Intel DQ5TML User manual

Intel®Desktop Board DQ57TML
Product Guide
Order Number: E95584-001
All manuals and user guides at all-guides.com
all-guides.com

Revision History
Revision Revision History Date
-001 First release of the Intel®Desktop Board DQ57TML Product Guide June 2010
Disclaimer
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,
EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS
GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR
SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR
IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR
WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT
OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. Intel products are not intended
for use in medical, life saving, or life sustaining applications. Intel may make changes to specifications and
product descriptions at any time, without notice.
Intel Desktop Board DQ57TML may contain design defects or errors known as errata which may cause the
product to deviate from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing
your product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel
literature, may be obtained from Intel Corporation by going to the World Wide Web site at:
http://www.intel.com/ or by calling 1-800-548-4725.
Intel, Intel Core, and Xeon are trademarks of Intel Corporation in the United States and other countries.
Other names and brands may be claimed as the property of others.
Copyright © 2010, Intel Corporation. All rights reserved.
All manuals and user guides at all-guides.com

iii
Preface
This Product Guide gives information about board layout, component installation, BIOS
update, and regulatory requirements for Intel®Desktop Board DQ57TML.
Intended Audience
The Product Guide is intended for technically qualified personnel. It is not intended for
general audiences.
Use Only for Intended Applications
All Intel Desktop Boards are evaluated as Information Technology Equipment (I.T.E.)
for use in personal computers (PC) for installation in homes, offices, schools, computer
rooms, and similar locations. The suitability of this product for other PC or embedded
non-PC applications or other environments, such as medical, industrial, alarm systems,
test equipment, etc. may not be supported without further evaluation by Intel.
Document Organization
The chapters in this Product Guide are arranged as follows:
1 Desktop Board Features: a summary of product features
2 Installing and Replacing Desktop Board Components: instructions on how to install
the Desktop Board and other hardware components
3 Updating the BIOS: instructions on how to update the BIOS
A Error Messages and Indicators: information about BIOS error messages and beep
codes
B Regulatory Compliance: describes the board’s adherence to safety standards and
EMC regulations and its product certifications
Conventions
The following conventions are used in this manual:
CAUTION
Cautions warn the user about how to prevent damage to hardware or loss of data.
NOTE
Notes call attention to important information.
All manuals and user guides at all-guides.com

Intel Desktop Board DQ57TML Product Guide
iv
Terminology
The table below gives descriptions of some common terms used in the product guide.
Term Description
GB Gigabyte (1,073,741,824 bytes)
GHz Gigahertz (one billion hertz)
KB Kilobyte (1024 bytes)
MB Megabyte (1,048,576 bytes)
Mb Megabit (1,048,576 bits)
MHz Megahertz (one million hertz)
All manuals and user guides at all-guides.com

v
Contents
1Desktop Board Features
Supported Operating Systems..............................................................................11
Desktop Board Components.................................................................................12
Processor..........................................................................................................14
Intel®Q57 Express Chipset .................................................................................15
Main Memory.....................................................................................................15
Graphics Subsystem...........................................................................................16
Integrated Graphics ....................................................................................16
Digital Visual Interface Graphics ............................................................16
VGA Graphics .....................................................................................16
PCI Express* x16 Graphics ..........................................................................16
Audio Subsystem ...............................................................................................17
LAN Subsystem .................................................................................................18
USB 2.0 Support................................................................................................19
SATA Support....................................................................................................19
SATA RAID ................................................................................................19
Intel®Rapid Recover Technology (Intel®RRT) ................................................19
Expandability.....................................................................................................20
Legacy I/O........................................................................................................20
BIOS................................................................................................................20
SATA Auto Configuration .............................................................................20
PCI*/PCI Express Auto Configuration.............................................................20
BIOS Security Passwords.............................................................................21
Hard Disk Drive Passwords...........................................................................21
Platform Management and Protection....................................................................23
Intel®vPro™ Technology .............................................................................23
Intel®Active Management Technology (Intel®AMT) .................................23
Intel®Virtualization Technology (Intel®VT) ............................................27
Intel®Trusted Execution Technology (Intel®TXT) ....................................27
Intel®Virtualization Technology for Directed I/O (Intel®VT-d)...................27
Intel®Remote PC Assist (Intel®RPAT) and Fast Call for Help .....................27
Trusted Platform Module (TPM) .............................................................28
Fan Speed Control and Hardware Monitoring ..................................................29
Power Management ....................................................................................29
Software Support ................................................................................29
Hardware Support ...............................................................................30
Onboard Speaker ...............................................................................................33
Real-Time Clock Subsystem.................................................................................33
2Installing and Replacing Desktop Board Components
Before You Begin ...............................................................................................35
Installation Precautions.......................................................................................36
Prevent Power Supply Overload ....................................................................36
Observe Safety and Regulatory Requirements.................................................36
Installing the I/O Shield ......................................................................................37
Installing and Removing the Desktop Board ...........................................................38
Installing and Removing a Processor.....................................................................39
All manuals and user guides at all-guides.com

