Indoff IRD230AB20R User manual

IRD230AB20R/L
Indoff, Incorporated
11816 Lackland Rd
St. Louis, MO 63146
REFRIGERATOR: IRD230AB20R/L
ONE FULL YEAR WARRANTY
Indoff guarantees to the original purchaser that this appliance will be free from
defects in material and workmanship for a period of one year from the date of
purchase, when the refrigerator is operated and maintained according to the
instructions attached to or furnished with this product.
FIVE FULL YEAR WARRANTY ON HERMETIC COMPRESSOR UNIT
Indoff additionally guarantees, to the original purchaser only, the hermetic motor
(compressor) furnished as a part of this refrigerator for a period of
five (5) years from the date of purchase, when this refrigerator is operated and
maintained according to instructions attached to or furnished with this product.
During the above warranty periods, Indoff and its authorized dealers or its
representatives retain the option to repair or replace the product, free of charge,
if installation is within the fifty (50) states and the District of Columbia. If
installation is outside the fifty (50) states, the cost of installation is borne by the
purchaser, and Indoff's warranty obligations hereunder shall be limited to
furnishing all replacement parts and materials, freight prepaid, to the continental
United States port designated by the purchaser.
In an effort to properly administer its warranty policy, Indoff or its representatives
may require a proof-of-purchase document before authorizing service or repair
to the appliance under this warranty.
Warranty service information is available by simply contacting Indoff at the
following number 1-800-843-3714 or by contacting the dealer from whom you
purchased this product.
It shall be the responsibility of the purchaser to deliver any compact refrigerator
or freezer of less than 4.0 cu. ft. in capacity to the nearest authorized service
station, as designated by Indoff or its representatives, to obtain service under
this warranty.
Except as provided herein, Indoff makes no other warranties, expressed or
implied, including warranties of merchantability and fitness for a particular
purpose. This warranty gives you specific rights, and you may also
have other rights which vary from state to state.
MODEL # _______________________ SERIAL # ________________________
Indoff, Incorporated | 11816 Lackland Road | St. Louis, MO 63146

WARNING/SAFETY PRECAUTIONS
To avoid any risk ofpersonal injury, material damage orincorrect use of the appliance, be sure
to observe the following safety precautions. (After reading these owner’s instructions, please
keep them in a safe place for reference).
Remember to hand them over to any subsequent owner.
CAUTION
CAUTION
Do notplug several appliances into the same sockets.
• This could cause overheating and the risk of fire.
Keep the power plug away from the rear of the fridge.
• A damaged power plug may cause fire due to overheating.
Do notdirectly spray water insideoroutside the fridge .
• There is a risk of fire or electric shock.
Do notbend the power cord excessively orplace heavy articles on it.
• This constitutes a fire hazard. If the power cord is damaged, have it replaced immediately by the manufacturer,
its service agent or a similarly qualified person.
Do notinsert the power plug with wet hands.
• You may receive an electric shock.
Do notput a container filled with water on top of the appliance.
• If the water spills on to any electrical parts, it may lead to fire or electric shock.
Do not store volatile and flammable substances in the refrigerator.
• The storage of benzene, thinner, alcohol, ether, LP gas or other such substances may cause an explosion.
Do notdisassemble, repair or alter the appliance.
• It may cause fire or abnormal operations, which may lead to injury.
Pull the power plug out of the socket before replacing the interior light in the refrigerator.
• Otherwise, there is a risk of electric shock.
• Only the customer service Approved Repair Agent may change the power cord and carry out any other repairs.
Improper Installations and repairs may put the user at considerable risk.
Be sure to earth the appliance.
• Otherwise, it may cause material damage and electric shock.
If you wish to dispose of the fridge, throw it away after removing the doororits seals.
Keep ventilation openingsin the appliance enclosure orin the built-in structure, clear ofobstruction.
Do notuse mechanical devices orother means to accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING
WARNING
Indicates that a danger of death or serious injury exists
CAUTION
Indicates that risk of personal injury or material damage exists
Do not store too much food in the appliance.
•When you open the door, an item may fall out and cause personal injury or material damage.
If the wall socket isloose, do notinsert the power plug.
•It may cause electric shock or fire.
Do notdisconnect the power cord bypulling on it.
•You may disconnecta wire and cause a short circuit.
Do not store pharmaceutical products, scientific material orother temperature-sensitive
products in the refrigerator.
•Products that require strict temperature controls must not be stored in the refrigerator.
Do notlet a child hang from the door.
•It may cause injury or damage the appliance.
Remove any foreign matter from the power plug pins.
•Otherwise, there is a risk of fire.
Do notput yourhand into the bottom area of appliance.
•Any sharp edges may cause personal injury.
After unplugging the appliance, wait for at least five minutes before plugging it again to the
wall socket.
•It may cause abnormal operation.
If the appliance isnotbeused for a long period of time, pull out the power plug.
•
•
•
•
•
Any
R-600a or R-134a is used as a refrigerant. Check the compressor label or the rating label to see
which refrigerant is used for your refrigerator.
When this product contains flammable gas(R-600a), please be aware of followings;
- Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of
obstruction.
- Do not damage the refrigerant circuit．
And contact your local authorities in regard to the safe disposal of this product.
Ensure that none of the pipes on the back of the appliance are damaged prior to disposal.
Do not allow children to play with this appliance.
C-Pentane is used as an insulation blowing gas.
The flammable insulation blowing gases require special disposal procedure. Please contact your
local authorities in regard to the environmentally safe disposal of this product.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
deterioration in the insulation may cause fire.

