Inter-m PC-9335AD User manual

PC-9335AD Stereo Double Cassette Deck
PHONES
POWER
ON
OFF
RESET
+20-3-6-11
8
L dB
R LEVEL
RELAY BLANKMEMOREC NOR HIGH
COUNTER
AB
>
DECK BDECK A
MIN MAX
REC LEVEL
MIN MAX
OUTPUT LEVEL
DUBBINGNOR HIGH
OPEN OPEN
AMS AMS AMS AMS
STEREO DOUBLE CASSETTE DECK
PC
9335AD
SKIP/B REC PAUSE
REC
MUTE
R/PLAYMEMO
MODE
DECK A
AUTO REVERSE
PLAY LOGIC DECK
DECK B
AUTO REVERSE
RECORDING PLAY LOGIC DECK
COUNTER
RESET
AB
L
R
dB
2
REC MEMO RELAY BLANK DUBBING
NOR HIGHPLAY SKIP
06 3
LEVEL
11
B370031OC03OC03
0210

Contents
Contents
Welcome
Warning.........................................................................................................................................1
Unpacking......................................................................................................................................2
Short Form Instructions.....................................................................................................................2
Installation
Environment....................................................................................................................................3
Important Safety Instructions.............................................................................................................3
Description.......................................................................................................................................4
Features............................................................................................................................................4
Accessories.....................................................................................................................................4
Front Panel ......................................................................................................................................5
Rear Panel .......................................................................................................................................6
Connections.....................................................................................................................................9
Operation ......................................................................................................................................10
Play..............................................................................................................................................10
Automatic Music Selection (AMS) ...................................................................................................10
Dubbing .......................................................................................................................................11
Recording.....................................................................................................................................11
Preventing Accidental Erasure ...................................................................................................12
Cassette Care and Handling ......................................................................................................12
Cassette Deck Maintenance........................................................................................................13
Applications ..................................................................................................................................14
Block Diagram ..............................................................................................................................15
Specifications ................................................................................................................................16
Service
Procedures....................................................................................................................................17
Schematic.....................................................................................................................................17
Parts List .......................................................................................................................................17
Variations and Options ...............................................................................................................17
Warranty .......................................................................................................................................17

1
PC-9335AD
STEREO DOUBLE CASSETTE DECK
Welcome
Welcome
A personal welcome to you from the management and employees of Inter-M
All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value,
and we are delighted you have purchased one of our products.
We sincerely trust this product will provide years of satisfactory service, but if anything is not to your complete
satisfaction, we will endeavor to make things right.
Welcome to Inter-M, and thank you for becoming part of our worldwide extended family!
Warning
Your Cassette Deck is designed to be placed in a horizontal position and it is important to allow at least two inches
of space behind your unit for adequate ventilation and cabling convenience. To avoid damage, never place the unit
near radiators, in front of heating vents, in direct sunlight, or in an excessively humid or dusty location.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
*Do not install this equipment in a confined space such as a book case or similar unit.
*The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such vases, shall be placed on the apparatus.
*Worded: “WARNING FOR YOUR PROTECTION PLEASE READ THE FOLLOWING-WATER AND MOISTURE: Unit should not be used
near water(e.g. near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc). Care should be taken
so than objects do not fall and liquids are not spilled into the enclosure through openings.”
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
This symbol is intended to alert the user to the
presence of important operation and maintenance
(servicing) instructions in the literature accompanying
the appliance.
Caution: To prevent electric shock do not use this (polarized) plug with
an extension cord, receptacle or other outlet unless the blades
can be fully inserted to prevent blade exposure.
Attentions: Pour prévenir les chocs électriques ne pas utiliser cette
fiche polarisée avec un prolongateur, une prise de courant
on une autre sortie de courant, sauf si les lames peuvent
étre insérées à fond sans en laisser aucune partie à
découvert.