Intel Desktop Board DQ57TML Product Guide
vi
Installing a Processor ..................................................................................39
Installing a Processor Fan Heat Sink..............................................................44
Connecting the Processor Fan Heat Sink Cable................................................44
Removing the Processor ..............................................................................44
Installing and Removing System Memory ..............................................................45
Guidelines for Dual-Channel Memory Configuration..........................................45
Two or Four DIMMs .............................................................................45
Three DIMMs ......................................................................................46
Installing DIMMs ........................................................................................47
Removing DIMMs........................................................................................49
Installing and Removing PCI Express x16 Graphics Cards.........................................49
Installing a PCI Express x16 Graphics Card ....................................................49
Removing a PCI Express x16 Graphics Card....................................................51
Connecting the SATA Drive Cables........................................................................52
Connecting a Diskette Drive ................................................................................53
Installing an Intel Z-U130 USB Solid-state Drive or Compatible Device ......................54
Connecting to the Internal Headers ......................................................................55
Front Panel Audio Header ............................................................................56
Internal Mono Speaker Header .....................................................................56
S/PDIF Header ...........................................................................................57
Chassis Intrusion Header .............................................................................57
Alternate Front Panel Power LED Header ........................................................57
Front Panel Header .....................................................................................58
Front Panel USB 2.0 Headers........................................................................58
Intel RPAT Header ......................................................................................59
Serial Header.............................................................................................59
Connecting to the Audio System...........................................................................60
Connecting Chassis Fan and Power Supply Cables...................................................61
Connecting Chassis Fan Cables .....................................................................61
Connecting Power Supply Cables ..................................................................62
Setting the BIOS Configuration Jumper .................................................................63
Clearing Passwords in the BIOS Setup Program ......................................................64
Replacing the Battery .........................................................................................65
3Updating the BIOS
Updating the BIOS with the Intel®Express BIOS Update Utility.................................71
Updating the BIOS with the ISO Image BIOS Update File or the Iflash Memory
Update Utility...............................................................................................72
Obtaining the BIOS Update File ....................................................................72
Updating the BIOS with the ISO Image BIOS Update File .................................73
Updating the BIOS with the Iflash Memory Update Utility .................................74
Updating the BIOS Using the F7 Function Key.................................................74
Recovering the BIOS...................................................................................75
AError Messages and Indicators
BIOS Error Codes...............................................................................................77
BIOS Error Messages..........................................................................................78
All manuals and user guides at all-guides.com
all-guides.com

