www.insignia-products.com 1
Welcome
Congratulations on your purchase of a high-quality Insignia product.
Your IS-PA040722A represents the state of the art in personal CD
player design, and is designed for reliable and trouble-free
performance.
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Getting to know your CD player . . . . . . . . . . . . . . . . . . . . . . . . 4
Setting up your CD player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Using your CD player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Additional functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Español. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Personal CD Player - combined.fm Page 1 Monday, June 27, 2005 1:27 PM

2
IS-PA040722A Personal CD player
www.insignia-products.com
Safety precautions
The lightning flash with arrowhead symbol within a
triangle is intended to alert you to the presence of
uninsulated dangerous voltage within the player’s
enclosure that may be of sufficient magnitude to
constitute risk of electric shock to persons.
The exclamation point within a triangle is intended to
alert you to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the player.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Warning This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Caution It is recommended to use a surge protector for AC connection.
Lightning and power surges ARE NOT covered under warranty for
this product.
Personal CD Player - combined.fm Page 2 Monday, June 27, 2005 1:27 PM

3
IS-PA040722A Personal CD player
www.insignia-products.com
Information for the user:
Modifications not authorized by the manufacturer may void the user’s
authority to operate this device.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance witch the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
• Place the unit on a stable surface.
• Avoid installing the unit in the following locations:
• Places exposed to direct sunlight or close to heat radiation
appliances such as electric heaters.
• On top of other stereo equipment that radiates too much
heat.
• Places lacking ventilation or dusty places.
• Places subject to constant vibration.
• Humid or moist places.
Personal CD Player - combined.fm Page 3 Monday, June 27, 2005 1:27 PM

4
IS-PA040722A Personal CD player
www.insignia-products.com
Getting to know your CD player
Location of controls
# Description # Description
1Stop button 7 Earphone or headphone
jack
2Play or pause button 8 Volume control
3Skip or search button 9 Program button
4Skip or search button 10 Random button
5 Display window 11 Mode button
12
11
10
9
8
7
6
5
4
3
1
2
Personal CD Player - combined.fm Page 4 Monday, June 27, 2005 1:27 PM

5
IS-PA040722A Personal CD player
www.insignia-products.com
Setting up your CD player
Power supply
To install the batteries (not supplied):
1Open the battery compartment cover.
2Insert two “AA” (LR6) alkaline batteries. Match the battery
polarities (+ and -) with those in the diagram inside the battery
compartment.
3Replace the cover.
WHEN TO REPLACE THE BATTERIES
When the indicator flashes in the LCD display, replace the
batteries with new alkaline batteries.
6 DC input jack 12 Open switch
Note For battery operation, the AC adapter lead must be disconnected
from the DC input jack.
# Description # Description
Personal CD Player - combined.fm Page 5 Monday, June 27, 2005 1:27 PM

6
IS-PA040722A Personal CD player
www.insignia-products.com
To connect the AC adapter (not supplied):
1Plug the round AC adapter plug into the DC input jack on the
player.
2Plug the AC power cord into a standard household power outlet.
Earphones or headphones
To listen with the earphones:
1Insert the plug of the stereo earphones (supplied) or stereo
headphones (not supplied) into the green PHONES jack.
2Place the earphones or stereo headphones on your ears.
Warning Avoid excessive sound levels and prolonged periods of listening
through earphones or headphones, which could impair your
hearing.
Personal CD Player - combined.fm Page 6 Monday, June 27, 2005 1:27 PM

7
IS-PA040722A Personal CD player
www.insignia-products.com
Using your CD player
Making connections
To connect the earphones:
• Plug the earphones firmly into the green PHONES jack. A poor
connection could generate noise during play.
Inserting a CD
To insert a CD:
1Open the cover by sliding the Open button to the right.
2Place the CD firmly onto the center spindle, then close the CD
cover.
Note Refer to “Power supply” on page 5 for information on battery
operation.
Personal CD Player - combined.fm Page 7 Monday, June 27, 2005 1:27 PM

