Intelligent G-Force Junior User manual
G-Force Junior
user manual
2Intelligent Facility Solutions
G-Force Junior Hand Dryer
ATTENTION: We invite you to read carefully and to keep hold of these instructions.
This manual supplies important information regarding maintenance and use, installation and
emergency information. A wrong installation can produce damages to persons or things, which the
constructor cannot be thought responsible about.
FEATURES
Tension 230 VAC
Frequency 50 - 60Hz
Absorption (power) total 900 WATT
(power is always indicated also on rating label on machine)
Protection Class Class II
Air flow 150 cbm/h, 2500 l/m
Dimensions 238 X 156 X 99,5 (MM)
CE-CEI Compliance RoHS – WEEE compliance
INSTRUCTIONS FOR INSTALLERS
THIS HAND DRYER HAS TO BE FIXED AT PROPER DISTANCE OF AT LEAST 60 CM FROM BATHTUB
OR SHOWER OR WASHBASIN.
Please verify that the electrical capacity of the system and the female plugs of current is
adapted to the maximum power of the apparatus.
Fix the dryer to the wall with the proper fixing box kit and mounting plate included in the
box. Plug the dryer or use the given dryer cable only also for concealed installation.
We suggest installing at least 120cm from ground, by air outlet distance.
This product is not intended to be used by people with reduced physical, sensory, mental,
or have a lack of experience and knowledge, unless they are controlled by a person
responsible for their safety.
Children should be supervised to prevent them from playing with the appliance.
If the power cord is damaged it should be replaced by the manufacturer or person with
similar technical qualification, to prevent any risk.
OPERATING
The hand dryer comes into operation and automatically stops by hands approaching and
moving away from the cone air outlet.
Warning: In case of an overload of internal temperature, a thermostat with automatic reset
protection suspends the operation of the engine.
This device gives the user greater safety of operation.
The unit has a heating element. Air is then heated by the power of motor and heating
element. This dryer allows considerable energy savings compared to traditional dryers,
reducing consumption as our trading indications. In case of overheating a safety
thermostat temporary switches off the heating element.
G-Force Junior 3
The device has a system that prevents vandalism continuous operation caused, by
example, covering the photocell.
If this occurs, the dryer can work without interruption for about 60 seconds, then
automatically stops waiting for (stand by)
It will simply be needed to remove the cover that blocks the photocells to ensure the dryer
will resume its normal function in 3-4 seconds.
MANTAINANCE
Warning: Before performing any maintenance, please disconnect the appliance from the
network.
Clean this dryer using a soft cloth dampened with water and detergent.
To ensure the durability and reliability of this product, periodically check that the grid
inlet and outlet of the cone are not clogged by dust or any equivalent material
FILTER HEPA H13 filter paper
The HEPA filter inside the machine, if present, guarantees air to be cleaned from
excessive dust and dirt. The filter must be periodically cleaned with a jet of compressed air
at a distance of about 20 cm. It must be replaced after a maximum of 1000 hours of use, in
conjunction with the cartridges motor brushes. The quality H13 HEPA filter paper, if
maintained in good condition and replaced as required above, will be able to protect
against bacteria and external factors that can go up to 99.997% of airborne particles.
BRUSH MOTOR (carbon brushes)
The motor brushes cartridge in the drive unit has a life of 500-600 hours of effective
operation. The duration of the same varies depending on the conditions of use and of
cleaning the filter and general maintenance of the appliance. It is needed to contact an
engineer in order to restore the brushes at the end of the cycle.
General warnings
Do not use this product for a different function from that to which it is intended: HAND
DRYER
• Do not leave the appliance exposed to atmospheric conditions such as rain, sun, etc.
• Make no changes of any kind to the device
• Do not obstruct the air outlet or mouth
• Do not insert any object into the grid or the outlet air
In case of failure and / or malfunction, remove the mains and consult with the
manufacturer or dealer
IMPORTANT INFORMATION
This product falls within the competence of the EC Directive 2002/96 (WEEE) on disposal
of electrical and electronic equipment. Complies with RoHS legislation
NOTE:
This product should not be disposed with household waste.
Recycle it at the appropriate structures.
Ask your local authority for recycling guidelines.
4Intelligent Facility Solutions
TROUBLE SHOOTING GUIDE
Cold air change the heating element
Continuous operating on electric board, decrease sensor sensibility by turning anticlockwise
the white trimmer on board
Not operating check all connections first, then change the electric board if
necessary
IMPORTANT INFORMATION
THIS PRODUCT IS INCLUDED IN THE EXPERTISE OF DIRECTIVE 2002/96 CE (WEEE-RAEE) CONCERNING
THE DRAINING OF ELECTRIC AND ELECTRONIC DEVICES. THIS PRODUCT MUST NOT BE REMOVED WITH
THE DOMESTIC DISCARDS. IT MUST BE RECYCLED BY ADEQUATE STRUCTURES. ENQUIRE THE MUNICIPAL
AUTORITHY AS REGARDS THE RECYCLING DIRECTIVES AND LOCATION OF THE ECOLOGICAL PLATFORMS
ATTE TO THE ADEQUATE DRAINING OF PRODUCTS. FURTHERMORE PLEASE REMEMBER THE FOLLOWING
THING: AGAINST DEVICE PURCHASE BEING EQUIVALENT, THE CLIENT HAS THE RIGHT TO THE FREE
RETIREMENT OF THE PRODUCT TO BE TAKEN BACK BY DISTRIBUTOR. THIS PRODUCT DOES NOT
CONTAIN ANY DANGEROUS SUBSTANCE AS ROHS DIRECTIVE 2002/95 CE (RoHS) TO THE HUMAN HEALTH,
NOT CONTAINING DAMAGING SUBSTANCES BUT IF LET GO IN THE ENVIRONMENT CAN UPSET
ECHOSYSTEMAS.
REMEMBER NOT TO USE THE PRODUCT FOR DIFFERENT USES, BEING THERE ELECTRIC SHOCK DANGER
IF INCORRECTLY USED.
SYMBOL OF THE CROSSED DRUM CONTAINED ON THE LABEL SHOWS THE
COMPLIANCE OF SUCH PRODUCT TO THE PROVISIONS OF WHICH ABOVE,
CONCERNING NEED OF DIFFERENTIATED DRAINING. IN CASE OF ABUSIVE
DRAINING ARE FORESEEN SANCTIONS UP TO EUR 100.000.
WARRANTY
This unit is under warranty for a period of 2 years from date of purchase, by proving with
receipt or invoice and stamp dealer.
The guarantee does not cover damage caused by:
• improper use, misuse or neglect
• accidental breakage or falling brakes not caused by the supplier
• incorrect connection to voltage different from that expected, spikes on the network
• improper tampering with equipment
Also excluded from the warranty are consumable items (cartridges carbon motor), whose
life depends on the terms and conditions of use. More information is available at the
offices of the distributor
Retailer stamp Date
Intelligent Facility Solutions Ltd
Electric Works
3 Concourse Way
Sheffield
S1 2BJ
T: +44 (0)114 2866394
email: service@ihdryers.co.uk
www.intelligenthanddryers.com
