Intel SSR316MJ2 User manual

Intel®Storage System SSR316MJ2
Cable Kit (FMJCABLES)
Installation Guide
Order Number: C75947-001

ii Intel®Storage System SSR316MJ2 Cable Kit
Important Safety Instructions
Important Safety Instructions
Read all caution and safety statements in this document before performing any of the instructions.
See Intel Server Boards and Server Chassis Safety Information at
http://support.intel.com/support/motherboards/server/safecert.htm.
Wichtige Sicherheitshinweise
Lesen Sie zunächst sämtliche Warn- und Sicherheitshinweise in diesem Dokument, bevor Sie eine
der Anweisungen ausführen. Beachten Sie hierzu auch die Sicherheitshinweise zu Intel-
Serverplatinen und -Servergehäusen unter
http://support.intel.com/support/motherboards/server/safecert.htm.
重要安全指导
在执行任何指令之前，请阅读本文档中的所有注意事项及安全声明。 和/或
http://support.intel.com/support/motherboards/server/safecert.htm 上的
Intel Server Boards
and Server Chassis Safety Information
（《Intel
服务器主板与服务器机箱安全信息》）。
Important Safety InstructionsConsignes de sécurité
Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce document
avant de suivre toute instruction. Consultez Intel Server Boards and Server Chassis Safety
Information rendez-vous sur le site
http://support.intel.com/support/motherboards/server/safecert.htm.
Instrucciones de seguridad importantes
Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar
cualquiera de las instrucciones. Vea Intel Server Boards and Server Chassis Safety Information en
http://support.intel.com/support/motherboards/server/safecert.htm.
WARNINGS
Storage system power on/off: The push-button on/off power switch on the
front panel of the storage system does not turn off the AC power. To remove
AC power from the storage system, you must unplug the AC power cord
from either the power supply or wall outlet.
Hazardous conditions—power supply: Hazardous voltage, current, and
energy levels are present inside the power supply enclosure. There are no
user-serviceable parts inside the power supply; servicing should only be done
by technically qualified personnel.

Intel®Storage System SSR316MJ2 Cable Kit iii
Hazardous conditions—devices and cables: Hazardous electrical
conditions may be present on power, telephone, and communication cables.
Turn off the storage system and disconnect telecommunications systems,
networks, modems, and the power cord attached to the storage system before
opening it. Failure to do so can result in personal injury or equipment
damage.
Avoid injury: Lifting the storage system chassis and attaching it to the rack
is a two-person job. If needed, use an appropriate lifting device. A fully
loaded Intel®Storage System SSR316MJ2 weighs approximately 31.8 kg (70
lbs.).
CAUTIONS
Temperature: The operating temperature of the storage system, when
installed in an equipment rack, must not go below 5 °C (41 °F) or rise above
35 °C (95 °F). Extreme fluctuations in temperature can cause a variety of
problems in the storage system.
Ventilation: The equipment rack must provide sufficient airflow to the front
of the storage system to maintain proper cooling. It must also include
ventilation sufficient to exhaust a maximum of 1900 BTUs per hour for a
fully loaded Intel®Storage System SSR316MJ2.
Disclaimer
Information in this document is provided in connection with Intel®products. No license, express or implied, by estoppel or
otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions
of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating
to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability,
or infringement of any patent, copyright or other intellectual property right. Intel products are not designed, intended or
authorized for use in any medical, life saving, or life sustaining applications or for any other application in which the failure of
the Intel product could create a situation where personal injury or death may occur. Intel may make changes to
specifications and product descriptions at any time, without notice.
Intel is a registered trademark of Intel Corporation or its subsidiaries in the United States and other countries.
*Other names and brands may be claimed as the property of others.
Copyright © 2004 Intel Corporation. All Rights Reserved.