8
IS-PA040722A Personal CD player
www.insignia-products.com
Playing a CD
To play a CD:
1Press the PLAY or PAUSE button.
2Adjust the volume control to a comfortable level.
3To stop, press the STOP button.
4Press the STOP button again, twice, to turn off the power.
To Press Display
Pause play [flashing]
Resume play after
pausing
Move to the start
of the current track once
Move to the start
of the previous
track
more than once
Move to the start
of the next track once
Move to the start
of later tracks more than once
Fast forward Press and hold
Rewind (fast) Press and hold
VOL.
Personal CD Player - combined.fm Page 8 Monday, June 27, 2005 1:27 PM

9
IS-PA040722A Personal CD player
www.insignia-products.com
Removing the CD
To remove the CD:
1Open the CD player by sliding the Open button to the right.
2Remove the CD by pressing on the center spindle.
Additional functions
Repeat play
You can play tracks over again in either Normal or Program play
mode. You can also repeat all the tracks or just one track.
To repeat single tracks:
1Press the MODE button while listening to the track you want to
hear again. The symbol is displayed in the LCD display.
2To repeat another track, press the or SKIP or SEARCH
buttons.
3To cancel Repeat play, press the MODE button three times.
To repeat all tracks:
1Press the Mode button twice during play. The symbol is
displayed in the LCD display and all the tracks will be repeated,
one after another.
2To cancel Repeat play, press the MODE button twice.
Intro play
To use Intro play:
1Press the Mode button 3 times to enter the Intro mode, “INTRO”
flashes on the display.
2Press the PLAY or PAUSE button. The CD plays the first
10 seconds of each track.
3Press the MODE button once to cancel Intro play and resume
normal playback.
After all tracks have been played, power is turned off automatically
after 60 seconds.
Personal CD Player - combined.fm Page 9 Monday, June 27, 2005 1:27 PM

10
IS-PA040722A Personal CD player
www.insignia-products.com
Random track play
To play random tracks:
1Press the RAND button once while the player is stopped.
“RAND” flashes in the LCD display and the player randomly plays
tracks.
2To cancel Random track play, press the RAND button once again.
Programmed play
You can program up to 24 tracks in the order you select.
To play tracks in programmed order:
1While the player is stopped, press the PROG button until “PGM”
flashes in the LCD display. The track number and order of play are
displayed.
2Press the or SKIP or SEARCH buttons to choose a track.
3Press the PROG button to include the track in the program.
4Repeat steps 2 and 3 to program all the tracks you want.
5Press the PLAY or PAUSE button. The “PGM” symbol stops
flashing and the player plays the selected tracks in the order you
specified.
6To cancel Program play, press the STOP button or open the
player’s cover.
To check the program:
• To check while you are programming, press the PROG button.
Each time you press the PROG button, the next track number
is displayed, in the order you specified.
Personal CD Player - combined.fm Page 10 Monday, June 27, 2005 1:27 PM

11
IS-PA040722A Personal CD player
www.insignia-products.com
Maintenance
Cleaning the case
Wipe with a soft cloth. If the case is very dirty, moisten the cloth with a
weak solution of non-caustic detergent and water.
Cleaning the lens
A dirty lens can cause skipping and can even stop the CD player from
working.
To clean dry particles and dust from the lens:
1Open the CD cover.
2Use a camera lens puffer/brush to blow repeatedly on the lens,
then wipe with the brush to remove dust.
3Blow again to remove loose particles.
To clean fingerprints from the lens:
• If the lens does not come clean with the puffer/brush, wipe it
with a soft cotton cloth.
Cleaning CDs
Using a soft cleaning cloth, wipe the CD from the center outwards.
Caution Do not use solvents such as benzene, thinners, commercial
cleaning fluids, or anti-static sprays designed for vinyl records.
Personal CD Player - combined.fm Page 11 Monday, June 27, 2005 1:27 PM

