Intel D865PCD User manual

Intel®Desktop Board
D865PCD Product Guide
Order Number: C68341-001

Revision History
Revision Revision History Date
-001 Final version of the Intel®Desktop Board D865PCD Product Guide. March 2004
If an FCC declaration of conformity marking is present on the board, the following statement applies:
FCC Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
For questions related to the EMC performance of this product, contact:
Intel Corporation
5200 N.E. Elam Young Parkway
Hillsboro, OR 97124
1-800-628-8686
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit other than the one to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to the equipment not expressly approved by Intel Corporation could void the user’s authority to
use the equipment.
Canadian Department of Communications Compliance Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the
Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numerique német pas de bruits radioélectriques dépassant les limites applicables aux appareils
numériques de la classe B prescrites dans le Réglement sur le broullage radioélectrique édictépar le ministére des
Communications du Canada.
Disclaimer
Information in this document is provided in connection with Intel®products. No license, express or implied, by estoppel or
otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel’s Terms and Conditions
of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating
to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability,
or infringement of any patent, copyright or other intellectual property right. Intel products are not intended for use in medical,
life saving, or life sustaining applications. Intel may make changes to specifications and product descriptions at any time,
without notice.
Desktop Board D865PCD may contain design defects or errors known as errata which may cause the product to deviate
from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product
order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be
obtained from Intel Corporation by going to the World Wide Web site at: http://www.intel.com/ or by calling
1-800-548-4725.
Intel, Pentium, and Celeron are registered trademarks of Intel Corporation or its subsidiaries in the United States and other
countries.
* Other names and brands may be claimed as the property of others.
Copyright © 2004, Intel Corporation. All rights reserved.

iii
Preface
This Product Guide gives information about board layout, component installation, BIOS Setup
menus, and regulatory requirements for Intel®Desktop Board D865PCD.
Intended Audience
The Product Guide is intended for technically qualified personnel.
Information Layout
The chapters in this Product Guide are arranged as follows:
1 Desktop Board Features: a summary of product features.
2 Installing and Replacing Desktop Board Components: instruction on how to install the desktop
board and other hardware components.
3 Updating the BIOS: instructions on how to update the BIOS.
4 Using the BIOS Setup Program: contents of the BIOS Setup menus and submenus.
5 Desktop Board Resources: Memory map, DMA channels, and interrupts.
A Error Messages and Indicators: BIOS error messages and beep codes.
B Regulatory Compliance: Regulatory compliance information.
Conventions
The following conventions are used in this manual:
WARNING
Warnings indicate conditions that, if not observed, can cause personal injury.
CAUTION
Cautions warn the user about how to prevent damage to hardware or loss of data.
NOTE
Notes call attention to important information.

Intel Desktop Boards D865PCD Product Guide
iv
Notations
Term Description
GB Gigabyte (1,073,741,824 bytes)
KB Kilobyte (1024 bytes)
MB Megabyte (1,048,576 bytes)
Mbit Megabit (1,048,576 bits)
MHz Megahertz (one million hertz)
* Third-party brands and names that are the property of their respective owners.

v
Contents
1Desktop Board Features............................................................................................11
Supported Operating Systems.............................................................................................12
Desktop Board Components................................................................................................13
Processor............................................................................................................................15
Main Memory ......................................................................................................................16
Intel®865P Chipset .............................................................................................................17
Graphics Subsystem ...........................................................................................................17
Audio Subsystem ................................................................................................................17
LAN Subsystem...................................................................................................................17
LAN Subsystem Software...........................................................................................17
RJ-45 LAN Connector LEDs .......................................................................................18
Input/Output (I/O) Controller ................................................................................................18
Hi-Speed USB 2.0 Support..................................................................................................18
Enhanced IDE Interface ......................................................................................................19
Accelerated Graphics Port (AGP)........................................................................................19
BIOS ...................................................................................................................................19
PCI Auto Configuration ...............................................................................................19
IDE Auto Configuration ...............................................................................................19
Security Passwords ....................................................................................................20
Chassis Intrusion.................................................................................................................20
Power Management Features .............................................................................................20
ACPI...........................................................................................................................20
Power Connectors ......................................................................................................20
Fan Connectors..........................................................................................................21
Suspend to RAM (Instantly Available PC Technology)................................................21
Resume on Ring.........................................................................................................21
Wake from USB..........................................................................................................21
Wake from PS/2 Keyboard/Mouse..............................................................................21
PME# Wakeup Support ..............................................................................................22
Speaker...............................................................................................................................22
Battery.................................................................................................................................22
Real-Time Clock..................................................................................................................22
2Installing and Replacing Desktop Board Components...................................23
Before You Begin ................................................................................................................23
Installation Precautions .......................................................................................................24
Installation Instructions........................................................................................................24
Ensure Electromagnetic Compatibility (EMC) Compliance..........................................24
Chassis and Component Certifications .......................................................................25
Prevent Power Supply Overload.................................................................................25
Place Battery Marking.................................................................................................25
Use Only for Intended Applications.............................................................................26
Installing the I/O Shield........................................................................................................26

