Intel® Desktop Board
DX58OG
Technical Product Specification
January 2012
Order Number: G13833-002
The Intel Desktop Board DX58OG may contain design defects or errors known as errata that may cause the product to deviate from published specifications.
Current characterized errata are documented in the Intel Desktop Board DX58OG Specification Updates.

Revision History
Revision Revision History Date
-001 First release of the Intel®Desktop Board DX58OG Technical Product
Specification
November 2010
-002 Specification changes January 2012
This product specification applies to only the standard Intel®Desktop Board DX58OG with BIOS
identifier SOX5820J.86A.
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,
EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS
GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR
SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR
IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR
WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT
OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. UNLESS OTHERWISE AGREED IN
WRITING BY INTEL, THE INTEL PRODUCTS ARE NOT DESIGNED NOR INTENDED FOR ANY APPLICATION IN
WHICH THE FAILURE OF THE INTEL PRODUCT COULD CREATE A SITUATION WHERE PERSONAL INJURY OR
DEATH MAY OCCUR.
All Intel®desktop boards are evaluated as Information Technology Equipment (I.T.E.) for use in personal
computers (PC) for installation in homes, offices, schools, computer rooms, and similar locations. The
suitability of this product for other PC or embedded non-PC applications or other environments, such as
medical, industrial, alarm systems, test equipment, etc. may not be supported without further evaluation by
Intel.
Intel Corporation may have patents or pending patent applications, trademarks, copyrights, or other
intellectual property rights that relate to the presented subject matter. The furnishing of documents and
other materials and information does not provide any license, express or implied, by estoppel or otherwise,
to any such patents, trademarks, copyrights, or other intellectual property rights.
Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”
or “undefined.” Intel reserves these for future definition and shall have no responsibility whatsoever for
conflicts or incompatibilities arising from future changes to them.
Intel desktop boards may contain design defects or errors known as errata, which may cause the product to
deviate from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your
product order.
Intel, Core i7, and Xeon are registered trademarks of Intel Corporation in the U.S. and other countries.
* Other names and brands may be claimed as the property of others.
Copyright ©2010-2012, Intel Corporation. All rights reserved.

iii
Board Identification Information
Basic Desktop Board DX58OG Identification Information
AA Revision BIOS Revision Notes
G10926-203 SOX5820J.86A 1,2
Notes:
1. The AA number is found on a small label on the component side of the board.
2. The X58 Express Chipset used on this AA revision consists of the following component:
Device Stepping S-Spec Numbers
Specification Changes or Clarifications
Table 1 indicates the Specification Changes or Specification Clarifications that apply to
the Intel®Desktop Board DX58OG.
Table 1. Specification Changes or Clarifications
Date Type of Change Description of Changes or Clarifications
January 2012 Specification
Changes
•Updated Table 2 on page 11 to correct an error in the
callouts.
•Updated Section 1.6.2 on page 21 to delete reference to
two red-colored eSATA connectors on the back panel.
Errata
Current characterized errata, if any, are documented in a separate Specification
Update. See http://developer.intel.com/products/desktop/motherboard/index.htm
for the latest documentation.

Intel Desktop Board D410PT Technical Product Specification
iv

v
Preface
This Technical Product Specification (TPS) specifies the board layout, components,
connectors, power and environmental requirements, and the BIOS for Intel®Desktop
Board DX58OG.
Intended Audience
The TPS is intended to provide detailed, technical information about Intel Desktop
Board DX58OG and its components to the vendors, system integrators, and other
engineers and technicians who need this level of information. It is specifically not
intended for general audiences.
What This Document Contains
Chapter Description
1 A description of the hardware used on Intel Desktop Board DX58OG
2 A map of the resources of the Intel Desktop Board
3 The features supported by the BIOS Setup program
4 A description of the BIOS error messages, beep codes, and POST codes
5 Regulatory compliance and battery disposal information
Typographical Conventions
This section contains information about the conventions used in this specification. Not
all of these symbols and abbreviations appear in all specifications of this type.
Notes, Cautions, and Warnings
NOTE
Notes call attention to important information.
CAUTION
Cautions are included to help you avoid damaging hardware or losing data.

