Intel AX965Q Installation and operation manual


Intel® Q965 LGA775 Core™ 2 Extreme/ Core™ 2 Quad/
Core™ 2 Duo/ Core™ Due/ Pentium 4/ Celeron D ATX
Main Board

Packing List
Before you begin installing your single board, please make sure that the
following parts have been shipped.
 1 x Intel Q965 ATX Main board
 1 x CD-ROM contains the followings:
•User’s Manual in PDF file
•Drivers
 4 x COM cable (9-pin, 260mm)
 1 x 2-in-1 FD/ATA cable
 4 x SATA cable kit (SATA/Power)
 1 x Startup Manual
Disclaimer and Notice
The manufacturer reserves the right to make changes,
without notice, to any product, including circuits and/or
software described or contained in this manual in order to
improve design and/or performance. The manufacturer
assumes no responsibility or liability for the use of the
described product(s), conveys no license or title under
any patent, copyright, or masks work rights to these
products, and makes no representations or warranties
that these products are free from patent, copyright, or
mask work right infringement, unless otherwise specified.
For the detail product information, please refer to user’s
manual.
15GS0600054T26

Product Overview
Specifications
System
CPU Supports Intel LGA 775 Core 2 Extreme/Core 2 Quad/Core 2 Duo/Core Duo/
Pentium 4 /Celeron D CPU with 65nm process technology
FSB 1066/800/533 MHz
BIOS Award 16 Mb SPI BIOS
System Chipset Intel 82Q965 GMCH/ ICH8
I/O Chipset Winbond W83627DHG-A
Memory 4 x 240-pin DIMM sockets support up to 8GB Dual Channel DDR2 800/667/533
SDRAM

System
H/W Status Monitor Monitoring temperatures, voltages, and cooling fan status. Auto throttling
control when CPU overheats
Expansion Slots One PCI Express x16, one PCI Express x4, five PCI slots (PCI Rev. 2.2
compliant)
S3 S3 Support
Smart Fan Control Yes
I/O
MIO 1x EIDE (Ultra DMA 133) , 8 x SATA 1 x FDD, 1 x LPT, 4 x RS-232, 1 x K/B,
1 x Mouse
USB 10 x USB 2.0 ports
IEEE-1394A / e-SATA 1 x IEEE-1394 (Optional), 1 x e-SATA
Display
Chipset Intel 82Q965 GMCH integrated Graphics Media Accelerator 3000
Display Memory Intel DVMT 4.0 supports 256 MB video memory
Resolution 2048 x 1536 @ 32 bpp (75 Hz)
VGA/LCD Interface PCI-E X16 VGA interface
HMDI Through ADD2 HMDI card
LVDS Through ADD2 LVDS card
DVI Through ADD2 DVI card
Secondary VGA Through ADD2 VGA card
Audio
AC97 Codec ADI AD1988 7.1-CH High Definition Audio Codec
Audio Interface Mic in, Line in, CD Audio in, Line out, 6-CH (6 jacks)
Ethernet
LAN1 Intel 82566DM PCI-E Gigabit LAN
Jumpers
Label Function Note
CLRTC Clear CMOS Normal *
Clear CMOS
KBPWR Keyboard Power +5V *
+5VSB

Connectors
Label Function Note
AAFP Front Panel Audio Connector
CPU_FAN,
CHA_FAN1,
CHA_FAN2
CPU & Chassis Fan Connector
CHA_FAN1
CHA_FAN2
CPU_FAN
F_PANEL System Panel Connector
IE1394_2
(Optional)
IEEE 1394a Connector
PWR_FAN Power Fan Connector
SPDIF_OUT Digital Audio Connector
TPM_SLOT1 Trusted Platform Module
(TPM) Connector
