Infinite Play Z6001 User manual

Z6001!
Installation and operation manual!

2
EN!
INFINITE PLAY!
DESCRIPTION:!
Main power supply for INFINITEPLAY audio and video door entry systems.!
!
START-UP TIME OF 2 MINUTES TO WAIT FOR ENTRANCE PANEL
SOUND!
With internet service in the home, you can establish a connection between
power supply (P5) and router to see services such as weather, news,
directly from videophone.!
Recommended the use of these cables, while respecting the CEI 64/8 for
video door entry systems.!
UTP CAT 5e for domestic routes dedicated to video door phone system !
FTP CAT 5e shared routes with tension cables!
UTP CAT 5e for outside with protective sheath in PVC!
All cables LSZH for Low Smoke Zero Halogen!
First to programming read the instructions carefully to get the full picture
on the features, functions and performance.!
!
!
!
!
!
!
!
!
POWER SUPPLY INSTALLATION ART. Z6001 - Z6002!
Mounting:!
This device can be mounted on DIN rail cabinets equipped (12 DIN space
modules)!
Connect the power supply with a bipolar switch breaker!
Terminal:!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
TECHNICAL CHARACTERISTICS: !
Polymer housing ABS V0!
Supply Voltage 90V - 260V the AC 50-60 Hz!
Operating temperature 0 °C to +45 °C!
Size 208x89x60 mm.!

3
EN!
INFINITE PLAY!
RJ45 PORTS DESCRIPTION FOR VIDEO DOOR ENTRY SYSTEM
CONNECTION!
!
!
MAIN POWER SUPPLY ART. Z6001!
Power supply unit PoE for villa or building video door entry system !
RJ45 ports:!
P1-P2-P3-P4 Dedicated to connecting ENTRANCE PANEL or VIDEO
DOOR PHONE!
P5 is dedicated to connecting of ROUTER for INTERNET!
!
MAIN POWER SUPPLY ART. Z6002!
Power supply unit PoE for four family video door entry system !
RJ45 ports:!
P1-P2-P3-P4-P5 Dedicated to connecting ENTRANCE PANEL or VIDEO
DOOR PHONE!
!
!
!
!
!
DISTRIBUTOR ON LANDING ART. Z60DV!
Need to distribute of VIDEO DOOR PHONE !
RJ45 ports:!
P1-P2-P3-P4-P5 Dedicated to the connection of VIDEO DOOR PHONE!
!
DISTRIBUTOR ART. Z60DT!
Need to distribute of ENTRANCE PANEL or CONCIERGE STATION !
RJ45 ports:!
P1-P2-P3-P4-P5 Dedicated to the connection of a ENTRANCE PANEL or
CONCIERGE STATION!
!
!
!
!
!
!
FIREWALL ART. Z600F!
If you need to connect to the internet in one of the houses is necessary to
insert an internal distributor 4 outputs FIREWALL Art.Z600F (attached
diagram)!
!
RJ45 ports:!
P1-P2-P3-P4 Dedicated to the connection of ENTRANCE PANEL, VIDEO
DOOR PHONE and ROUTER for INTERNET!
P5 Input connection to backbone!
Z6001!
Z6002!
P5
P4
P3
P2
P1
P5
P4
P3
P2
P1
Z60DV!
Z60DT!
P5
P4
P3
P2
P1
Z600F!

4
EN!
INFINITE PLAY!
!
MATERIAL NEEDED:!
1 skein of CAT5 Ethernet cable!
Connectors RJ45 plug!
1 scissor!
1 crimping tool 8-pin!
Recommended a tester for checking LAN cables!
!
MAKE A STRAIGHT CABLE!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
PROCEDURE:!
1) SKINNING CABLE (25-30 mm)!
!
2) ORDER cable as shown and line-up , cutting the connectors with
scissors at the same height (about 10mm)!
"!
3) INSERT THE CABLE IN CONNECTOR RJ45 as shown in figure!
!
4) CRIMPING WIRE with clamp!
!
5) FINAL CHECK OPERATION with tester!
Altezza
10mm
!"#$ %&'($)&*&+$,-./0$
1" White"orange"
2" Orange"
3" White"green"
4" Blue"
5" White"blue"
6" Green"
7" White"brown"
8" Brown"

