Indoff ABSOCOLD ARD104A User manual

Printed in MexicoIndoff, Incorporated
11816 Lackland Rd
St. Louis, Mo 63146
Part No. 8336460123600B
(PR1160AB - PR1960AB - PR1960AS)
COMMERCIAL HOTEL REFRIGERATOR MODELS: ARD104A / ARD204A
SUITE FRIDGE®
TWO FULL YEAR WARRANTY
Absocold guarantees to the original purchaser that this Commercial Hotel Refrigerator will be free from defects in material and
workmanship for a period of two (2) years from the date of purchase, when this refrigerator is operated and maintained according to
instructions attached to or furnished with this product. Any misuse or abuse of this product makes warranty null and void.
FIVE FULL YEAR WARRANTY ON
HERMETIC COMPRESSOR UNIT
Absocold additionally guarantees, to the original purchaser only, the hermetic motor (compressor) furnished as a part of this refrigerator
for a period of five (5) years from the date of purchase, when this refrigerator is operated and maintained according to instructions
attached to or furnished with this product.
During the above warranty periods, Absocold and its authorized dealers or its representatives retain the option to repair or replace the
product, free of charge, if installation is within the fifty (50) states and the District of Columbia. If installation is outside the fifty (50)
states, the cost of installation is borne by the purchaser, and Absocold’s warranty obligations hereunder shall be limited to furnishing all
replacement parts and materials, freight prepaid, to the continental United States port designated by the purchaser.
In an effort to properly administer its warranty policy, Absocold or its representatives may require a proof-of-purchase document before
authorizing service or repair to the appliance under this warranty.
Warranty service information is available by simply contacting Absocold at 1 [phone] or by contacting the dealer from whom you
purchased this product.
Except as provided herein, Absocold makes no other warranties, expressed or implied, including warranties of merchantability and
fitness for a particular purpose.
This warranty gives you specific rights, and you may also have other rights which vary from state to state.
USE AND CARE GUIDE
For parts or service information, call Absocold: [phone] or [phone].
Record in the space provided below the serial number and model number of this appliance.
They are located on the serial plate affixed to the backside of the refrigerator or inside the refrigerator affixed to the inner liner surface on
the right hand side.
Model # ____________________ Serial # ____________________
Underwriters’ Laboratories, Inc., Listed
Commercial Refrigerators
Refrigerated Storage Cabinets
IMPORTANT WARNING
An empty refrigerator is a very dangerous attraction to children. Remove the gasket, latches, lids or doors from unused appliances, or take some other
action that will guarantee the appliance harmless.
DANGER: Risk of child entrapment. Before you throw away your old refrigerator:
•Take off the doors.
•Leave the shelves in place so that children may not easily climb in.
READ THIS INFORMATION
It will tell you how to operate and care for your refrigerator.
It also offers tips on how to get the best as well as lowest cost performance.
UCG-ARD104A/204A-119

INSPECT
Inspect for shipping damage. If damaged or parts are missing, notify your
Absocold dealer at once.
INSTALLATION REQUIREMENTS
Remove all packing material and tape. Install on a level floor or well-
supported counter. Avoid any direct sunlight, heat source, or moisture.
This refrigerator is designed to be freestanding — that is, the appliance is to
be installed at least 2” from the wall and the cabinet bottom is at least ¾” to
1” above the floor or carpet, in order to let the air circulate freely around
the refrigerator.
ELECTRICAL REQUIREMENTS
115 volts, 60 Hz.
ELECTRICAL GROUNDING
(for 115-volt models only)
Must be grounded. Uses 110-115 volts, 60 Hz.
(60 cycles A.C.) Do not use extension cord. Use three-prong plug, with
three-prong grounded wall outlet.
Unless the above grounding method is followed, you are not protected
against severe or lethal shock, in the event of a short circuit of an electrical
component or wiring of refrigerator.
TO CONTROL TEMPERATURE
This function is not designed for guests, but only for hotel management.
Temperature control is adjustable through the 1/4" diameter hole in the
rear cover plate. With a Phillips screwdriver rotate counterclockwise for a
warmer setting, and clockwise for a colder setting. The refrigerator is
shipped at a medium setting for your convenience.
THINGS YOU OUGHT TO KNOW
WHEN THE QUICK CHILL ‘N SNOOZE ® REFRIGERATOR IS INSTALLED
ADVANCED FUNCTIONS*
Advanced functions that can provide
greater control over the refrigerator’s
operation:
SNOOZE® function
Turns compressor off for 8 hours.
1. Push the SNOOZE button once.
Red light appears when it is
activated.
2. The refrigerator will be off for 8 hours.
3. During this period, temperature of refrigerator will rise, but
once 8 hours have passed, it will start back up automatically.
4. To deactivate SNOOZE function, simply push SNOOZE
button again.
QUICK CHILL® function
Turns compressor on continuously for 2 hours.
1. Push the QUICK CHILL button once. A green light appears
when it is activated.
2. The refrigerator’s compressor will operate continually for 2
hours. After this period, the refrigerator will return to normal
operation. This function cools beverages faster than normal
operation.
3. To deactivate QUICK CHILL function, simply push
QUICK CHILL button again.
CAUTION
Should you unplug the refrigerator, allow at least three minutes before restarting in order to allow the start relay to function properly.
USE AND CARE INFORMATION
•TIPS ON EVERYDAY USE AND CARE
DEFROST : As far as temperature control is set at ordinary position, evaporator is automatically defrosted and no manual operation is
needed to defrost. Defrosted water is drained out to evaporating tray on the back of the refrigerator and is evaporated automatically.
FOR ALL CLEANING : Mix 2 tablespoons baking soda with 1 quart warm water, or use mild soap. No strong cleaners, scouring powder or
pads should be used.
•BEFORE CALLING FOR SERVICE
Check plug and fuse. Test outlet with lamp or other device. Check red SNOOZE light (located inside of refrigerator). If this light is on,
compressor is off for 8 hours. You can turn it on by pressing SNOOZE button one more time. When you call, refer the model number and
the problem to the Service Department at your nearest authorized Service Center or contact Absocold at [phone] or (765)
935-7501.
DANGER—ELECTRICAL SHOCK HAZARD. Disconnect power before servicing.
WARNING!
•This refrigerator should be connected directly to a grounded electrical wall outlet.
No extension cords, multi-connection bars, etc. should be used.
*Patent No.: US 7,634,918 B2
