Intellihot i200 User manual

To avoid product damage, personal injury, or
even possible death, carefully read, understand,
and follow all the instructions in the Installation
and the Operation manuals before installing this
product. Improper installation, adjustment, alteration, or
maintenance can cause injury, loss of life, and/or property
damage. This water heater should be installed and
serviced by a qualified technician. The lack of proper
service can result in a dangerous condition.
This manual contains safety information, installation
instructions, and maintenance procedures. It must be left
with the homeowner or placed near the water heater in a
noncombustible place. The homeowner should retain this
manual for future reference.
3OHDVH Fall us first if you have any questions about this
product. We can help you with questions about LQVWDOODWLRQ
and operation, or if there LV damage or missing parts when
you unpack this unit.
&all 877-835-1705 between 7 am and 4 pm Central
time, Monday through Friday, before returning the unit to the
store.
Due to Intellihot’s policy of continuous product DQG
WHFKQRORJ\ improvement, the design and/or technical
specifications are subject to change without notice.
Serial Number: ___________________________________
Date of Installation: ___ / ___ / ______
IGT-MNL0001 (12/2012)
WARNING
If the information in these instructions is not followed
exactly, a fire or explosion could result causing
property damage, personal injury, or death.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
fire department.
— Installation and service must be performed by
a qualified installer, service agency, or the gas
supplier.
WARNING
If the information in these instructions is not followed
exactly, a fire or explosion could result causing
property damage, personal injury, or death.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS
• Evacuate all persons from the vehicle.
• Shut off the gas supply at the gas container or
source.
• Do not touch any electrical switch, or use any phone
or radio in the vehicle.
• Do not start the vehicle’s engine or electric generator.
• Contact the nearest gas supplier or qualified service
technician for repairs.
• If you cannot reach a gas supplier or qualified service
technician, contact the nearest fire department.
• Do not turn on the gas supply until the gas leak(s)
has been repaired.
— Installation and service must be performed by
a qualified installer, service agency, or the gas
supplier.
— Ne pas entreposer ni utiliser d’essence ou
ni d’autres vapeurs ou liquides inflammables
à proximité de cet appareil ou de tout autre
appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ
• Ne pas tenter d’allumer d’appareil.
• Ne touchez à aucun interrupteur; ne pas vous
servir des téléphones se trouvant dans
le bâtiment.
• Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions
du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur,
appelez le service des incendies.
— L’installation et l’entretien doivent être assurés
par un installateur ou un service d’entretien
qualifié ou par le fournisseur de gaz.
AVERTISSEMENT
Assurez-vous de bien suivre les instructions données
dans cette notice pour réduire au minimum le
risque d’incendie ou d’explosion ou pour éviter tout
dommage matériel, toute blessure ou la mort. — Ne pas entreposer ni utiliser d’essence ou
ni d’autres vapeurs ou liquides inflammables
à proximité de cet appareil ou de tout autre
appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ
• Évacuez le véhicule.
• Coupez l’alimentation en gaz au réservoir ou à la
source.
• Ne touchez à aucun interrupteur ; ne pas vous servir
du téléphone ou de la radio du véhicule.
• Ne pas démarrer le moteur du véhicule ni aucune
génératrice électrique.
• Appelez le fournisseur de gaz le plus proche ou un
technicien qualifié.
• Si vous ne pouvez rejoindre ni un fournisseur ni un
technicien qualifié, appelez le service des incendies le
plus proche.
• Ne pas rétablir l’alimentation en gaz tant que la fuite
n’a pas été réparée.
— L’installation et l’entretien doivent être assurés
par un installateur ou un service d’entretien
qualifié ou par le fournisseur de gaz.
AVERTISSEMENT
Assurez-vous de bien suivre les instructions données
dans cette notice pour réduire au minimum le
risque d’incendie ou d’explosion ou pour éviter tout
dommage matériel, toute blessure ou la mort.
Rating and safety information inside.
(Caractéristiques et renseignementsde sécurité à l'intérieur)
FACTORYPRESET FOR USE WITH
NATURAL GAS
Direct-Vent Automatic Instantaneous Water Heater
(Chauffe-eauautomatique instantané à ventilation directe)
FOR INDOOR INSTALLATIONONLY
(POURINSTALLATION À L'INTÉRIEUR SEULEMENT)
120 Volt,60 Hz, 5 Amps
Typeof Gas
(Typede gaz)
:
. . . . . . . . . . . . . . . .
Input Rating
(Entrerle Classement)
: Btu/hr Maximum . . .
Btu/hr Minimum . . .
Maximum Inlet Gas Pressure: . . . . . . . . . . . .
Minimum Inlet Gas Pressure: . . . . . . . . . . . .
Minimum Inlet Gas Pressure (for adjustments): . .
Maximum Water Pressure: . . . . . . . . . . . . .
Minimum Water Pressure: . . . . . . . . . . . . .
Recovery Rating: . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
Thermal Effi
ciency / :
Energy Factor:
NOx Emissions:
. . . . . . . .
(Pursuantto South Coast Air Quality Management District Rule 1146.2)
(Moinsde 20 ppm)
(Jusqu'à98 % / 0.94) (Jusqu'à 98 % / 0.94)
(Moinsde 20 ppm)
(Dégagementsminimums)
(Desnon-combustibles) (D'uneconstruction
combustible)
(conformément au règlement 1146.2 du "South Coast Air Quality Management District)
Top of heater
Minimum Clearances
From
Non-Combustibles
From Combustible
Construction
(Dessus du chauffe-eau)
Back of heater
(Arrière du chauffe-eau)
Front of heater
(Avantdu chauffe-eau)
Bottom of cabinet
(Côté canalisation)
Side (Côté)
5/8 in (15.8 mm)
6 in (15.2 cm)
6 in (15.2 cm)
2 in (50.8 mm)
12 in (30.4 cm)
5/8 in (15.8 mm)
6 in (15.2 cm)
2 in (50.8 mm)
1/2 in (12.7 mm)
12 in (30.4 cm)
Intellihot Green TechnologiesInc.
2900 W. Main St.
Galesburg, IL 61401
Phone: [phone]
Email: [email protected]
Web: www.intellihot.com
Factory Preset
Natural Gas
(Réglageen usine pour gaz naturel)
199,000
20,000
13.0 W.C. (3.20 kPa)
8.0 W.C. (2.00 kPa)
8.0 W.C. (2.00 kPa)
150 psi (1034 kPa)
15 psi (103 kPa)
265 GPH (1003 LPH)
Up to 98% / 0.94
Less than 20 ppm
Field Conversion* to
Propane Gas
(Conversion*sur place au gaz propane)
199,000
20,000
10.5 W.C. (2.62 kPa)
3.0 W.C. (0.76 kPa)
11.0 W.C. (2.74 kPa)
150 psi (1034 kPa)
15 psi (103 kPa)
265 GPH (1003 LPH)
Up to 98% / 0.94
Less than 20 ppm
Check Box if
Convertedto
PropaneGas
*Referto Installation and Operation
manualfor conversion procedure.
(Seréférer au manuel d'installation et
defonctionnement pour la procédure de
conversion.)
PRÉRÉGLAGESD'USINE POUR UTILISATION AVEC
GAZ NATUREL
(Pressionde gaz d'arrivée maximum)
(Pressiond'eau maximum)
(Pressiond'eau minimum)
(Caractéristiquede recouvrement)
(Efficacitéthermique / Facteur énergétique)
(Émissionsde NOx)
(Pressionde gaz d'arrivée minimum)
(Pressionde gaz d'arrivée minimum (pour ajustements))
Cocherla case si converti au gaz propane
ETL STICKER
Serial Number:
IGT-LBL-0005-01
(Numérode série)
(CollantETL)
IQVWDOODWLRQ
2SHUDWLRQ0DQXDO
Intellihot ModelV
i200, i200P, i250, and i250P
,QWHOOLJHQW:DWHU+HDWHUV
8OWUD/RZ12[DSSOLHVWRLL3RQO\

