INTERNATIONAL®
CUB CADET®
86,108, 128,129
149, and 169
TRACTORS and
ROTARY MOWERS
INTERNATIONAL
OPERATOR'S MANUAL
>r
' t
t*
•->r
k . r
^ •
♦ r •
S--
•• S.V
4

To The Owner
Assembled in this manual are operation, lubri¬
cation, and maintenance instructions for the
International Cub Cadet 86, 108, 128, 129, 149,
and 169 Tractors. The material has been prepared
in detail to help you better understand the correct
care and efficient operation of your tractor. Before
you operate the tractor, study this manual care¬
fully. New copies may be ordered from your dealer
at a nominal price.
Your local International Harvester dealer is inter¬
ested in the performance you receive from this
tractor. He has factory-trained servicemen. In¬
formed in the latest method of servicing tractors,
modern tools, and original-equipment IH service
parts which assure proper fit and good perfor¬
mance.
The International Cub Cadet 129, 149, and 169
Tractors have a hydrostatic drive. It is the best
hydraulic drive unit available and will require
minimum service if recommended operation and
maintenance procedures are followed. Should you
have difficulties with the unit consult your
International Harvester dealer. UNDER NO CIR¬
CUMSTANCES SHOULD YOU ATTEMPT TO
SERVICE THESE UNITS YOURSELF. Only your
dealer is authorized to repair or replace units on
this drive under the terms of the warranty. Should
you desire additional information not found in this
manual, contact your International Harvester
dealer.
The International Cub Cadet 86, 108, and 128
Tractors have a conventional clutch and trans¬
mission.
To obtain top performance and assure economical
operation the tractor should be inspected, depend¬
ing on its use, periodically, or at least once a year,
by your International Harvester dealer.
When in need of parts, always specify the model,
chassis, and engine serial numbers, including the
prefix and suffix letters. Write these serial numbers
in the space provided on page 4.

TECHNICAL PUBLICATIONS AVAILABLE
Your International Harvester Dealer and
his factory trained servicemen are best
qualified to service your equipment. Up-
to-date instructions and adequate special
tools are also a part of your Dealer's
service facilities.
This Operator's Manual was prepared to
instruct you in proper and safe operation
and maintenance of your equipment. If
you desire additional information you
may purchase Service Manuals and/or
Parts Catalogs. Copies of the Operator's
Manual are also available.
Fill out this order blank and forward
together with your check or money
order in the appropriate amount (U.S.
Funds) to:
International Harvester Company
— Cut Along This Line-
Title
Number Qty.
Price
Each
Operator's Manual
‘ —
International Cub Cadet 86.
108, 128,129,149, and 169
Tractors and Rotary
Mowers.
1 084 322 R1
Rev. 1
3.30
Parts Catalog
International Cub Cadet
Tractors and Equipment.
TC-157
7.50
Service Manuals
International Cub Cadet
86.108,109,128,129,149,
and 169 Tractors and IH
Equipment.
1
GSS-1439
6.00
Listing of Agricultural/Industrial
Equipment Sen/ice Manuals . . .
GSS-5042
1.00
TOTAL
o
PRINTING AND
DISTRIBUTION SERVICES
807 Blackhawk Drive
Westmont, Illinois 60559
Attention: Cashier
Please Print
Name__ _ _
Street Address__
City „_____
State_______
Zip Code
Date Signed
Do not send cash or stamps
Prices subject to change without notice.