Contents
vii
BRegulatory Compliance
Safety Standards ...............................................................................................79
Battery Caution ..........................................................................................79
European Union Declaration of Conformity Statement..............................................80
Product Ecology Statements ................................................................................81
Recycling Considerations .............................................................................81
China RoHS ...............................................................................................84
EMC Regulations ................................................................................................85
FCC Declaration of Conformity......................................................................85
Canadian Department of Communications Compliance Statement......................86
Japan VCCI Statement ................................................................................86
Korea Class B Statement .............................................................................87
Ensure Electromagnetic Compatibility (EMC) Compliance..................................87
Product Certifications..........................................................................................88
Board-Level Certifications ............................................................................88
Chassis- and Component-Level Certifications..................................................89
Chassis and Component Certifications............................................................89
ENERGY STAR*, e-Standby, and ErP Compliance ....................................................90
Figures
1. Intel Desktop Board DQ57TML Components......................................................12
2. LAN Status LEDs ..........................................................................................18
3. Location of the Intel ME “M” State LED ............................................................25
4. Location of the Intel MEBX Reset Header..........................................................26
5. Location of the Standby Power Indicator ..........................................................32
6. Installing the I/O Shield ................................................................................37
7. Intel Desktop Board DQ57TML Mounting Screw Hole Locations............................38
8. Unlatch the Socket Lever...............................................................................39
9. Lift the Load Plate.........................................................................................40
10. Remove the Socket Cover..............................................................................41
11. Remove the Processor from the Protective Cover ..............................................42
12. Install the Processor .....................................................................................42
13. Lower the Load Plate.....................................................................................43
14. Secure the Load Plate in Place........................................................................43
15. Connecting the Processor Fan Heat Sink Power Cable to the Processor
Fan Header..................................................................................................44
16. Example Dual-Channel Memory Configuration with Two DIMMs ...........................45
17. Example Dual-Channel Memory Configuration with Four DIMMs...........................46
18. Example Dual-Channel Memory Configuration with Three DIMMs.........................46
19. Use DDR3 DIMMs .........................................................................................47
20. Installing a DIMM .........................................................................................48
21. Installing a PCI Express x16 Graphics Card ......................................................50
22. Removing a PCI Express x16 Graphics Card......................................................51
23. Connecting a SATA Cable...............................................................................52
24. Connecting a Diskette Drive ...........................................................................53
25. Installing an Intel Z-U130 USB Solid-State Drive or Compatible Device ................54
26. Internal Headers ..........................................................................................55
27. Back Panel Audio Connectors .........................................................................60
28. Location of the Chassis Fan Headers................................................................61
29. Connecting Power Supply Cables ....................................................................62
All manuals and user guides at all-guides.com

Intel Desktop Board DQ57TML Product Guide
viii
30. Location of the BIOS Configuration Jumper Block ..............................................63
31. Removing the Battery ...................................................................................69
32. Intel Desktop Board DQ57TML China RoHS Material Self Declaration Table............84
Tables
1. Feature Summary.......................................................................................... 9
2. Intel Desktop Board DQ57TML Components......................................................13
3. LAN Status LEDs States.................................................................................18
4. Master Key and User Hard Disk Drive Password Functions ..................................21
5. Intel ME “M” State LED Behavior.....................................................................25
6. Front Panel Audio Signal Names for Intel HD Audio............................................56
7. Front Panel Audio Header Signal Names for AC ’97 Audio ...................................56
8. Internal Mono Speaker Header .......................................................................56
9. S/PDIF Header Signal Names .........................................................................57
10. Chassis Intrusion Header Signal Names ...........................................................57
11. Alternate Front Panel Power LED Header Signal Names ......................................57
12. Front Panel Header Signal Names ...................................................................58
13. Standard USB 2.0 Headers Signal Names.........................................................58
14. Front Panel USB Header with Intel Z-U130 USB Solid-State Drive or
Compatible Device Support Signal Names ........................................................59
15. Intel RPAT Header Signal Names ....................................................................59
16. Serial Port Header ........................................................................................59
17. Jumper Settings for the BIOS Setup Program Modes..........................................64
18. BIOS Beep Codes .........................................................................................77
19. Front-panel Power LED Blink Codes .................................................................78
20. BIOS Error Messages ....................................................................................78
21. Safety Standards..........................................................................................79
22. EMC Regulations...........................................................................................85
23. Regulatory Compliance Marks.........................................................................88
All manuals and user guides at all-guides.com