5
EN!
INFINITE PLAY!
!
SYSTEM PROGRAMMING!
!
There are two types of configurations:!
1) Using an internal video door when you first start is recommended for
small building!
!
2) For systems of higher dimensions can be a system configuration from a
PC by software!
!
To be connected PC to any RJ45 port of InfinitePlay system by patch
cords.!
"!
INSTALLER SETUP:!
!
KEY PASSWORD: 000000!
!
Setup by video door phone !
!
VIDEO DOOR PHONE ID:!
!
Building 01!
Floor 103!
Apartment 050!
Internal device 04!
!
PHASES OF CONFIGURATION:!
The configuration steps of the system are divided into only 5 points!
!
1. BASIC SETTINGS!
2. ENTRANCE PANEL!
3. POWER SUPPLY!
4. VIDEO DOOR PHONE!
5. MAPPING ENTRANCE PANEL!
!
1. BASIC SETTINGS!
To be programmed the basic parameters for system!
!
CONCIERGE ( yes / no )!
SOS PANIC BUTTON ( yes / no )!
VISIBILITY SYSTEM( all video intercom device/ only master video intercom
device )!
SYSTEM SETTING TIME !
!
2. ENTRANCE PANEL!
To be programmed all parameters of entrance panel in the system!
!
IDENTIFICATION NUMBER = 1C52040001 – 1C5204NNNN!
!
CUSTOM ID: from 1 to 200 !
!
NAME ENTRACE PANEL: Via Ferrero!
!
ANSWER TIME (1 to 255 s) !
Default value 30 s!
!
CONVERSATION TIME (1 to 255 s) !
Default value 120 s!
!
SELF-START TIME(1 to 255 s) !
Default value 30 s!
!
AUDIO INDOOR-OUTDOOR (0% to 100%) !
Default value 50%!
!
ENTRANCE PANEL RINGTONE REPETITION ( yes / no )!
!
!
!
SAVE SETTINGS BEFORE YOU GET OUT OF SETUP!
BACK SAVE

6
EN!
INFINITE PLAY!
!
3. ALIMENTATORE!
A video door phone system can contain several distributors Z60DT!
!
IDENTIFICATION NUMBER = 0000000000!
!
DEVICE NAME: es: Main elettrical panel ground floor!
!
OUTPUT!
!
FUNCTION:!
To be assign one of the following functions that appear in the video
intercom. If you have an “X” the function is disabled.!
!
TIMEOUT:!
The time of OUTPUT can be programmed!
!
TIME LOCK: ( from 1 to 30s ) default value 1s!
TIME AUX1: ( from 1 to 30s ) default value 1s!
TIME AUX2: ( from 1 to 30s ) default value 1s!
TIME AUX3: ( from 1 to 30s ) default value 1s!
!
ENTRANCE PANEL:!
Through ”entrance panel" binds the selected function to one or more
entrance panel present in the system.!
!
To a call from entrance panel will be displayed one priority function.!
!
LINK:!
This parameter enables indirect opening of the lock, at the same time as
the opening of the lock of another entrance panel, at the command of an
interphone/monitor interphone. Indirect opening can be associated with
different entrance panels. !
!
For example: LOCK type Z6001 (1) with LOCK type Z6001 (2).!
!
When you press lock push button, will operate both entrance panel at
same time by their respective power supplies.!
!
INPUTS!
Module type Z6001 receives the command from four N/O push button
and when closing, they send the messages to output.!
!
INPUT CALL allows you to make a call from an entrance panel to an
indoor video door phone.!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
SAVE SETTINGS BEFORE YOU GET OUT OF SETUP!