2PC-9335AD
STEREO DOUBLE CASSETTE DECK
Unpacking
Please take a few minutes to read this manual to familiarize yourself with important information regarding
product features, and operation.
As with most electronic devices, ORIGINAL PACKAGING (OR EQUAL) IS REQUIRED in the unlikely event that
the product needs to be returned for servicing.
Short Form Instructions
Preparing your PC-9335AD for Recording or Playback in your system
1. Before switching on the AC mains power to the PC-9335AD, be sure to properly connect the input and output
signal cables to avoid pops and noise in your system (AC Mains will be connected at step 2 below). The PC-
9335AD is equipped with one set of input connectors for stereo program material, as well as two separate
sets of output connectors. Connect the input connectors to the device from which you will record. Then
determine which set of outputs is best suited for your application. One set of outputs utilizes stereo RCA
connectors and has a variable output level, controlled by a potentiometer located on the front panel. The other
output is monaural and is fixed in level, with a single output connector. Connect the appropriate output(s) to
the input(s) of the device intended to receive the signal. If you are using the stereo output connections, be sure
to connect the Left and Right outputs of the PC-9335AD to the Left and Right inputs of the device that follows
in the signal chain, in order to maintain the proper channel integrity of the stereo signal.
2. Connect the AC Mains power.
3. Make sure the input signal level control is at minimum (counterclockwise)
4. Make sure the Output level control is at minimum (counterclockwise) position if the stereo outputs are to be used.
5. Switch the AC mains power ON.
6. Depress the OPEN button to open the cassette door.
7. Load a Cassette into the player.
8. Close the Cassette Door.
9. Depress one of the PLAY buttons (◀) or (▶), to begin playback.
10. Slowly increase the output level to achieve the desired signal level (if the stereo output jacks are being used
in your system).
11. Depress the OPEN button to open the Deck B door.
12. Load a blank cassette into Deck B.
13. Close the Deck B door.
14. Position the MODE selector to record on one side or both sides of the cassette, as desired.
15. Press RECORD button.
16. Adjust RECORD LEVEL until -11dB LED indicator flashes (illuminates intermittently).
17. Press PLAY button to begin recording.
18. Press STOP button to end recording.

3
PC-9335AD
STEREO DOUBLE CASSETTE DECK
Installation
Installation
Environment
Never place this product in an environment which could alter its performance or reduce its service life. Such
environments usually include high levels of heat, dust, moisture, and vibration.
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
S3125A
S3125A

4PC-9335AD
STEREO DOUBLE CASSETTE DECK
Features
Features
- FULL LOGIC AUTO-REVERSE
Logic-controlled auto-reverse is provided for continuous playback.
- NORMAL AND HIGH-SPEED SYNCHRO DUBBING
Synchro dubbing from Deck A to Deck B is available at normal or high speed.
- RESERVE TIMER
Automatically begins playing or recording when AC mains power is switched on.
- AUTOMATIC MUSIC SEARCH
Will automatically Fast-Forward or Rewind to the beginning of the next program or current program.
- DIGI-LINK
Remote Control Compatible with the “Digi-link” control system only available in Korea (not used in other
countries). It uses PHILIPS-CODE.
- SKIP BLANK
Fast-forwards through blank spaces between programs or at end of tape.
- DIGITAL TAPE COUNTER (DECK B)
This numeric display shows the current position of the tape relative to the last time the counter was reset to zero (000).
Accessories
Detachable AC Mains Power Cable
2 Stereo RCA Cables
Description
Description
The PC-9335AD is a stereo double cassette player/recorder that requires 3U rack space for mounting.

5
PC-9335AD
STEREO DOUBLE CASSETTE DECK
Front Panel
Front Panel
1. MEMORY BUTTON
Tape will end the Fast Forward or Rewind functions when the Tape Counter reaches approximately “000”
(only when the Memory Button is ON).
2. RELAY PLAY (R/PLAY)
This function expands the operation of the MODE SELECTOR to include both decks. RELAY PLAY is active
when the indicator in the display screen is illuminated.
Side one only Play Mode – Playback automatically stops when the tape reaches the end of side one of
both cassettes.
Auto-Reverse Mode – Playback automatically stops when the tape reaches the end of both side one
and side two both cassettes.
Continuous Play Mode – Playback automatically repeats using the Auto-Reverse function of both
cassettes until stopped manually.
3. SKIP/B BUTTON
Depress this button to enable the Skip Blank function. This will automatically fast wind to the next program on
the tape that is playing after detecting a period of more than 10 seconds of silence between programs or at
the end of a tape. The blank/skip indicator in the display screen will indicate the blank/skip mode has been
selected.
COUNTER
RESET
AB
L
R
dB
2
REC MEMO RELAY BLANK DUBBING
NOR HIGHPLAY SKIP
06 3
LEVEL
11
PHONES
POWER
ON
OFF
d
DECK BDECK A
MIN MAX
REC LEVEL
MIN MAX
OUTPUT LEVEL
DUBBINGNOR HIGH
OPEN OPEN
AMS AMS AMS AMS
STEREO DOUBLE CASSETTE DECK
PC
9335AD
SKIP/B REC PAUSE
REC
MUTE
R/PLAYMEMO
MODE
DECK A
AUTO REVERSE
PLAY LOGIC DECK
DECK B
AUTO REVERSE
RECORDING PLAY LOGIC DECK
115
16 17 18 19 20 21 22 23
2 3 4 5 6 7 8 9 10 11 12 13 14

