InStore Design Display IDD-PSNTSSET User manual

Pipeline Display Table Instructions
ITEM#:IDD-PSNTSSET or IDD-PSNTLSET
PAGE 1

FLANGE 4X
TABLE TOP 1X
CROSS BAR 2X
PIPE LEG ASSEMBLY 2X
SCREWS 16X
COUPLING 1X
INCLUDED PARTS
TOOLS REQUIRED: POWER DRILL WITH PHILLIPS HEAD DRILL BIT
TOOL RECOMMENDED/OPTIONAL: RULER/MEASURING TAPE
PAGE 2

1
SCREW THE CROSS BARS INTO THE COUPLING AS SHOWN.
TIGHTEN IT FULLY.
1
PAGE 3

2
3
2
3
SCREW THE CROSS BAR TO ONE OF THE PIPE LEG ASSEMBLIES AS SHOWN.
TIGHTEN IT FULLY.
TURN THE PIPE LEG AND CROSS BAR ASSEMBLY ONTO ITS SIDE SO THE
CROSS BAR IS FACING UP AS SHOWN.
PAGE 4

4
SCREW THE REMAINING PIPE LEG ASSEMBLY ONTO THE CROSS BAR AS
TIGHT AS POSSIBLE WHILE KEEPING THE 4 LEGS POINTING TO THE GROUND.
4
PAGE 5

5
5A
WITH 2 PEOPLE, FLIP THE PIPE ASSEMBLY ONTO ITS FEET.
5A
SCREW THE FLANGES TO THE TOPS OF THE PIPE LEG ASSEMBLIES.
TIGHTEN IT FULLY.
PAGE 6

7
7
ALLIGN THE ASSEMBLY APPROXIMATELY ON THE CENTER OF TABLE TOP.
USING POWER DRILL SCREW FLANGES TO TABLE TOP.
ALTERNATIVELY, USE TEMPLATE TO ALIGN ASSEMBLY TO THE CENTER OF
TABLE TOP.
6
PLACE THE TABLETOP ONTO A SURFACE THAT WILL NOT DAMAGE THE
FINISH.
NOTE: A RULER OR TAPE MEAURER CAN BE USED TO ASSURE THE FLANGES
ARE EQUALLY SPACED ON ALL SIDES.
6
PAGE 7
