Intel EVO UA210021-GG User manual

INS TA LLAT I ON GUID E | 06.20 2 1
UA210021-GG EVO DIGITAL TABLE 4 SIDES DLB ES COSTCO

Table (x1)
Dynamic LightBox Header (x1) M6x25 Screw (x4)
M6x12 Screw (x4)
INFORMATION
Installation package
2
M6x25mm - Qty 4 pcs
M6x12mm - Qty 4 pcs
for installing divider
Fact Tag Holder (x6)

Phillips Screwdriver (X1)
Alcohol Pad (X2)
Micro Fiber Cleaning Cloth (X1)
Gloves (X2)
Tools provided for Installation
INFORMATION
3


OVERVIEW
4
Expected Result
4 LED Sides

Remove the long side plywood edge.
Cut the straps on the crate. Open the crate.
Tool Box
Dynamic Light-Box Divider
Tool Box
Ins t a llation Ins t r uctions
5
1
3 4
2
Dynamic Light-Box Divider

FORKLIFT
FORKLIFT
Release the thumb screws and remove the cover plates. Insert the forks through the holes.
 Re-install the cover plates.
Ins t a llation Ins t r uctions
6
5
7 8
6

Dynamic Light-Box Divider (DLB)
2 PEOPLE REQUIRED
CAUTION DO NOT PINCH CABLES
Open each table-top by pulling them towards you. Install the DLB divider onto the table frame in the center area.
 Install right side DLB divider with provided screws.
GENTLE QUICK PULL WILL RELEASE
CAUTION DO NOT PINCH CABLES CAUTION DO NOT PINCH CABLES
Ins t a llation Ins t r uctions
7
9
11 12
10
M6x25
Long Screw
(x2)
M6x12
Short Screw
(x2)

Connect 4 cables on one side and 2 cables on the other side.
Ins t a llation Ins t r uctions
8
13 14
15 16
Find the AC cable in the display. Wire the AC cable through the service hole on the workboard.

If the AC power is from the ceiling.



Power up the display.
Choose one side and use the screw driver to remove the screw and
top cover plate.
 Wire the power cable through the top hole and the channel
on the header.
Ins t a llation Ins t r uctions
9
17 18
19 20
Ceiling Power Steps - Op�on 1


Adjust feet levelers with provided tool. Do this on all 4 corners.

Tighten feet and adjust for leveling.
REQUIRED STEP
Ins t a llation Ins t r uctions
10
21
23 24
22
Ceiling Power Steps - Op�on 2
Wire the power cable next to the Divider.

Ins t a llation Ins t r uctions
11
25 26
Place fact tag holders on table top. 

Troubleshoo�ng Guide:
No Power
No Video


No Power/ No Video 
ISSUE RESOLUTION
Display Standards Check List:
Func�onality Check List:





B:Make sure Dynamic Light Box has moving lights.
 AA
A
D
A
C
B
CB
D:Verify product selector has content. Click through various

Troubleshooting
INFORMATION
12

Display wiring diagram
TECHNICAL INFORMATION
13