Intellihot Green Technologies, Inc. 3
www.intellihot.com (877-835-1705)
TABLE OF CONTENTS
Table of Contents
TABLE OF CONTENTS. . . . . . . . . . . . . . . . . . . . .3
ITEMS SHIPPED WITH WATER HEATER . . . . . .4
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Safety Icon Nomenclature. . . . . . . . . . . . . . . . . . . . . . 6
Personal Protection . . . . . . . . . . . . . . . . . . . . . . . . . 6
Prohibited Actions. . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Hazard Avoidance . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operation and Installation Warnings . . . . . . . . . . . . . . 6
TECHNICAL SPECIFICATIONS . . . . . . . . . . . . .10
SPECIFICATIONS (NOMENCLATURE) . . . . . . .12
DIMENSIONAL SPECIFICATIONS . . . . . . . . . . .13
QUICK REFERENCE INSTALLATION GUIDE . .14
PREPARATION BEFORE INSTALLATION . . . . .16
Selecting an Installation Site . . . . . . . . . . . . . . . . . . . 16
High Elevation Installations . . . . . . . . . . . . . . . . . . 17
Water Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
WALL MOUNTING. . . . . . . . . . . . . . . . . . . . . . . .19
Mounting Block Installation Method. . . . . . . . . . . . . . 19
Plywood Installation Method . . . . . . . . . . . . . . . . . . . 19
GAS CONNECTION. . . . . . . . . . . . . . . . . . . . . . .20
GAS PIPE SIZING TABLES . . . . . . . . . . . . . . . .21
Gas Pipe Sizing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Natural Gas Pipe Sizing . . . . . . . . . . . . . . . . . . . . . 21
LP Gas Pipe Sizing . . . . . . . . . . . . . . . . . . . . . . . . 21
COMBUSTION (FRESH) AIR INLET EXHAUST
OUTLET CONNECTIONS . . . . . . . . . . . . . . . . . .22
VENTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Combustion (All) Air From the Outdoors . . . . . . . . 24
Outdoor Air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Two Openings or Ducts. . . . . . . . . . . . . . . . . . . . 24
Size of Openings. . . . . . . . . . . . . . . . . . . . . . . . . 24
Attic Combustion Air . . . . . . . . . . . . . . . . . . . . . . 24
Under-floor Combustion Air. . . . . . . . . . . . . . . . . 24
Opening Requirements . . . . . . . . . . . . . . . . . . . . 24
Combustion (All) Air From Inside the Building . . . . 26
Required Volume. . . . . . . . . . . . . . . . . . . . . . . . . 26
Confined Space. . . . . . . . . . . . . . . . . . . . . . . . . . 26
Unusually Tight Construction . . . . . . . . . . . . . . . 26
Power Vent Installation Examples . . . . . . . . . . . . . 26
INSTAL HOT WATER LINES. . . . . . . . . . . . . . . .27
INSTAL COLD WATER LINES . . . . . . . . . . . . . .28
INSTALL CONDENSATE DRAIN . . . . . . . . . . . .29
CONNECT ELECTRICAL POWER / INITIAL
STARTUP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
MULTIPLE UNITS . . . . . . . . . . . . . . . . . . . . . . . . 31
MEASURING GAS PRESSURE . . . . . . . . . . . . . 36
PROPANE (LPG) CONVERSION . . . . . . . . . . . . 37
ADJUSTING THE CO2LEVEL. . . . . . . . . . . . . . .39
Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Display Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Setting the Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Adjusting the Water Temperature . . . . . . . . . . . . . . . 44
Customer Screens. . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Domestic Heating Mode. . . . . . . . . . . . . . . . . . . . . 45
Programming ON/OFF Run Times. . . . . . . . . . . . . 45
WATER HEATER PROGRAMMING SECTION . .45
Recirculation Setup . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Cascading (Daisy Chain). . . . . . . . . . . . . . . . . . . . . . 47
Technician Screens . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Pressure Booster (pump models only . . . . . . . . . . 48
Fast Start Selection . . . . . . . . . . . . . . . . . . . . . . . . 48
Flow Booster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Blower Ramp Selection . . . . . . . . . . . . . . . . . . . . . 49
Flow Control Selection . . . . . . . . . . . . . . . . . . . . . . 50
Fuel Type Selection . . . . . . . . . . . . . . . . . . . . . . . . 50
Blower Override . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Diagnostic Code and Error Log Selection . . . . . . . 51
Diagnostic Code and Error Log Selection . . . . . . . 52
Adjusting CO2Levels Selection . . . . . . . . . . . . . . . 52
Commercial Heating Selection. . . . . . . . . . . . . . . . 52
MAINTENANCE. . . . . . . . . . . . . . . . . . . . . . . . . .53
Cleaning the Inlet Water Y-Strainer . . . . . . . . . . . . . . 54
Draining the Water Heater. . . . . . . . . . . . . . . . . . . . . 54
Filling the Water Heater. . . . . . . . . . . . . . . . . . . . . . . 55
TROUBLESHOOTING CHART . . . . . . . . . . . . . .55
WIRING DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . 57
COMMERCIAL OPTIONS . . . . . . . . . . . . . . . . . .58
Commercial Option #1 . . . . . . . . . . . . . . . . . . . . . . 59
Commercial Option #2 . . . . . . . . . . . . . . . . . . . . . . 59
Commercial Option #3 . . . . . . . . . . . . . . . . . . . . . . 59
Commercial Option #4 . . . . . . . . . . . . . . . . . . . . . . 59
Commercial Option #5 . . . . . . . . . . . . . . . . . . . . . . 59
Commercial Option #6 . . . . . . . . . . . . . . . . . . . . . . 59
OPERATIONAL DIAGRAM . . . . . . . . . . . . . . . . .59
WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Effective Start Date . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Heat Exchanger Coil . . . . . . . . . . . . . . . . . . . . . . . . . 61
All other Parts and Components . . . . . . . . . . . . . . . . 61
Labor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Shipping Costs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Definition of Potable Water . . . . . . . . . . . . . . . . . . . . 61
WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Not Covered by this Warranty . . . . . . . . . . . . . . . . . . 62
Warranty Limitations . . . . . . . . . . . . . . . . . . . . . . . . . 62
How to Make a Claim . . . . . . . . . . . . . . . . . . . . . . . . 62
Requirements for the State of Massachusetts . . . . . 63
Notice Before Installation . . . . . . . . . . . . . . . . . . . . 63
NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

