Infinity 880 BF User manual

880 BF
ROOM SEALED INSET LIVE FUEL EFFECT GAS FIRE
OWNER'S MANUAL
INCLUDES
USER INSTRUCTION
&
INSTALLATION & MAINTENANCE
INSTRUCTIONS
Please read these instructions carefully before you start
using the appliance
Keep this booklet handy for future reference
This appliance is
For use in GREAT BRITAIN or
IRELAND only
TELFORD
SHROPSHIRE
ENGLAND

LT 6456 (Iss 2 046/14)
2
INFINITY 880 BF Instructions
CONTENTS
PAGE
User’s Instructions
SECTION ONE Important Information 3
Consumer Protection 3
Health and Safety Notice 3
SECTION TWO Introduction 5
SECTION THREE Operation 5
Lighting the Fire 5
Turning Off the Fire 5
Replacing Appliance Batteries 7
SECTION FOUR Cleaning and Fuel Bed Laying 7
Cleaning: Glass Panel 8
Cleaning and Replacing Fuel Bed 9
Installation Instructions
SECTION FIVE Appliance Data 12
SECTION SIX Regulations and Warnings 13
SECTION SEVEN Siting the Appliance 14
General Requirements 14
SECTION EIGHT Preparing the Appliance for Installation 15
SECTION NINE Install the appliance 16
Installing the Appliance into a Cavity Wall 16
Connecting the Gas Supply 17
Check Burner Pressure and General Operation……………………………….17
SECTION TEN Assemble the Appliance 18
SECTION ELEVEN Instruct and Advise Customer 19
Maintenance Instructions
SECTION TWELVE Maintenance Instructions 20
General 20
Replacement of Gas Control 20
Replacement of Injector 20
Replacement of the Thermocouple 21
Replacement of Pilot Injector 21
Replacement of EDB Unit 21

LT 6456 (Iss 2 046/14)
3
INFINITY 880 BF Users Instructions
SECTION ONE Important Information
Consumer Protection Information
As manufacturers and suppliers of heating products, we take every care, as far as is reasonably
practicable, that these products are so designed and constructed as to meet the general safety
requirement when properly used and installed. To this end, our products are thoroughly tested and
examined before despatch.
IMPORTANT NOTICE: Any alteration that is not approved by the appliance manufacturer could
invalidate the approval of the appliance, operation of the warranty and could affect your statutory
rights.
Health and Safety Notice
Important
This appliance could contain some of the materials, indicated below, that could be interpreted as
being injurious to health and safety. It is the users / installers responsibility to ensure that the
necessary personal protective clothing is worn when handling these materials, see below for
information.
Artificial Fuels, Mineral Wool, Insulation Material, Refractory/Ceramic Fibres, Glass Yarn - may
be harmful if inhaled, may be irritating to skin, eyes, nose and throat.
When handling avoid inhaling and contact with skin or eyes. Use disposable gloves, facemasks
and eye protection. After handling wash hands and other exposed parts. If a vacuum is used for
cleaning the coals or cleaning after servicing / installation it is recommended that it be of the type
fitted with a HEPA filter.
Disposal of refractory/ceramic materials. To keep dust to a minimum these materials
should be securely wrapped in polythene and be clearly labelled ‘RCF waste’. These materials are
not classified as ‘hazardous waste’ and should be disposed of at a site licensed for the disposal of
industrial waste.
INTRODUCTION
The INFINITY 880 BF is an inset room sealed decorative fuel-effect gas appliance.
The INFINITY 880 BF is available in Natural Gas only.
The INFINITY 800 BF must not be installed into a natural draught flue or chimney.
The INFINITY 880 BF should only be installed and serviced by a competent person i.e. GAS
SAFE registered, in accordance with the GAS SAFETY (INSTALLATION AND USE)
REGULATIONS.
The INFINITY 880 BF does not require a chimney, but must be installed against an outside wall.
It is important that the flue terminal is regularly checked and kept clear at all times.
If the terminal is accessible to people (i.e. less than 2m above a walkway, balcony etc.) the
terminal guard must be fitted to prevent access to the flue outlet, which becomes hot when the fire
is in use.
As the INFINITY 880 BF is a room sealed appliance (i.e. air for the combustion process is taken
from outside the room) no purpose built ventilation is required.
The INFINITY 880 BF is designed and tested to meet the requirements of the European Standard
EN 613.