9
1 Desktop Board Features
This chapter briefly describes the features of Intel®Desktop Board DQ57TML. Table 1
summarizes the major features of the Desktop Board.
Table 1. Feature Summary
Form Factor MicroATX (243.84 millimeters [9.60 inches] x 243.84 millimeters
[9.60 inches])
Processor Support •Intel®Core™ i7, Intel®Core™ i5, Intel®Core™ i3, Intel®Pentium
processors, and Intel®Xeon®processor 3400 series in an LGA1156
package:
―Integrated graphics processing (processors with Intel®Graphics
Technology)
―External graphics interface controller
―Integrated memory controller
Chipset Intel®Q57 Express Chipset consisting of the Intel®Q57 Express
Platform Controller Hub (PCH)
Memory Support •Four 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM)
sockets
•Support for DDR3 1333 MHz and DDR3 1066 MHz DIMMs
•Support for 1 Gb and 2 Gb memory technology
•Support for up to 16 GB of system memory with four DIMMs using
2 Gb memory technology
•Support for non-ECC memory
•Support for ECC memory with Intel Xeon processor 3400 series
Graphics Support •Integrated graphics support for processors with Intel Graphics
Technology:
―DVI-D
―VGA
•Discrete graphics support for a PCI Express* 2.0 x16 add-in
graphics card
Audio Intel®High Definition Audio, featuring the Realtek* ALC662-VC audio
codec with:
•6-channel (5.1) audio via back panel connectors
•Front panel audio header that supports Intel High Definition Audio
and AC ’97 Audio
•S/PDIF out header
•Internal mono speaker header
Expansion
Capabilities
•One PCI Express 2.0 x16 add-in card connector
•Two PCI Express 1.1 x1 add-in card connectors
•One PCI* bus connector
continued
All manuals and user guides at all-guides.com

Intel Desktop Board DQ57TML Product Guide
10
Table 1. Feature Summary (continued)
Peripheral
Interfaces
•Twelve USB 2.0 ports:
―Four ports are implemented with back panel connectors
―Eight ports are implemented with four dual-port internal headers
(one header supports an Intel®Z-U130 USB Solid-state Drive or
compatible device)
•Four onboard Serial ATA (SATA) 3.0 Gb/s ports
•One back panel parallel port connector
•One serial port header
•One PS/2 back panel connector for mouse/keyboard support
LAN Support Intel®82578DM Gigabit (10/100/1000 Mb/s) Ethernet LAN controller
with support for:
•Intel®Active Management Technology (Intel®AMT) 6.0
•ASF 2.0
BIOS •Intel®BIOS resident in an SPI Flash device
•Support for Advanced Configuration and Power Interface (ACPI),
Plug and Play, and SMBIOS
Instantly Available
PC Technology
•Support for PCI Local Bus Specification, Revision 2.2
•Support for PCI Express Base Specification, Revision 2.0
•Suspend to RAM support
•Wake on PCI, PCI Express, LAN, front panel, serial, PS/2, and USB
ports
Hardware
Monitoring
•Intel®Quiet System Technology (Intel®QST) implemented through
the Intel®Management Engine (Intel®ME) in the Intel Q57 PCH
•Voltage sense to detect out of range power supply voltages
•Thermal sense to detect out of range thermal values
•Three fan headers using PWM control
•4-pin headers for processor, front chassis, and rear chassis fans
•4-wire and 3-wire (linear) fan speed control support for front and
rear chassis fans
•Support for Platform Environmental Control Interface (PECI)
Intel®vPro™
Technology
•Intel® Advanced Management Technology (Intel®AMT) 6.0
•Intel® Trusted Execution Technology (Intel® TXT)
•Intel®Remote PC Assist (Intel®RPAT)
•Intel®Fast Call for Help
•Intel®Virtualization Technology (Intel®VT)
•Intel®Virtualization for Directed I/O (Intel®VT-d)
All manuals and user guides at all-guides.com
