IB100
I-BUS isolator
The IB100 isolator is a peripheral device
which, when connected to the I-BUS,
allows you to configure two groups of
peripherals by means of galvanic
isolation of the electrical power, Ground
and the D and S data channels of each
group. Using this principle, the group of
peripherals connected and powered
directly from the control panel (group A)
can be separated from the group
connected to the control panel via the
isolator, therefore, not powered by the
control panel (group B).
The isolator also regenerates the D and S
signals, thus limiting signal/power loss
due to the excessive wire length of the I-
BUS.
The isolator is available in 3 versions:
•IB100-RP, model with BUS and power
supply isolation functions, housed in
white box, manages open-tamper but
not dislodgemnent-tamper signals.
•IB100-RU, model with BUS and power
supply isolation functions, housed in
black box with on-view terminals, no
tamper management.
•IB100-A, model with BUS, power
supply and isolated DC/DC convertor
isolation functions, housed in white
box, manages open-tamper but not
dislodgemnent-tamper.
A
I-BUS A terminal board
(to control panel) All models
B
I-BUS B terminal board
C
Open-tamper terminal Only for
IB100-RP
and IB100-A
D
Open-tamper microswitch
E
Configuration button
All models
F
Isolation jumpers
G
I-BUS A communiction LED
(green)
H
I-BUS B communiction LED
(red)
I
BUS A power supply LED
(green)
Only for
IB100-A
L
BUS B power supply LED
(green)
M
Voltage output trimmer
Installation
manual
A
BC
D
E
F
L
I
M
G
H
DCMIINIEIB100-R110-20140609

2
IB100
Note
Use “Maximum current absorption from control panel” for the correct dimensioning of the BUS absorptions
between the control panel and the isolator.
Configurations
The IB100-RP and IB100-RU isolators can be configured as follows:
• The default configuration provides galvanic isolation and regeneration of the D and S signals whereas the
electrical power is carried over BUS A and BUS B.
• Interrupting the jumpers [F] isolates the electrical power and ground of BUS A and BUS B. This configuration
will allow you to power BUS B from an external power supply.
The IB100-A model operates using the configuration which provides galvanic isolation of the D and S signals and
the electrical power. It also has an isolated DC/DC convertor which powers the devices connected to BUS B,
without the need of an external power supply. The output power voltage supplied by the convertor can be
adjusted by means of the trimmer [M], values range from 12 to 16Vdc.
The IB100-RP and IB100-A isolators manage open-tamper signals via microswitch [D] which regenerates the
signal to the control panel via terminal [C].
Addressing the device
In order to allow the control panel to distiguish the various isolators connected to the I-BUS, it is necessary to
assign a different address to each isolator.
To assign the addresses, work carefully through the following steps:
1. Put the control panel in Service mode or access the Programming phase.
2. Press and hold key [E] until LEDs [G] and [H] go Off.
3. Release key [E]; the green LED [G] will start to blink. The number of blinks indicate the device address.
4. To change the address, press the as many times as is necessary to reach the required address. During this
phase the red LED [H] acts as a monitor and goes ON each time the key is pressed (feedback signal). Once
you have set the desired address, wait 5 seconds, LEDs [G] and [H] will blink simultaneously to confirm the
address has been saved.
5. The Programming phase will end automatically if the key is not pressed within 5 seconds.
Technical specifications IB100-RP IB100-RU IB100-A
Minimum input voltage 9 V dc
Maximum input voltage 16 V dc
Output voltage interval / 12-16 Vdc
Typical current draw
50 mA 110 mA
Maximum output current / 500 mA
Maximum current absorption
from control panel
/ 900 mA
Operating temperature
-5 / +40 °C
Dimensions [mm] 125 x 79 x 26 105 x 58 x 18 170 x 79 x 26
INIM Electronics reserves the right to change the
technical specifications of this product without prior
notice.