LT 6456 (Iss 2 046/14)
4
INFINITY 880 BF Users Instructions
SECTION ONE Important Information.
The INFINITY 880 BF is battery operated; therefore no mains electrical supply is required. Power to
the appliance is provided by 6 high power alkaline 1.5V batteries (“C” size) (a spare set of 6 “C”
batteries is supplied with the appliance
An audible repeated bleep warning indicates that the appliance batteries need changing or charging
(if rechargeable batteries have been used).
Important: Batteries should be changed as soon as possible as the appliance will not light if
the battery power gets to low.
SECTION ONE Important Information Cont.
The Appliance is for use on Natural Gas ( G20 @ 20mbar ) only.
Failure to install appliance correctly could lead to prosecution.
In GB (Great Britain), the appliance must be installed by a competent person i.e. GAS SAFE
registered, in accordance with the GAS SAFETY (INSTALLATION AND USE) REGULATIONS,
The Building Regulations (or The Building Regulations (Scotland) or The Building Regulations
(Northern Ireland)) and The Current I.E.E. Wiring Regulations, if appropriate.
In IE (Ireland), the appliance must be installed by a competent person and installed in
accordance with the current edition of I.S.813 Domestic Gas Installation, the current Building
Regulations and the current ETCI rules for electrical installation, if appropriate.
Although the INFINITY 880 BF is fitted with a glass front which acts as a dress guard it is strongly
recommended that a fireguard should be used for the protection of children, the elderly or infirm.
Fireguards should conform to B. S. 6539 (1984) (Fireguards for use with solid fuel appliance).
Care should be taken to prevent any damage being caused to surrounding soft furnishings or
decoration. Many wall coverings may become discoloured if placed too close to the appliance, it is
strongly recommended that any proposed wall covering intended for use immediately above the
appliance should be tested in the hottest position (immediately above) first. Run the fire on high
over a few days
All combustible material must be removed from behind the fire and fire trim.
The first time you light your new appliance a smell may occur due to its new condition. This is
quite normal and will soon disappear after a few hours use at maximum setting (open a window
until the smell disappears)
With use the inside of the air box will change colour, particularly the sides and rear. This is quite
normal and often adds to the overall effects of the appliance.
The appliance MUST NOT be used if the glass panel is not correctly fitted or if this panel is
cracked or broken.
Any debris should be cleaned from the appliance. A vacuum cleaner can be used but only after all
the loose shapes have been removed.
Prior to removing or cleaning the coals refer to the ‘Health and Safety Notice’ located on
page 3 of this booklet.
The appliance should be serviced annually by a competent person i.e. a GAS SAFE registered
engineer in accordance with these instructions.
The glass or any part of the appliance MUST NOT be cleaned or wiped whilst the appliance is
HOT, to do so could be dangerous and may damage the paintwork of the appliance.