Intel Desktop Boards D865PCD Product Guide
vi
Installing and Removing the Desktop Board........................................................................27
Installing and Removing a Processor ..................................................................................28
Installing a Processor .................................................................................................28
Installing the Processor Fan Heat Sink .......................................................................28
Connecting the Processor Fan Heat Sink Cable.........................................................29
Removing the Processor ............................................................................................29
Installing and Removing Memory ........................................................................................30
Installing DIMMs .........................................................................................................31
Removing DIMMs .......................................................................................................31
Installing and Removing an AGP Card ................................................................................32
Installing an AGP Card ...............................................................................................32
Removing the AGP Card ............................................................................................32
Connecting the IDE Cable ...................................................................................................33
Connecting Internal Headers...............................................................................................34
Connecting the Front Panel Header............................................................................35
Connecting the USB 2.0 Header.................................................................................35
Installing a Front Panel Audio Solution .......................................................................36
Connecting Hardware Control and Power Cables................................................................37
Connecting the Chassis Intrusion Cable .....................................................................38
Connecting Fans ........................................................................................................38
Connecting Power Supply Cables...............................................................................38
Add-In Card and Peripheral Interface Connectors ...............................................................39
Setting the BIOS Configuration Jumper Block .....................................................................40
Clearing BIOS Passwords ...................................................................................................41
Back Panel Connectors.......................................................................................................42
Replacing the Battery ..........................................................................................................43
3Updating the BIOS .......................................................................................................47
Updating the BIOS with the Intel®Express BIOS Update Utility...........................................47
Updating the BIOS with the Iflash Memory Update Utility ....................................................48
Obtaining the BIOS Update File..................................................................................48
Updating the BIOS......................................................................................................48
Recovering the BIOS..................................................................................................49
4Using the BIOS Setup Program ..............................................................................51
Maintenance Menu..............................................................................................................52
Main Menu ..........................................................................................................................53
Advanced Menu ..................................................................................................................54
PCI Configuration Submenu .......................................................................................55
Boot Configuration Submenu......................................................................................56
Peripheral Configuration Submenu.............................................................................57
ATA/IDE Configuration Submenu ...............................................................................59
PATA Submenu..........................................................................................................60
Diskette Configuration Submenu ................................................................................62
Event Log Configuration Submenu .............................................................................63
Video Configuration Submenu ....................................................................................64
USB Configuration Submenu......................................................................................65
Chipset Configuration Submenu .................................................................................66
Fan Control Submenu.................................................................................................68

Contents
vii
Security Menu .....................................................................................................................69
Power Menu ........................................................................................................................70
ACPI Submenu...........................................................................................................71
Boot Menu...........................................................................................................................72
Boot Device Priority Submenu ....................................................................................73
Hard Disk Drives Submenu.........................................................................................74
Removable Devices Submenu....................................................................................75
ATAPI CD-ROM Drives ..............................................................................................76
Exit Menu ............................................................................................................................77
5Desktop Board Resources........................................................................................79
Memory Map .......................................................................................................................79
DMA Channels ....................................................................................................................79
Interrupts.............................................................................................................................80
AError Messages and Indicators ...............................................................................81
BIOS Beep Codes ...............................................................................................................81
BIOS Error Messages..........................................................................................................82
BRegulatory Compliance .............................................................................................85
Safety Regulations ..............................................................................................................85
European Union Declaration of Conformity Statement.........................................................85
Product Ecology Statements ...............................................................................................86
EMC Regulations ................................................................................................................87
Product Certification Markings (Board Level).......................................................................88

