infa-secure WG101 User manual

Stroller
Assembly Instructions
For model(s)
WG101, WG102
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE
USE. YOUR CHILD’S SAFETY MAY BE AFFECTED IF YOU DO NOT
FOLLOW THESE INSTRUCTIONS.
Service Phone: [phone]

Warnings
• This stroller is to be used for one child only.
• It is suitable for children from birth to approximately 36 months old
(up to a weight of no more than 17kg).
• Do not leave the harness buckled when not tted to a child in the
stroller because the harness can form loops which could be a
strangulation hazard.
• Regularly inspect, maintain and clean the stroller to ensure it stays
in good condition. Eg check that the harness straps are not frayed,
all buckle and locking devices work correctly, etc.
• Only use parts and accessories approved by the manufacturer.
• We do not recommend that this stroller is used on stairs or
escalators. If it is used on stairs or escalators then we recommend
that the child is removed and carried separately
• DO NOT use near an open re, exposed ame or excessive heat
source that may damage the stroller or injure the child.
• The brakes must always be applied when the stroller is not moving
or being used.
• This stroller is not suitable for running or jogging with.
• Ensure all locking devices are engaged correctly before use.
• Do not overload the basket (max 4.5kg)
• Do not allow your child to climb unassisted into or stand on the
stroller.
• This stroller is designed for use on at or gently sloping surfaces and
may be unstable or tip over on steep sloping and uneven surfaces.
• All folding mechanisms have a risk of nger traps. Please take care
not to leave ngers or parts of the body between moving parts
when folding and unfolding this stroller.
• Take care when carrying or lifting this stroller, do not carry it by the
fold release handle.
• When not in use, store in a safe place where it will not be damaged
by exposure to a wet/damp environment, excessive heat source,
etc. Also do not store heavy items on top of the stroller that may
damage it in any way.
WARNING

Warnings
A tether wrist strap is provided on the
handlebar. Slide your hand through the tether
wrist strap loop whenever you use the stroller.
Only remove your hand from the tehter strap
loop when the brakes have been applied to
the stroller wheels.
Use the tether wrist stap to prevent the stroller rolling away.
TO AVOID INJURY OR DEATH:
• ALWAYS APPLY THE BRAKES WHENEVER THE STROLLER IS
STATIONARY.
• DO NOT LEAVE CHILDREN UNATTENDED.
• SECURE THE CHILD IN THE HARNESS AT ALL TIMES.
• DO NOT CARRY EXTRA CHILDREN OR BAGS ON THIS
STROLLER.
• MAKE SURE CHILDREN ARE CLEAR OF ANY MOVING PARTS
IF YOU ADJUST THE STROLLER.
WARNING
WARNING
Do not use as a carry cot. Stroller can not be used in
positon below.
WARNING WARNING

Parts List 2
Carton Contents 3
Assembly
- Frame 4
- Wheels 4
- Seat Unit 5
- Hood 6
- Hood (Disassembly) 7
- Seat Attachment 7
- Handrail 7
- Harness 8
- Harness Detachment 8
Usage
- Seat to Sleeping Cot Conversion 9
- Handrail Function 10
- Harness 11
- Wheel Function 12
- Brakes 13
- Handlebar Function 13
- Seat Reclining Adjustment 14
- Reversible Seat 14
- Folding 15
Optional Accessories
- Rain Cover 17
- Mosquito Net 17
- Foot Cover 18
- Travel System 18
Care and Maintenance 19
Index
Drawings in this manual are for illustration purposes only;
actual product may vary. The manufacturer reserves the right to
change any specification or features without prior notice.