7
EN!
INFINITE PLAY!
!
4. VIDEO DOOR PHONE!
At the first installation is requested the physical position of the device:!
!
PROGRAMMING ID IDENTIFICATION CODE!
!
Building 01!
Floor 103!
Apartment 050!
Internal device 04!
!
In these kit ZK171 - ZK172 - ZK174 the monitor ID CODE : !
01 000 001 00!
!
USER NAME:!
!
The name will appear in the display entrance panel Art.Z100D!
!
VISIBILITY ENTRANCE PANEL:!
!
You can select the list of entrance panels that can call this device.!
Default all entrance panels call everyone users!
!
FILTER FUNCTIONS AVAILABLE:!
!
At the request of a user, you can disable an auxiliary function that is also
used by other residents!
!
VISIBILITY:!
!
GROUPS INTERNAL INTERCOM CALLS!
Select the list of all internal devices apartment that you can call!
!
GROUPS EXTERNAL INTERCOM CALLS!
Select the list of the internal intercom of the building that you can call!
!
!
AUTOMATIC OPENING LOCK:!
!
AUTO LOCK (YES / NO)!
when a call comes in the monitor sends the command lock (doctor
function)!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
SAVE SETTINGS BEFORE YOU GET OUT OF SETUP!

8
EN!
INFINITE PLAY!
!
5. MAPPING ENTRANCE PANEL !
!
ENTRANCE PANEL SET UP!
Select the entrance panel to set their parameters ( touch push button or
display)!
!
PANEL RINGTONE REPEAT (sound 1 or sound 2)!
!
VOLUME ENTRANCE PANEL (from 0% to 100%)!
Default value 50%!
!
CALL BUTTON!
It is possible to combine the touch push buttons to a internal device!
For example:!
button 1 call device 01 000 001 00!
!
In case of entrance panel with display Art Z100D you can set up:!
!
PROPERTY LOGO (JPG format)!
!
STATUS MESSAGES!
-YES the entrance panel show messages!
(Calling, in conversation, door lock, end the conversation)!
-NO!
!
BUILDING NAME!
!
WELCOME MESSAGE!
!
ALTERNATION MESSAGE!
!
TIME ALTERNATION!
Settable in seconds!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
SAVE SETTINGS BEFORE YOU GET OUT OF SETUP!

9
EN!
INFINITE PLAY!
OPERANTING ISTRUCTIONS!
!
1. FUNCTION BAR ( BUTTONS ON THE RIGHT) !
HOME !
RETURN !
SETUP!
SEARCH!
!
2. VIDEO DOOR PHONE WIDGET!
LOCK !
LIGHT STAIR!
GATE !
!
3. DATA AND TIME!
4. METEO (with internet connection)!
5. VIDEO DOOR PHONE FUNCTION!
Available to the call (green symbol)!
Do not disturbe (red symbol, choose how long)!
!
!
!
ANSWERING A CALL!
!
1. VIDEO DOOR PHONE FUNCTION!
2. TO END THE CALL!
3. MUTE MICROPHONE!
4. TO ANSWERING A CALL!
!
!
!
!
!
!
!
!
!
!
IPCALL VIDEO DOOR PHONE APP!
!
1. VIDEO DOOR PHONE FUNCTION!
2. CONCIERCE LIST!
INTERCOM CONTACT LIST!
ENTRANCE PANEL LIST!
LOG ACTIVITIES!
3. SETUP / AUDIO SETTINGS!
!
!
!
!
!
!
!
MESSAGING!
!
TO SEND TEXT MESSAGES AND FILES ( JPG – PDF ) FROM MONITOR
TO CONCIERCE AND FROM CONCIERGE TO MONITOR!
!
THE COMMUNICATION IS ABLE BETWEEN INTERNAL MONITOR AND
CONCIERCE!
1
2
3
5
4
1
2
3
4
1
2 3

