s ch a way as to allow
eno gh room for ventilation beneath the washer-dryer.
Electric and water connections
Connecting the water inlet hose
1. Insert seal A into the
end of the inlet hose
and screw the latter
onto a cold water tap
with a 3/4 gas threaded
mo th (see figure).
Before making the
connection, allow the
water to r n freely ntil
it is perfectly clear.
2. Connect the other end
of the water inlet hose to
the washer-dryer,
screwing it onto the
appliance's cold water
inlet, sit ated on the top
right-hand side on the
rear of the appliance
(see figure).
3. Make s re there are no kinks or bends in the hose.
The water press re at the tap m st be within the
val es indicated in the Technical details table
(on the next page).
If the water inlet hose is not long eno gh, contact
a specialist store or an a thorised serviceman.
Ens re that the s pply taps are allowing water
thro gh. Old taps may seize in the closed position
and th s prevent water reaching the machine.
A
Downloaded From WashingMachine-Manual.com Manuals

3
GB
Connecting the drain hose
Connect the drain hose,
witho t bending it, to a
draining d ct or a wall
drain sit ated between
65 and 100 cm from
the floor;
The drain hose may be
connected to an
nder-sink trap. Before
connecting the drain
hose from the machine
ens re that any blanks
or removable ends
have been taken off
the spigot.
If it is place over the
edge of a basin or sink
be s re the free end of
the hose sho ld not be
nderwater.
 We advise against the se of hose extensions; in
case of absol te need, the extension m st have the
same diameter as the original hose and m st not
exceed 150 cm in length.
Ens re that if the drain hose is p shed into a
standpipe, that the end does not go down more
than 15cms (6 inches). If the hose is p shed down
too far, this may ca se the machine to self -syphon
ie. contin o sly empty as it is filling.
Electric connection
Before pl gging the appliance into the mains
socket, make s re that:
 the socket is earthed and in compliance with the
applicable law;
 the socket is able to s stain the appliance's
maxim m power load indicated in the Technical
details table (see page 5);
 the s pply voltage is incl ded within the val es
indicated on the Technical details table
(see page 5);
 the socket is compatible with the washer-dryer's
pl g. If this is not the case, replace
the socket or the pl g.
Yo r appliance is now s pplied with a 13 amp f sed
pl g it can be pl gged into a 13 amp socket for
immediate se. Before sing the appliance please
read the instr ctions below.
WARNING - THIS APPLIANCE MUST BE EARTHED.
THE FOLLOWING OPERATIONS SHOULD BE
CARRIED OUT BY A QUALIFIED ELECTRICIAN.
Replacing the fuse:
When replacing a fa lty f se, a 13 amp ASTA
approved f se to BS 1362 sho ld always be sed,
and the f se cover re-fitted. If the f se cover is lost,
the pl g m st not be sed ntil a replacement is
obtained.
Replacement f se covers:
If a replacement f se cover is fitted, it m st be of
the correct colo r as indicated by the colo red
marking or the colo r that is embossed in words on
the base of the pl g. Replacements can be obtained
directly from yo r nearest Service Depot.
Removing the plug:
If yo r appliance has a non-rewireable mo lded pl g
and yo sho ld wish to re-ro te the mains cable
thro gh partitions, nits etc., please ens re that
either:
the pl g is replaced by a f sed 13 ampere re-
wearable pl g bearing the BSI mark of approval.
or:
the mains cable is wired directly into a 13 amp cable
o tlet, controlled by a switch, (in compliance with
BS 5733) which is accessible witho t moving the
appliance.
Disposing of the plug:
Ens re that before disposing of the pl g itself, yo
make the pins n sable so that it cannot be
accidentally inserted into a socket.
Instr ctions for connecting cable to an alternative pl g:
Important: the wires in the mains lead are colo red
in accordance with the following code:
Green & Yellow Earth
Blue Neutral
Brown Live
65 - 100 cm
Where it connects
to the waste water
pipe cut end off
spigot or remove the
blanking cap
Downloaded From WashingMachine-Manual.com Manuals

4
GB
GREEN &
YELLOW
BROWN
BLUE
13 ampere fuse
CROSS-BAR
CORD GRIP
As the colo rs of the wires in the lead may not
correspond with the colo red markings identifyng
the terminals in yo r pl g, proceed as follows:
Connect Green & Yellow wire to terminal marked E
or or colo red Green or Green & Yellow.
Connect Brown wire to terminal marked L or
colo red Red.
Connect Bl e wire to terminal marked N or colo red
Black.
If a 13 amp pl g (BS 1363) is sed it m st be fitted
with a
13 amp f se, either in the pl g or adaptor or at the
distrib tion board.
If yo are in any do bt the electrical s pply to yo r
machine, cons lt a q alified electrician before se.
How to connect an alternative pl g:
The wires in this mains lead are colo red in
accordance with the following code:
BLUE NEUTRAL (N)
BROWN LIVE (L)
GREEN & YELLOW EARTH (E)
Disposing of the appliance:
When disposing of the appliance please remove the
pl g by c tting the mains cable as close as possible
to the pl g body and dispose of it as described
above.
 The washing machine sho ld not be installed in an
o tdoor environment, not even when the area is
sheltered, beca se it may be very dangero s to
leave it exposed to rain and th nderstorms.
 When the washing machine is installed, the mains
socket m st be within easy reach.
 Do not se extensions or m ltiple sockets.
 The power s pply cable m st never be bent or
dangero sly compressed.
 The power s pply cable m st only be replaced by
an a thorised serviceman.
Warning! The company denies all liability if and when
these norms are not respected.
The first wash cycle
Once the appliance has been installed, and before
yo se it for the first time, r n a wash cycle with
detergent and no la ndry, setting the 90°C
programme witho t a pre-wash cycle.
Downloaded From WashingMachine-Manual.com Manuals

5
GB
Technical details
Model WIDXL 126
Dimensions
59.5 cm wide
85 cm high
53.5 cm deep
Capacity from 1 to 6 kg for the wash programme;
from 1 to 4 kg for the drying programme
Electric
connections
please refer to the technical data plate
fixed to the machine
Wat e r
connections
maxim m press re 1 MPa (10 bar)
minim m press re 0.05 MPa (0.5 bar)
dr m capacity 52 litres
pin speed p to 1200 rpm
Control
programmes
according to
EN 50229
directive
Wash: programme 2; temperat re 60°C;
r n with a load of 6 kg.
Drying: first drying cycle performed with
a 2 kg load and the DRYING knob on
the setting;
Second drying cycle performed with a 4
kg load and the DRYING knob on the
setting.
This appliance is compliant with the
following E ropean Comm nity
Directives:
- 89/336/CEE of 03/05/89
(Electromagnetic Compatibility) and
s bseq ent amendments
- 2002/96/CE
- 2006/95/CE (Low Voltage)