12
IS-PA040722A Personal CD player
www.insignia-products.com
Troubleshooting
Problem Possible cause Solution
The CD player
does not work. The batteries are low or dead. Replace the batteries.
The AC adapter is not
correctly connected. Check the AC adapter connection.
The CD does
not play. The CD was incorrectly inserted. Reinsert the CD, label up.
The CD is defective. Try another CD.
The CD compartment is not
closed. Close the CD compartment.
There is condensation in the
CD compartment. Remove the CD and leave the cover open for about an hour in a
dry environment.
There is no
sound in the
earphones.
The earphone jack is not
correctly inserted. Reinsert the earphone plut into the jack.
The volume control is turned
down. Increase the volume.
The batteries are low. Replace the batteries or use the
AC adapter.
The CD is defective. Try another CD.
The CD skips
during play. The CD or lens is dirty. Clean or replace the CD, or clean the lens.
Strong shaking or vibrations. Place the CD player on a flat and
stable surface without vibration.
Personal CD Player - combined.fm Page 12 Monday, June 27, 2005 1:27 PM

13
IS-PA040722A Personal CD player
www.insignia-products.com
Specifications
Copyright
© 2005 Insignia. Insignia and the Insignia logo are trademarks of Best Buy Enterprise
Services, Inc. Other brands and product names are trademarks or registered
trademarks of their respective holders. Specifications and features are subject to
change without notice or obligation.
AUDIO
Frequency
response 20 Hz ~ 20 KHz
Wow and flutter Below measurable levels
Number of channels 2 channels (stereo)
Output level Earphones: 15mW (32 Ohms)
GENERAL
Power supply 2 “AA” (LR6) alkaline batteries
Power supply
socket 4.5V ( )
DC socket 3.5 mm
Personal CD Player - combined.fm Page 13 Monday, June 27, 2005 1:27 PM

14
IS-PA040722A Personal CD player
www.insignia-products.com
Bienvenue
Félicitations d’avoir acheté ce produit Insignia de haute qualité. Le
modèle IS-PA040722A est la dernière avancée technologique dans
la conception de lecteur de DVD individuel et a été conçu pour des
performances et une fiabilité totale.
Table des matières
Bienvenue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Mesures de sécurité . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Présentation du lecteur de CD . . . . . . . . . . . . . . . . . . . . . . . . 17
Configuration du lecteur de CD. . . . . . . . . . . . . . . . . . . . . . . . 18
Fonctionnement du lecteur de CD . . . . . . . . . . . . . . . . . . . . . 20
Autres fonctions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Entretien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Dépannage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Caractéristiques . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Español. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Personal CD Player - combined.fm Page 14 Monday, June 27, 2005 1:27 PM

15
IS-PA040722A Personal CD player
www.insignia-products.com
Mesures de sécurité
L'éclair fléché au centre d'un triangle équilatéral prévient
l'utilisateur de la présence de tensions élevées non
isolées dans le lecteur, pouvant constituer un risque de
choc électrique pour les personnes.
Le point d’exclamation au centre d’un triangle équilatéral
prévient l’utilisateur de la présence d’instructions
importantes dans le manuel de l’utilisateur livré avec
l'appareil concernant son utilisation et son entretien.
ATTENTION
RISQUE DE CHOC
ÉLECTRIQUE
NE PAS OUVRIR
Avertissement Cet appareil est conforme à l’article 15 du règlement de la FCC.
Son fonctionnement est soumis aux deux conditions suivantes :
(1) Cet appareil ne doit pas provoquer d’interférence dangereuses
et (2) il doit accepter toute interférence reçue, y compris celles
risquant d’engendrer un fonctionnement indésirable.
Attention Il est recommandé d’utiliser un limiteur de surtension sur la
connexion au secteur. La foudre et les surtensions ne sont pas
couvertes par la garantie de ce produit.
Personal CD Player - combined.fm Page 15 Monday, June 27, 2005 1:27 PM