LT 6456 (Iss 2 046/14)
5
INFINITY 880 BF Users Instructions
SECTION TWO Introduction
The INFINITY 880 BF is an inset room sealed decorative fuel-effect gas appliance designed for
use in locations that do not have a conventional chimney. The appliance must be installed against
an outside wall because the air to support combustion is taken from the outside and the products
of combustion are expelled to the outside.
The appliance incorporates a safety device in the form of a FLAME SUPERVISION DEVICE,
which constantly monitors the flame and will cause the gas to be switched off if the flames are
extinguished for any reason. THIS DEVICE MUST NOT BE OVERRIDDEN. If this situation
occurs on a regular basis have the appliance checked by a qualified engineer. The problem may
be due to a blocked or restricted flue.
Before removing the, trim, glass shapes for cleaning the fire should be turned off, and left to cool
down.
NOTE: In use some discoloration of the components will take place in the combustion box, this is
normal, but can be kept to a minimum if the shapes are placed correctly (i.e. after cleaning). See
Section 4.
As with all heating appliances certain areas (Working Surfaces) become very hot when the
appliance is in use.
SECTION THREE Operation
To light the appliance using the remote hand set:
a. Point the remote control hand set in the direction of
the appliance and press the button. Continue to
hold the button for approximately 2 seconds and
release. When released a bleep should be and heard
the appliance will automatically go through the ignition
sequence and the pilot should ignite. Once the pilot is
alight the appliance will automatically go to the high
setting (approximately 20-25sec).
b. If the ignitor stops sparking and the pilot fails to light
press the button for at least 2 seconds and
release, again a bleep should be heard. Then repeat
the lighting procedure.* See note on page 7
c. With the appliance lit, by pressing key the operational mode is switched from manual to Room
thermostat setting and vice versa. When Room thermostat mode is active, the display shows the
set temperature value and the “AUTO” icon will appear on the LCD display. By using the arrow
key the desired room temperature can be set. When manual mode is active, the display shows
the “MAN” icon plus the flame icon and a five level bar icon setting. By pressing the arrow key,
the flame picture can be adjusted at five stages between high and low flame. If level 5 is currently
active, the icon max below the flame icon will appear.
d. To switch off the appliance press the button for at least 2 seconds and on releasing the button
the appliance will bleep and then shut off. For pilot setting press the for 1 second and
release.The pilot symbol will appear on the LCD display.Pressing the button will bring the fire
back onto main flame.

LT 6456 (Iss 2 046/14)
6
INFINITY 880 BF Users Instructions
SECTION THREE Operation Cont.
e. The appliance can be switched off with out using the hand set by removing the appliance batteries
located below the air grill cover. When the batteries are removed there will be a delay (up
3minutes) after which, double bleeps may be heard and shortly after the appliance will extinguish.
Ensure that the battery is reconnected once the fire as been extinguished. The appliance cannot
be operated without the use of the handset.
Room Thermostat mode
The remote handset checks the room temperature at a fixed time intervals. Depending on the
difference between set room temperature and the actual room temperature the remote proceeds to
modulate in one level steps. Once the room temperature is reached it moves to standby position pilot
only.
The icon “PILOT” will appear on the LCD display. As soon as the actual room temperature falls below
the SET room temperature, the system will move from standby to the high flame level. From this point
it will proceed again the modulation process.
Note: Due to the temperature checks at timed intervals, the display temperature on the handset may exceed
the room setting temperature before the appliance defaults to the pilot setting.
TO REPLACE BATTERY IN HAND SET (3 AAA TYPE BATTERIES)
Remove the cover from the rear of the handset and fit replacement battery.
Clock Regulation
As soon as the batteries are fitted the timer digits will blink. Using the arrow
key increase or decrease the hour, minutes and week`s value. By pressing the
Owill set and shift setting until complete.
Changing Clock Setting During Operation
To amend timer setting press both the and O keys simultaneously for three seconds, the written
clock will appear. To change the clock settings, repeat the above described operation.
Change From Celsius to Fahrenheit
With remote OFF, keeping pressed key at least for 5 seconds, the temperature unit changes
from Celsius to Fahrenheit degrees and vice versa.
Battery level indication (Handset)
When the batteries have to be changed in the handset, the related icon will appear.
Setting the sleep mode
To activate the sleep mode: With the fire switched on press the O button. The sleep symbol
will appear top right . The sleep symbol replaces the time indicator in this mode. Using the
arrow key increase the sleep mode in 15 minute intervals (a small star will be visible next to the sleep
symbol once any time is set) .Once the set time is reached, the fire will completely switch off
without any further intervention.