Parts List | 2
Parts List
(A) Adjustable Handle
Button
(B) Handle button
(C) Seat Height
Adjuster
(D) Handle Reversible
Adjustor
(E) Brake Controller
(F) Seat Supporting
Base
(G) 2nd Stroller
Folding Button
(H) Stroller-folding
Handle
(I) Rear Wheel
(J) Hood
(K) Front Handrail
(L) Front Handrail
Button
(M)Footrest Leg
(N) Front Wheel
Housing
(O) Front Wheel
Quick-Release
Button
(P) Front Wheel
Rotating Lever
(Q) Front Wheel
(R) Basket
(S) Stroller Strap
(T) Cot Adjuster Dial
(U) Cot Conversion Bar
G
J
F
HT
U
E
D
AB C
I
K
L
M
N
O
QRS
P

3 | Carton Contents
Carton Contents
Rear wheels x 2
Stroller Frame x 1
Front wheels x 2
Seat Unit x 1
Basket x 1 Foot Cover x 1* Mosquito Net x 1*
Optional Accessory
* supplied with some models
Rain Cover x 1*
Handrail x 1
Please check all parts are included in the carton; if there are any
missing parts, please contact the InfaSecure Service Department
on 02 4728 8090.

Assembly | 4
Assembly
Frame
12 3
4
Open the front legs in the direction of the arrow A. The frame is fully
opened when you hear a “click”. Lift up the handle as indicated B.
Wheels
1
4
2 3
A
B
A
B

5 | Assembly
Step 1. Assemble the front wheels then x the wheel axles into leg
housings as shown in 1and 2. It is xed when you hear a “click”.
Step 2. Assemble rear wheels and x the rear wheel axles into the rear
wheel housings as shown in 3and 4, it is xed when you hear a “click”.
Try to move and rotate all the wheels by hand to ensure all the
wheels are firmly fixed on wheel housing before use.
Seat Unit
12 3
Footrest Assembly
Step 1. Unfold the seat unit as indicated 1. Plug the footrest leg into the base
2. It is xed when you hear a “click” 3.
Seat Bottom Assembly
Fasten the hook-and-loop strips over the tube as shown 4, then
attach the harness anchors to the tube under the seat 5, 6. The seat
unit is now completely assembled.
45 6
1 2
3 4
1
2 3
4
5 6

Assembly | 6
Hood
457
12
E
D
C
Hood Assembly
Step 1. Connect the two zipper sections together.
Step 2. Pull zip to x hood onto seat unit.
Step 3. Insert hood frame into the opening of the hood and pull
through 5, ensuring the small bend on the frame near the attachment
point 6is angled away from the seat unit. Then attach the frame at
point Eto slot D, 7. 8. The hood is now securely assembled.
6
3
5
6
E D 7 8

7 | Assembly
Hood Disassembly
Step 1. Push on the plastic at point Ain the direction of the arrow to
unclip and detacth from slot B, 1 2.
Step 2. Pull on the hood connector 2and it will easily slide free.
Step 3. Unlatch the elastic band from the connector C, and detatch
the metal bar D; the canopy can now be completely removed 3.
1 2 3
A
C
B
D
Slot the seat’s connector to the attachment point on the frame until
you hear a “click” for both sides. The seat is now xed in the stroller
1,2.
Pull up on each side of the seat unit to ensure it is firmly fixed.
Press the buttons on both sides of the hand rail and pull to release 1,2.
Seat Attachment
Handrail
1
1
2
2
A
B1 2
2
C
D3
1 2
1 2

Assembly | 8
3
1 2
A
A A
AB
Back Support
Harness
4
A
1 2
4
3

9 | Usage
1
1
2
2
3
3 4
Seat-To-Sleeping Cot Conversion (method 1)
Press the adjust button A, then adjust the seat into the horizontal
position 12. Unlock the belt buckles B& C, 3.The seat is now in
the bassinet mode 4.
4
Usage
Seat-To-Sleeping Cot Conversion (method 2)
Press the button on Cot Adjustment Dial Ato release 2, then adjust
the seat into the horizontal position 3. Squeeze the two bars together
4to release footrest.
Ensure the Cot Adjustment Dial is fully turned before Cot
conversion.
A
A
B
B
C
C
A2
3
4
A
1 2 B C 3
4