iv Intel®Storage System SSR316MJ2 Cable Kit
Revision History
Date Revision
Number Modifications
Sept. 16, 2004 1.0 Initial release
Oct. 7, 2004 1.1 Minor edits
Contents
About the Cable Kit............................................................................................. 7
Kit Contents.............................................................................................................................7
About this Document.......................................................................................... 8
SATA Cables Installation Procedures............................................................... 9
Required Tools........................................................................................................................9
Power Down System and Remove Chassis Cover...............................................................10
Unseat Hard Disk Drives from Hard Disk Drive Bays ...........................................................11
Remove Front Panel Cables from Front Panel Board...........................................................12
Remove Phillips Screws from Fan Assembly........................................................................13
Remove Fan Connectors from Baseboard............................................................................14
Remove Fan Assembly from the System and SATA Cables from the Host Bus Adapter
Cards............................................................................................................................15
Remove I2C Cables from System .........................................................................................16
Remove Power Distribution Board Module Connectors from Backplane Board...................17
Cut the Plastic Ties that Bundle the SATA Cables ...............................................................18
Remove Backplane Board from the System.........................................................................19
Remove Backplane Board from Metal Shroud......................................................................20
Install SATA Cables to Existing Backplane Board................................................................21
Re-connect the I2C Cables....................................................................................................22
Re-connect Power Distribution Board Module Connectors to Backplane Board ..................23
Re-Install Backplane Board...................................................................................................24
Connect SATA Cables to HBA Cards...................................................................................25
Re-insert Fan Assembly into System....................................................................................26
Re-attach Fan Assembly to System......................................................................................27
Re-attach System Fan Assembly Connectors to Baseboard................................................28
Re-seat Front Panel Board Cables.......................................................................................29
Re-seat Hard Disk Drives in Hard Disk Drive Bays...............................................................30
Finishing Up..........................................................................................................................31
Front Panel Cables Installation Procedures................................................... 32
Required Tools......................................................................................................................32
Power Down System and Remove Chassis Cover...............................................................33

Intel®Storage System SSR316MJ2 Cable Kit v
Figure 23. Removing Chassis Cover ....................................................................................33
Remove Front Panel Cables from Front Panel Board...........................................................34
Remove Front Panel Cables from Baseboard ......................................................................35
Install Front Panel Cables on Baseboard..............................................................................36
Re-seat Front Panel Board Cables.......................................................................................37
Finishing Up..........................................................................................................................38
I2C Cables Installation Procedures.................................................................. 39
Required Tools......................................................................................................................39
Power Down System and Remove Chassis Cover...............................................................39
Figure 29. Removing Chassis Cover ....................................................................................39
Remove Front Panel Cables from Front Panel Board...........................................................40
Remove Phillips Screws from Fan Assembly........................................................................41
Remove Fan Connectors from Baseboard............................................................................42
Remove Fan Assembly from the System..............................................................................43
Remove I2C Cables from System .........................................................................................44
Installing I2C Cables in the System.......................................................................................45
Re-insert Fan Assembly into System....................................................................................46
Re-attach Fan Assembly to System......................................................................................47
Re-attach System Fan Assembly Connectors to Baseboard................................................48
Re-seat Front Panel Board Cables.......................................................................................49
Finishing Up..........................................................................................................................50
Figures
Figure 1. Removing Chassis Cover............................................................................................10
Figure 2. Unseat Hard Disk Drives and Hard Disk Drive Carriers ..............................................11
Figure 3. Removing Front Panel Cables.....................................................................................12
Figure 4. Removing Phillips Screws to Release the Fan Assembly............................................13
Figure 5. Removing Fan Connectors from the Baseboard .........................................................14
Figure 6. Removing Fan Assembly and SATA Cable Connectors..............................................15
Figure 7. Removing the I2C Cables from the Backplane Board..................................................16
Figure 8. Removing the Power Distribution Board Module Connectors......................................17
Figure 9. Cutting the Plastic Ties that Bundle the SATA Cables................................................18
Figure 10. Removing the Backplane Board from the System.....................................................19
Figure 11. Removing the Backplane Board from the Metal Shroud............................................20
Figure 12. Installing New Backplane Board into Metal Shroud...................................................21
Figure 13. Re-connecting the I2C Cables....................................................................................22
Figure 14. Re-Connecting the Power Distribution Board Module Connectors............................23
Figure 15. Installing the New Backplane Board in the System...................................................24
Figure 16. Connecting the SATA Cables to the HBA Cards.......................................................25