4Intellihot Green Technologies, Inc.
www.intellihot.com (877-835-1705)
The following items are shipped with the water heater;
upper mounting bracket (1), condensate KRVH (2),
Operator’s manual (3), communication cable (4), O-rings
(5), and tee fitting (6).
IH-78
To avoid product damage, personal injury, or
even possible death, carefully read, understand,
and follow all the instructions in the Installation
and the Operation manuals before installing
thisproduct. Improper installation, adjustment, alteration,
or maintenance can cause injury,loss of life, and/or
property damage. This water heater should be installed
and serviced by a qualified technician. The lack of proper
service can result in adangerous condition.
This manual contains safety information, installation
instructions, and maintenance procedures. It must be left
with the homeowner or placed near the water heater in a
noncombustible place. The homeowner should retain this
manual for future reference.
Due to Intellihot’spolicy of continuous product
improvement and technology,thedesign and/or technical
specifi
cations are subject to change without notice.
Serial Number: ___________________________________
Date of Installation: ___ / ___ / ______
IGT-MNL002(10/2011 )
WARNING
If the information in these instructions is not followed
exactly, a fire or explosion could result causing
propertydamage, personal injury, or death.
—Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light anyappliance.
•
Do not touch any electrical switch; do not use
any phone inyour building.
•
Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
•
If you cannot reach your gassupplier, call the
fire department.
— Installation and service must be performed by
aqualified installer, service agency, or the gas
supplier.
WARNING
If the information in theseinstructions is not followed
exactly, a fire or explosion couldresult causing
propertydamage, personal injury, or death.
— Do not store or use gasoline or other flammable
vaporsand liquids in the vicinity of this or any other
appliance.
WHATTO DO IF YOU SMELL GAS
•Evacuateall persons from the vehicle.
•Shutoff the gas supply at the gas container or
source.
•Donot touch any electrical switch, or use any phone
orradio in the vehicle.
•Donot start the vehicle’s engine or electric generator.
•Contactthe nearest gas supplier or qualified service
technicianfor repairs.
•Ifyou cannot reach a gas supplier or qualified service
technician,contact the nearest fire department.
•Donot turn on the gas supply until the gas leak(s)
hasbeen repaired.
—
Installationand service must be performed by
aqualified installer, service agency, or the gas
supplier.
— Nepas entreposer ni utiliser d’essence ou
ni d’autres vapeurs ou liquides inflammables
à proximité de cet appareil ou de tout autre
appareil.
QUEFAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ
•
Nepas tenter d’allumer d’appareil.
•
Ne touchez àaucun interrupteur; ne pas vous
servir des téléphones se trouvant dans
lebâtiment.
•
Appelezimmédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions
dufournisseur.
•
Sivous ne pouvez rejoindre le fournisseur,
appelezle service des incendies.
— L’installation et l’entretien doivent être assurés
parun installateur ou un service d’entretien
qualifiéou par le fournisseur de gaz.
AVERTISSEMENT
Assurez-vousde bien suivre les instructions données
dans cette notice pour réduire au minimum le
risque d’incendie ou d’explosion ou pour éviter tout
dommagematériel, toute blessure ou la mort.
—
Ne pas entreposer ni utiliser d’essence ou
ni d’autres vapeurs ou liquides inflammables
à proximité de cet appareil ou de tout autre
appareil.
QUEFAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ
•Évacuezle véhicule.
•
Coupezl’alimentation en gaz au réservoir ou àla
source.
•
Netouchez à aucun interrupteur ;ne pas vous servir
dutéléphone ou de la radio du véhicule.
•Nepas démarrer le moteur du véhicule ni aucune
génératriceélectrique.
•Appelezle fournisseur de gaz le plus proche ou un
technicienqualifié.
•
Sivous ne pouvez rejoindre ni un fournisseur ni un
technicienqualifié, appelez le service des incendies le
plusproche.
•
Nepas rétablir l’alimentation en gaz tant que la fuite
n’apas été réparée.
—
L’installationet l’entretien doivent être assurés
parun installateur ou un service d’entretien
qualifiéou par le fournisseur de gaz.
AVERTISSEMENT
Assurez-vousde bien suivre les instructions données
dans cette notice pour réduire au minimum le
risque d’incendie ou d’explosion ou pour éviter tout
dommagematériel, toute blessure ou la mort.
Ratingandsafetyinformationinside.
(Caractéristiquesetrenseignementsdesécuritéà l'intérieur)
FACTORYPRESETFORUSEWITH
NATURALGAS
Direct-VentAutomaticInstantaneousWaterHeater
(Chauffe-eauautoma
tiqueins
tanta
néàventilationdirecte)
FORINDOORINSTALLATIONONLY
(POURINSTALLATIONÀL'INTÉ
RIEURSEULE
MENT)
120Volt,60Hz,5Amps
TypeofGas
(Typedegaz)
:
... .. . . . .. .. . ...
InputRating
(EntrerleClassement)
:Btu/hrMaximum. ..
Btu/hrMinimum...
MaximumInletGasPressure:.. .... . . ....
MinimumInletGasPressure:... . . . . . . ...
MinimumInletGasPressure(foradjustments): ..
MaximumWaterPressure: . . . .. .. . . . . . .
MinimumWaterPressure: .. . . . . .. . . . . .
RecoveryRating:.... ... .. . .. .. . . ..
.. . . . . .. . . . . . . . . ..
ThermalEffi
ciency/:
EnergyFactor:
NOxEmissions:
... . . . . .
(PursuanttoSouthCoast
AirQualityManagementDistrictRule1
146
.2)
(Moinsde20ppm)
(Jusqu'à98%/0
.94)(Jusqu'à98
%/0.94)
(Moinsde20ppm)
(Dégagem
entsmini
mums)
(Desnon-c
ombustibles)(D'uneconstruction
combustible)
(conformémentaurèglement1146.2du"Sout
hCoastAirQualityManagement
District)
Topofheater
MinimumClearances
From
Non-Combustibles
FromCombustible
Construction
(Dessusduchauffe-eau)
Backofheater
(Arrièreduchauffe-eau)
Frontofheater
(Avantduchauffe-eau)
Bottomofcabinet
(Côtécanalisation)
Side(Côté)
5/8in(15.8mm)
6in(15.2cm)
6in(15.2cm)
2in(50.8mm)
12in(30.4cm)
5/8in(15.8mm)
6in(15.2cm)
2in(50.8mm)
1/2in(12.7mm)
12in(30.4cm)
IntellihotGreenTechnologiesInc.
2900W.MainSt.
Galesburg,IL61401
Phone:[phone]
Email:[e-mail]
Web:www.intellihot.com
FactoryPreset
NaturalGas
(Réglageenus
ine
pou
rgaz
naturel)
199,000
20,000
13.0W.C.(3.20kPa)
8.0W.C.(2.00kPa)
8.0W.C.(2.00kPa)
150psi(1034kPa)
15psi(103kPa)
265GPH(1003LPH)
Upto98%/0.94
Lessthan20ppm
FieldConversion*to
PropaneGas
(C
onve
rsion*
surplaceaugazpropane)
199,000
20,000
10.5W.C.(2.62kPa)
3.0W.C.(0.76kPa)
11.0W.C.(2.74kPa)
150psi(1034kPa)
15psi(103kPa)
265GPH(1003LPH)
Upto98%/0.94
Lessthan20ppm
CheckBoxif
Convertedto
PropaneGas
*RefertoInstalla
tionandOperati
on
manualforconversi
onprocedu
re.
(Seréférerauman
ueld'instal
lationet
defoncti
onnementpo
urlapro
cédured
e
conv
ersion.)
PRÉRÉGLA
GES
D'US
INEPOURUTILIS
A
TIO
NAVEC
GAZNATUREL
(Pressiondegazd'arrivéemaximum)
(Pressiond'eaumaximum)
(Pressiond'ea
uminimu
m)
(Caractéri
stiquederecouvrement)
(Efficacitéthermique/Facteurénergétique)
(ÉmissionsdeNOx)
(Pressiondegazd'arrivéeminimum)
(Pressiondegazd'arrivéeminimum(pourajustements))
Cocherlacasesicon
vertiaugazpro
pane
ETLSTICKER
SerialNumber:
IGT-LBL-0005-01
(Numérodeséri
e)
(CollantET
L)
INSTALLATION
MANUAL
Intellihot Models
NG150i, NG185i, NG200i, NG230i
P150i, P185i, P200i, P230i
Intelligent Water Heaters
Intelligent Water Heaters
I
n
t
e
llig
en
tW
a
t
er
H
ea
t
er
s
Intelligent Water Heaters
1
2
3
4
5
6
ITEMS SHIPPED WITH WATER HEATER
IMPORTANT
&RQGHQVDWHGUDLQKRVHKDV]LSWLHVWRNHHS
ORRS'RQRWXQGRRUFXWWKHVH]LSWLHV

Intellihot Green Technologies, Inc. 5
www.intellihot.com (877-835-1705)
WARNING
Intellihot cannot anticipate every circumstance that might
involve a potential hazard and our warnings are, therefore, not
all-inclusive. Proper installation, operation, and service is your
responsibility.
You must be satisfied that the operation and settings of the
water heater are safe for you and for others.
To avoid product damage, personal injury, or even
possible death, carefully read, understand, and
follow all the instructions in the Installation and
Operation manual and on the water heater before
installation, operation, or service.
IGT-LBL-0001-01
Pour éviter un dommage au produit, une blessure personnelle
ou même la mort, lire avec soin, comprendre et suivre toutes
les instructions dans le manuel d'installation et de fonction-
nement et sur le chauffe-eau avant l'installation, le fonction-
nement ou l'entretien.
Intellihot ne peut pas prévoir toutes les circonstances qui
pourraient impliquer un danger potentiel et par conséquent,
nos avertissements ne comprennent pas tout. L'installation, le
fonctionnement et l'entretien correct sont votre
responsabilité.
Vous devez être certain que le fonctionnement et les réglages
du chauffe-eau sont sécuritaires pour vous et pour les autres.
Safety Alert Symbols
This is the safety alert symbol. It is used to alert
you to potential personal injury hazards. Obey
all safety messages that follow this symbol to
avoid possible injury or death.
This manual contains DANGERS, SAFETY
INSTRUCTIONS, CAUTIONS, IMPORTANT NOTICES,
and NOTES which must be followed to prevent the
possibility of improper service, damage to the equipment,
personal injury, or death. The following key words call the
readers’ attention to potential hazards.
Hazards are identified by the “Safety Alert Symbol”
and followed by a signal word such as “DANGER”,
“WARNING”, or “CAUTION”.
DANGER
Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury. This signal word is limited to
the most extreme situations.
WARNING
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.
NOTICE
Indicates that equipment or property damage can result if
instructions are not followed.
SAFETY
INSTRUCTIONS
Safety instructions (or equivalent) signs indicate specific safety-
related instructions or procedures.
NOTE: Contains additional information important
to a procedure.
IMPORTANT
Indicates that equipment or property damage can
result if instructions are not followed.
NOTE: Provides additional information that is
helpful for installation or operation of the water
heater.
SAFETY