LT 6456 (Iss 2 046/14)
7
INFINITY 880 BF Users Instructions
SECTION THREE Operation Cont.
To Deactivate the sleep mode:
When the fire is next operated, the sleep mode will automatically appear unless it is re-set to zero.
This can be done by pressing the O key and using the button to decrease the time set by 15
minute intervals until back to zero.
If you experience unexplained outing on the fire please check that the sleep mode is switched off.
Child Lock (Handset)
To activate `Child Lock` : Press and hold the Mode Key O button for 5 seconds, this will lock and
disable the handset and a “padlock” symbol will appear on the bottom of the screen. This can be
done while the fire is “off” or “on”. To deactivate this function press and hold the Mode Key O for 5
seconds and the “padlock” symbol will disappear.
LOW BATTERY INDICATION (APPLIANCE)
If you hear a repeated ‘bleep’ sound come from the appliance this indicates the appliance battery
pack is low and should be changed. If this is ignored the system will go into a lock out mode, which
will not allow the appliance to be used until a new set of batteries are loaded.
NOTE: The appliance cannot be used when the battery is completely discharged.
TO REPLACE APPLIANCE BATTERIES (6 High Power Alkaline C 1.5V)
a. Remove the Decorative in fills LH and RH.
b. Lift and remove the inlet cover located within the fireplace frame.( This is located at the bottom of
the fire between the glass panel and fireplace frame.
c. Remove the battery holder from within the battery holder and replace the six high power alkaline
C batteries as a complete set.
WARNING, batteries will overheat if fitted incorrectly, when fitting the batteries ensure that
they are fitted as per the marking on the rear of the holder (i.e. minus of battery against
spring).
e. Once the new batteries are loaded the fire will continue to bleep until re-set. Press the ON / OFF
key for at least 2 seconds, on release a bleep sound will be heard and the ignition process will start. If
the fire continues to bleep this may indicate a loose connection or badly loaded batteries.
*Important : If the fire burner or pilot is extinguished for any reason, do not attempt to re-light
the pilot for at least 3 minutes.
INFINITY 880 BF Users Instructions
SECTION FOUR Cleaning & Laying the fuel bed
Warning:-Before you clean any part of the appliance ensure that the appliance is switched off and
cool.
CLEANING: BLACK PAINTED SURFACES
These surfaces should be dusted regularly and any marks removed with a soft cloth.
Abrasive or chemical cleaner should never be used.

LT 6456 (Iss 2 046/14)
8
INFINITY 880 BF Users Instructions
SECTION FOUR Cleaning & Laying the fuel bed
CLEANING: GLASS PANEL
From time to time it may be necessary to clean
the glass panel.
We recommend you use a Ceramic Hob Cleaner
(brands such as HOB BRITE and VITRO CLEN
have been found to be acceptable) these are
available from most leading Supermarkets.
Remove the glass panel as follows:
Carefully lift out the in fill covers LH and RH.
Remove the top fixing cover.
Remove the three of fixing bracket located on
the top and sides of the glass panel.
Carefully lift the glass panel up out off the
bottom location. Lay the glass panel down on
a flat working surface on top of an old opened
newspaper with the side to be cleaned
uppermost.
Follow the Instructions on the Hob Cleaner
Bottle.
On stubborn stains (where the appliance has
been used for a long period without glass panel
being cleaned), use a new Brillo Pad well wetted
with the Hob cleaner applied directly to it.
Ensure all the residues of the cleaner are
removed with a damp cloth and the glass panel is
completely dry before fitting to the appliance.
Note: - If the loose shapes have not been placed
correctly, causing the gas flame to contact the glass this may result in glass staining that cannot be
removed by cleaning.
Re-assemble in reverse order ensuring a tight seal against glass assembly.
Re-fit the fascia.
CLEANING AND REPLACING fuel bed shapes
Important: - Refer to the ‘Health & Safety Notice located on page 3 of this booklet
before cleaning or replacing any refractory material.
Use only the shapes provided NO OTHER SHAPES SHOULD BE ADDED to the
appliance

LT 6456 (Iss 2 046/14)
9
The Fuel bed set consists of:
11 Log Shapes.
1 Bag of Bark Chips.
INFINITY 880 BF Users Instructions
SECTION FOUR Cleaning & Laying the fuel bed Continued
Log Fuel Bed Layout.
Locate the burner cover as
shown.
Place two of the log shape on top
of the air tray inlet shelf as
shown.
Place a further 2 off log shapes
along the front edge of the burner
cover as shown.