Intel Desktop Boards D865PCD Product Guide
viii
Figures
1. Desktop Board D865PCD Components ........................................................................13
2. Installing the I/O Shield .................................................................................................26
3. Location of Mounting Screw Holes................................................................................27
4. Installing a Processor....................................................................................................28
5. Connecting the Processor Fan Heat Sink Cable to the Processor Fan Connector ........29
6. Installing a Memory Module ..........................................................................................30
7. Removing the AGP Card...............................................................................................32
8. Connecting the IDE Cable.............................................................................................33
9. Internal Headers ...........................................................................................................34
10. Location of Hardware Control Headers and Power Connectors ....................................37
11. PCI Bus Add-in Card and Peripheral Interface Connectors...........................................39
12. Location of the BIOS Configuration Jumper Block.........................................................40
13. Back Panel Connectors.................................................................................................42
14. Removing the Battery ...................................................................................................46
Tables
1. Feature Summary .........................................................................................................11
2. Desktop Board Components .........................................................................................14
3. Supported Processors ..................................................................................................15
4. RJ-45 10/100 Ethernet LAN Connector LEDs ...............................................................18
5. Front Panel Header.......................................................................................................35
6. USB 2.0 Header............................................................................................................35
7. Front Panel Audio Header Signal Names......................................................................36
8. Jumper Settings for the BIOS Setup Program Modes ...................................................40
9. BIOS Setup Program Menu Bar....................................................................................51
10. BIOS Setup Program Function Keys.............................................................................52
11. Maintenance Menu .......................................................................................................52
12. Main Menu....................................................................................................................53
13. Advanced Menu............................................................................................................54
14. PCI Configuration Submenu .........................................................................................55
15. Boot Configuration Submenu ........................................................................................56
16. Peripheral Configuration Submenu ...............................................................................57
17. ATA/IDE Configuration Submenu..................................................................................59
18. PATA Submenus ..........................................................................................................60
19. Diskette Configuration Submenu...................................................................................62
20. Event Log Configuration Submenu ...............................................................................63
21. Video Configuration Submenu ......................................................................................64
22. USB Configuration Submenu ........................................................................................65
23. Chipset Configuration Submenu ...................................................................................66
24. Hardware Management.................................................................................................68
25. Security Menu...............................................................................................................69
26. Power Menu..................................................................................................................70
27. ACPI Submenu .............................................................................................................71
28. Boot Menu ....................................................................................................................72
29. Boot Device Priority Submenu ......................................................................................73
30. Hard Disk Drives Submenu...........................................................................................74

Contents
ix
31. Removable Devices Submenu......................................................................................75
32. ATAPI CD-ROM Drives Submenu.................................................................................76
33. Exit Menu......................................................................................................................77
34. System Memory Map ....................................................................................................79
35. DMA Channels..............................................................................................................79
36. Interrupts ......................................................................................................................80
37. Beep Codes..................................................................................................................81
38. BIOS Error Messages ...................................................................................................82
39. Safety Regulations........................................................................................................85
40. EMC Regulations..........................................................................................................87
41. Product Certification Markings ......................................................................................88

Intel Desktop Boards D865PCD Product Guide
x

11
1 Desktop Board Features
This chapter describes the main features of Intel®Desktop Board D865PCD. Table 1 summarizes
these features.
Table 1. Feature Summary
Form Factor MicroATX at 9.6-inches by 9.6-inches
Processor Support for:
• Intel®Pentium®4 processor (2.2 GHz or higher) in an mPGA478-pin package
with 533/400 MHz system bus
• Intel®Celeron®processor (2.0 GHz or higher) in an mPGA478-pin package
with 400 MHz system bus
Main Memory • Two 184-pin, 2.5 V SDRAM Dual Inline Memory Module (DIMM) sockets
• Dual channel 333/266 MHz DDR SDRAM interface
• Designed to support up to 2 GB of system memory
Chipset Intel®865P chipset consisting of:
• Intel®82865P Memory Controller Hub (MCH) with Accelerated Hub
Architecture (AHA) bus
• Intel®82801EB I/O Controller Hub (ICH5)
• 4 Mbit Firmware Hub (FWH)
Graphics • Intel 865P chipset
• 1.5 V and 0.8 V only AGP connector
• Single AGP port via the connector or integrated graphics
• AGP 3.0 including 1x/4x/8x AGP data transfers and 1x/4x/8x Fast Writes
Audio • Intel 865P chipset (AC ’97)
• Realtek* audio codec
LAN (optional) Intel®Pro 10/100 Ethernet LAN (Intel®82502EZ) and RJ-45 connector
Peripheral Interfaces • Up to six USB 2.0 ports
—Four ports routed to the back panel
—Two ports routed to the internal USB header
• Two IDE interfaces with Ultra DMA-33 and ATA-66/100 support
• One diskette drive interface
• One parallel port
• One serial port
• One VGA port
• PS/2* keyboard and mouse ports
Expansion Capabilities Three PCI bus add-in card connectors (SMBus routed to PCI bus 2)
BIOS • Intel/AMI BIOS
• 4 Mbit symmetrical flash memory
• Support for SMBIOS
Power Management • Support for Advanced Configuration and Power Interface (ACPI)
• Suspend to RAM (STR)
• Wake on USB, PCI, RS-232, PS/2, LAN, and front panel