6Intellihot Green Technologies, Inc.
www.intellihot.com (877-835-1705)
Safety Icon Nomenclature
Icons signal a type of hazard and warn of personal
protection issues, prohibited actions, and hazard
avoidance.
Personal Protection
Read the manual
Eye protection
High water temperature
Fill water tank before connecting to electrical
power
Disconnect power
Connect power
Close gas valve
Open gas valve
5 Wait five minutes
Use two people when lifting heavy objects
Prohibited Actions
No open flame
Use proper tools
Do not use if submerged under water
No liquid around electrical component
Hazard Avoidance
Disconnect power electrical hazard
Electrocution RUVKRFNhazard
Hot liquid, burn hazard
Hot surface
Lifting hazard
Pressurized liquid
Safety alert symbol
Slipping injury
Tripping injury
Fire hazard
Explosion hazard
Provide proper ventilation
Operation and Installation Warnings
To avoid serious injury or death, read, understand and
follow all the precautions listed here.
DANGER
Vapors from flammable liquids will explode and can
cause a fire, resulting in personal injury or death. The
water heater has a burner that can come on at any
time and ignite vapors. DO NOT use or store flammable
liquids around the water heater.
Improper venting can cause a build-up of carbon monoxide.
Breathing carbon monoxide can result in brain damage or
death. DO NOT operate the water heater unless it is properly
vented to the outside and has an adequate fresh air supply
for safe operation. Inspect the exterior exhaust gas outlet port and
fresh air inlet port on a regular basis to ensure they are functioning
properly.
A concentration of carbon monoxide as small as 0.04% (400
parts per million) in the air can be fatal. When making high
fireor low fire adjustments, CO levels must be monitored
using a flue gas analyzer sXFK that D &2 level of no more
than 400SSPLVH[FHHGHGDWDQ\WLPHGXULQJRSHUDWLRQ
Adjusting the “low fire offset” or the “main flow restrictor” in
small increments can result in a significant increase in CO
concentration. To avoid serious injury or death, DO NOT
make any adjustments to the gas valve without monitoring
the exhaust gases with a fully functional and calibrated flue gas
analyzer.
WARNING
The Intellihot water heater must be installed by a licensed
plumber, licensed gas fitter, and/or professional service
technician. Improper installation and/or operation can cause
a potentially hazardous situation, which, if not avoided, could
result in serious injury or death, and will void the warranty.
Proper care is your responsibility. Carefully read and
understand the Operation Information in this manual before
operating the Intellihot water heater.
Make sure you know the location of the gas shut-off valve
and how to operate it. Immediately close the gas shut-off
valve if the water heater is subjected to fire, overheating,
flood, physical damage, or any other damaging condition that
might affect the operation of the unit. Have the water heater checked
by a qualified technician before resuming operation.
SAFETY

Intellihot Green Technologies, Inc. 7
www.intellihot.com (877-835-1705)
WARNING
Do not power up the unit unless the gas and water supply
valves are fully opened. Make sure the fresh air intake port
and exhaust gas port are open and functional.
DO NOT attempt to install, service, or repair this water heater
yourself. There are no serviceable parts which can be
changed by the owner. Contact a qualified technician if your
water heater needs repair or maintenance. Ask your gas
supplier for a list of qualified service providers.
Keep the area around the water heater clean and free of all
materials that can burn. DO NOT store or place gasoline, oils,
spray paint, or other flammable products near the water heater.
DO NOT use spray paint, hair spray, or any other flammable
spray near the water heater or near the exterior fresh air inlet
port. DO NOT place any items in or around the exterior
exhaust gas outlet port and/or fresh air inlet port that could
restrict or block the flow in or out of the vent system.
DO NOT store or place newspapers, laundry, or other
combustible items near the water heater or the exterior
exhaust gas outlet and/or fresh air inlet port.
The owner should inspect the system monthly for damage,
water stains, signs of rust, corrosion, and exhaust vent and
air intake blockage. If inspection of the unit shows signs of
damage, the water heater should be shut off until the problem
is repaired by a qualified technician.
DO NOT allow children to operate this unit. DO NOT use this
unit if it does not appear to be operating correctly.
A qualified technician should service and inspect the water
heater annually.
The water heater temperature is factory set to 120°F (49°C).
To avoid scalding, always check the temperature of the hot
water before bathing, showering, washing, etc. DO NOT
adjust the water temperature while the Intellihot water heater
is being used by other persons.
IMPORTANT
Do not use the water heater if any part has
been under water. Immediately call a qualified service
technician and have the unit inspected. Replace any
components that have been under water.
The Intellihot water heater is equipped with a three prong plug. It
should only be plugged directly into a properly grounded three
prong receptacle. DO NOT remove the ground prong from the plug.
DO NOT alter or modify the water heater or water heater controls.
This can be dangerous and will void the warranty.
SAFETY

8Intellihot Green Technologies, Inc.
www.intellihot.com (877-835-1705)
Always read and follow all warnings on water heater
safety decals and in the manual. If the Installation and
Operation manual is missing, go to www.intellihot.com
or contact Intellihot [phone] for a replacement.
Use this water heater at your own risk. The outlet
temperature of the Intellihot water heater is factory preset
to 120°F (49°C). The temperature can only be changed by
using the control panel on the front of the water heater.
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
Flammable vapors can ignite and
cause serious damage or injury.
This water heater is factory preset for NATURAL GAS.
For propane conversion, refer to the manual.
Connecting the water heater to any other gas supply can result
in property damage, serious injury, and even death.
Suitable for water (potable) heating and
space heating. The water heater MUST NOT be
connected to any heating system or components previously
used with a nonpotable water heating appliance.
Do not use toxic chemicals, such as used for boiler
treatment, in potable water space heating systems.
This appliance must be installed in accordance with
local codes or, in the absence of local codes, the
National Fuel Gas Code, ANSI Z223.1/NFPA 54 or the
CSA B149.1, Natural Gas and Propane Installation Code.
Pressure Relief Valve
A pressure relief valve complying with the Standard for
Relief Valves for Hot Water Supply Systems, ANSI Z21.22
or CAN1-4.4 Temperature, Pressure, Temperature and Pressure
Relief Valves and Vacuum Relief Valves must be installed in a
proper outlet port of water heater at the time of installation
according to local codes.
No valve is to be placed between the relief valve and the
water heater.
The discharge from the temperature/pressure relief valve
should be directed to the ground or into a drain system
which will prevent a burn hazard or property damage. The
piping must not have a reducing coupling or other restriction
in the discharge line. The discharge line must be installed to
allow complete drainage of both the valve and line.
If the system requires water for space heating at
temperatures higher than required for other uses, a
mixing valve must be installed to temper the water for those
other uses in order to reduce scald hazard potential.
The pressure relief valve must not be removed or
plugged.
FOR YOUR SAFETY READ BEFORE OPERATING
OPERATING INSTRUCTIONS
TO TURN OFF GAS TO WATER HEATER
If you do not follow these instructions exactly, a fire or explosion
may result, causing property damage, personal injury, or loss of life.
A. This water heater does not have a pilot. It is
equipped with an ignition device which automatically
lights the burner. Do not try to light burner manually.
B. BEFORE OPERATING, smell all around the water
heater area for gas. Be sure to smell next to the
floor because some gas is heavier than air and will
settle on the floor.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
•Do not touch any electric switch; do not use any phone
in your building.
•Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
•If you cannot reach your gas supplier, call the fire or police
department.
C. Use only your hand to turn manual gas shut-off valve.
Never use tools. If manual gas shut-off valve will not
turn by hand, don’t try to repair it, call a qualified
service technician. Force or attempted repair may result in a
fire or explosion.
D. Do not use this water heater if any part has been under
water. Immediately call a qualified service technician
to inspect water heater and replace any part of control
system and any gas control which has been under water.
DANGER
DANGER
WARNING
1. Turn OFF electrical power to water heater.
2. Turn manual gas shut-off valve to OFF position.
Intellihot Green Technologies Inc. Phone: [phone]
www.intellihot.com
Hot water temperature over 125°F (52°C) can
cause severe burns instantly or death from
scalding. Children, disabled, and elderly are at
the highest risk of being scalded. Do not leave
children or the infirm unsupervised. Check
temperature of hot water before taking a shower
or bath. To control water temperature to a
particular faucet, temperature limiting valves can be installed
by your service professional.
If water heater is not operating, follow these instructions. This
appliance is equipped with an ignition device which automati-
cally lights the burner. Do not try to light the burner manually.
1.
2.
3.
4.
5.
5
6.
7.
8.
If water heater will not operate, follow instructions “To Turn Off
Gas To Water Heater” and call your service technician or gas
supplier.
STOP! Read the safety information above on this
label.
Never use water heater unless it is completely filled
with water.
Turn OFF electrical power supply to the water heater.
Turn gas shut-off valve clockwise to “OFF” position.
Do not force.
Wait five (5) minutes to clear out any gas. If you then
smell gas, STOP! Follow step “B” above on this
label. If you don’t smell gas, go to next step.
Turn manual gas shut-off valve to “ON” position.
Turn ON electrical power to unit.
Wait until default temperature (120°) is displayed.
Set desired water temperature. Turn on hot water
faucet.
IGT-LBL-0002-01
SAFETY