10
EN!
INFINITE PLAY!
OPERATION:!
!
Important: For the monitor operation, the ID must have already been pro-
grammed. To check this, in all devices!
!
Operating times!
The answer and the conversation times depend on the configuration of the
corresponding entrance panel parameters. !
!
- Answer time (for entrance panel call): Default value 30 s!
- Answer time (for intercommunicating call): 30 s!
- Conversation time (for entrance panel call): Default value 120 s!
- Self-activation time (for entrance panel call): Default value 10s!
!
Answering a call!
A call from the outdoor entrance panel or from an intercommunicating
device can be answered during the chime cycle or once it has ended. To
answer, press green push button; to end the call, press red push button.!
!
Receiving a door call!
The monitor can receive calls from a door call button if connected to
terminals M and FP directly When the door call button is pressed, the
monitor emits a different tone to the one used for outdoor entrance panel
calls or intercommunicating calls.!
!
Making an intercommunicating call!
To make a call to another indoor unit, is neccessary to open the videodoor
phone app and choose the name to the contacts list.!
!
Muting the ringtone during a call (Mute function)!
When receiving a call from an outdoor entrance panel or from an intercom
device, the call ringtone can be muted by pressing button MUTE in home
page widget. You can set the mute time ( for example 30 minutes )!
!
Door lock command!
If you press the lock button by home page widget to send a lock opening
command to the entrance panel. The lock is connect to the power supply
for security !
!
Self-start!
The videodoor phone is able to recognize the entrance panel or CCTV
cameras.!
From the entrance list you can make a self-start function for monitoring
and conversation.!
!
Calling a concierge station!
Form the concierge list you can call the concierce service ( lobby,
managment office, guard office)!
!
Alarm and Panic buttons!
The monitor can sand two alarms to Concierce station!
Connecting a button dirctly to terminals M and AL, you can sand an alarm
( gas detector, smoke detector ) to concierge!
If connecting a button dirctly to terminals M and P, you can sand an panic
alarm to concierge . This function is able from widget SOS!
!
Choice a ringtone!
Through the settings you can choose between different electronic
ringtone.!
!
Ringtone volume adjustment!
Through the settings you can choose between different volume levels plus
mute.!

11
EN!
INFINITE PLAY!
SINGLE RESIDENCE SYSTEM WITH 7” VIDEO DOOR PHONE AND ONE AUDIO-VIDEO ENTRANCE PANEL!
P1
Mains
90-260Vac
50-60Hz
Entrance panel
L
P3 P4 P5
HOME INTERNET
CAT5
CAT5
CAT5
IN2 – Stair light
IN3 – Driveway gate
IN3IN2
1
2
P
CH1
FP
RJ45
Panic Button
Alarm INPUT
GND
Outdoor call button
S+
AUX1 AUX2
12Vcc 1A Lock
AUX1- Stair light
AUX2 – Driveway gate
Power Supply
Z6001
Terminals Up to 100mt
1,2,3,4,5 RJ45
Cable CAT 5
Lock 1,5 mm2
Other 1 mm2
Conductor section
RJ45
IN4 – free
IN1–Lock release
IN1
P2
Entrance panel Video door phone
AUX3
AUX3 - free
PORTE RJ45
AL
GND
N
GND GND
GND – INPUT
GND – INPUT
S-
Lock return
COM
1
COM
2
COM
3
USB
IN4
PW-
PW+
Power +12V
Relè additional chime
CH2
USB
M
Relè additional chime
Power -
Video door phone
Entrance panel Video door phone