6PC-9335AD
STEREO DOUBLE CASSETTE DECK
4. OPEN BUTTON
Depress this button to open the corresponding cassette door.
5. NORMAL/HIGH DUBBING SPEED SELECTOR
Select dubbing speed and initiate dubbing by depressing the corresponding button. The selected dubbing
speed will be indicated in the display screen.
6. LEVEL METER
Displays the input signal level when recording, or the output signal level of a tape during playback.
7. DISPLAY LAMP
Display status of operation.
8. COUNTER RESET
Depress this button to reset tape counter to zero.
9. TAPE COUNTER
This numeric display shows the current position of the tape relative to the position of the tape when the
counter was reset to zero (000).
10. MODE SELECTOR
This selector switch permits the selection of the desired mode of operation.
Single Side only Play Mode – Operation automatically stops at the end of one side of the cassette that
is playing.
Auto-Reverse Mode – Operation automatically stops at the end of both sides of the cassette that is
playing.
Continuous Play Mode – Operation automatically repeats Auto-Reverse mode of the cassette until
stopped manually.
11. REC BUTTON (●)
Depress this button to prepare to record. The deck will remain in record-pause mode until the play button is
selected to begin the recording or the stop button is depressed to cancel the recording. The record indicator in
the display screen will indicate the record button has been depressed. Both tape direction indicators will flash
in the display screen while in the record-pause mode.
12. PAUSE BUTTON ( II )
Depressing the Pause button during playback or recording will temporarily stop the cassette tape. Both tape
direction indicators for the corresponding deck will flash in the display screen while in the pause mode.

7
PC-9335AD
STEREO DOUBLE CASSETTE DECK
13. REC MUTE
Depressing this button will create a 4-second blank segment (for AMS) and then end the recording. Does not
apply when using the dubbing function.
14. RECORDING LEVEL CONTROL
This control determines the recording input signal level.
15. OUTPUT LEVEL
This control determines the output signal level of the Variable Output.
16. CASSETTE DOOR
It opens and closes smoothly with gear damper.
17. REVERSE BUTTON (◀)
Press to playback/record side one of the cassette. Deck A is capable of playback only, Deck B is capable of
playback or record. The direction of tape travel and Deck selection will be indicated in the display screen.
18. STOP BUTTON (■)
Depress this button to stop all functions.
19. FORWARD BUTTON (▶)
Press to play/record side one of the cassette. Deck A is capable of playback only, Deck B is capable of
playback or record. The direction of tape travel and Deck selection will be indicated in the display screen.
20. REWIND BUTTON (◀◀ AMS)
Depress this button to prepare to record. The deck will remain in record-pause mode until the play button is
selected to begin the recording or the stop button is depressed to cancel the recording. The record indicator in
the display screen will indicate the record button has been depressed. Both tape direction indicators will flash
in the display screen while in the record-pause mode.
21. FAST-FORWARD BUTTON (AMS ▶▶)
Depress this button to fast wind the tape in the forward direction to the closest section of the cassette tape that
has a minimum of 4 seconds of silence. The Automatic Music Search feature AMS may cause the tape to stop
fast-winding during a quiet section within a program or to fast-wind past a program that is preceded by less
than 4 seconds of silence.
22. HEADPHONE JACK
This jack is for the connection of stereo headphones. The signal level (volume) is controlled by the output
signal level control.
23. POWER SWITCH
The position of this switch determines whether the power is ON or OFF. The switch will illuminate to indicate
the power is ON.