Intellihot Green Technologies, Inc. 9
www.intellihot.com (877-835-1705)
Utiliser ce chauffe-eau à vos propres risques. La température
de sortie du chauffe-eau Intellihot est réglée en usine à 49 °C
(120 °F). La température peut être modifiée seulement en
utilisant le panneau de commande à l'avant du chauffe-eau.
Ne pas entreposer ou utiliser de gazoline
ou autres vapeurs ou liquides
inflammables à proximité de cet appareil
ou autre. Les vapeurs inflammables
peuvent s'enflammer et causer un
dommage sérieux ou une blessure.
Vapeurs inflammables
Soupape de surpression
DANGER
AVERTISSEMENT
Intellihot Green Technologies Inc. Téléphone: 877-835 1705
www.intellihot.com
GT-LBL-0003-01
Toujours lire et suivre tous les avertissements sur les
décalcomanies de sécurité sur le chauffe-eau et dans le
manuel. Si le manuel d'installation et de fonctionnement
n'est pas disponible, visiter le www.intellihot.com ou
contacter Intellihot [phone] pour un remplacement.
Une température d'eau chaude de plus de 52 °C
(125 °F) peut causer des brûlures sévères instan-
tanément ou la mort par ébouillantage. Les enfants,
les personnes handicapées et les personnes âgées
sont les plus à risque d'être ébouillantées. Ne pas
laisser les enfants ou les infirmes sans supervision.
Vérifier la température de l'eau chaude avant de
prendre une douche ou un bain. Des vannes régulatrices de
température peuvent être installées par votre professionnel
d'entretien afin de contrôler la température de l'eau sur un robinet en
particulier.
Ce chauffe-eau est préréglé en usine pour le GAZ
NATUREL. Pour la conversion au propane, se référer au
manuel. Connecter le chauffe-au à toute autre alimentation
en gaz peut causer un dommage à la propriété, une blessure
sérieuse et même la mort.
Une soupape de surpression conforme à la norme Relief
Valves for Hot Water Supply Systems, ANSI Z21.22 ou
CAN1-4.4 Temperature, Pressure, Temperature and
Pressure Relief Valves and Vacuum Relief Valves doit être
installée dans le bon port de sortie du chauffe-eau au moment de
l'installation conformément aux codes locaux.
La décharge de la soupape de température/surpression
devrait être dirigée vers le sol ou dans un système de drain
qui empêchera un risque de brûlure ou un dommage à la
propriété. La tuyauterie ne doit contenir aucun raccord réducteur
ou autre restriction dans la ligne de décharge. La ligne de
décharge doit être installée afin de permettre un drainage complet
de la vanne et de la ligne.
Convient pour le chauffage de l'eau (potable) et le chauffage
des locaux. Le chauffe-eau NE DOIT PAS être connecté à un
système de chauffage ou à des composants utilisés pour un
appareil de chauffage d'eau non potable.
Ne pas utiliser de produits chimiques toxiques, comme
ceux utilisés pour le traitement de chaudière, dans des
systèmes de chauffage de locaux et d'eau potable.
Aucune vanne ne doit être placée entre la soupape de
surpression et le chauffe-eau.
La soupape de surpression ne doit pas être retirée ou
bouchée.
Cet appareil doit être installé conformément aux codes
locaux, ou , en l'absence de codes locaux, selon le National
Fuel Gas Code, ANSI Z223.1/NFPA 54 ou le Code
d'installation du gaz naturel et du propane, CSA B149.1.
Si le système exige de l'eau pour le chauffage de locaux à
des températures plus élevées que celles pour d'autres
usages, une vanne de mélange doit être installée pour
tempérer l'eau pour ces autres usages afin de réduire la possi-
bilité de blessure par ébouillantage.
POUR VOTRE SÉCURITÉ, LIRE AVANT D'UTILISER
INSTRUCTIONS DE FONCTIONNEMENT
POUR ARRÊTER L'ALIMENTATION
EN GAZ AU CHAUFFE-EAU
Si vous ne suivez pas ces instructions exactement, un incendie ou
une explosion pourrait résulter causant des dommages à la
propriété, une blessure personnelle ou une perte de vie.
A.
B.
QUE FAIRE SI VOUS SENTEZ DU GAZ
• Ne pas essayer d'allumer aucun appareil.
•Ne toucher aucun interrupteur électrique; n'utiliser aucun
téléphone dans votre édifice.
•Appeler immédiatement votre fournisseur de gaz à partir du
téléphone d'un voisin. Suivre les instructions du fournisseur de gaz.
•Si vous ne pouvez pas rejoindre votre fournisseur de gaz, appeler
le service d'incendie ou de police.
C.
D.
DANGER
1. METTRE HORS FONCTION l'alimentation électrique au chauffe-eau.
2. Tourner la vanne d'arrêt manuelle du gaz à la position d'arrêt (OFF).
1.
2.
3.
4.
5.
5
6.
7.
8.
Si le chauffe-eau ne fonctionne pas, suivre les instructions
« Pour arrêter l'alimentation en gaz au chauffe-eau » et appeler
votre technicien d'entretien ou votre fournisseur de gaz.
ARRÊTEZ! Lire les renseignements de sécurité
ci-dessus sur cette étiquette.
Ne jamais utiliser le chauffe-eau à moins qu'il soit
entièrement rempli d'eau.
METTRE HORS FONCTION l'alimentation électrique au
chauffe-eau.
Tourner la vanne d'arrêt manuelle du gaz dans le sens
des aiguilles d'une montre à la position d'arrêt (OFF).
Ne pas forcer.
Attendre cinq (5) minutes pour laisser le gaz s'évaporer.
Si vous sentez du gaz, ARRÊTEZ! Suivre l'étape « B »
ci-dessus sur cette étiquette. Si vous ne sentez pas de
gaz, passer à l'étape suivante.
Tourner la vanne d'arrêt manuelle du gaz à la position
de fonctionnement (ON).
METTRE EN FONCTION l'alimentation électrique à
l'appareil
Attendre jusqu'à ce que la température
par défaut (120°) soit affichée. Régler la température
désirée pour l'eau. Ouvrir le robinet d'eau chaude.
Ce chauffe-eau n'a pas de pilote. Il est muni d'un
dispositif d'allumage qui allume automatiquement
le brûleur. Ne pas essayer d'allumer le brûleur
manuellement.
AVANT D'UTILISER, sentir tout autour du chauffe-eau
pour détecter une odeur de gaz. S'assurer de sentir
près du plancher parce que certains gaz sont plus
lourds que l'air et retombent sur le plancher.
Utiliser seulement votre main pour tourner la vanne
d'arrêt manuelle du gaz. Ne jamais utiliser d'outils. Si la
vanne d'arrêt manuelle du gaz ne peut pas être tournée
à la main, ne pas essayer de la réparer, appeler un
technicien d'entretien qualifié. Une réparation forcée ou tentée
pourrait causer un incendie ou une explosion.
Ne pas utiliser ce chauffe-eau si une partie de celui-ci a
été sous l'eau. Appeler immédiatement un technicien
d'entretien qualifié pour inspecter le chauffe-eau et
remplacer toute partie du système de commande et
toute commande de gaz qui a été sous l'eau.
Si le chauffe-eau ne fonctionne pas, suivre ces instructions. Cet
appareil est muni d'un dispositif d'allumage qui allume automatique-
ment le brûleur. Ne pas essayer d'allumer le brûleur manuellement.
SAFETY