vi Intel®Storage System SSR316MJ2 Cable Kit
Figure 17. Re-inserting the Fan Assembly into the System........................................................26
Figure 18. Re-attaching the Fan Assembly to the System..........................................................27
Figure 19. Re-attaching the System Fan Assembly Connectors ................................................28
Figure 20. Re-seating Front Panel Board Cables.......................................................................29
Figure 21. Re-seating Hard Disk Drives in Hard Disk Drive Bays...............................................30
Figure 22. Re-attaching the Chassis Cover................................................................................31
Figure 23. Removing Chassis Cover..........................................................................................33
Figure 24. Removing Front Panel Cables...................................................................................34
Figure 25. Removing Front Panel Cables from Baseboard ........................................................35
Figure 26. Installing Front Panel Cables on Baseboard .............................................................36
Figure 27. Re-seating Front Panel Board Cables.......................................................................37
Figure 28. Re-attaching the Chassis Cover................................................................................38
Figure 29. Removing Chassis Cover..........................................................................................39
Figure 30. Removing Front Panel Cables...................................................................................40
Figure 31. Removing Phillips Screws to Release the Fan Assembly .........................................41
Figure 32. Removing Fan Connectors from the Baseboard .......................................................42
Figure 33. Removing Fan Assembly...........................................................................................43
Figure 34. Removing the I2C Cables from the Backplane Board................................................44
Figure 35. Installing I2C Cables...................................................................................................45
Figure 36. Re-inserting the Fan Assembly into the System........................................................46
Figure 37. Re-attaching the Fan Assembly to the System..........................................................47
Figure 38. Re-attaching the System Fan Assembly Connectors ................................................48
Figure 39. Re-seating Front Panel Board Cables.......................................................................49
Figure 40. Re-attaching the Chassis Cover................................................................................50

Intel®Storage System SSR316MJ2 Cable Kit 7
About the Cable Kit
Enclosed is your new Intel®FMJCABLES Cable Kit. The Intel®FMJCABLES Cable Kit contains
16 SATA Cables, Two IDE Cables, One Front Panel Cable, and Three I2C Cables.
 NOTE
This document describes how to install the Intel®FMJCABLES SATA
Cables, Intel®FMJCABLES IDE Cables, the Intel®FMJCABLES Front
Panel Cable, and Intel®FMJCABLES I2C Cables into the Intel®Storage
System SSR316MJ2.
Kit Contents
•Intel®FMJCABLES SATA Cables
•Intel®FMJCABLES IDE Cables
•Intel®FMJCABLES Front Panel Cable
•Intel®FMJCABLES I2C Cables

8 Intel®Storage System SSR316MJ2 Cable Kit
About this Document
The Intel®FMJCABLES Cable Kit contains SATA Cables, Front Panel Cables, and I2C Cables.
The Intel®FMJCABLES Installation Guide contains separate installation instructions for each of
the three sets of cables.

Intel®Storage System SSR316MJ2 Cable Kit 9
SATA Cables Installation Procedures
Required Tools
•Cross-head (Number 1 Size Phillips*) screwdriver
•Wire cutters

10 Intel®Storage System SSR316MJ2 Cable Kit
Power Down System and Remove Chassis Cover
A. From within the Intel®Storage System Console, power down your system.
B. Remove both AC Power cords from the AC Power inputs on your system. See Figure 1.
C. Loosen the two thumb screws from the top of the chassis cover. See Figure 1.
D. Facing the front of the chassis, push the top cover rearward, and then lift it up to remove it.
A
D
B
C
C
Figure 1. Removing Chassis Cover

Intel®Storage System SSR316MJ2 Cable Kit 11
Unseat Hard Disk Drives from Hard Disk Drive Bays
A. Pressing down on the hard disk drive handle release mechanisms, unlatch the handle on the
hard disk drives and hard disk drive carriers. See Figure 2.
B. Rotate the hard disk drive and hard disk drive carrier handles downward. See Figure 2.
C. Slide the hard disk drives and hard disk drive carriers at least halfway out of the hard disk drive
bays. See Figure 2. It is not necessary to completely remove the hard disk drives from the bays.
A
B
C
Figure 2. Unseat Hard Disk Drives and Hard Disk Drive Carriers

12 Intel®Storage System SSR316MJ2 Cable Kit
Remove Front Panel Cables from Front Panel Board
A. Remove the Primary IDE Cable labeled J5 from its connector receptacle on the front panel
board. See Figure 3.
B. Remove the Secondary IDE Cable labeled J3 from its connector receptacle on the front panel
board. See Figure 3.
C. Remove the Front Panel Cable labeled J1 from its connector receptacle on the front panel
board. See Figure 3.
D. Remove the front panel power connector from its connector receptacle on the front panel board.
See Figure 3.
E. Move the front panel cables from underneath the fan assembly shroud and backplane and away
from the front part of the system.
ABCD
Figure 3. Removing Front Panel Cables