1 Thermostat
2 Glass Shelf
3 Magnetic Gasket
4 Door Liner
5 Bottle Racks
6 Adjustable front feet
START
Testing
Clean the parts of the refrigerator with lukewarm water containing a little neutral
detergent and with clear water, and wipe them dry.
Notes: Electric parts of the refrigerator can only be wiped by dry cloth.
1. Remark: turn the thermostat knob to the "4" position, turn on electricity. The compressor begin to work..
2. Open the door 30 minutes later, if the temperature in the refrigerator decreased obviously, it
shows that the refrigerator system works well. When the refrigerator operates for a period of time,
the temperature controller will automatically set the temperature within limits it opens.
1.The temperature in the refrigerator compartment is controlled by
the temperature controller installed on the back wall of the
refrigerator compartment.
2.Turn the thermostat knob to right or left, you can regulate the
temperature inside the refrigerator.
3.The marks on the knob are the temperature grades, not the
exact number of the degrees of temperature.”OFF” shows a forced
STOP and “7” shows the lowest temperature. Turn the knob from
"1"position to "7"position, the temperature decreases continuously.
You may set the temperature control selector to any position
according to what you need.
4.Please set the selector to "4" position in normal use.

Cleaners: The cleaners noted below are available.
Never use harsh, abrasive cleaners, heavy-duty cleaners, or solvents on
any surface.
Exterior: Wipe with damp, sudsy cloth, rinse and dry.
For stubborn stains and for periodic waxing, use silicon wax.
Evaporator: When refrigerator needs defrosting turn thermostat dial to “OFF”.
Do not use sharp instruments.
Refrigeration Section: Wash shelves and other removable parts in warm sudsy
water, rinse and dry.
Wash interior with baking soda solution (3 table spoons to
one quart of water) or warm sudsy water, rinse and dry.
Magnetic Door Seals: Wash with warm sudsy water.
The Finishing Touch:
Replace all parts and return thermostat dial to desired setting.
• Install refrigerator in a convenient location away from extreme heat and
cold. Allow sufficient clearance between the refrigerator and side wall so
the door will open for a fully usable interior.
• Select a place with strong level floor.
• Allow 2 inches of space between the
refrigerator and the wall.
1. When out of operating for a long time:
Remove the power supply cord.
Dry your refrigerator opening the door for 2-3 days.
2. When you get ready to move:
Securely fasten removable interior parts (or move and package them
separately)
Do not lay your refrigerator horizontally, or compressor may be damaged.
When you need service: Before you call for service make
sure you need it, check a few things noted below for
yourself first.
If refrigerator is not operating:
Is the power supply cord unplugged?
Is home fuse blown or circuit breaker off?
If refrigerator is warmer than usual:
Has the door been open frequently or for a long period?
Is refrigerator overcrowded-preventing good air circulation?
Is the hot thing stored without cooling?
Is the clearance between refrigerator’s side and the wall allowed
sufficiently?
If there are unusual sounds:
Is refrigerator placed on the level?
Are foreign objects behind the refrigerator?
Are dishes on refrigerator shelves vibrating?
If so, rearrange the dishes.
rerutcafunam eht yb decalper eb tsum ti ,degamad si droc ylppus eht fI
a diova ot redro ni nosrep deifilauq similarly a ro tnega ecivres sti ro
.drazah
5 6
HOW TO CLEAN
WHAT TO DO...
HOW TO INSTALL
HOW TO LEVEL
UP DOWN
If the front of the appliance is slightly higher than the rear, the
door can be opened and closed more easily.
1. The appliance tilts up to the left.
Turn the left adjusting leg in the direction of the arrow until
the appliance is level.
2. The appliance tilts down to the right.
Turn the right adjusting leg in the direction of the arrow until
the appliance is level.

2.3 cu.ft
Product:39.7 lb / Packing:44.1 lb
18.50(W)×17.60(D)×25.04(H) in.
18.5
24.6
18.5
17.6
15.4
24.6
23.8
23.7
18.5
8.0
33.4 34.8
115°