CONTENTS
TO THE OWNER Inside cover
SERVICE MANUAL INFORMATION
CONTENTS 1 to 3
SERIAL NUMBER LOCATION 4
INTRODUCTION 4
WORK SAFELY • FOLLOW THESE
RULES
INSTRUMENTS AND CONTROLS 6, 7
BEFORE OPERATING YOUR NEW
TRACTOR 8
OPERATING THE ENGINE 8,9
Throttle lever
Governor
Lifting the hood
Starting the engine
Stopping the engine
FUEL SYSTEM 10, 11
Fuel shut-off valve
Carburetor adjustments
DRIVING THE TRACTOR 11 to 15
Adjusting the seat
Clutch and brake pedal
Locking the brake
International Cub Cadet 86, 108
and 128 Tractors
Clutch-brake pedal
Gearshift lever
Starting the tractor
Stopping the tractor
Creeper shift lever
Operating the creeper drive
International Cub Cadet 129, 149
and 169 Tractors
Brake pedal
Speed control lever
Starting the tractor
Release lever
Stopping the tractor
EQUIPMENT LIFT HANDLE 15
Height adjustment
HITCHING EQUIPMENT TO THE
TRACTOR 16
Drawbar
Three-point hitch
- 1 -

CONTENTS
REAR POWER TAKE-OFF 17
Operating the rear power
take-off with the tractor
standing still
Operating the rear power
take-off with the tractor in
motion
FRONT POWER TAKE-OFF 18
Operating the front power
take-off clutch
Adjusting the power take-off
clutch
ELECTRIC LIFT 18. 19
HYDRAULIC LIFT
ENGINE COOLING AND AIR
CLEANER 21
Engine cooling
Dry type air cleaner
ELECTRICAL SYSTEM 21 to 24
Ignition switch
Safety starting switch
Charge indicator
Hour meter
Spark plug
Motor generator
Motor generator belt
Lights
Fuse
PNEUMATIC TIRES 24, 25
Rear tires
Care of tires
Inflation
Operating pressure for tires
Mounting tires on the rim
Rear wheel weights
Tire chains
Overloading
FRONTWHEELS 26
Front quick attaching latch
Front wheel toe-in
Turning radius
CLUTCH-BRAKE
International Cub Cadet 86, 108
and 128 Tractors 27,28
Adjusting the clutch
Adjusting the brakes
BRAKES
International Cub Cadet 129, 149
and 169 Tractors 29
Adjusting the brakes
•2

CONTENTS
STORING THE TRACTOR
30
TO THE OWNER
46
Removing from storage
INTRODUCTION
47
EXTRA EQUIPMENT AND
ACCESSORIES
31
WORK SAFELY - FOLLOW THESE
RULES
TROUBLE SHOOTING
31,32
LUBRICATION
33,34
OPERATING YOUR MOWER
48
LUBRICATION TABLE
35
ADJUSTING AND OPERATING
49 to 55
LUBRICATION GUIDE
Starting the mower
Stopping the mower
International Cub Cadet 86,
Level adjustment
Vbelt
108 and 128 Tractors
36 to 38
V L
Height of cut
Cleaning
LUBRICATION GUIDE
Blade care
Lubrication
International Cub Cadet 129,
149 and 169 Tractors
39 to 41
General
Mowing
SPECIFICATIONS
41 to 44
SETTING UP
57 to 64
OPERATING INSTRUCTIONS
INTERNATIONAL ROTARY
mowers 45 to 55
- 3 -

SERIAL NUMBER LOCATION
«U M7t '
Serial No. 500 718 and above.
MODEL _
DELIVERY
DATE
INTRODUCTION
A variety of extra equipment and accessories is
available. Where operating and maintaining instruc¬
tion is required, it is included in the instruction for
operating and maintaining the tractor. Disregard
the instructions for equipment not on your tractor.
LEFT and RIGHT indicate the left and right sides
of the tractor when facing forward in the driver's
seat. Reference to FRONT indicates the grille end
of the tractor; to REAR the drawbar end.
This manual is for tractors with Serial No. 507 000 and above.
4