Intel®Storage System SSR316MJ2 Cable Kit 13
Remove Phillips Screws from Fan Assembly
A. Using a Number 1 size Phillips Screwdriver, remove the two Phillips screws (there is one screw
on each side of the system) that hold the system fan assembly in place. See Figure 4. Set these
screws aside. They will be re-installed later.
A
Figure 4. Removing Phillips Screws to Release the Fan Assembly

14 Intel®Storage System SSR316MJ2 Cable Kit
Remove Fan Connectors from Baseboard
A. Remove the wire connector for Fan 3 from the baseboard header labeled J2K1. See Figure 5.
B. Remove the wire connector for Fan 4 from the baseboard header labeled J4K2. See Figure 5.
C. Remove the wire connector for Fan 5 from the baseboard header labeled J4K4. See Figure 5.
A
A
B
C
B
C
Figure 5. Removing Fan Connectors from the Baseboard

Intel®Storage System SSR316MJ2 Cable Kit 15
Remove Fan Assembly from the System and SATA
Cables from the Host Bus Adapter Cards
A. Simultaneously pull up on both sides of the fan assembly and remove the fan assembly from
the storage system. Set the fan assembly on a static-free surface.
B. Carefully remove the 16 SATA Cable connectors from the three SATA Host Bus Adapter
Cards near the back of the system. Make a note of the number labels on each SATA Cable. The
new SATA Cables will connect to the SATA Host Bus Adapter Cards in the same numeric
order. See Figure 6.
A
A
B
Figure 6. Removing Fan Assembly and SATA Cable Connectors

16 Intel®Storage System SSR316MJ2 Cable Kit
Remove I2C Cables from System
A. Make a note of the header positions of the three I2C Cable connectors. After installation of the
SATA Cables has been completed, you will re-connect these connectors to the same headers.
Carefully remove the I2C Cable connector labeled JP4 from its I2C Cable header on the
backplane board. Carefully remove the I2C Cable connector labeled SL2J6 from its I2C Cable
header in the HBA Card set. See Figure 7.
B. Carefully remove the I2C Cable connector labeled JP6 from its I2C Cable header on the
backplane board. Carefully remove the I2C Cable connector labeled SL3J6 from its I2C Cable
header in the HBA Card set. See Figure 7.
C. Carefully remove the I2C Cable connector labeled JP7 from its I2C Cable header on the
backplane board. Carefully remove the I2C Cable connector labeled SL4J6 from its I2C Cable
header in the HBA Card set. See Figure 7. Set the I2C Cable connectors on a static-free surface.
ABC
ABC
Figure 7. Removing the I2C Cables from the Backplane Board

Intel®Storage System SSR316MJ2 Cable Kit 17
Remove Power Distribution Board Module Connectors
from Backplane Board
A. Carefully remove the two 12-pin Power Distribution Board Module connectors from the
backplane board. See Figure 8.
A
Figure 8. Removing the Power Distribution Board Module Connectors

18 Intel®Storage System SSR316MJ2 Cable Kit
Cut the Plastic Ties that Bundle the SATA Cables
A. Cut the plastic cable ties that bundle the SATA Cables. See Figure 9.
A
Figure 9. Cutting the Plastic Ties that Bundle the SATA Cables

Intel®Storage System SSR316MJ2 Cable Kit 19
Remove Backplane Board from the System
A. Using a Number 1 size Phillips Screwdriver, remove the two Phillips screws on each side of the
system that hold the backplane board in place. See Figure 10. Set these screws aside. They will
be re-installed later.
B. Using a Number 1 size Phillips Screwdriver, remove the four Phillips screws from the steel lip
that holds the backplane board in place. See Figure 10. Set these screws aside. They will be re-
installed later.
C. Carefully remove the backplane board from the storage system. Pay attention to sharp edges on
the backplane board. See Figure 10.
Figure 10. Removing the Backplane Board from the System

20 Intel®Storage System SSR316MJ2 Cable Kit
Remove Backplane Board from Metal Shroud
A. Using a Number 1 size Phillips Screwdriver, remove the two Phillips screws on each side of the
backplane board that hold the backplane board in its metal shroud. See Figure 11. Set these
screws aside. They will be re-installed later.
B. Carefully remove the backplane board from the metal shroud. Pay attention to sharp edges on
the backplane board and metal shroud. See Figure 11.
C. Remove all SATA Cable connectors from the backplane board. Remove the SATA Cables
from the system.
A
A
AA
A
B
C
Figure 11. Removing the Backplane Board from the Metal Shroud