LT 6456 (Iss 2 046/14)
10
INFINITY 880 BF Users Instructions
SECTION FOUR Cleaning & Laying the fuel bed Continued
Log Fuel Bed Layout
Place the Decorative Bark shapes
as shown.
Place 3 off log shapes as shown.

LT 6456 (Iss 2 046/14)
11
INFINITY 880 BF Users Instructions
SECTION FOUR Cleaning & Laying the fuel bed Continued
Log Fuel Bed Layout
Place 2 off log shapes as shown.
Place the last Two large shapes
LH and RH as shown.

LT 6456 (Iss 2 046/14)
12
INFINITY 880 BF Installation Instructions
SECTION FIVE Appliance Data
Fire Box dimensions: Height 1030mm
Width 785mm
Forward Projection: 42mm
Weight: 35kg
Flue Length………………………………………...100mm (minimum) to 600mm (maximum)
No bends or joined flue pipes should be used in the
flue system.
Pressure Test Point Location: Gas inlet elbow
Gas Connection: 8.0mm O/D, tube.
Data Badge Location: On bottom right hand said of fire box behind trim.
MODEL
Natural Gas (G20) Version
Category of appliance
CII
NOXClass
3
Efficiency Class
1
Gas Category
I2H
Gas Type
G20 Natural Gas
Gas Pressure +/- 1.0mbar
20 mbar
Gas Input (Max)
5.0 KW Gross
(Min)
2.4 kW Gross
Injectors size
360 Mark
NOTE: The efficiency of this appliance has been measured as specified in BS EN613-2001 and the
result is 80.9% natural gas. The gross calorific value of the fuel has been used for this efficiency
calculation. Gastec have certified the test data from which it has been calculated. The efficiency
value may be used in the UK Government’s Standard Assessment Procedure (SAP) for energy rating
of dwellings.

LT 6456 (Iss 2 046/14)
13
INFINITY 880 BF Installation Instructions
SECTION SIX Regulations and Warnings
This appliance must only be installed in Great Britain or Ireland.
The appliance is available in natural gas only.
This appliance must be installed on a suitable outside wall.
No special ventilation bricks or vents are required into the room containing the appliance.
In GB (Great Britain)
It is the law that all gas appliances must be installed by a competent person; i.e. a GAS SAFE
registered installer, in accordance with the current Gas Safety (Installation and Use) Regulations
(as amended), all relevant parts of the local and national building regulations and all relevant
recommendations of the current British Standards. Failure to do so could lead to prosecution.
The following are the relevant codes of practice and British Standards: -
B.S. 5871 PART 2 B.S. 5440 PART 1
B.S. 6891 B.S. 1945
Note:- This appliance must be installed to current versions of the above standards and include
any relevant amendments.
The Building Regulations issued by The Department of the Environment.
The Building Standards (Scotland) (Consolidated) Regulations issued by The Scottish
Development Office.
IN IE, (Ireland)
The appliance must be installed by a competent person and installed in accordance with the
current edition of I.S.813 Domestic Gas Installation, the current building regulations, and the
current ETCI rules for electrical installation, if appropriate.
WARNINGS
As this appliance has components, which get very hot as with all such fires, it is recommended
that a fireguard should be used for the protection of children, the elderly, or the infirm. Fireguards
should conform to B.S.6539 (1984) (Fireguards for use with solid fuel appliances).
During initial use, an odour may be evident. This will soon disappear if the fire is run on its
maximum setting for a few hours.
Care must be taken to prevent any damage being caused to surrounding soft furnishing or
decoration, e.g. wall coverings may become discoloured if placed too close to the appliance.

LT 6456 (Iss 2 046/14)
14
INFINITY 880 BF Installation Instructions
SECTION SEVEN Siting the Appliance
(When installing in a timber framed dwelling reference must be made to the specific installation
requirements stated in Section 9 Installing the Appliance in Timber Framed Dwelling).
GENERAL REQUIREMENTS
The flue and air duct length must be between 100mm to 600mm.
The fire is supplied with a standard pipe length of 600mm Flue length.
The flue and air duct must not have any bends.
The flue outlet must terminate on a suitable outside wall.
The minimum flue terminal clearances, which must be maintained, are as shown below.
A Directly below an openable window or other opening. E.g. air brick 300mm
B Below gutters, soil pipes or drain pipes 300mm
C Below eaves 300mm
D Below balconies or carport roofs 600mm
E From vertical drain pipes and soil pipes 75mm
F From internal and external corners 300mm
G Above ground, roof or balcony level 370mm
H From a surface facing the terminal 600mm
I From a terminal facing the terminal 1200mm
J From an opening in a car port into a dwelling e.g. door, window, etc 1200mm
K Vertically from a terminal on the same wall 1500mm
L Horizontally from a terminal on the same wall 300mm