WORK SAFELY-FOLLOW THESE RULES
A This symbol is used to call your attention to instructions
concerning your personal safety. Be sure to observe and
following these instructions.
Disengage all clutches and shift into neutral before
starting the engine.
Disengage power to any attachments and stop
engine before leaving operator's seat or making any
repairs or adjustments.
Know the controls and how to stop quickly —
READ THE OPERATOR'S MANUAL.
Do not allow children or adults to operate the
equipment without proper instruction.
Clear work area of objects which might be picked
up and thrown.
Disengage power to any attachment when trans¬
porting or not in use.
Do not carry passengers of give rides. Keep child¬
ren, pets, and by-standers a safe distance away.
Always disengage the power take-off, shift trans¬
mission into neutral, set the parking brake, stop
the engine, and remove ignition key when leaving
the machine unattended.
Reduce speed on slopes and in sharp turns to
prevent tipping or loss of control.
Stay alert for holes in terrain and other hidden
hazards.
Don't stop or start suddenly when going uphill or
downhill.
Use care when pulling loads or using heavy
equipment: — A. Use only approved hitch points.
B. Limit loads to those you can safety control.
C. Don't turn too sharp, and use care when
backing. D. Use counterweight or wheel weights
when suggested in Operator's Manual.
Watch out for traffic when crossing or near
roadways.
When using any attachments, never direct discharge
of material toward bystanders nor allow anyone
near the machine while in operation.
Handle gasoline with care - it is highly flammable:
— A. Use approved gasoline container. B. Never
remove the fuel tank cap or fill the fuel tank when
the engine is running, is hot, or indoors. Also, do
not smoke when working around inflammable fuel.
Wipe up spilled gasoline. C. Replace gasoline cap
securely. D. Open doors if engine is running in a
garage — exhaust gases are dangerous.
Keep machine in good operating condition and
keep safety devices in place. Use guards or shields
as instructed in Operator's Manual.
It is recommended that the machine be stopped
and inspected for damage after striking a foreign
object and that any damage be repaired before
restarting and operating the machine.
Always depress the brake pedal and set the brake
pedal lock before working on the machine. Dis¬
engage alt implements and shift the transmission
into neutral.
5

INSTRUMENTS AND CONTROLS
Your Cub Cadet Tractor has been safety engineered. Thoroughly
acquaint yourself with all the instruments and controls before
attempting to start or operate the tractor.
Instruments and controls on the International Cub Cadet 86, 108, and 128 Tractors.
1. Brake pedal lock.
2. Choke control button.
3. Clutch-brake pedal .
4. Creeper shift lever*..
5. Front power take-off clutch lever
6. Gearshift lever.
7. Lift handle cam stop.
8. Lighting switch button* .
9. Ignition switch .
10. Throttle.
11. Electric lift control switch* ....
12. Charge indicator .
See page 12
See page 9
See pages 12 and 13
See page 13
See page 18
See page 13
See page 15
See page 21
See page 8
See page 18 and 19
See page 22
* Optional Equipment
6

INSTRUMENTS AND CONTROLS
Instruments and controls on the International Cub Cadet 129, 149, and 169 Tractors.
1. Brake pedal lock.
2. Brake pedal.
3. Speed control lever.
4. Choke control button.
5. Front power take-off clutch lever.
6. Charge indicator ..
7. Hydraulic lift control handle.
8. Throttle lever .
9. Ignition switch .
10. Lighting switch button* (Standard on Models 149 and 169) ....
11. Lift handle cam stop.
12. Release lever.
13. Hour meter— (Standard on Model 169 only).
Electrict lift* (Not shown.) Available on all but the
Model 149 and 169 Tractors.
See page 14
See page 14
See page 14
See page 9
See page 18
See page 22
See page 20
See page 8
See page 21
See page 15
See page 15
See page 22
* Optional Equipment
7

BEFORE OPERATING YOUR NEW TRACTOR
Lubrication . Lubricate the entire tractor. See pages 33 to 41
Tires. Check the air pressure. See pages 24 to 26
Fuel System . Fill the fuel tank with gasoline. See pages 10 and 11.
OPERATING THE ENGINE
1. Fuel tank filler cap
2. Fuel tank
3. Carburetor (not seen)
4. Fuel line
5. Fuel shut off valve
6. Air cleaner
Fuel System.
THROTTLE LEVER
This lever controls the speed of the engine. When
set in a given position, it will maintain a uniform
engine speed.
When using power take-off operated equipment,
best performance is achieved with the throttle lever
in the "FAST" position.
GOVERNOR
The governor is set at the time the engine Is
assembled and should not require readjustment
unless the governor arm is removed or loosened
from the governor shaft. Consult your
International Harvester dealer if the governor does
not function properly.
8