10 Intellihot Green Technologies, Inc.
www.intellihot.com (877-835-1705)
i200 i200P i250 i250P
Type
Fuel
Minimum / Maximum Input (Btu/h)
Combustion Efficiency
Thermal Efficiency
Energy Factor
Dimensions H x W x D (inches)
89098909)sbl(thgieW
Water Inlet / Outlet Connection
Gas Inlet Connection
Minmum Flow Rate
Ignition
Venting Type
Venting Materials
Max 3” Vent Length - Single Pipe / Power Vent
Max 3” Vent Length - Two pipe / Direct Vent
Max 2” Vent Length - Single Pipe / Power Vent
(2” not allowed at elevations above 4,000 ft)
Max 2” Vent Length - Two Pipe / Direct Vent (2”
not allowed at elevations above 4,000 ft)
Common Venting
Safety
Water Pressure Min / Max (PSI)
NG/LP- Minimum Static Gas Pressure 1/2"
NG/LP- Minimum Static Gas Pressure 3/4"
NG/LP - Maximum Static Gas Pressure
Gas Pressure for Adjustments
Electrical
Power Consumption
Features i200 i200P i250 i250P
Recirculation / Tank Loading No-Pump Built-In Pump No-Pump Built-In Pump
Cascading
Heat Exchanger
Performance i200 i200P i250 i250P
Hot Water Capacity (35F Rise)
Hot Water Capacity (45F Rise)
Hot Water Capacity (77F Rise)
Domestic Mode Temp. Settings
Commercial Mode Temp. Settings
Warranty (with recirculation)
200 ft, deduct 5 ft per 90°elbow 130 ft, deduct 5 ft per 90°elbow
100 ft, deduct 5 ft per 90° elbow 65 ft, deduct 5 ft per 90° elbow
21 ft, deduct 5 ft per 90° elbow
N/A
5" (non-corrugated, black iron) 6" (non-corrugated, black iron)
100 – 185°F
5.0
13.2
10.3
6.0
Note: 1Due to Intellihot's Policy of continuous product improvements, design, and technical specifications are subject to change
2Energy Star and Low NOx are applicable to i200 and i200P models.
8.4
Masterless, 10 units
Expandable, Stainless 316L
100 – 140°F
25.9 x 17.5 x 14.2 (3.7 cu. ft)
3/4" NPT
3/4" NPT
2.5" (non-corrugated, black iron)
No minimum flow rate for "P" models / 0.6 GPM
Sch. 40 PVC, Sch. 40 CPVC, Polypropylene, Stainless Steel
Residential - Heat Exchan
g
er coil - 15
y
ears, Parts – 5
y
ears, Labor – 1
y
ear
Commercial - Heat Exchanger coil – 6 years, Parts – 5 years, Labor – 1 year
10.8
14”
Yes
26 ft, deduct 5 ft per 90° elbow
Flame Rod, Thermal Fuse, Overheat Prevention Device, Fan Speed Monitor, Flue
Temperature Monitor, Blocked Vent Detector, Water Leak Detector, Water Shut-Off
Valve, 2X10A Fuse, Dual Flame Sensing
98%
Direct Vent (2 pipe - intake & exhaust), Power vent (1 pipe - exhaust only)
Electronic Spark Ignition
A/N39.0
%29%49
Parameters
000,052/000,03059,991/000,03
Models
Indoor, Wall hung, Fully Condensing
Preset for NG / LP Convertible
30 / 150
500W (Max 4.2 Amps), 8W (Standby)
8" for NG, 11" for LP
120V AC, 60 Hz
TECHNICAL SPECIFICATIONS

Intellihot Green Technologies, Inc. 11
www.intellihot.com (877-835-1705)
In order for the water heater to operate properly and
efficiently, the clearances specified in the table below are
required.
Required Mounting Clearances
Location From
Combustibles
From Non-
Combustibles
Service
Clearance1
Top 6” (15.2 cm) 2” (50.8 cm) 12” (30.4 cm)
Back25/8” (15.8 mm) 5/8” (15.8 mm) 5/8” (15.8 mm)
Sides 1” (25.4 mm) 1/2” (12.7 mm) 5/8” (15.8 mm)
Front 2” (5.1 cm) 2” (5.1 cm) 30” (76.2 cm)
Bottom 12” (30.4 cm) 12” (30.4 cm) 12” (30.4 cm)
1Service clearances are suggested dimensions to allow for normal
service of the unit.
2Installing (hanging) the unit with the included brackets automatically
sets this dimension.
CO2and CO Standards
Description CO2Range (%) Max. CO Level (ppm)
Natural Gas
High Fire 8.8% to 9.1% < 200 ppm
Low Fire 8.6% to 8.9% < 60 ppm
LP Gas
High Fire 8.8% to 9.1% < 200 ppm
Low Fire 8.6% to 8.9% < 60 ppm
Max Vent Length For Various Duct Sizes And
Number Of Units
Number
of Units
Venting
Type
Duct Size and Model
2” 3” 4” 6” 8”
i2003 i2003 i2503 i2003 i2503 i2003 i2503 i2003 i2503
11 pipe - PV 26 200 130 200 130
2 pipe - DV 21 100 65 100 65
21 pipe - PV 200 130
2 pipe - DV 100 65
31 pipe - PV 100 30 200 130
2 pipe - DV 50 30 100 65
41 pipe - PV 200 130
2 pipe - DV 100 65
51 pipe - PV 200 130
2 pipe - DV 100 65
61 pipe - PV 200 130
2 pipe - DV 100 65
71 pipe - PV 150 45
2 pipe - DV 75 45
81 pipe - PV 100 30 200 130
2 pipe - DV 50 30 100 65
91 pipe - PV 200 130
2 pipe - DV 100 65
10 1 pipe - PV 200 130
2 pipe - DV 100 65
PV = Power Vent
DV = Direct Vent
Note: Reduce the maximum equivalent length above by 5 feet per 90° elbow used and by 2 feet per 45° elbow.
Do not exceed the above set limits.
Top Connections
Description Specification2
Gas Supply Inlet Connection 3/4” Male NPT
&ROGWater ,QOHW Connection 3/4” Female NPT
+RW Water Outlet Connection 3/4” Female NPT
Exhaust Gas Vent 3” O.D.1
Fresh Air Intake 3” O.D.1
1Requires a 3” to 2” reducer when using 2” venting pipe.
2Using sizes other than specified can cause damage to the water
heater and will void the warranty.
Bottom Connections
Description Specification1
Drain Connection 3/4” Female NPT
Condensate Drain Connection 3/4” Nipple (3/4” flex hose)
Power Supply 120V AC Power Cord
1Using sizes other than specified can cause damage to the water
heater and will void the warranty.
TECHNICAL SPECIFICATIONS

12 Intellihot Green Technologies, Inc.
www.intellihot.com (877-835-1705)
IH-01
Safetyinformationandwiring diagram inside of front cover.Safety informationand wiring diagraminsideoffront cover.
EXHAUST
INLET
CHECK
VALVE
CHECK
VALVE
HOT WATER
OUT
GAS LINE
TEMPERATURE
AND PRESSURE
VALVE
WATER HEATER
DRAIN VALVE
CONTROL
PANEL
CONDENSATE
DRAIN
GATE VALVE
COLD WATER
INLET
GAS LINE
WATER TRAP
COLD WATER
IN
CHECK
VALVE
GAS
LINE
HOT WATER
TO USAGE
POINT
STRAINER
HOT
WATER
STORAGE
TANK
Typical installation of i200P piped with storage tank.
DIP Switch Locations on Control Board
SW
SWPropane
DIP Switch Settings (Réglages des commutateurs DIP)
&DVFDGH7HUPLQDWLRQ2))
7HUPLQDLVRQHQFDVFDGH2))
Natural Gas
(Gaz naturel)
Cascade 7HUPLQDWLRQ21
(7HUPLQDLVRQHQFDVFDGH21)
SPECIFICATIONS (NOMENCLATURE)