LT 6456 (Iss 2 046/14)
15
INFINITY 880 BF Installation Instructions
SECTION SEVEN Siting the Appliance Continued
Please note with early cavity wall design prior to 1970. The minimum depth requirement may well be
difficult to obtain. This could result in the need for the fire box to be spaced further from the internal
surface of the plaster and to achieve this larger rebated surround maybe necessary.
Ensure that gas supply is suitably sited
Check with the supplier or manufacturer
that the surround meets 1500C minimum
rating (attention should especially be given
to man made materials such as resin).
When installing in a timber framed
dwelling reference must be made to the
specific installation requirements stated in
Clearance to Shelf
Minimum clearance from hearth or base of
opening to underside of combustible shelf should
be 1040mm provided the shelf depth is 75mm
(3”). This gives a minimum clearance above the
appliance of 140mm. For a shelf of 150mm (6”)
the minimum height above the hearth or base of
opening must be 1120mm. This will give a
minimum clearance above the appliance of
220mm.
Clearance to Sides of Fire
Minimum width between vertical sides of combustible surround should not be less than 875 mm provided fire
is central to the surround and sides do not project more than 150 mm. When vertical side forward projection is
increased by 12.5 mm add 50 mm to inside width of surround.
*Please note - Appropriate measures should be taken when installing into a working flue
system i.e. out through an existing chimney *
SECTION EIGHT Preparing the Appliance for Installation
Carefully unpack the appliance from the carton and check the contents.
Lift away the Box of ceramics, glass panel and Fire frame components.
Remove the refractory components from the inside of the packaging.
The appliance is now ready for installation.
INSTALLING THE APPLIANCE INTO CAVITY WALL Ensure it is a suitable outside wall
constructed of non-combustible materials and that the flue position meets the requirements
previously described in Section 8.
Mark a vertical line on the wall at the intended centre of the appliance up from the horizontal line
for a height of 887mm.
If insetting into the wall mark the position for a lintel (Minimum 1040mm) above the top horizontal
line.
Using a long masonry drill, make one pilot holes completely through the wall. Ensure the holes
are drilled accurately at the centres and square to the wall both horizontally and vertically at the
cross points previously marked.
If insetting into the wall proceed as follows: Cut out the brickwork of the inner skin of the cavity
wall for the lintel, and fix the lintel.
Cut out the brickwork under the lintel, between the two outside vertical lines into the cavity.
Ensure the cutout width is square and try the appliance into the opening.
ALL DIMENSIONS IN mm
B
“A”
HEARTH TO SHELF
1040 MIN
790 MIN
840 MAX.
188
MIN