OPERATING THE ENGINE
LIFTING THE HOOD
The tractor hood is arranged to swing up and
forward to make the engine and fuel tank readily
accessible. To raise the hood take hold of the
spring latches on each side of the pedestal and lift
up and out to release the spring latches from the
hood crossmember.
1. H ood spring latch
(one on each side)
STARTING THE ENGINE
1. Be sure there is an adequate supply of gasoline
in the fuel tank.
A CAUTION! Never remove the fuel tank
cap or fill the fuel tank when the engine
is running, is hot, or indoors. Also, do
not smoke when working around inflammable fuel.
2. B e sure the fuel shut-off valve is open.
3. Pull the choke control button all the way out.
More or less choking may be necessary due to
variations in temperature, grade of fuel, etc. Little
or no choking will be needed when the engine is
warm.
4. Place the throttle lever half-way between
"SLOW" and "FAST".
5. Place the throttle lever half-way between
"SLOW" and "FAST".
6. To start the engine the clutch-brake pedal must
be pressed all the way down and the power
take-off clutch handle must be in the disengaged
position to actuate the safety starting switches.
On the International Cub Cadet 129, 149, and 169
Tractors the speed control lever will return to
neutral when the clutch-brake pedal is pressed all
the way down.
International Cub Cadet 86, 108, and 128 Trac¬
tors: Check to see that the gearshift lever is In the
neutral position.
All Models: Turn the Ignition key clockwise to the
"START" position and release it as soon as the
engine starts; however do not operate the motor
generator for more than 30 seconds at any one
time. If the engine does not start within this time,
turn the key "OFF" and wait a few minutes, then
try again.
5. After the engine starts, slowly release the
clutch-brake pedal and gradually push the choke
control button all the way in. Do not use the
choke to enrich the fuel mixture, except when
necessary to start the engine.
STOPPING THE ENGINE
Move the throttle lever to the "SLOW" position
and allow the engine to idle for a short time before
stopping. Then turn the key to the "OFF"
position.
9

FUEL SYSTEM
FUEL SYSTEM
This engine is designed to operate on leaded
gasoline with a 93 minimum octane rating or on
unleaded or low lead gasoline with a 91 minimum
octane rating (Research Method).
The use of unleaded gasoline will lengthen spark
plug and valve life, maintain engine performance
longer, and reduce rust and corrosion of engine
while stored.
The fuel tank filler cap has an air vent. Keep the
vent open at all times to assure proper flow of the
fuel.
A CAUTION! Never remove the fuel tank cap
or fill the fuel tank when the engine is
running, hot, or when near an open flame.
Do not smoke when working around inflammable
fuel, as the air around the tractor is mixed with a
highly explosive vapor. When pouring fuel, keep
the container or hose nozzle in contact with the
metal of the fuel tank to avoid the possibility of an
electric spark igniting the gas. Do not spill gasoline
on a hot engine.
FUEL SHUT-OFF VALVE
Be sure the shut-off valve under the fuel tank is
open. Screw out the needle stem (shut-off valve)
until the seat on the stem is tight against the stop
to prevent leakage or seepage when the valve is in
its full-open position.
CARBURETOR ADJUSTMENTS
The carburetor is adjusted at the factory and under
normal operation conditions it will not require
readjusting. However, if the engine does not
operate properly, it is recommended a new air
cleaner be installed before performing carburetor
adjustments. If this adjustment has been disturbed
for any reason, proceed as follows:
International Cub Cadet 86 Tractor.
1. Governor control rod
2. Idle adjustment screw
3. Throttle stop screw
4. High speed adjustment screw
5. Fuel shut-off valve
6. Fuel line
7. Air cleaner
International Cub Cadet 108, 128, 129,
149, and 169 Tractors.
10