Intellihot Green Technologies, Inc. 13
www.intellihot.com (877-835-1705)
Selecting a Location
IH-79
361 ,3
[14 1/4”]
35,36
[1 3/8”]
Top View
Bottom View
Front View
L/H Side View
442,6
[17 7/16”]
Right
Side
Left
Side
155,4
[6 1/8”]
68,86
[2 3/4”]
Mounting
Wall Surface
347,3
[13 11/16”]
14
[9/16”]
64,6
[2 9/16”]
102,4
[4 1/8”]
185,1
[7 5/16”]
Hot Water
Out
3/4 NPT
Gas Inlet
3/4 NPT
Exhaust Port
3” PVC
59,11 [2 5/16”]
57,79
[2 1/4”]
198,7
[7 25/32”]
Drain Port/PRV 3/4-NPT
Power Cord
Condensate Drain
107,1
[4 7/32”]
59,94
[2 3/8”]
DIMENSIONAL SPECIFICATIONS

14 Intellihot Green Technologies, Inc.
www.intellihot.com (877-835-1705)
The quick reference illustrations show the installation
of two i200P water heaters connected together with a
storage tank. Installation of a single unit or up to five
units is basically the same. When installing multiple
units, refer to the Multiple Units section for additional
information.
1. Select a location. Note that the piping can be
configured to enter or exit the unit from either the left or
right side, as viewed from the front.
2. Mount the water heater(s) to the wall.
a. Attach two 2x4 mounting blocks (at least 23” for a
single unit or 46” long for two units) to the wall. The
uppermost mounting bRDUGV should be at the
desiredheight for the top of the unit.
IH-80
b. Attach a second mounting block 1”FHQWHUWR
FHQWHUbelow the upper mounting block.
c. Attach metal mounting bracket(s) to the upper
mounting block approximately 3” on either side
of the center and 1/2” down from the top of the
mounting block.
d. $GMXVWDQGWLJWKHQWKHERWWRPEUDFNHWWRWKHXQLWVVR
WKDW the unitto hangVvertically on the wall.
e. Hang the unit on the mounting bracket. If multiple
units are installed, the spacing between the units
should be approximately 6”.
Safetyinformation and wiring diagram inside offront cover. Safety information and wiring diagram inside of front cover.
IH-81
3. Install the gas lines, as shown in the illustration.
IH-82
Safetyinformation and wiring diagram inside of front cover. Safetyinformation and wiring diagram inside of front cover.
a. Temporarily place a short section of 3” schedule
40 PVC pipe on one of the air inlets in order to
judge clearance allowances as the gas piping is
assembled.
b. Due to limited wall clearance, connect the union as
your final step of gas piping.
c. Check for gas leaks at this point in the assembly
process.
QUICK REFERENCE INSTALLATION GUIDE

Intellihot Green Technologies, Inc. 15
www.intellihot.com (877-835-1705)
4. Install the combustion air inlet and flue gas outlet PVC
piping.
Note: The inlet and outlet pipes from the unit are
3” diameter while the header piping is 4” diameter,
as shown in the illustration. The larger header
piping is required whenever multiple units are
installed.
IH-83
Safetyinformation and wiring diagram inside of front cover. Safety information and wiring diagram inside of front cover.
5. Install and connect the hot water lines. If an optional
hot water storage tank is required, connect the hot
water lines to this tank. If required, install a pressure
relief valve or a temperature and pressure relief valve.
IH-84
Safetyinformation and wiring diagram inside of front cover. Safetyinformation and wiring diagram inside offron tcover.
6. Install and connect the cold water lines.
Safetyinformation and wiring diagraminside of frontcover.Safetyinformation and wiring diagraminside offront cover.
IH-85
7. Connect and route the condensate trap and drain line
to an appropriate discharge site or drain.
8. Verify gas pressure.
9. Connect the 120 Volt power supply.
Safetyinformation and wiring diagram inside of front cover.Safetyinformation and wiring diagram inside of front cover.
IH-85a
10. Test fire the unit by opening all hot water faucets.
Water Connections
QUICK REFERENCE INSTALLATION GUIDE
   



16 Intellihot Green Technologies, Inc.
www.intellihot.com (877-835-1705)
Selecting an Installation Site
1. Select an interior location for the installation. Each
installation is unique; therefore, take the time to find the
best location for the water heater.
a. Install the water heater near locations that use hot
water, such as bathroom, kitchen, or laundry room
faucets.
b. Select a location that minimizes the length of the
water pipe.
c. If the distances are long or if the faucet or appliance
requires “instant” hot water, we recommend running
a recirculation line back to the water heater from the
furthest fixture. Insulate the hot water supply and
recirculation lines.
IMPORTANT
When installing this water heater, follow all local
building codes and the current edition of the National
Fuel Gas Code (ANSI Z223.1/NFPA 54) in the USA or
National Gas and Propane Installation Code (CAN/CGA
B149.1) in Canada, when installing this product.
d. Select a location away from foot traffic and away
from areas where dust, debris, chemical agents, or
other combustible materials could accumulate.
e. Allow sufficient space for service and maintenance
access to all gas, water, and drain connections.
f. Make sure the location meets all building code
requirements.
g. Make sure the wall surface the water heater is
mounted onto will support the weight of the unit.
SAFETY
INSTRUCTIONS
The Intellihot i200 and i250 water heaters weigh 90 lbs. The i200P
and i250P weigh 98 lbs.
2. Minimize the distance that the exhaust gas vent and
fresh air intake must travel to an exterior wall.
a. The exhaust vent outlet must not be located next to
a walkway, near soffit vents, crawl space vents, or
other areas where condensate (water vapor) could
cause damage or create a hazard.
b. The fresh air inlet vent must be located at least 12”
from the exhaust vent.
c. Contaminated or dirty air drawn into the intake
pipe can damage the water heater. The Intellihot
warranty does not cover damage caused by
airborne contaminants.
IMPORTANT
Reduce the maximum equivalent length by 5 feet
per 90° elbow and by 2 feet per 45° elbow. Intake
and exhaust venting pipes have the same allowable
lengths. Do not exceed these set limits.
EXAMPLE: A 3” vent line or fresh air intake line
(Model i200) with the six 90 degree elbows would
be limited to a length of 70 feet in a WZLQSLSH
FRQILJXUDWLRQ
3. Locate the unit close to a drain and near gas and water
connections.
The water heater produces a significant amount of
condensate during normal operation and should be
located near a suitable drain where damage from
a possible leak will be minimal. Installing the water
heater in a location without a drain will void the
warranty and Intellihot will not be responsible for
any resulting water damages that may occur as a
result. For additional information, refer to the Install
Condensate Drain section.
The water heater should be located in an area where
leakage from the unit or water pipes will not result in
damage to the area around the appliance or to lower
floors of the structure. When such locations cannot
be avoided, it is recommended that a suitable drain
pan, adequately drained, be installed under the water
heater. The pan must not restrict combustion air flow.
Gas Connection PREPARATION BEFORE INSTALLATION

