Technical Manual
Reference 2000.6
Reference 2000.6
ACOUSTIC & ELECTRICAL SPECIFICATIONS
•Nominal Impedance 8 ohms
•Max Amp Power 200 watts
•Frequency Response 35Hz – 20kHz
•Sensitivity 92 dB SPL, 1 watt @ 1 meter
•Crossover Frequency 3600Hz
SYSTEM COMPONENTS:
•Cabinet (Black Ash) 331046-001 (Not for sale)
(Cherry) 331046-002 (Not for sale)
•Grille (Upper) 333204-001
(Lower) 330976-001
•Low Frequency 6 1/2” (160mm) Co-injected
Transducer woofer, shielded 330617-002
DC Resistance 7.2 ohms ±10%
• High Frequency 1” (25mm) Neodymium
Transducer Soft Dome 333232-001
SYSTEM COMPONENTS: (cont.)
DC Resistance 4.0 ohms ±10%
•Crossover Network 331103-003
AURAL SWEEP TEST SPECIFICATIONS:
•System Aural Sweep Test 6.0V Input 20 Hz to 20 kHz
•L.F. Aural Sweep Test 6.0V Input 20 Hz to 4kHz
•H.F. Aural Sweep Test 2.0V Input 3kHz to 20 kHz
PHYSICAL SPECIFICATIONS
•Enclosure dimensions: 40” x 7 1/2” x 14 3/8” (H x W x D)
(1016 x 190 x 365mm)
SHIPPING WEIGHT:
• 40.4 lbs. (18.1 kg) Each
WARRANTY:
• Refer to Warranty Statement packed with each product.
Owner's Manual
331351-001
Spiked Foot Set
331360-001
Survey Card
330033-001
Top Foam
331081-001
Bottom Foam
331082-001
OWNER'S
MANUAL
Outer Carton
331083-001
;;;
;;;
yyy
yyy
;;
;;
yy
yy
;;;
;;;
;;;
yyy
yyy
yyy
;;
;;
;;
yy
yy
yy
PACKAGING
Driver
High Frequency
333232-001
Driver(2)
Low Frequency
330617-002
Blue
Black
Red/Black
Red/Black
Red
Red
331103-003
Network
WIRING DIAGRAM
L1
0.65 mH
C1
30.0 mfd
50V
C2
20.0 mfd
100V
R1
2.00 ohm
5W
L2
0.40 mH
35" RED
35" RED/BLACK
17" RED
17" RED/BLACK
34" BLUE
32" BLACK
+LF
–LF
+HF
–HF
250
+LF
250
–LF
205
205
110
205
R3 (–002 ONLY)
10.0 ohm 5W
L3
0.20 mH
R2
3.3 ohm 5W
C3
3.3 mfd
100V
+IN
–IN
INPUT
2000.6 SCHEMATIC
9-98
Infinity Systems, Inc. 250 Crossways Park Dr., Woodbury, New York 11797
331109-001
Front baffle
331119-001
Kick Baffle
333232-001
1" Tweeter
333204-001
Grille Assembly
Cabinet (Not for Sale)
Black Ash 331046-002
Cherry 331046-002
330834-001
Tweeter Cup
63563 (4)
#6 x 3/4 PPH
Screw
905502-004 (2)
#4-40x1/4 PPH Zinc.
Screw
331121-001
Base Front Foot
331075-002
Rear Base Assembly
331723-001
Red Terminal
331724-001
Black Terminal
330617-002
Woofer
63563 (4)
#6 x 3/4 PPH
331875-001 (2)
Grille Gasket
331296-001
Logo
+ IN
— IN
35" RED/BLACK
35" RED
34" BLUE
32" BLACK
Acoustic Filter
(Not for Sale)
330976-001
Bottom Grille
Port Tube
(Not for sale)
Screws (10)
900101-016
331103-003
Crossover Network
Screws (3)
900101-016
COMPONENT EXPLODED VIEW
Reference 2000.6
SERVICE NOTE:
For access to the drivers the front baffle must be
removed (4 screws).
Reference 2000.6
9-98