8PC-9335AD
STEREO DOUBLE CASSETTE DECK
Rear Panel
Rear Panel
1. DC 24V
These terminals are for connecting 24V DC emergency power or DC mains. Observe proper polarity when
making connections.
2. RESERVE TIMER
Allows for unattended playback or recording on Deck B when power is restored to the unit. This slide switch is
used to select the desired mode of operation.
PLAY position: The unit will begin playing a cassette tape when AC mains power is applied to the AC input.
RECORD position: The unit will begin recording onto a cassette tape when AC mains power is applied to the AC input.
OFF position: The unit will be in the stop mode when AC mains power is applied to the AC input.
3. AC MAINS POWER INPUT
Connect the supplied AC Mains power cord here.
4. MONO OUTPUT (FIXED)
1/4” jack connector for a mono line level output that is not affected by the Output Level control.
5. STEREO OUTPUT (VARIABLE)
Dual-RCA connectors for a stereo line level output. The output signal level (volume) is determined by the front
panel Output Level control.
6. LINE IN
Dual-RCA stereo connectors for line-level input signals for recording.
7. DIGI-LINK
Connector for use with other DIGI-LINK compatible equipment available in Korea.
12
34567
12
MONO OUTPUT
FIXED
REC PLAYOFF
TIMER
DIGI-LINK
LL
/MONO
RR
LINE
DC INPUT
24V,1.25A
~AC INPUT: 230V 50Hz, 24W
FUSE:T125mAL/250V
www.inter-m.com
(UNBALANCED) (VARIABLE)
OUT IN
MODEL NO. PC-9335AD
STEREO DOUBLE
CASSETTE DECK
MADE IN KOREA
NO USER SERVICEABLE PARTS INSIDE.
RISQUE DE CHOC ELECTRIQUE NE
CTRIC SHOCK, DO NOT REMOVE COVER.
CAUTION;
AVIS;
TO REDUCE THE RISK OF FIRE
REPLACE ONLY WITH SAME TYPE FUSE.
CAUTION;
TO REDUCE THE RISK OF ELE-
PAS OUVRIR.
UTILISER UN FUSIBLE DE RECHANGE DE
MEME TYPE.
PERSONNEL.
REFER SERVICING TO QUALIFIED SERVICE

9
PC-9335AD
STEREO DOUBLE CASSETTE DECK
Connections
Connections
Inter-M products are wired to reflect accepted wiring practices used throughout the world.
Connect the outputs to an appropriate device. Common and standard rules of interconnect apply, including the
ability to split output signals but not combine two signals to one input.
Unbalanced RCA and 1/4” jack connectors are wired as described:
Tip is Positive
Sleeve is Common
Connecting the Output Terminals
Connect one end of the cable supplied with the Cassette Deck to the output terminals, left (L) and right (R) of the
Cassette Deck, and the other end to the TAPE PLAY input terminals, left (L) and right (R), of the mixer or other
suitable device.
Connecting the Input Terminals
Connect one end of the cable supplied with the Cassette Deck to the input terminals, left (L) and right (R) of the
Cassette Deck, and the other end to the TAPE REC output terminals, left (L) and right (R), of the mixer or other
suitable device.
Make a connection to only ‘L/MONO’ input for voice recording.
Signal
Ground
TipSleeve
UNBALANCED MONO OUTPUT(1/4˝ Jack)
TipSleeve
STEREO INPUT/OUTPUT(RCA Jack)

10 PC-9335AD
STEREO DOUBLE CASSETTE DECK
Operation
Operation
Play
1. Choose one of the three play modes with the Play Mode Selector buttons
Single Side only Play Mode – Operation automatically stops at the end of
one side of one cassette.
Auto-Reverse Mode - Operation automatically stops at the end of both sides of one cassette.
Continuous Play Mode - Operation automatically repeats Auto-Reverse mode of one cassette until
stopped manually.
2. Switch the AC mains power on.
3. Press OPEN Button to open cassette door of Deck A.
4. Insert tape to be played into Deck A.
5. Close Deck A cassette door.
6. Repeat steps 3 - 5 for Deck B if desired.
7. Press Play Button on Deck A.
Automatic Music Selection (AMS)
1. Follow “Play” instructions (above) to prepare for Relay Play.
2. During Playback, Press Fast Forward (▶▶) or Rewind (◀◀) Button to Fast-Wind to Next Program or to the
Beginning of the Program Playing to initiate Relay Play.
NOTE: Automatic Music Selection will fast-wind the tape to the closest portion of the tape with a minimum of 4
seconds of silence. This may cause AMS to stop fast-winding during a quiet section within a program or
to fast-wind past a program that is preceded by less than 4 seconds of silence.