FUEL SYSTEM
CARBURETOR ADJUSTMENTS - Continued
CAUTION! Be sure the brake pedal is in
the locked position, transmission is in
neutral, and the mower is disengaged
before adjusting the carburetor.
Adjusting the High-Speed Adjustment Screw
Turn the high speed adjustment screw counter¬
clockwise approximately two turns from the closed
position and start the engine.
Be sure the choke is fully open when adjusting.
After the engine has reached normal operating
temperature, place the throttle lever in the fast
position and turn the high speed adjustment screw
clockwise to the leanest mixture that will allow
satisfactory acceleration and steady governor
operation. Then, turn counterclockwise to the
richest mixture that allows satisfactory operation.
The difference between the rich and lean points is
about 1/2 turn. Set the mixture to the rich end of
this range.
If the engine misses and backfires under load, the
high speed mixture is too lean. The high speed
adjustment screw must be turned counter-clock¬
wise 1/4 turn at a time until the condition is
corrected.
If the engine shows a sooty exhaust and is sluggish
under load, the high speed mixture is too rich. The
high speed adjustment screw must be turned
clockwise 1/4 turn at a time until the condition is
corrected.
Adjusting the Idle Adjustment Screw
After the high speed adjustment screw Is adjusted,
it may be necessary to readjust the idle adjustment
screw as each affects the other.
Close the idle adjustment screw to its seat by
turning it clockwise; then open it one turn. Start
the engine and operate it at fast idling speed
(without any load) until thoroughly warm.
While the engine is running at fast idle speed, it is
advisable to screw in the throttle stop screw a few
turns to keep the engine from stopping when the
throttle lever is moved to the fully retarded
"SLOW" position. The engine will then be idling at
a fairly high speed and the throttle stop screw can
be backed out a little at a time until the desired
idle speed is obtained.
If the engine misses or rolls while backing out the
throttle stop screw, the idle adjustment screw may
be adjusted in or out until the engine operates
smoothly. Speed up the engine for a few seconds;
then recheck the idle adjustment. A slight adjust¬
ment in or out will give the smoothest idle.
DRIVING THE TRACTOR
PREPARING THE TRACTOR FOR EACH DAY'S WORK
Check the crankcase oil level and add new oil if necessary. See pages 34 and 35.
Clean the air cleaner element if necessary. See page 21.
Inspect the tires for general condition. See page 26
11

DRIVING THE TRACTOR
ADUSTING THE SEAT
Adjusting the seat.
Before starting the tractor, adjust the seat to the
most comfortable driving position. Tile the seat
forward over the steering wheel, loosen the four
cap screws in the seat support, and slide the seat
assembly forward or rearward to the position
which is most comfortable for the operator.
Retighten the cap screws after the seat is adjusted.
NOTE: The battery is located in a well under the
operator's seat for ease in servicing or replacement
when necessary.
CLUTCH AND BRAKE PEDAL
Brake pedal lock in the engaged position.
LOCKING THE BRAKE
Always lock the brake when the tractor is parked
on a grade. To lock the brake, press down on the
pedal; then place the brake pedal lock in the
engaged position. To disengage the lock, press
down on the pedal, lift the lock up and place it In
the disengaged position.
12