Intel Desktop Board DX58OG Technical Product Specification
vi
Other Common Notation
# Used after a signal name to identify an active-low signal (such as USBP0#)
GB Gigabyte (1,073,741,824 bytes)
GB/s Gigabytes per second
Gb/s Gigabits per second
GT/s Giga transfers per second
KB Kilobyte (1024 bytes)
Kbit Kilobit (1024 bits)
kbits/s 1000 bits per second
MB Megabyte (1,048,576 bytes)
MB/s Megabytes per second
Mbit Megabit (1,048,576 bits)
Mbits/s Megabits per second
xxh An address or data value ending with a lowercase h indicates a hexadecimal value.
x.x V Volts. Voltages are DC unless otherwise specified.
* This symbol is used to indicate third-party brands and names that are the property of their
respective owners.

vii
Contents
1Product Description
1.1Overview........................................................................................ 11
1.1.1Feature Summary ................................................................ 11
1.1.2Board Layout
....................................................................... 13
1.1.3Block Diagram ..................................................................... 15
1.2Legacy Considerations...................................................................... 16
1.3Online Support................................................................................ 16
1.4Processor ....................................................................................... 16
1.5System Memory .............................................................................. 17
1.5.1Memory Configurations ......................................................... 18
1.6Intel®X58 Chipset........................................................................... 20
1.6.1USB ................................................................................... 20
1.6.2Serial ATA Interfaces ............................................................ 21
1.7Real-Time Clock Subsystem .............................................................. 22
1.8Legacy I/O Controller
....................................................................... 22
1.8.1Consumer Infrared (CIR)
....................................................... 22
1.9Audio Subsystem............................................................................. 23
1.9.1Audio Subsystem Software .................................................... 23
1.9.2Audio Connectors and Headers
............................................... 24
1.10LAN Subsystem
............................................................................... 25
1.10.1Intel®82567L Gigabit Ethernet Controller ................................ 25
1.10.2LAN Subsystem Software....................................................... 26
1.10.3RJ-45 LAN Connector with Integrated LEDs .............................. 26
1.11Hardware Management Subsystem .................................................... 27
1.11.1Hardware Monitoring and Fan Control...................................... 27
1.11.2Fan Monitoring
..................................................................... 27
1.11.3Chassis Intrusion and Detection.............................................. 27
1.11.4Thermal Monitoring .............................................................. 28
1.12Power Management ......................................................................... 29
1.12.1ACPI................................................................................... 29
1.12.2Hardware Support ................................................................ 33
1.13Onboard Power and Reset Buttons ..................................................... 38
2Technical Reference
2.1Memory Resources .......................................................................... 39
2.1.1Addressable Memory............................................................. 39
2.1.2Memory Map........................................................................ 41
2.2Connectors and Headers................................................................... 41
2.2.1Back Panel Connectors
.......................................................... 42
2.2.2Component-side Connectors and Headers ................................ 43
2.3Jumper Block
.................................................................................. 53

Intel Desktop Board DX58OG Technical Product Specification
viii
2.4Mechanical Considerations ................................................................ 55
2.4.1Form Factor......................................................................... 55
2.5Electrical Considerations
................................................................... 56
2.5.1Power Supply Considerations ................................................. 56
2.5.2Fan Header Current Capability................................................ 57
2.5.3Add-in Board Considerations .................................................. 57
2.6Thermal Considerations
.................................................................... 57
2.7Reliability ....................................................................................... 60
2.8Environmental ................................................................................ 60
3Overview of BIOS Features
3.1Introduction ................................................................................... 61
3.2BIOS Flash Memory Organization
....................................................... 62
3.3Resource Configuration .................................................................... 62
3.3.1PCI Autoconfiguration ........................................................... 62
3.4System Management BIOS (SMBIOS)................................................. 63
3.5Legacy USB Support ........................................................................ 63
3.6BIOS Updates ................................................................................. 64
3.6.1Language Support ................................................................ 64
3.6.2Custom Splash Screen .......................................................... 65
3.7BIOS Recovery................................................................................ 65
3.8Boot Options................................................................................... 66
3.8.1Optical Drive Boot ................................................................ 66
3.8.2Network Boot....................................................................... 66
3.8.3Booting Without Attached Devices........................................... 66
3.8.4Changing the Default Boot Device During POST ........................ 66
3.9Adjusting Boot Speed....................................................................... 67
3.9.1Peripheral Selection and Configuration..................................... 67
3.9.2BIOS Boot Optimizations ....................................................... 67
3.10BIOS Security Features .................................................................... 68
3.11BIOS Performance Features .............................................................. 69
4Error Messages and Beep Codes
4.1Speaker ......................................................................................... 71
4.2BIOS Beep Codes ............................................................................ 71
4.3Front-panel Power LED Blink Codes
.................................................... 72
4.4BIOS Error Messages ....................................................................... 72
4.5Port 80h POST Codes ....................................................................... 73