16
IS-PA040722A Personal CD player
www.insignia-products.com
Avis à l’utilisateur :
Des modifications non autorisées par le fabricant peuvent annuler le
droit de l’utilisateur à faire fonctionner cet appareil.
Cet équipement a été testé et déclaré conforme aux limitations
prévues dans le cadre de la catégorie B des appareils numériques,
définie par l’article 15 du règlement de la FCC. Ces limites ont été
établies pour fournir une protection raisonnable contre les
interférences nuisibles lors d’une installation résidentielle. Cet
équipement génère, utilise et diffuse des ondes radio et s’il n’est pas
installé ni utilisé en conformité avec les instructions dont il fait l’objet,
il peut provoquer des interférences indésirables avec les
communications radio. Cependant, il n’est pas possible de garantir
qu’aucune interférence ne se produira dans une installation
particulière. Si cet équipement est source d’interférences gênant la
réception d'ondes radio ou télévisées (déterminé en éteignant et en
rallumant l’équipement), il est recommandé que l’utilisateur tente de
corriger le problème en suivant au moins l'une des mesures
suivantes :
• Réorienter ou déplacer l’antenne réceptrice.
• Augmenter la distance entre l’équipement et le récepteur.
• Brancher l’équipement dans la prise électrique d’un circuit
différent de celui auquel le récepteur est relié.
• Contacter le revendeur ou un technicien radio/télévision
qualifié.
• Positionner l’unité sur une surface stable.
• Éviter d’installer cet appareil dans les emplacements ci-après :
• Des emplacements recevant la lumière directe du soleil ou
à proximité d’appareils générant un rayonnement
thermique, des chauffages électriques par exemple.
• Au-dessus d’autres équipements stéréophoniques
générant une trop forte quantité de chaleur.
• Des emplacements dont la ventilation est limitée ou très
poussiéreux.
• Des emplacements recevant constamment des vibrations.
• Des emplacements humides.
Personal CD Player - combined.fm Page 16 Monday, June 27, 2005 1:27 PM

17
IS-PA040722A Personal CD player
www.insignia-products.com
Présentation du lecteur de CD
Emplacement des commandes
# Description # Description
1Touche Stop (Arrêt) 7 Prise d’écouteur ou de
casque d’écoute
2 Touche Play/Pause
(Lecture/Pause)
8 Commande du volume
3Touche Skip/Search
(Sauter/Rechercher)
9 Touche Program
(Programmation)
4Touche Skip/Search
(Sauter/Rechercher)
10 Touche Random (Lecture
aléatoire)
12
11
10
9
8
7
6
5
4
3
1
2
Personal CD Player - combined.fm Page 17 Monday, June 27, 2005 1:27 PM

18
IS-PA040722A Personal CD player
www.insignia-products.com
Configuration du lecteur de CD
Alimentation
Pour installer les piles (non fournies) :
1Ouvrir le couvercle du compartiment à piles.
2Insérer deux piles alcalines (LR6) AA. S’assurer que la polarité (+
et -) des piles corresponde à celle du schéma à l'intérieur du
compartiment des piles.
3Replacer le couvercle.
QUAND REMPLACER LES BATTERIES
Lorsque le témoin clignote sur l’écran LCD, remplacer les piles
alcalines par des piles neuves.
5 Fenêtre d'affichage 11 Touche Mode
6 Prise d’entrée CC 12 Touche d’ouverture
Remarque Le fil de l'adaptateur CA doit être déconnecté de la prise d’entrée
CC pour que les piles puissent fonctionner.
# Description # Description
Personal CD Player - combined.fm Page 18 Monday, June 27, 2005 1:27 PM

19
IS-PA040722A Personal CD player
www.insignia-products.com
Pour connecter l’adaptateur CA (non inclus) :
1Brancher la fiche ronde de l’adaptateur CA dans la prise d’entrée
CC du lecteur.
2Brancher le cordon d'alimentation CA dans une prise murale
standard.
Écouteurs ou casque d’écoute
Pour utiliser les écouteurs :
1Insérer la fiche des écouteurs stéréo (inclus) ou le casque
d’écoute stéréo (non inclus) dans la prise PHONES verte.
2Mettre les écouteurs aux oreilles ou porter le casque d'écoute
stéréo.
Avertissement Éviter un niveau sonore excessif ou une écoute prolongée par
écouteurs ou casque d'écoute, ce qui pourrait affecter l'ouïe.
Personal CD Player - combined.fm Page 19 Monday, June 27, 2005 1:27 PM