11
PC-9335AD
STEREO DOUBLE CASSETTE DECK
Dubbing (copying tapes)
1. Set Play Mode Selector to desired position.
2. Switch the AC mains power on.
3. Insert the cassette to be copied into Deck A.
4. Insert the cassette onto which you wish to dub (record) into Deck B.
5. Press the Dubbing button that corresponds with the desired dubbing speed.
6. Press Stop button to end dubbing.
NOTE: If monitoring of dubbing is desired, tapes should be dubbed at normal speed. Normal speed dubbing
will also result in improved quality of dubbed tapes.
Recording
1. Set Play Mode Selector to desired position.
2. Switch the AC mains power on.
3. Depress the OPEN button to open the Deck B cassette door.
4. Load a blank cassette into Deck B with the side to be recorded facing outward.
5. Close cassette door.
6. Position the MODE selector to record on one side or both sides of the cassette, as desired.
7. Press REC Button.
8. Adjust RECORD LEVEL until -11dB mark illuminates (flashes) intermittently.
9. Position the MODE selector to record on one side or both sides of the cassette, as desired.
10. Press PLAY button to begin recording.
11. Press STOP button to end recording.

12 PC-9335AD
STEREO DOUBLE CASSETTE DECK
Preventing Accidental Erasure
Preventing Accidental Erasure
You can prevent cassette tapes from accidental erasure by removing the tab on the top of the cassette shell.
Remove tab on top of tape to avoid
accidental erasure
To record on a cassette after the tab has been removed,
cover opening with cellophane tape.
Cassette Care and Handling
Cassette Care and Handling
1. Keep a cassette in its case when not in use.
2. Cassette tapes should be kept away from sources of magnetism such as speakers or television sets.
3. Do not touch the exposed portion of the cassette tape.
4. Keep cassette tapes out of direct sunlight.

13
PC-9335AD
STEREO DOUBLE CASSETTE DECK
Cassette Deck Maintenance
Cassette Deck Maintenance
After every 10 hours of use of the cassette deck, the tape heads should be cleaned to help maintain the best
possible sound quality.
Record/Play Head
Clean Tape Head with a cotton
swab moistened with alcohol or a
commercial head cleaner

14 PC-9335AD
STEREO DOUBLE CASSETTE DECK
Applications
Applications
12
MONO OUTPUT
FIXED
REC PLAYOFF
TIMER
DIGI-LINK
LL
/MONO
RR
LINE
DC INPUT
24V,1.25A
~AC INPUT: 230V 50Hz, 24W
FUSE:T125mAL/250V
www.inter-m.com
(UNBALANCED) (VARIABLE)
OUT IN
MODEL NO. PC-9335AD
STEREO DOUBLE
CASSETTE DECK
MADE IN KOREA
NO USER SERVICEABLE PARTS INSIDE.
RISQUE DE CHOC ELECTRIQUE NE
CTRIC SHOCK, DO NOT REMOVE COVER.
CAUTION;
AVI S;
TO REDUCE THE RISK OF FIRE
REPLACE ONLY WITH SAME TYPE FUSE.
CAUTION;
TO REDUCE THE RISK OF ELE-
PAS OUVRIR.
UTILISER UN FUSIBLE DE RECHANGE DE
MEME TYPE.
PERSONNEL.
REFER SERVICING TO QUALIFIED SERVICE
RX RX TX TX G24VRXRX TX TX G24V
RX RX TX TX G24VRXRX TX TX G24V
RX RX TX TX G24VRX
RM 11 RM 12
RM 15 RM 16
RM 3 RM 4
RM 7 RM 8
RX TX TX G24V
RX RX TX TX G24VRXRX TX TX G24V
RESET
PC 1 PC 2 DRP / INTERFACE LINK 1 LINK 2
RS-422RS-232
DIGI LINK
HC HCG
12
EM AUDIO OUTFROM DRG-8232
RX RX TX TX G 24V RX RX TX TX G 24V
RX RX TX TX G 24V RX RX TX TX G 24V
RX RX TX TX G 24V RX
RM 9 RM 10
RM 13 RM 14
RM 1 RM 2
RM 5 RM 6
RX TX TX G 24V
RX RX TX TX G 24V RX RX TX TX G 24V
DC INPUT
24V
OFF
ON
OUTPUT
STAND-BY
MIC MIC/VOLUME
MAX
MIN
FIRE
10dB
CLIP
40dB
PROT
OUTPUT & PROTECTION
POWER
OFF
ON
TIMER
OFF PLAY
DISC SELECTOR 1234 5DISC SKIP OPEN/CLOSE ON OFF
POWER
-SKIP-SEARCH STOP/CLEAR PLAY/PAUSE
5DISC AUTOMATICDISC LOADING SYSTEM
PROG/REV REPEAT TIMER DISC INTRO
HIGHDENSITY 1-BITD/A CONVERTER
RANDOM
1 2 3 4 5
PROG
TRACK INDEX INTRO
RANDOMREPEAT ALL 1 DISCS
VOLUME
MAX
MIN
DOWN
UP
6
1
7
2
8
3
9
4
0
5
PRESET
SCAN
MEMORY
OFF
ON
AM
MONO/ ST FM
MODE
PRESET/TUNE
MONO
MHz
KHz
PT-9107SD
CD-3500
KEY BOARD
PO-9106
PA-9312/9324/9336
EP-9216
PP-9213
PC-9335AD
DIGI-LINK CONTROL UNIT
SPEAKERS
DUCK P.PWR
CH1CH2
DUCK P.PWR
CH3CH4CH5CH6CH7CH8CH9
LINE IN
MIC IN
L
RR
L
R
L
2
1
AUX
1
2
PRIORITY
+-
DC INPUT
24V
INSERTREC OUT
MASTER
2
1
SUB OUT
OUTPUT INPUTINPUT
LINE IN
MIC IN
LINE IN
MIC IN
LINE IN
MIC IN
LINE IN
MIC IN
LINE IN
MIC IN
LINE IN
MIC IN
LINE IN
MIC IN
LINE IN
MIC IN
ON
ON

