INFINITY
®
REFERENCE SPEAKERS
Looking for a moremoving audio experience? Take Infinity®car audio for a ride.
Innovative materials and breakthrough engineering have always put Infinity products out
in front ofthe competition. So expectextreme output from these speakers, but be
prepared for accuracy and detail that may surprise you. Infinity Reference Series
loudspeakers continue to be the top-selling premium speakers in the world. For instance,
the 6-1/2-inch Reference coaxial model has been the number-one-selling car audio
multielement speaker for four years straight. With proprietary features such as patent-
pending Plus One®cones, true 4-ohm topology, UniPivot™(patent no. 6,002,780) edge-driven
tweetersand the industry-leading Intermount III (patent no. 6,505,705) and I-Mount™
(patent no. 5,859,917) mounting systems, as well as the Starfish™tweeter-mounting
adapter, Reference Series speakers leave the competition scrambling to keep up.

m u l t i e l e m e n t s
TEXTILE-DOME TWEETERS
EDGE-DRIVEN
UNIPIVOT
TO ENSURE PROPER IMAGING
PLUS ONE
POLYPROPYLENE WOOFER CONES
4022i
4" (100mm) Two-Way Loudspeaker
Plus One®(patent pending) woofer cone
Edge-driven, textile-dome tweeter
2-Ohm impedance
Sensitivity: 92dB
Frequency response: 85Hz – 21kHz
Power handling, RMS: 35 watts
Power handling, peak: 105 watts
5022i
5-1/4" (130mm)
Two-Way Loudspeaker
Plus One®(patent pending) woofer cone
Edge-driven, textile-dome tweeter
with UniPivot™(patent no. 6,002,780)
2-Ohm impedance
Sensitivity: 92dB
Frequency response: 67Hz – 21kHz
Power handling, RMS: 45 watts
Power handling, peak: 135 watts
6022i
6-1/2" (160mm)
Two-Way Loudspeaker
Plus One®(patent pending) woofer cone
Edge-driven, textile-dome tweeter
with UniPivot™(patent no. 6,002,780)
Intermount III (patent no. 6,505,705)
woofer-mounting system
2-Ohm impedance
Sensitivity: 93dB
Frequency response: 53Hz – 21kHz
Power handling, RMS: 60 watts
Power handling, peak: 180 watts
6022si
6-1/2" (160mm ) Two-Way
Shallow-Mount Loudspeaker
Plus One®(patent pending) woofer cone
Edge-driven, textile-dome tweeter
Intermount III (patent no. 6,505,705)
woofer-mounting system
2-Ohm impedance
Sensitivity: 93dB
Frequency response: 53Hz – 21kHz
Power handling, RMS: 50 watts
Power handling, peak: 150 watts
9622i
6" x 9" Two-Way Loudspeaker
Plus One®(patent pending) woofer cone
Edge-driven, textile-dome tweeter with
UniPivot™(patent no. 6,002,780)
2-Ohm impedance
Sensitivity: 94dB
Frequency response: 46Hz – 21kHz
Power handling, RMS: 100 watts
Power handling, peak: 300 watts
PLUS ONE®CONES
This patent-pending technology
delivers a cone with more surface
area than that in competing models
of the same size. This increase can
be as much as 30 percent, depending
on the individual speaker model. The
benefit is increased bass output and
maximized efficiency.
TRUE 4-OHM TOPOLOGY
All Reference Series speakers
include reduced voice-coil impedance
to extract the most power possible
from any and all amplifiers designed
todrive loads of 4 ohms or less. Many
factory-installed systems incorporate
2-ohm speakers and include amplifiers
designed to drive those loads. Merely
replacing those reduced-impedance
speakerswith conventional 4-ohm
models is hardly an upgrade, since
the power output from the amplifier
will be reduced. True 4-ohm topology
addresses this as well.
EDGE-DRIVEN, TEXTILE-
DOME TWEETERS
These are not commonly used W-domes,
but fully edge-driven dome tweeters
like those found in better home audio
speakers. The benefit is increased
power handling and reduced
distortion at high output levels.

multielements
c o m p o n e n t s
©2008 Harman International Industries, Incorporated.