Contents
ix
5Regulatory Compliance and Battery Disposal Information
5.1Regulatory Compliance..................................................................... 79
5.1.1Safety Standards.................................................................. 79
5.1.2European Union Declaration of Conformity Statement
................ 80
5.1.3Product Ecology Statements................................................... 81
5.1.4EMC Regulations .................................................................. 83
5.1.5ENERGY STAR* 5.0, e-Standby, and ErP Compliance ................. 86
5.1.6Regulatory Compliance Marks (Board Level)
............................. 87
5.2Battery Disposal Information............................................................. 88
Figures
1. Major Board Components.................................................................. 13
2. Block Diagram ................................................................................ 15
3. Memory Channel and DIMM Configuration ........................................... 19
4. Back Panel Audio Connectors ............................................................ 24
5. LAN Connector LED Locations............................................................ 26
6. Thermal Sensors and Fan Headers ..................................................... 28
7. Locations of Onboard LED Indicators .................................................. 37
8. Location of the Power and Reset Buttons ............................................ 38
9. Detailed System Memory Address Map ............................................... 40
10. Back Panel Connectors ..................................................................... 42
11. Component-side Connectors and Headers ........................................... 43
12. Connection Diagram for Front Panel Header ........................................ 50
13. Connection Diagram for Front Panel USB Headers ................................ 52
14. Location of the Jumper Block............................................................. 53
15. Board Dimensions ........................................................................... 55
16. Localized High Temperature Zones..................................................... 58

Intel Desktop Board DX58OG Technical Product Specification
x
Tables
1. Specification Changes or Clarifications ..................................................iii
2. Feature Summary............................................................................ 11
3. Components Shown in Figure 1 ......................................................... 14
4. Supported Memory Configurations ..................................................... 18
5. Audio Jack Support.......................................................................... 23
6. LAN Connector LED States ................................................................ 26
7. Effects of Pressing the Power Switch .................................................. 30
8. Power States and Targeted System Power........................................... 31
9. Wake-up Devices and Events ............................................................ 32
10. System Memory Map ....................................................................... 41
11. Component-side Connectors and Headers Shown in Figure 11................ 44
12. Front Panel Audio Header ................................................................. 45
13. Serial ATA Connectors...................................................................... 45
14. Front Panel IEEE 1394a Header ......................................................... 45
15. Chassis Intrusion Header.................................................................. 46
16. Front and Rear Chassis (3-Pin) Fan Headers
........................................ 46
17. Processor and Rear Chassis 2 (4-Pin) Fan Headers ............................... 46
18. Auxiliary Front Panel Power/Sleep LED Header..................................... 47
19. Processor Core Power Connector........................................................ 48
20. Main Power Connector...................................................................... 49
21. Auxiliary PCI Express Graphics Power Connector .................................. 49
22. Front Panel Header .......................................................................... 50
23. States for a One-Color Power LED...................................................... 51
24. States for a Two-Color Power LED...................................................... 51
25. BIOS Setup Configuration Jumper Settings.......................................... 54
26. Recommended Power Supply Current Values ....................................... 56
27. Fan Header Current Capability........................................................... 57
28. Thermal Considerations for Components ............................................. 59
29. Environmental Specifications............................................................. 60
30. BIOS Setup Program Menu Bar.......................................................... 62
31. BIOS Setup Program Function Keys.................................................... 62
32. Acceptable Drives/Media Types for BIOS Recovery ............................... 65
33. Boot Device Menu Options ................................................................ 66
34. Supervisor and User Password Functions............................................. 68
35. BIOS Beep Codes ............................................................................ 71
36. Front-panel Power LED Blink Codes.................................................... 72
37. BIOS Error Messages ....................................................................... 72
38. Port 80h POST Code Ranges.............................................................. 73
39. Port 80h POST Codes ....................................................................... 74
40. Typical Port 80h POST Sequence........................................................ 77
41. Safety Standards............................................................................. 79
42. EMC Regulations ............................................................................. 83
43. Regulatory Compliance Marks............................................................ 87