Intel Desktop Boards D865PCD Product Guide
12
Related Links
For more information about Intel Desktop Board D865PCD, including the Technical Product
Specification (TPS), BIOS updates, and device drivers, go to:
http://support.intel.com/support/motherboards/desktop/
Supported Operating Systems
The desktop board supports the following operating systems:
• Microsoft Windows* 98 SE
• Microsoft Windows Me
• Microsoft Windows 2000 Professional
• Microsoft Windows XP Professional

Desktop Board Features
13
Desktop Board Components
Figure 1 shows the approximate location of the major components on Desktop Board D865PCD.
OM16826
USB 2.0
Line
In
USB 2.0
AB
E
F
H
G
I
K
L
M
N
O
P
R
T
U
D
J
S
V
C
Q
W
Figure 1. Desktop Board D865PCD Components

Intel Desktop Boards D865PCD Product Guide
14
Table 2. Desktop Board Components
Label Description
A CD-ROM audio connector (ATAPI-style)
B Front panel audio header
C AGP connector
D Rear chassis fan header
E 12 V processor core voltage connector
F Processor socket
G Processor fan header
H Intel 82865P (MCH)
I DIMM sockets
J Main power connector
K Diskette drive connector
L Primary IDE connector
M Secondary IDE connector
N Front chassis fan header
O Chassis intrusion header
P Speaker
Q BIOS configuration jumper
R Alternate power/sleep LED header
S Front panel header
T Intel 82801EB (ICH5)
U USB 2.0 header
V Battery
W PCI bus add-in card connectors
Related Links
Go to the following links for the latest information about:
• Intel Desktop Board D865PCD, http://www.intel.com/design/motherbd
• Processors, http://support.intel.com/support/motherboards/desktop
• Audio software and utilities, http://www.intel.com/design/motherbd
• LAN software and drivers, http://www.intel.com/design/motherbd

Desktop Board Features
15
Processor
CAUTION
Failure to use an ATX12V power supply, or not connecting the 12 V processor core voltage power
supply connector to Desktop Board D865PCD may result in damage to the desktop board and/or
power supply.
Desktop Board D865PCD supports a single Intel Pentium 4 processor or Intel Celeron processor.
Processors are not included with the desktop board and must be purchased separately.
The processor connects to the Intel desktop board through the mPGA478-pin socket. The Intel®
processors may be removed and replaced to accommodate supported higher speed processors.
Desktop Board D865PCD supports the processors listed in Table 3.
Table 3. Supported Processors
Type Designation (GHz) FSB Frequency (MHz) L2 Cache (KB)
Intel®Pentium®4 processor
(with HT Technology)
3.06 533 512
Intel Pentium 4 processor 2.80A, 2.40A 533 1024
2.8, 2.66, 2.53, 2.4B, and
2.26
533 512Intel Pentium 4 processor
2.6, 2.5, 2.40, 2.20, 2A,
1.80A, and 1.60A
400 512
Intel®Celeron®processor 2.8, 2.7, 2.6, 2.5, 2.4, 2.3,
2.2, 2.1, and 2.0
400 128
Desktop Board D865PCD requires an ATX12V compliant power supply to function according to
desktop board specifications. The board has two ATX12V compliant power supply connectors that
are needed to provide extra power to the Intel 865P chipset and Intel processor.
Related Links
Go to the following link or sections in this manual for more information about:
• The latest supported Intel processors for Desktop Board D865PCD
http://support.intel.com/support/motherboards/desktop/
• Installing or upgrading the processor, page 28 in Chapter 2
• The location of the ATX12V compliant power supply connectors, page 38

