4-CHANNEL FULL-RANGE AMPLIFIER WITH
DIFFERENTIAL-SIGNAL INPUTS
Easy-to-install, compact design
Independently variable electronic crossover
Variable bass boost
Preamp outputs
125W RMS x 4, at 4 ohms
≤ 1% THD + N*
150W RMS x 4, at 2 ohms
≤ 1% THD + N*
300W RMS x 2, at 4 ohms
≤
1% THD + N*
THD + N: 0.05%
Signal-to-noise ratio: 85dBA (reference: 1W into 4 ohms)*
Signal-to-noise ratio: 106dBA (reference: rated power into 4 ohms)
Frequency response: 10Hz – 75kHz (–3dB)
* CEA-2006A-compliant
800-WATTMONO SUBWOOFER AMPLIFIER WITH DIFFERENTIAL-SIGNAL
INPUTS AND DYNAMIC BASS OPTIMIZATION
Easy-to-install, compact design
Variable electronic crossover
DBO – variable bass EQ, plus subsonic filter
Preamp outputs
500W RMS x 1, at 4 ohms ≤1% THD + N*
800W RMS x 1, at 2 ohms ≤1% THD + N*
1 Ohm, stable
THD + N: 0.05%
Signal-to-noise ratio: 85dBA (reference: 1W into 4 ohms)*
Signal-to-noise ratio: 112dBA (reference: rated power into 4 ohms)
Frequency response: 20Hz – 320Hz (–3dB)
* CEA-2006A-compliant
7-1/16"
179mm
13"
329mm
1-3/4"
44mm
5-CHANNEL TOTAL-SYSTEM AMPLIFIER WITH DIFFERENTIAL-SIGNAL
INPUTS AND DYNAMIC BASS OPTIMIZATION
Unified system amplifier solution
Easy-to-install, compact design
Independently variable electronic crossover
DBO – variable bass EQ, plus subsonic filter
Selectable subwoofer input
50W RMS x 4, plus 200W RMS x 1, at 4 ohms
≤ 1% THD + N*
75W RMS x 4, plus 300W RMS x 1, at 2 ohms
≤ 1% THD + N*
150W RMS x 2, at 4 ohms
≤
1% THD + N* plus
200W RMS x 1, at 4 ohms
≤ 1% THD + N*
THD + N: 0.05%
Signal-to-noise ratio: 85dBA (reference: 1W into 4 ohms)*
Signal-to-noise ratio: 102dBA (reference: rated power into 4 ohms)
Frequency response: 10Hz – 75kHz and 15Hz – 320Hz (–3dB)
* CEA-2006A-compliant
7-1/16"
179mm
14-3/16"
360mm
1-3/4"
44mm
© 2008 Harman International Industries, Incorporated.
All rights reserved.
Part No. KAPPAAMPPI11-08
Features, specifications and appearance are subject
to change without notice.
Designed, edited and digitally produced by the
Harman Consumer Group Marketing & Design Center, Woodbury, NY.
Printed on paper made with 100% post-consumer fiber.
Infinity and Kappa are trademarks of Harman International Industries,
Incorporated,registered in the United States and/or other countries.
DirectFET is a trademark of International Rectifier Corporation.
250 Crossways Park Drive
Woodbury, NY 11797 USA
516.674.4INF (4463) Fax [phone]
www.infinitysystems.com
KAPPA
® AMPLIFIERS
Infinity®Kappa®Series car loudspeakers
have long delivered sound quality that
rivals the best home audio systems.
Now Infinity engineers close the loop
with a new line of slim-profile,
high-output amplifiers worthy of the
Kappa name.With a choice of subwoofer,
4-channel and total-system units, all
with advanced power technology,
noise-canceling circuitry and plenty of
sheer muscle, there’s a Kappa amp for
every car, SUV, truck and musical taste
out there.

KAPPA
®
CLASS D/DIRECTFET®TECHNOLOGY
Kappa amps feature high-power Class D
circuit topology with DirectFET®
transistors, a design that increases power
output and overall efficiency, with
improved heat transfer from the
transistors to the chassis. So you enjoy
better performance from significantly
smaller amps.
DYNAMIC BASS OPTIMIZATION (DBO)
Available on Kappa One and Kappa Five
amps, DBO is a proprietary variable
subsonic filter with variable bass boost.
Unlike conventional fixed-frequency
filters, DBO conserves power at
frequencies below 100Hz,protecting
woofers in vented-box applications from
overexcursion, and flattening response
through the lowest octaves in sealed-box
and infinite-baffle applications.
NONSTOP THERMAL PROTECTION
As you’d expect,Kappa amps feature smart
circuitry to protect your speakers in the
event of short circuits or problems with
your battery, alternator or voltage regulator.
But Kappa amps also protect themselves
against excess heat, with circuits that
cool the amplifier down by gradually
reducing output without shutting it down
completely. So the music never stops, no
matter how hot things start to get.
ULTRALOW-PROFILE DESIGN
At just 1-3/4" high, Kappa amps will fit
under most seats.Or virtually anywhere
else that’s convenient.
N
OISE
-C
ANCELING
S
IGNAL
I
NPUTS
Kappa amps use differential-signal
inputs with high common-mode noise
rejection for all speaker-level and
line-level outputs from source units.
Because noise from the vehicle’s
alternator and other electrical
components is radiated into the
positive and negative leads of each
signal input equally, amplifying the
difference between the leads
effectively cancels out the noise,
leaving only the music.
KAPPA
®
ONE
SUBWOOFER AMPLIFIER
KAPPA
®
FOUR
4-CHANNEL POWER AMPLIFIER
KAPPA
®
FIVE
5-CHANNEL TOTAL-SYSTEM
POWER AMPLIFIER

KAPPA
®
CLASS D/DIRECTFET®TECHNOLOGY
Kappa amps feature high-power Class D
circuit topology with DirectFET®
transistors, a design that increases power
output and overall efficiency, with
improved heat transfer from the
transistors to the chassis. So you enjoy
better performance from significantly
smaller amps.
DYNAMIC BASS OPTIMIZATION (DBO)
Available on Kappa One and Kappa Five
amps, DBO is a proprietary variable
subsonic filter with variable bass boost.
Unlike conventional fixed-frequency
filters, DBO conserves power at
frequencies below 100Hz,protecting
woofers in vented-box applications from
overexcursion, and flattening response
through the lowest octaves in sealed-box
and infinite-baffle applications.
NONSTOP THERMAL PROTECTION
As you’d expect,Kappa amps feature smart
circuitry to protect your speakers in the
event of short circuits or problems with
your battery, alternator or voltage regulator.
But Kappa amps also protect themselves
against excess heat, with circuits that
cool the amplifier down by gradually
reducing output without shutting it down
completely. So the music never stops, no
matter how hot things start to get.
ULTRALOW-PROFILE DESIGN
At just 1-3/4" high, Kappa amps will fit
under most seats.Or virtually anywhere
else that’s convenient.
N
OISE
-C
ANCELING
S
IGNAL
I
NPUTS
Kappa amps use differential-signal
inputs with high common-mode noise
rejection for all speaker-level and
line-level outputs from source units.
Because noise from the vehicle’s
alternator and other electrical
components is radiated into the
positive and negative leads of each
signal input equally, amplifying the
difference between the leads
effectively cancels out the noise,
leaving only the music.
KAPPA
®
ONE
SUBWOOFER AMPLIFIER
KAPPA
®
FOUR
4-CHANNEL POWER AMPLIFIER
KAPPA
®
FIVE
5-CHANNEL TOTAL-SYSTEM
POWER AMPLIFIER