11
1Product Description
1.1 Overview
1.1.1 Feature Summary
Table 2 summarizes the major features of the board.
Table 2. Feature Summary
Form Factor ATX (12.00 inches by 9.60 inches [304.80 millimeters by 243.84 millimeters])
Processor •Intel®Core™ i7 and Intel®Xeon®Processors in an LGA1366 socket
Memory •Six 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM) sockets
•Support for DDR3 2400 MHz, 2133 MHz, 1866 MHz, 1600 MHz, 1333 MHz, and
1066 MHz DIMMs.
―Speeds over 1600 Mhz via XMP profiles
•Support for up to 24 GB of system memory with 6 DIMMs using 4 Gb memory
technology
•Support for ECC and non-ECC memory
•XMP version 1.2
Chipset Intel®X58 Chipset, consisting of:
•Intel®X58 I/O Hub (IOH)
•Intel®82801IJR I/O Controller Hub (ICH10R)
Audio Intel®High Definition Audio subsystem using the Realtek* ALC892 audio codec.
Legacy I/O Control Winbond W83677HG-I legacy I/O controller for Consumer Infrared (CIR)
Peripheral
Interfaces
•Two USB 3.0 ports are implemented with stacked back panel connectors (blue)
•Twelve USB 2.0 ports:
―Six ports are implemented with stacked back panel connectors (black)
―Six front panel ports implemented through four internal headers
•Eight internal SATA interfaces with RAID support:
―Two SATA 6 Gb/s interfaces through Marvel 88SE9128 controller (blue)
―Six SATA 3 Gb/s interfaces through the ICH10R (black)
•Two IEEE 1394a ports:
―One port via a back panel connector
―One port via an internal header for front panel cabling
BIOS •Intel®BIOS resident in the Serial Peripheral Interface (SPI) Flash device
•Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and System Management BIOS (SMBIOS)
Instantly Available
PC Technology
•Support for PCI Local Bus Specification Revision 2.2
•Support for PCI Express* Revision 2.0
•Suspend to RAM support
•Wake on PCI, front panel, CIR, and USB ports
continued

Intel Desktop Board DX58OG Technical Product Specification
12
Table 2. Feature Summary (continued)
LAN Support Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel 82567L Gigabit
Ethernet Controller
Expansion
Capabilities
•One Conventional PCI* bus add-in card connector (SMBus routed to the
Conventional PCI bus add-in card connector)
•Two PCI Express 2.0 x16 bus add-in card connectors
•Three PCI Express 1.1 x1 bus add-in card connectors
Hardware Monitor
Subsystem
•Hardware monitoring and fan control ASIC Heceta 6P
•Voltage sense to detect out of range power supply voltages
•Thermal sense to detect out of range thermal values
•Four fan headers using PWM control
•Three fan sense inputs used to monitor fan activity
•Fan speed control using voltage control (4-pin fan headers front and rear)
•Support for Product Environmental Control Interface (PECI)

Product Description
13
1.1.2 Board Layout
Figure 1 shows the location of the major components on Intel Desktop Board DX58OG.
Figure 1. Major Board Components
Table 3 lists the components identified in Figure 1.