Intel Desktop Boards D865PCD Product Guide
16
Main Memory
NOTE
To be fully compliant with all applicable Intel®SDRAM memory specification addendums, the
board should be populated with DIMMs that support the Serial Presence Detect (SPD) data
structure. If your memory modules do not support SPD, you will see a notification to this effect on
the screen at power up. The BIOS will attempt to configure the memory controller for normal
operation.
The desktop board supports system memory as defined below:
• Dual channel and up to four 184-pin Double Data Rate (DDR) SDRAM Dual Inline Memory
Module (DIMMs) connectors with gold-plated contacts.
• Supported memory configurations are:
Memory Speed Processor
Front Side Bus
Frequency
Memory Speed
Outcome
Pentium 4 processor 533 MHz 333 MHzDDR333
Pentium 4 processor or
Celeron processor
400 MHz 266 MHz
Pentium 4 processor 533 MHz or 400 MHz 266 MHzDDR266
Celeron processor 400 MHz 266 MHz
• Support for:
 Unbuffered, non-registered DIMMs
 Serial Presence Detect (SPD) memory only
 Support for Suspend to RAM (STR), S3 ACPI state
 Non-ECC DDR
 2.5 V memory
Related Links
Go to the following links or section in this manual for more information about:
• The latest list of tested memory, http://support.intel.com/support/motherboards/desktop/
• SDRAM specifications, http://www.intel.com/technology/memory/pcsdram/spec/
• Installing memory, page 30 in Chapter 2

Desktop Board Features
17
Intel®865P Chipset
The Intel 865P chipset consists of the following devices:
• Intel 82865P Memory Controller Hub (MCH) with AHA bus
• Intel 82801EB I/O Controller Hub (ICH5) with AHA bus
• Firmware Hub (FWH)
Related Link
For more information about the Intel 865P chipset, go to:
http://developer.intel.com/design/nav/pcserver.htm
Graphics Subsystem
The graphics subsystem features the following:
• The Intel 865P chipset
• 1.5 V and 0.8 V only AGP connector
• Single AGP port via the connector or integrated graphics
• AGP 3.0 including 1x/4x/8x data transfers and 1x/4x/8x Fast Writes
Audio Subsystem
The audio subsystem features the following:
• Intel 865P chipset (AC ’97)
• Realtek ALC202A audio codec
Related Links
Go to the following link or sections in this manual for more information about:
• Audio drivers and utilities, http://support.intel.com/support/motherboards/desktop/
• Installing the front panel audio solution, page 35 in Chapter 2
LAN Subsystem
The optional LAN provides a Fast PCI LAN subsystem. The LAN subsystem provides the
following functions:
• 10/100 Ethernet LAN (Intel 82502EZ)
• Support for RJ-45 connector with status indicator LEDs
• Programmable transit threshold
• Configurable EEPROM that contains the MAC address
LAN Subsystem Software
For LAN software and drivers, refer to the D865PCD link on Intel’s World Wide Web site at:
http://support.intel.com/support/motherboards/desktop

Intel Desktop Boards D865PCD Product Guide
18
RJ-45 LAN Connector LEDs
Two LEDs are built into the RJ-45 LAN connector. Table 4 describes the LED states when the
board is powered up and the 10/100 Ethernet LAN subsystem is operating.
Table 4. RJ-45 10/100 Ethernet LAN Connector LEDs
LED Color LED State Indicates
Off 10 Mbit/sec data rate is selected.Green
On 100 Mbit/sec data rate is selected.
Off LAN link is not established.
On (steady state) LAN link is established.
Yellow
On (brighter and pulsing) The computer is communicating with another computer on the
LAN.
Input/Output (I/O) Controller
The super I/O controller features the following:
• Low pin count (LPC) interface
• One serial port
• One parallel port with Extended Capabilities Port (ECP) and Enhanced Parallel Port
(EPP) support
• Serial IRQ interface compatible with serialized IRQ support for PCI systems
• PS/2-style mouse and keyboard interfaces
• Interface for one 1.44 MB or 2.88 MB diskette drive
• Intelligent power management, including a programmable wake up event interface
• PCI power management support
Hi-Speed USB 2.0 Support
NOTE
Computer systems that have an unshielded cable attached to a USB port might not meet FCC
Class B requirements, even if no device or a low-speed USB device is attached to the cable.
Use a shielded cable that meets the requirements for a full-speed USB device.
The desktop board supports up to six USB 2.0 ports via ICH5; four ports routed to the back
panel and two routed to the internal USB 2.0 headers. USB 2.0 ports are backward compatible with
USB 1.1 devices. USB 1.1 devices will function normally at USB 1.1 speeds.
Disabling Hi-Speed USB in the BIOS reverts all USB 2.0 ports to USB 1.1 operation. This may be
required to accommodate operating systems that do not support USB 2.0.
NOTE
USB devices are limited to USB 1.1 transfer rates prior to operating system and driver
initialization.

