Intellihot Legionator iL3.5 Quick start guide

Installation & Operational Manual
Legionator iL3.5 | iL6.0

17 Legionator iL3.5/iL6 Operation Instruction
Aug 2023 - Revision 00
6. Operation Instruction
6.1 Overall Dimensions
The dimension of the water heater is as shown in Fig. 8, the unit of measurement is
in millimeters (inch values are in bracket).
The User interface presents the MULTIFUNCTION button is as shown in Fig. 9
Figure 8
Figure 9

Legionator iL3.5/iL6 Operation Instruction 18
Aug 2023 - Revision 00
6.2 Interface

19 Legionator iL3.5/iL6 Operation Instruction
Aug 2023 - Revision 00
6.3 Operation
For the convenience of consumers, the water heater adopts ONE-BUTTON
OPERATION, which consists of 6 steps by the way of moving up or down.
Your water heater is ready to use when the electricity and water connections are
turned ON and the water heater enters Standby mode. There won’t be any displays
right now.
•
Press MULTIFUNCTION button again,
you can choose the temperature mode
At this time, you can choose temperature
unit by pressing UP / DOWN button.
UP: temperature display in degree
Fahrenheit (°F)
DOWN: temperature display in degree
Celsius (°C)
Press MULTIFUNCTION button again,
you can choose working of ozonation
At this time, you can choose working
or not working of ozone generator by
pressing UP / DOWN button.
UP: automatic working of ozone
generator (O3 Auto)
DOWN: Turns off ozone generator (O3
Off)
•
Press MULTIFUNCTION button and hold
for 5 -10 seconds, the appliance will cut
off automatically, and there will be no
displays

Legionator iL3.5/iL6 Operation Instruction 20
Aug 2023 - Revision 00
6.4 Auto Memory
When the water heater restarts after an intermittent shut OFF due to power failure,
the automatic memory function in the water heater will re-set the water heater to its
previous (most recent) operational mode or user settings.
6.5 Auto Resume
When there is a power outage and/or water supply outage, the water heater will shut
OFF automatically for safety and protection of the water heater. When the power
supply and/or water supply resumes, the water heater will automatically re-start on
its own. There is no need to press the MULTIFUNCTION button to restart the water
heater.
6.6 Auto Sleeping
After a total of 45-minutes continuously running and heating the water, the auto sleep
function will cause the water heater to shut down automatically for safety reasons. In
these conditions, the user can press the MULTIFUNCTION button to restart the water
heater.
6.7 Temperature Setting
Make sure all the connections and fittings of the water heater are secured. Purge all
the air from the water heater before switching the ON button.
The flow of water activates the flow sensor to send signals to the digital microprocessor
in the water heater that controls the heating element to heat the water.
Use the temperature settings to increase or decrease the water temperature and/or
water flow rate in your water heater (by using the field supplied manual shut-off valves
as per Figure 5).
Press UP or DOWN on the mode buttons to set your required water temperature.
When the water flow rate reaches the maximum heating capacity of the water heater,
a maximum temperature will be achieved based on the water flow rate and the rated
power of the heater. When the excessive water flow rate is gradually reduced the
water heater will achieve the Set-Point (SP) temperature.
When the water flow rate is cut-off, the flow sensor sends the signals to the digital
microprocessor to turn OFF the heating element, during this time, the water heater
will be on Standby mode until the flow sensors sends back signals to the digital
microprocessor to turn ON the heating element in order to continue the flow of hot
water, as needed by the user.

21 Legionator iL3.5/iL6 Maintenance
Aug 2023 - Revision 00
6.8 Ozonation
The ozonator feature in the water heater generates controlled ozone (O3) that kills
bacteria present in the water lines. This special feature is proven to safeguard our
water heater users’ health, especially to those vulnerable to water borne diseases.
This water heater has options for the user to choose between AUTOMATIC and
OFF ozonier operation. The water heater will be set to AUTOMATIC operation mode
that activates ozonization on pre-designed intervals. This would provide sufficient
sterilization and disinfection that is required to kills the bacteria present in the water
lines.
Press the MULTIFUNCTION button to switch to the OFF operation mode. Press the
UP button to turn ON (AUTO) and DOWN button to turn OFF the ozonization process.
Ozone concentration is strictly controlled to a safe level that complies with US Health
and Human Safety guidelines.
The unique odor of ozone emitted from the water shall confirm that the water heater
is disinfected. During ozonation, make sure to have enough air ventilation around the
water heater. Frequent ozonation of the water heater is not recommended.
6.9 Anti-Freezing
Do not install the water heater at ambient room temperature below freezing. Install the
water heater at a location at room temperature.
Always make sure to check the water temperature before turning ON the water heater
power. If the water inside the water heater turns into ice, you must wait until the ice is
melted. Use of water heater when the water is frozen may cause damage to internal
components of the water heater and shall void the warranty conditions.
7. Maintenance
7.1 Pre-Filtration
It is recommended to use the inlet pre-filter to extend the service life of your water
heater. Make sure to check and clean the filter every 3 months.
7.2 After-Use Safety
Turn off the outlet flow after use of the water heater.
Make sure to turn off the main power switch and water supply if the water heater in
unattended.
We recommend to clean the Faucet spray head every 3 months for optimum
performance.
7.3 Maintenance
This water heater does not require any major maintenance.