Usage | 10
5 6
the footrest will drop 5. The seat is now in the bassinet mode 6.
To ensure your baby’s safety, we recommend that you keep the
bassinet faced towards you when in use.
5 6
Handrail Function
1 2
A
Easy Access
Press one of the handrail buttons Ato release it and ip the handrail
out to one side 2. This will allow easy access to the seat.
Press the button Aon the opposite side and the handrail can either
be removed or will swivel down out of the way for easy access.
A
2
A
DO NOT USE THIS BASSINET ONCE THE CHILD CAN SIT UP
UNAIDED. Maximum weight of child; 9kgs. For use with models:
WG101 & WG102.
DO NOT USE THIS SEAT WITH ANY OTHER MODELS OF PRAMS/
STROLLER. Maximum weight of child; 17kgs. For use with models:
WG101 & WG102.
WARNING

11 | Usage
4
Attaching the Buckles
Attach the buckles onto the shoulder straps 1, then onto the buckles
of the waist straps ( Ato Band Cto D) then attach these to the
central buckle Euntil you hear a “click” 2.
Releasing the Buckles
Press down on the central button to release the straps.
Adjusting the Harness
Adjust the shoulder and waist straps for a rm and comfortable t by
using the adjuster 3.
The height of the shoulder straps are adjustable to two positions 4
. The lowest position Fis for under 6 months, and position Gis for
between 6 months and 36 months. Adjust the height by pulling the
buckles out of the seat and attaching them to the other position.
Always use the safety harness when the child is in the stroller.
G
F
1
A B C D
E2
3
4
F G
Harness
1 2 3
AE
B D
C
BD

Usage | 12
Wheel Function
1 2
2
3
A
Front Wheel Lock
Pull the front wheel locking lever upward 1until you hear a “click”.
Front Wheel Removal
Press down the front wheel quick-release button and the wheel will
release 2,3.
Rear Wheels Removal
Press the quick release button A, then pull out the wheels.
1
2 3
A

13 | Usage
Brakes
1
A
B
Apply the Rear Wheel Brake
Pull up on the red brake lever Ato apply the brakes.
Release the Rear Wheel Brake
Press down the second lock Bto release the brakes.
Handle Bar Function
1 32
A
B
A
Reversing The Handle
Pull up on the two reversing levers Awhile pushing the handle bar to
the opposite side. Listen for a “click” as the handle bar securely locks
into place.
Height Adjustment
Press the one-handed button on the handle bar Band pull up or
push down on the handle bar to quickly adjust its height. The handle
will click into the height slots.
A
B
A
B

Usage | 14
Seat Reclining Adjustment
Reversible Seat
1
1 2 3
Press the recline adjustment button Aand push down or pull up on
the seat to adjust to the desired position 1.
Ensure that the seat has locked into position correctly before
putting your child into the seat.
Simultaneously press the safety release buttons Aon either sides
of the seat to lift it off the frame. Attach it again to the frame in the
desired direction 1,3.
Ensure that the seat is securely attached by lifting it up and
ensuring it does not come loose.
A
A
A
1 3
A
1

15 | Usage
2
Folding The Stroller
Folding The Handle
Press the height adjustment button on the handle to lower the handle
to lowest position 1, then pull up on both the handle reversing
adjusters to fold down the handle 2.
Removing The Seat
Simultaneously press the safety release button Aon both sides of
seat unit and lift up the seat 3.
1 3
A
54
7
6
BC
Fold the Frame
Simultaneously slide the stroller folding safety lock B, 4and pull the
stroller folding handle Cup 5. Then push down on the center of the
basket 6and the frame will fold inwards 7.
B4
C5
6 7
1
2
A
3

Usage | 16
Folding The Stroller (Cont.)
Using the Storage Strap
With the stroller folded, detach the storage strap from the hook-and-
loop on the side of the basket 8. Undo the the strap’s fastener and
loop it around the nearest leg and handle 9. Fasten the strap and
ensure it is secure 10 .
When unfolding the stroller, ensure that the storage strap is secured
to the hook-and-loop in the basket so it does not get damaged.
8109
8
9
10

17 | Optional Accessories
Optional Accessories
1
1
Using the Rain Cover
Simply place the Rain Cover over the Seat Unit, ensuring it
comfortably and securely protects the child 1.
Using the Mosquito Net
Simply place the Mosquito Net over the open portion, ensuring it
comfortably and securely protects the child 1.
Rain Cover (supplied with some models)
Mosquito Net (supplied with some models)
1
1