LT 6456 (Iss 2 046/14)
16
MARKING OUT WALL FOR
CAVITY RECESSED
INSTALLATIONS
FLOOR SURFACE
CENTRE LINE OF
INSTALLATION
HEARTH SURFACE LINE
OR BASE LINE FOR
HOLE IN WALL (150mm min. from floor)
MARK POSITION
OF LINTEL
605.00
490.00
INFINITY 880 BF Installation Instructions
SECTION SEVEN Siting the Appliance Continued
Using 150mm core drill cut a holes following the pilot holes. Drill from the outside through to the
cavity to give a good finish on the outside.
Remove any cavity insulation from the cutout opening and for a further 100mm into the cavity gap
each side and above.
Pack “Rockwool” around the sides and top of the opening into the cavity for a depth of 100mm.
Also put some behind the firebox if space is available.
Offer the appliance into the opening and mark through the gas pipe entry hole (see connecting the
gas supply section).
Pass a tape measure through the core-drilled holes and record the distance from the spigots to
the surface of the outside wall. Include the length of the spigots themselves in this measurement
and increase both the recorded distances by 15mm (5/8”) each for the engagement allowance.
Cut the lengths from the one 600mm flue pipe provided.
Remove the appliance from the opening, and position the gas supply (see connecting the gas
supply later in this manual), taking account of the relative gas regulations regarding a gas pipe in
a cavity (sleeving and sealing etc). Note the gas feed must be fitted with an isolation valve.
Position and seal the pipe to their respective spigots on the rear of the appliance (use flue seal or
fire cement to ensure airtight seal, it must not obstruct the flue).
Push the appliance back into the opening and fill any space behind the appliance with
“Rockwool”.
Complete the gas connection (see connecting the gas supply later in this manual).
Drill the four fixing holes through the hole in the flange of the appliance and fix back using plug
and screws.
If the flue outlet is fitted below 2m from the floor or a balcony then a flue terminal guard must be
fitted.
887
1040
Measurement taken from
floor Level to the flue pilot
height and lintel minimum
clearance

LT 6456 (Iss 2 046/14)
17
INFINITY 880 BF Installation Instructions
SECTION TEN CONNECTING THE GAS SUPPLY
TURN OFF ANY GAS APPLIANCES THAT ARE FED BY THE METER AND ISOLATE THE GAS
SUPPLY BY TURNING OFF AT THE METER.
The Gas Connection can be made by removing the
gas inlet cover located on the left hand side of the
fire box sump assembly. Remove the 8 off fixing
screw and remove the plate plus gas kit. Please
note special attention should be taken not to
damage the gas kit.
You will then have access to the isolating cock
which is fitted in the supply feed.
When a concealed gas fitting from the rear is
required it is necessary to route the pipe to the left
side of the unit, taking into account the requirements
of BS 6891 1988 dealing with enclosed pipes.
When installing the firebox into a cavity wall, any
part of the installation pipe work installed in the void open to the cavity wall must be enclosed in a
gas tight sleeve. It must be sealed at the point at which the sleeved installation pipe enters the fire
(The Gas Safety (Installation and Use) Regulations Certificate of exemption number 1 of 1996).
Where the pipe enters the fire the outer sleeve must be sealed to the grommet and the pipe must
be sealed to its outer sleeve using suitable mastic.
CHECK BURNER PRESSURE AND GENERAL OPERATION
Remove the screw from the pressure test point on the burner inlet elbow and fit a pressure test
gauge.
Turn on the gas to the appliance and operate as described in section three. Check that the inlet
pressure 20mbar +/- 1 mbar for natural gas.
Turn off the appliance and remove pressure test gauge.
Refit the screw into the pressure test point and turn on the appliance again, check that the screw
has sealed with leak detection fluid.
Turn the appliance off.
Refit the gas inlet cover and gas kit.Please note special attention should be taken not to
damage the gas kit.

LT 6456 (Iss 2 046/14)
18
INFINITY 880 BF Installation Instructions
SECTION TEN Assemble the
appliance continued
Taking special care remove the ceramic liner set
from within the packaging. The rear liner is in two
pieces. Place the bottom rear liner upon the top
edge to the air tray. Angle the upper rear line into
the fire box assembly and place on top of the rear
bottom line.

With the two rear liner in position. Offer
the LH and RH side liner into the
bottom brackets within the burner Shelf
assembly. (Please note the patterned
edge must be positioned along the
front). Push the top of the liner back
into the chamber sides and bend the
finger fold brackets to locate the side
liners.
Fit the burner cover within the base of the burner tray.
Position the shapes components as described in section four of this
manual; it is important that the shapes are positioned exactly as
described to ensure the correct operation of the appliance. Badly
positioned shapes may result in the gas flame being driven forward onto
the glass and permanently marking it.
The fireplace frame can now be fitted by sliding the assembly over the
4mm location studs positioned on the LH and RH flange of the fire box.
When positioned tighten all six off fixings.
Taking great care, locate the glass panel within the gap
between bottom retaining bracket and glass seal.
When located push back against the seal and locate and
tighten the three fixing brackets. (Please note over
tightening the fixing nuts can result in damage to the
glass panel).
Load 6 off of the 1.5 v “C” batteries into the holder
provided and attach to battery lead. Locate the loaded