Desktop Board Features
19
Enhanced IDE Interface
The ICH5’s IDE interface handles the exchange of information between the processor and
peripheral devices like hard disks, CD-ROM drives, and Iomega Zip* drives inside the computer.
The interface supports:
• Up to four IDE devices (such as hard drives)
• ATAPI-style devices (such as CD-ROM drives)
• Older PIO Mode devices
• Ultra DMA-33 and ATA-66/100 protocols
• Laser Servo (LS-120) drives
Accelerated Graphics Port (AGP)
NOTE
Desktop Board D865PCD is only compatible with 0.8 V and 1.5 V AGP cards.
The AGP connector is keyed for 0.8 V and 1.5 V AGP cards only; the connector is not mechanically
compatible with legacy 3.3 V AGP cards. Do not attempt to install a legacy 3.3 V AGP card.
AGP is a high-performance interface for graphics-intensive applications, such as 3D graphics.
AGP is independent of the PCI bus and is intended for exclusive use with graphical display devices.
The AGP 3.0 connector supports 8x, 4x, and 1x AGP cards.
Related Links
For information about installing the AGP card, see page 32 in Chapter 2.
BIOS
The BIOS provides the Power-On Self-Test (POST), the BIOS Setup program, the PCI and IDE
auto-configuration utilities, and the video BIOS. The BIOS is stored in the Firmware Hub.
The BIOS can be updated by following the instructions in Chapter 3 on page 47.
PCI Auto Configuration
If you install a PCI add-in card in your computer, the PCI auto-configuration utility in the BIOS
automatically detects and configures the resources (IRQs, DMA channels, and I/O space) for that
add-in card. You do not need to run the BIOS Setup program after you install a PCI add-in card.
IDE Auto Configuration
If you install an IDE device (such as a hard drive) in your computer, the IDE auto-configuration
utility in the BIOS automatically detects and configures the device for your computer. You do not
need to run the BIOS Setup program after installing an IDE device. You can override the auto-
configuration options by specifying manual configuration in the BIOS Setup program.
To use ATA-66/100 features, the following items are required:
• An ATA-66/100 peripheral device
• An ATA-66/100 compatible cable
• ATA-66/100 operating system device drivers

Intel Desktop Boards D865PCD Product Guide
20
Security Passwords
The BIOS includes security features that restrict whether the BIOS Setup program can be accessed
and who can boot the computer. A supervisor password and a user password can be set for the
Setup and for booting the computer, with the following restrictions:
• The supervisor password gives unrestricted access to view and change all Setup options. If
only the supervisor password is set, pressing <Enter> at the password prompt of Setup gives the
user restricted access to Setup.
• If both the supervisor and user passwords are set, you must enter either the supervisor password
or the user password to access Setup. Setup options are then available for viewing and
changing depending on whether the supervisor or user password was entered.
• Setting a user password restricts who can boot the computer. The password prompt is
displayed before the computer is booted. If only the supervisor password is set, the computer
boots without asking for a password. If both passwords are set, you can enter either password
to boot the computer.
Chassis Intrusion
The board supports a chassis security feature that detects if the chassis cover has been removed.
The security feature uses a mechanical switch on the chassis that can be connected to the chassis
intrusion header on the desktop board. See Figure 10 on page 37 for the location of the chassis
intrusion header.
Power Management Features
Power management is implemented at several levels, including:
• Advanced Configuration and Power Interface (ACPI)
• Hardware support:
 Power connectors
 Fan connectors
 Suspend to RAM (Instantly Available PC technology)
 Resume on Ring
 Wake from USB
 Wake from PS/2 keyboard/mouse
 PME# wakeup support
ACPI
ACPI gives the operating system direct control over the power management and Plug & Play
functions of a computer. The use of ACPI with the desktop board requires an operating system that
provides full ACPI support.
Power Connectors
The desktop board has two power connectors. See Figure 10 on page 37 for the location of the
power connectors.