15
PC-9335AD
STEREO DOUBLE CASSETTE DECK
Block Diagram
Block Diagram

Specifications
Specifications
- ELECTRICAL
Type........................................................................Auto-Reverse double cassette deck with operating controls
Track System.....................................................4-track 2-channel Stereo play (deck A) & record/play (deck B)
Record and Erase System..................................................................AC Bias System (Bias Frequency: 87 kHz)
Tape Speed...............................................4.76cm/sec (Playback/Record), 7.14cm/sec (High Speed Dubbing)
Head .............................................................................................................DECK A: Rotating reverse head
..........................................................................................................................................(Play head x1)
..................................................................................................................DECK B: Rotating reverse head
.................................................................................................................................(Rec/play head x 1)
...................................................................................................................................... (Erase head x 1)
Motor..........................................................................................................................High torque DC motor
Wow and Flutter ..........................................................................................Less than 0.3% (JIS WTD) WRMS
Fast Winding Time ..........................................................................................100 sec (±) 5 sec. (C-60 TAPE)
Frequency Response ...............................................................................(±3dB) 125Hz-6.3kHz, Normal Tape
Signal to Noise(S/N) ............................................................................................................Over than 40dB
Input Sensitivity/Impedance .....................................................................................................160mV/10kΩ
Output Level/Impedance .........................................................................................................600mV/600Ω
Erase Ratio...........................................................................................................................................45dB
- GENERAL
Power Source ................................................................100–120VAC or 220V–240VAC; 50/60Hz, 24V DC
..............................................................(Supplied AC mains transformer depends on country requirements)
Power Consumption ..............................................................................................................................24W
Weight................................................................................................................................... 5.8kg/12.8lb
Dimensions......................................................................482(W)x132(H)x280(D)mm/19(W)x5.2(H)x11(D)in
Operating Temperature............................................................................................................-10°C ~ 40°C
* Specifications and design subject to change without notice.
16 PC-9335AD
STEREO DOUBLE CASSETTE DECK

17
PC-9335AD
STEREO DOUBLE CASSETTE DECK
Service
Service
Procedures
Take steps to insure the problem is not related to operator error or other products within the system. Information
provided in the troubleshooting portion of this manual may help with this process. Once it is certain that the
problem is related to the product contact your warranty provider as described in the warranty section of this
manual.
Schematic
A Schematic is available by contacting your warranty provider.
Parts List
A Parts List is available by contacting your warranty provider.
Variations and Options
Variations and Options
Variations
AC mains requirement of either 100-240VAC 50/60Hz depending on country requirements. No other
variations exist for this product.
Options
No optional items are available for this product.
Warranty
Warranty
Warranty terms and conditions vary by country and may not be the same for all products. Terms and conditions
of warranty for a given product may be determined first by locating the appropriate country which the product
was purchased in, then by locating the product type.
To obtain specific warranty information and available service locations contact Inter-M directly or the authorized
Inter-M Distributor for your specific country or region.

MADE IN KOREA
July 2005 9007104310