LT 6456 (Iss 2 046/14)
19
INFINITY 880 BF Installation Instructions
SECTION TEN Assemble the appliance continued
Holder within the bracket at the bottom of the fireplace assembly.
Fit the Inlet cover at the bottom of the appliance
between the glass panel and fireplace frame
assembly.
Finally Slide the LH and RH infill strip within the
fireplace frame and the glass panel.
When assembly is complete please refer to section three operation.
INFINITY 880 BF Installation Instructions
SECTION ELEVEN Instruct and Advise the Customer
Demonstrate the lighting and extinguishing procedure to the consumer/user and the removal and
refitting of the trim for cleaning.
Explain that for the first few hours of the fire operating there will be an initial odour. This is due to
the curing of the paint, the appliance should be operated on its high setting, and it is
recommended that a window is left open until that odour has completely disappeared.
Instruct on the glass removal and refitting.
Instruct on the shapes cleaning and advise that a vacuum cleaner can be used but only after all
the loose shapes have been removed. Refer to ‘Health & Safety Notice (See Section One) at
the front of this booklet before proceeding.
Advise customer that with use the inside of the air box will change colour, particularly the sides
and rear. This is quite normal and often adds to the overall effects of the appliance.
Advise that the appliance should be serviced annually by a competent person i.e. a Gas safe
registered engineer in accordance with these instructions.
Although the appliance is fitted with a glass front which acts as a dress guard it is strongly
recommended that a fireguard should be used for the protection of children, the elderly or infirm.
Fireguards should conform to B. S. 6539 (1984) (Fireguards for use with solid fuel appliance).
Hand these instructions to the user.

LT 6456 (Iss 2 046/14)
20
Infinity 880 BF Maintenance Instructions
SECTION TWELVE Maintenance Instructions
General
Servicing should be carried out annually by a competent person such as a GAS SAFE-registered
person in accordance with the relevant regulations, to ensure the safe and correct operation of the
appliance.
Warning: - Before commencing any service or replacement of parts, turn off the gas supply to
the fire.
After servicing check for gas soundness.
When ordering spare parts please quote appliance name and serial number these can be found
on the data badge, which is located on the left hand side of the base of the appliance.
If soot has accumulated check to establish cause, rectify and clean flue accordingly.
Important: - Refer to ‘Health & Safety Notice (See Page 3) at the front of this
booklet before removing the fuel bed components.
Examine the shapes for signs of cracking and replace if necessary.(IMPORTANT) see shape
layout procedure in section four of this manual before attempting to replace items, which should
only be replaced as a complete set with no extra shapes added.
Replacement of Gas Control
1. Remove the infill strips LH and RH and the inlet cover.
2. Remove the 3 off glass retaining brackets positioned on both sides and top of the glass panel.
3. Remove the glass panel.
4. Remove all shapes and the burner cover plate.
5. Remove the fixing screws from the gas inlet cover and gas kit and shut off restrictor. Break the
8mm compression joint on burner tray outlet pipe.
6. Remove the 3M nut which attaches the EDB unit to the base of the firebox.
7. Remove all the No 6 screws fixing the burner sump to the firebox shelf. Lift the complete
burner sump assembly and gas kit out of the firebox shelf.
8. With the sump assembly removed. Disconnect the Valve Motor wire, Ignition wire and
Thermocouple interrupter wires from the E.D.B.
9. Disconnect all the pipes and thermocouple from the Gas Valve.
10. Change, service or replace the valve and re-assemble in reverse order.
11. Re-assemble the complete tray into the fire in reverse order and re-connect all parts.
12. Turn on the Gas supply, check for soundness and recomission.
Replacement of Injector
1. Repeat operations 1-9 for removal of gas control.
Clean or replace injector and replace in reverse order, ensuring that the seal around the
injector fixing is sound (change if in doubt).
2. Turn on the gas supply, check for soundness and re- commission.