12
EN!
INFINITE PLAY!
P1
Entrance panel
Video door phone 1
L
P3 P4 P5
Internet of building
CAT5
CAT5
CAT5
IN3IN2
1
S+
AUX1 AUX2
12Vcc 1A Lock
Power Supply
Z6001
RJ45
IN1
P2
AUX3
PORTE RJ45
GND
N
GND GND
S-
Lock return
COM
1
COM
2
COM
3
USB
IN4
Video door phone 2
DOUBLE RESIDENCE SYSTEM WITH 7” VIDEO DOOR PHONE AND ONE AUDIO-VIDEO ENTRANCE PANEL!
Entrance panel Video door phone
2
P
CH1
FP
RJ45
AL
PW-
PW+
CH2
USB
M
2
P
CH1
FP
RJ45
Panic Button
Alarm INPUT
GND
Outdoor call button
AL
PW-
PW+
Power +12V
Relè additional chime
CH2
USB
M
Relè additional chime
Power -
Panic Button
Alarm INPUT
GND
Outdoor call button
Power +12V
Relè additional chime
Relè additional chime
Power -
Mains
90-260Vac
50-60Hz
Terminals Up to 100mt
1,2,3,4,5 RJ45
Cable CAT 5
Lock 1,5 mm2
Other 1 mm2
Conductor section
IN2 – Stair light
IN3 – Driveway gate
AUX1- Stair light
AUX2 – Driveway gate
IN4 – free
IN1–Lock release
AUX3 - free
GND – INPUT
GND – INPUT

13
EN!
INFINITE PLAY!
Entrance panel
Video door phone 1
CAT5
CAT5
CAT5
RJ45
Video door phone 2
with internet connection
DOUBLE RESIDENCE SYSTEM WITH 1 VIDEO DOOR PHONE, 2 VIDEO DOOR PHONES WITH INTERNET CONNECTION AND ONE AUDIO-VIDEO
ENTRANCE PANEL WITH TWO PUSH BUTTONS!
HOME INTERNET
12Vcc 1A Lock
1
2
P
CH1
FP
AL
PW-
PW+
CH2
USB
M
2
P
CH1
FP
AL
PW-
PW+
CH2
USB
M
FIREWALL Distributor
Z600F
Power Supply
Z6001
Terminals Up to 100mt
1,2,3,4,5 RJ45
Cable CAT 5
Lock 1,5 mm2
Other 1 mm2
Conductor section
Internet of building

14
EN!
INFINITE PLAY!
Entrance panel
CAT5
CAT5
RJ45
MULTIPLE RESIDENCE SYSTEM WITH ONE AUDIO-VIDEO ENTRANCE PANEL, POWER SUPPLY, DISTRIBUTOR AND 12 VIDEO DOOR PHONES !
12Vcc 1A Lock
CAT5
CAT5
Video door phone
1
2
P
CH1
FP
AL
PW-
PW+
CH2
USB
M
2
P
CH1
FP
AL
PW-
PW+
CH2
USB
M
Video door phone
Video door phone
Distributor Z60DV
Distributor Z60DVDistributor Z60DV
Power Supply
Z6001
Video door phone
Internet of building
Terminals Up to 100mt
1,2,3,4,5 RJ45
Cable CAT 5
Lock 1,5 mm2
Other 1 mm2
Conductor section

15
EN!
INFINITE PLAY!
CAT5
CAT5
BUILDING COMPLEX SYSTEM WITH TWO AUDIO-VIDEO ENTRANCE PANELS, POWER SUPPLY, CONCIERGE STATION AND DISTRIBUTOR!
CAT5
Video door phone
12Vcc 1A Lock
CONCIERGE
INTERNET
of building
Entrance panel
12Vcc 1A Lock
1
1
2
P
CH1
FP
AL
PW-
PW+
CH2
USB
M
Video door phone
Distributor Z60DVDistributor Z60DV
Power Supply
Z6001
Distributor Z60DT
Terminals Up to 100mt
1,2,3,4,5 RJ45
Cable CAT 5
Lock 1,5 mm2
Other 1 mm2
Conductor section

16
EN!
INFINITE PLAY!
CONNECTION VARIANTS:!
!
!
WIRING DIAGRAM ADDITIONAL ELECTRONIC CHIME!
WIRING DIAGRAM DOOR CALL BUTTON !
Additional chime C.A.
Power supply
230Vac
Relè
Additional chime C.C.
Power supply
12 - 24Vdc
Video door phone
=
Video door phone
Contact – Push button - Sensor
2
P
CH1
FP
RJ45
AL
PW-
PW+
CH2
USB
M
2
P
CH1
FP
RJ45
AL
PW-
PW+
CH2
USB
M
2
P
CH1
FP
RJ45
AL
PW-
PW+
CH2
USB
M
ALLARM INPUT to concierge
Power supply
12 Vdc
Video door phone
Panic Button
Alarm INPUT
GND
Outdoor call button
Power +12V
Relè additional chime
Relè additional chime
Power -
Panic Button
Alarm INPUT
GND
Outdoor call button
Power +12V
Relè additional chime
Relè additional chime
Power -
Panic Button
Alarm INPUT
GND
Outdoor call button
Power +12V
Relè additional chime
Relè additional chime
Power -