Intellihot Green Technologies, Inc. 17
www.intellihot.com (877-835-1705)
4. Locate the water heater and all water pipes in an area
where the ambient temperature always remains above
freezing.
a. When the water heater is connected to an electrical
power supply, it will automatically prevent the water
inside the unit from freezing.
b. The unit’s freeze protection system will not prevent
the water in surrounding pipes from freezing.
NOTICE
In cold climates, if there is a power failure, the unit’s
freeze protection system will not operate, and can
result in water freezing inside the heat exchanger.
To prevent damage to the water heater, turn OFF the gas
supply and inlet water valve. Open the drain valve and
completely drain the unit.
Damage caused by freezing water is not covered by the
Intellihot warranty.
5. Select an appropriate location for the combustion air
and exhaust pipes to exit the house. Use the diagram
and chart on the next page to make this determination.
High Elevation Installations
For operation at elevations above ,00 feet, Intellihot
model ratings should be reduced by 4% for each 1,000
feet above sea level.
Water Quality
3RWDEOHZDWHULVGHILQHGDVGULQNDEOHZDWHUVXSSOLHGIURP
XWLOLW\RUZHOOZDWHULQFRPSOLDQFHZLWK(3$VHFRQGDU\
PD[LPXPFRQWDPLQDQWOHYHOV&)5SDUWDV
VKRZQLQWKHWDEOHEHORZ,I\RXUZDWHUFRQWDLQV
FRQWDPLQDQWVKLJKHUWKDQRXWOLQHGE\(3$WKHQZDWHU
WUHDWPHQWLVUHFRPPHQGHGDQGDGGLWLRQDOPDLQWDLQHQFH
PD\EHUHTXLUHGIf you suspect that your water is
contaminated in any wayRUZDWHUKHDWHUHUURUVRFFXU,
discontinue use of the water heater and contact an
authorized technician or licensed professional.
Contaminant Maximum Allowable Level
Total Hardness 200 mg/l (12 grains/gallon)
Aluminum 0.05 to 0.2 mg/l
Chloride 250 mg/l
Copper 1.0 mg/l
Iron 0.3 mg/l
Manganese 0.05 mg/l
pH 6.5-8.5
Sulfate 205 mg/l
Total Dissolved Solids (TDS) 500 mg/l
Zinc 205 mg/l
PREPARATION BEFORE INSTALLATION

18 Intellihot Green Technologies, Inc.
www.intellihot.com (877-835-1705)
Venting Connections
IH-31
B
K
F
B
J
GDE
B
Fixed
Closed
Fixed
Closed
Operable
B
B
V
V
V
V
I
V
V
V
V
V
X
X
B
C
H
L
A
A
M
Operable
Inside Corner
Detail
Air Inside Inlet
Vent Terminal
Area Where Terminal is Not Permitted
V
X
ANSI Z223.1 / NFPA 54 for USA and CAN/CSA B149.1 for Canada - Venting Requirements
USA Clearance Canada Clearance
Item Description Specification Specification
A Above grade, veranda, porch, deck, or balcony 1 ft 1 ft
B Window or door that may be opened 1 ft** 3 ft
C Permanently closed window * *
D Vertical clearance to a ventilated soffit, eves, or overhang 3 ft*** *
E Unventilated soffit, eves, or overhang 3 ft*** *
F Outside corner * *
G Inside corner * *
H Each side of centerline extended from meter/regulator * 3 ft within a height 15 ft above the
meter/regulator assembly
I Service regulator vent outlet * 3 ft
J Nonmechanical air supply inlet or combustion air inlet
to any other appliance 1 ft** 3 ft
K Mechanical air supply inlet 3 ft above if 6 ft
within 10 ft
horizontally
L Above paved sidewalk or paved driveway on public property * 7 ft
M Under veranda, porch, deck, or balcony * 1 ft
*Not specified in ANSI Z223.1 / NFPA 54 or CAN/CGA-B146.
Use clearances in accordance with local building codes and local gas supplier.
** 4 feet (1.2 m) below or to the side of opening and 1 foot (300 mm) above opening.
*** Intellihot recommendation.
PREPARATION BEFORE INSTALLATION

Intellihot Green Technologies, Inc. 19
www.intellihot.com (877-835-1705)
Secure the unit to the wall using either two wood
mounting blocks or one piece of 3/4” plywood, as
described in this section.
Mounting Block Installation Method
1. Attach two 2x4 or 2x6 mounting blocks (horizontal
framing), at least 18 inches long, to the wall.
a. In wood or steel construction, use adequate wood/
metal screws and secure the mounting blocks with
at least two screws in each vertical wall stud (four
screws total).
b. In concrete block or solid concrete wall construction,
attach the mounting blocks with at least four
masonry screws or suitable masonry wall anchors in
each mounting block.
IH-26
21”
2
3
1
SAFETY
INSTRUCTIONS
The Intellihot water heaters weigh 90 to 100 lbs (40.8 to 45.4 kg)
and must be securely attached to the wall. Mounting hardware is
included and should be used to mount the unit.
2. Level upper bracket (2) and attach it to the mounting
block with at least four appropriately sized wood
screws (do not use drywall screws).
CAUTION
Lifting Hazard
According to the National Institute for Occupational
Safety and Health, the recommended maximum safe
lifting weight is 51 pounds, with all lifting conditions perfect—
minimal forward reach, steady load close to the body, straight back,
load between knees and shoulders, and good grips. To avoid
personal injury, always use these proper lifting techniques and use
two people to move the water heater which weighs 80 pounds.
3. With assistance, hang the unit on the upper wall
bracket, interlocking bracket (1) on the back of the unit
and wall bracket (2).
4. Install two appropriately sized wood screws in lower
bracket (3) to secure the unit to the wall.
5. Make sure the unit is plumb and level and tighten the
four sheet metal screws on bottom bracket (3). When
properly installed, there should be a 5/8” air space
between the back of the water heater and the mounting
blocks.
Plywood Installation Method
1. Mount a piece of 3/4” plywood (at least 32” high x 20”
wide) to the wall.
a. In wood or steel construction, use adequate wood/
metal screws and secure the plywood with at least
two screws in each vertical wall stud.
b. In concrete block or solid concrete wall construction,
attach the plywood with at least four masonry
screws or suitable masonry wall anchors.
IH-27
32”
8”
20”
2
3
1
2. Follow Steps 2 through 5 in the above procedure to
complete the installation.
WALL MOUNTING

20 Intellihot Green Technologies, Inc.
www.intellihot.com (877-835-1705)
WARNING
FIRE AND/OR EXPLOSION HAZARD
To avoid serious injury or even death, the gas line
installation and the gas line inlet pressure test
must be done by a licensed professional.
Always match the water heater with the type of gas supplied to the
unit (natural gas or LP gas). The water heater is factory preset for
natural gas.
Make sure the gas line pressures are within normal limits. Pressures
outside normal limits can result in poor performance and hazardous
operating conditions.
1. Determine if the Intellihot water heater will use natural
gas (factory preset) or LP (propane) gas.
a. To convert the unit to propane, refer to the Propane
(LPG) Conversion section in this manual.
b. Make sure your gas supply matches the rating decal
located on the side of the water heater.
2. Make sure the gas pressure meets the requirements
for the unit, as shown in the tables.
Parameters
Models
i200 i200P i250 i250P
NG/LP- Minimum Static
Gas Pressure 1/2"
5” (non-corrugated,
black iron)
6” (non-corrugated,
black iron)
NG/LP- Minimum Static
Gas Pressure 3/4"2.5” (non-corrugated, black iron)
NG/LP - Maximum
Static Gas Pressure 14”
Gas Pressure for
Adjustments 8” for NG, 11” for LP
3. Make sure the supply line is correctly sized for the
maximum output of the water heater model being
installed. The Intellihot water heater should be the
first appliance to be connected to the gas supply line.
a. Determine the gas requirement of the water heater(s)
and other appliances requiring gas. The supply line
must be sized according to the COMBINED total
maximum BTUH draw for all the appliances as if they
were all operating at the same time.
IH-77
1/2” 1/2”
Intellihot
1” 1” 1”
Gas
Meter
Home
Wall
Laundry Stove
Less then 40’
Typical installation when using 1/2” gas line.
b. Measure the length of the gas supply line from the
gas meter to the water heater or other appliances
requiring gas.
c. Use the Gas Pipe Sizing tables in this manual or
refer to the gas line manufacturers sizing information
to determine the correct diameter for the supply pipe.
d. The diameter of the gas lines, shown in the
illustration, will vary according to the specific
installation requirements.
NOTE: Always clean the inside of the gas line of
any dirt or debris before connecting the piping to
the unit.
4. Install a gas union connection with a short piece of 3/4”
NPT pipe.
5. Following local building codes, install a manual shut-off
valve.
6. Connect the manual shut-off valve to the gas supply
line. Also install a GLUWSRFNHWGULSOHJ off of the main
supplyline, as shown.
Main Supply Line
'ULSOHJ
Union
Manual
Shut-off
Valve
7. Leak test the gas line piping before placing the unit
in operation. Only use approved leak detector liquid
solutions to check for leaks.
IMPORTANT
Do not fire (operate) the water heater until all
connections have been completed and the heat
exchanger is filled with water.
GAS CONNECTION