Intel Desktop Board DX58OG Technical Product Specification
14
Table 3. Components Shown in Figure 1
Item/callout
from Figure 1 Description
A Front panel audio header
B PCI Express x1 bus connector
C PCI Express x1 bus connector
D Conventional PCI bus add-in card connector
E PCI Express x16 bus add-in card connector (Secondary)
F PCI Express x1 bus add-in card connector
G PCI Express x16 bus add-in card connector (Primary)
H Rear chassis fan header
I Intel 82X58 IO Hub (IOH)
J Back panel connectors
K Processor fan header
L Processor core power connector (2 x 4)
M LGA1366 processor socket
N DIMM 4 socket
O DIMM 1 socket
P DIMM 5 socket
Q DIMM 2 socket
R DIMM 6 socket
S DIMM 3 socket
T Main power connector (2 x 12)
U Front chassis fan header
V Intel 82801IJR I/O Controller Hub (ICH10R)
W SATA connectors (six 3 Gb/s interfaces (black) and two 6 Gb/s interfaces (blue))
X Chassis intrusion header
Y Piezoelectric speaker
Z Front panel USB headers (3)
AA Consumer IR receiver (input) header
BB Consumer IR emitter (output) header
CC BIOS Setup configuration jumper block
DD Front panel header
EE Auxiliary front panel power LED header
FF Post Code LED display
GG IEEE 1394a front panel header
HH Battery
II Onboard Reset button
JJ Onboard Power button
KK Auxilliary chassis fan header
LL Status LEDs

Product Description
15
1.1.3 Block Diagram
Figure 2 is a block diagram of the major functional areas of the board.
Figure 2. Block Diagram

Intel Desktop Board DX58OG Technical Product Specification
16
1.2 Legacy Considerations
This board differs from other Intel Desktop Board products, with specific changes
including (but not limited to) the following:
•No parallel port
•No floppy drive connector
•No serial port
•No PS/2 connectors
1.3 Online Support
To find information about… Visit this World Wide Web site:
Intel Desktop Board DX58OG http://www.intel.com/products/motherboard/index.htm
Desktop Board Support http://www.intel.com/p/en_US/support?iid=hdr+support
Available configurations for the Intel
Desktop Board DX58OG
http://ark.intel.com
Supported processors http://processormatch.intel.com
Chipset information http://www.intel.com/products/desktop/chipsets/index.htm
BIOS and driver updates http://downloadcenter.intel.com
Tested memory http://www.intel.com/support/motherboards/desktop/sb/CS-
025414.htm
Integration information http://www.intel.com/support/go/buildit
1.4 Processor
The board is designed to support the Intel Core i7 and Intel Xeon Processors in an
LGA1366 socket.
Other processors may be supported in the future. This board is designed to support
processors with a maximum wattage of 130 W. The processor listed above is only
supported when falling within the wattage requirements of the Intel Desktop Board
DX58OG. See the Intel web site listed below for the most up-to-date list of supported
processors.
For information about… Refer to:
Supported processors http://processormatch.intel.com
CAUTION
Use only the processors listed on the web site above. Use of unsupported processors
can damage the board, the processor, and the power supply.
#
INTEGRATOR’S NOTE
This board has specific requirements for providing power to the processor. Refer to
Section 2.5.1 on page 56 for information on power supply requirements for this board.

Product Description
17
1.5 System Memory
The board has six DIMM sockets and supports the following memory features:
•1.5 V, 1.3 V, and 1.25 V DDR3 SDRAM DIMMs
•Three independent memory channels with interleaved mode support
•Unbuffered, single-sided or double-sided DIMMs with the following restriction:
Double-sided DIMMs with x16 organization are not supported.
•24 GB maximum total system memory. Refer to Section 2.1.1 on page 39 for
information on the total amount of addressable memory.
•Minimum total system memory: 1 GB
•ECC and non-ECC DIMMs
•Serial Presence Detect
•DDR3 2400 MHz, 2133 MHz, 1866 MHz, 1600 MHz, 1333 MHz, and 1066 MHz
SDRAM DIMMs
•XMP version 1.2 performance profile support for memory speeds above 1600 MHz
NOTE
To be fully compliant with all applicable DDR SDRAM memory specifications, the board
should be populated with DIMMs that support the Serial Presence Detect (SPD) data
structure. This allows the BIOS to read the SPD data and program the chipset to
accurately configure memory settings for optimum performance. If non-SPD memory
is installed, the BIOS will attempt to correctly configure the memory settings, but
performance and reliability may be impacted or the DIMMs may not function under the
determined frequency.