17
EN!
INFINITE PLAY!
CONNECTION VARIANTS:!
!
WIRING DIAGRAM DOOR RELESE CONTROL !
P1
L
P3 P4 P5
IN2 – Stair light
IN3
IN2
S+
AUX1 AUX2
12Vcc 1A Lock
12345$6789+$*9:;7$
<1=<>?')$$
AUX2 - Driveway gate
Power Supply
Z6001
IN1
P2
AUX3
AUX3 - free
PORTE RJ45
GND
N
GND GND
GND – INPUT
S-
Lock return
COM
1
COM
2
COM
3
USB
IN4
STAIRS LIGHT CONTOL
P1
L
P3 P4 P5
IN3
IN2
S+
AUX1 AUX2
12Vcc 1A Lock
Power Supply
Z6001
IN1– Lock release
IN1
P2
AUX3
PORTE RJ45
GND
N
GND GND
GND – INPUT
S-
COM
1
COM
2
COM
3
USB
IN4
WIRING DIAGRAM DOOR RELESE CONTROL!
wire 1,5mm2
DOOR RELEASE CONTROL
Mains
90-260Vac
50-60Hz
Mains
90-260Vac
50-60Hz
AUX1- Stair light
AUX2 – Driveway gate
AUX3 - free

18
EN!
INFINITE PLAY!
INSTALLATION NOTE : !

19
EN!
INFINITE PLAY!
SAFETY INSTRUCTIONS FOR INSTALLERS!
"!
This equipment is used in video door entry and home & building
automation systems.!
!
The instructions in this document provide important information about
safety, installation, use and maintenance of the product.!
!
Verify that the equipments are undamaged, after purchase.!
!
The packaging contains potential dangerous sources for children (screws
and dowels).!
!
The installation must respect the current CEI regulations.!
!
It is necessary to install to the power sypply a protection bipolar type
switch to video door entry system.!
!
Before connecting this equipment verify the output voltage supplied from
the distribution network.!
!
Before performing maintenance operations, disconnect the device.!
!
In case of failure or malfunction, disconnect the device and contact the
technical assistance centre.!
!
Do not obstruct opening of ventilation or heat exit slots.!
!
The protection bipolar type switch must be located in the main framework
of the House.!
WARNING:!
This equipment must be fixed to the wall according to the installation
instructions.!
"!
This leaflet must always be attached to the system documentation.!
!
!
!
Product is according to EC Directive 2004/108/EC, 2006/95/EC and
following norms. !
Directive 2012/19/UE (WEEE)!
!
The crossed-out wheelie bin symbol marked on the product indicates that
the product must be assigned to a differentiated collection centre for
electrical and electronic equipment or returned to the dealer to purchase a
new product.!
!
For further details regarding the collection systems available, contact your
local waste disposal service.!
!
The user is responsible for assigning the equipment purchased, to the
appropriate collection facilities.!
!
!
!
!
Risks connected to substances considered as dangerous (WEEE).!
!
According to the WEEE Directive, these electrical and electronic products
contain harmful substances for people and the environment.!
!
It is obligatory treat the recycling of the materials in such way to avoid
negative impacts on the environment and people’s health.!
!
Adaptation to current regulations allows a correct recycling of which the
product is made..!

!
Via Monte Grappa, 25!
31020 Villorba (TV) ITALY!
Tel. [phone]!
Fax. [phone]!
www.infiniteplay.com!
ENG!
18901001 – RL00 01 14!
ZEALABS - ITALY!