All rights reserved. Part No. INFREFSPKRPI3-08
Features, specifications and appearance are subject to change
without notice. Designed, edited and digitally produced by the
Harman Consumer Group Marketing & Design Center, Woodbury, NY.
Infinity and Plus One are trademarks of Harman International
Industries, Incorporated, registered in the United States and/or
other countries. I-Mount, UniPivot and Starfish are trademarks of
Harman International Industries, Incorporated.
250 Crossways Park Drive, Woodbury, NY 11797 USA
516.674.4INF (4463) Fax [phone]
www.infinitysystems.com
9623i
6" x 9" Three-Way Loudspeaker
Plus One®(patent pending) woofer cone
Textile-dome midrange and edge-driven,
textile-dome tweeter
2-Ohm impedance
Sensitivity: 94dB
Frequency response: 46Hz – 21kHz
Power handling, RMS: 100 watts
Power handling, peak: 300 watts
3022cf
3-1/2" (87mm)
Two-Way Loudspeaker
Plus One®(patent pending)
woofer cone
Balanced-dome tweeter
2-Ohm impedance
Sensitivity: 91dB
Frequency response: 85Hz – 21kHz
Power handling, RMS: 25 watts
Power handling, peak: 90 watts
6422cf
4" x 6" Two-Way Loudspeaker
Plus One®(patent pending) woofer cone
Edge-driven, textile-dome tweeter
OEM replacement – fits GM, Nissan
2-Ohm impedance
Sensitivity: 91dB
Frequency response: 72Hz – 21kHz
Power handling, RMS: 40 watts
Power handling, peak: 120 watts
6422cfp
4" x 6" Two-Way
Plate Loudspeaker
Plus One®(patent pending)
woofer cone
Edge-driven, textile-dome tweeter
2-Ohm impedance
Sensitivity: 91dB
Frequency response: 72Hz – 21kHz
Power handling, RMS: 45 watts
Power handling, peak: 135 watts
6822cf
6" x 8"/5" x 7"
Two-Way Loudspeaker
Plus One®(patent pending)
woofer cone
Edge-driven, textile-dome tweeter
with UniPivot™(patent no. 6,002,780)
2-Ohm impedance
Sensitivity: 93dB
Frequency response: 49Hz – 21kHz
Power handling, RMS: 60 watts
Power handling, peak: 180 watts
5020cs
5-1/4" (130mm) Two-Way
Component System
Plus One®(patent pending)
woofer cone
Edge-driven, textile-dome tweeter
I-Mount™(patent no. 5,859,917)
tweeter kit with Starfish™OEM adapter
Outboard passive crossovers
with tweeter-level adjustment
2-Ohm impedance
Sensitivity: 92dB
Frequency response: 67Hz – 21kHz
Power handling, RMS: 75 watts
Power handling, peak: 225 watts
6820cs
6" x 8"/5" x 7" Two-Way
Component System
Plus One®(patent pending)
woofer cone
Edge-driven, textile-dome tweeter
I-Mount™(patent no. 5,859,917)
tweeter kit with Starfish™OEM adapter
Outboard passive crossovers
with tweeter-level adjustment
2-Ohm impedance
Sensitivity: 93dB
Frequency response: 49Hz – 21kHz
Power handling, RMS: 90 watts
Power handling, peak: 270 watts
6020cs
6-1/2" (160mm) Two-Way
Component System
Plus One®(patent pending)
woofer cone
Edge-driven, textile-dome tweeter
I-Mount™(patent no. 5,859,917)
tweeter kit with Starfish™OEM adapter
Outboard passive crossovers
with tweeter-level adjustment
2-Ohm impedance
Sensitivity: 93dB
Frequency response: 53Hz – 21kHz
Power handling, RMS: 90 watts
Power handling, peak: 270 watts
1021t
1" (25mm)
Textile-Dome Tweeter
Edge-driven motor structure
I-Mount™(patent no. 5,859,917)
tweeter kit with Starfish™OEM adapter
In-line crossover network
2-Ohm impedance
Sensitivity: 93dB
Frequency response: 2.5kHz – 21kHz
Power handling, RMS: 50 watts
Power handling, peak: 150 watts