Intel Desktop Board DX58OG Technical Product Specification
18
Table 4 lists the supported DIMM configurations.
Table 4. Supported Memory Configurations
DIMM
Capacity Configuration (Note)
SDRAM
Density
SDRAM Organization
Front-side/Back-side
Number of SDRAM
Devices
512 MB SS 1 Gbit 64 M x16/empty 4
1024 MB SS 1 Gbit 128 M x8/empty 8
1024 MB SS 2 Gbit 128 M x16/empty 4
2048 MB DS 1 Gbit 128 M x8/128 M x8 16
2048 MB SS 2 Gbit 128 M x16/empty 8
4096 MB DS 2 Gbit 256 M x8/256 M x8 16
8192 MB DS 4 Gbit 512 M x8/512 M x8 16
Note: “DS” refers to double-sided memory modules (containing two rows of SDRAM) and “SS” refers to
single-sided memory modules (containing one row of SDRAM).
For information about… Refer to:
Tested Memory http://www.intel.com/support/motherboards/desktop/sb/CS-
025414.htm
XMP Tested Memory http://www.intel.com/personal/gaming/extremememory.htm
1.5.1 Memory Configurations
The Intel Core i7 and Intel Xeon Processors support the following types of memory
organization:
•Tri/Dual channel (Interleaved) mode. This mode offers the highest
throughput for real world applications. Interleaving reduces overall memory
latency by accessing the DIMM memory sequentially. Data is spread amongst the
memory modules in an alternating pattern.
⎯Three independent memory channels give two possible modes of interleaving:
•Tri-channel mode is enabled when identical matched memory modules are
installed in each of the three memory channels (blue connectors).
•Dual channel mode is enabled when two of the blue memory connectors are
populated with matched DIMMs.
•Single channel (Asymmetric) mode. This mode is equivalent to single channel
bandwidth operation for real world applications. This mode is used when only a
single DIMM is installed or the installed memory modules are not matched.
Technology and device width can vary from one channel to the other.
For information about… Refer to:
Memory Configuration Examples http://www.intel.com/support/motherboards/desktop/sb/cs-
011965.htm

Product Description
19
Figure 3 illustrates the memory channel and DIMM configuration.
Figure 3. Memory Channel and DIMM Configuration

Intel Desktop Board DX58OG Technical Product Specification
20
1.6 Intel®X58 Chipset
The Intel X58 chipset consists of the following devices:
•Intel 82X58 IOH with Direct Media Interface (DMI) interconnect
•Intel 82801IJR I/O Controller Hub (ICH10R)
The IOH component provides interfaces to the processor and the PCI Express graphics
connectors. The ICH10R is a centralized controller for the board’s I/O paths.
For information about Refer to
The Intel X58 chipset http://www.intel.com/products/desktop/chipsets/index.htm
Resources used by the chipset Chapter 2
1.6.1 USB
The board supports up to 14 USB ports. The port arrangement is as follows:
•Two USB 3.0 ports are implemented with stacked back panel connectors (blue)
•Six USB 2.0 ports are implemented with stacked back panel connectors (black)
•Six USB 2.0 front panel ports implemented through three internal headers
The Intel X58 Express Chipset provides the USB controller for the 2.0 ports. The two
USB 3.0 ports are provided by the NEC* UPD720200 controller. All 14 USB ports are
high-speed, full-speed, and low-speed capable. The USB 3.0 ports are super-speed
capable.
For information about Refer to
The location of the USB connectors on the back panel Figure 10, page 42
The location of the front panel USB headers Figure 11, page 43