DRIVING THE TRACTOR
International Cub Cadet 86,108 and 128 Tractors
CLUTCH-BRAKE PEDAL
The combination clutch-brake pedal is used to
disengage the engine from the transmission when
shifting gears and to actuate the brake to stop the
tractor. The pedal must be pressed all the way
down to activate the safety starting switch when
starting the engine.
To disengage the clutch, and apply the brake, press
the pedal all the way down.
GEARSHIFT LEVER
This lever is used to select various gear ratios
provided in the transmission. There are three
forward speeds and one reverse speed. Refer to
"SPECIFICATIONS" on page 42.
STARTING THE TRACTOR
1. Advance the throttle lever slightly.
2. Disengage the clutch by pressing the clutch
pedal all the way down, and release the brake lock.
Move the gearshift lever to the desired speed.
3. Start the tractor in motion by slowly releasing
the clutch pedal and moving the throttle lever to
the position where the engine operates best for the
load to be handled.
NOTE: When using power take-off operated
equipment, best performance is achieved with the
throttle lever in the "Fast" position.
NOTE: Do not shift gears while the engine clutch
is engaged or while the tractor is in motion.
NOTE: Do not rest your foot on the pedal while
driving the tractor, as this will result in excessive
clutch lining wear.
free the tractor by speeding up the engine and
suddenly engaging the clutch. Try backing out
instead of going forward.
CAUTION! Do not carry passengers or
give rides. Keep children, pets, and
bystanders a safe distance away.
STOPPING THE TRACTOR
Disengage the clutch by pressing the pedal all the
way down. Move the gearshift lever to the "N"
position. Before dismounting always lock the
pedal, disengage the power take-off, and turn the
ignition "OFF".
CREEPER SHIFT LEVER
The creeper drive (optional) provides a slower
speed In each respective gear, by a four-to-one
reduction in speed from direct drive. When the
creeper shift lever is all the way forward, it is in
direct drive, or all the way rearward, it is in creeper
drive.
OPERATING THE CREEPER DRIVE
To operate the tractor in creeper drive, depress the
pedal and move the creeper shift lever all the way
rearward. Then select the transmission speed de¬
sired and proceed as instructed under "Starting the
Tractor".
NOTE: Do not use a mid-point position on the
creeper drive as neutral. Neutral position must be
selected only with the standard transmission gear¬
shift lever.
The following table shows the speeds available in
each of the three forward gears and the reverse
gear.
Always be sure the rear wheels are free to turn.
Under any adverse conditions, do not attempt to
13

DRIVING THE TRACTOR
International Cadet 86,108 and 128 Tractors
OPERATING THE CREEPER DRIVE
SPEED TABLE
Miles Per Hour
A ^ F
Direct
Creeper
Ocai
Drive
Drive
First
2.3
.6
Second
3.5
1.0
Third
6.8
1.7
Reverse
2.5
.6
DRIVING THE TRACTOR
International Cub Cadet 129,149, and 169 Tractors
BRAKE PEDAL
The brake pedal must be pressed alt the way down
to activate the safety starting switch. When the
brake pedal is in the depressed position it auto¬
matically moves the speed control lever to the "N"
position.
The tractor can be stopped either by pressing the
pedal all the way down, or placing the speed
control lever in the "N" position.
SPEED CONTROL LEVER
This lever is used to select any speed from a
standstill "N” position to eight miles per hour in
the forward direction and to four miles per hour In
the reverse direction.
Moving the speed control lever forward provides
increased forward speed, and moving the lever
rearward provides the reverse speeds.
NOTE: Do not rest your foot on the brake pedal
while driving the tractor as this would cause the
speed control lever to return to the “N" position.
NOTE: On tractors with a rotary tiller the follow¬
ing instructions are required.
1. Engage the Power Take-Off clutch, and move
the throttle to "Fast".
2. Lower the rotary tiller to the desired cutting
depth.
3. Move the speed control lever to start forward
motion. NOTE: In rotary tilling application, the
tractor is used to hold the rotary tiller back rather
than to pull the unit as in plowing or mowing.
4. Move the speed control lever back to a position
to maintain proper mulching of the soil.
5. W ith a hydrostatic drive, it may be necessary to
vary the speed control lever as the soil conditions
vary. With a gear driven tractor, under similar
conditions it may be necessary to declutch or to
use the brake.
14

DRIVING THE TRACTOR
International Cub Cadet 129, 149, and 169 Tractors
STARTING THE TRACTOR
1. Depress the brake pedal and release the brake
lock. Move the throttle lever to the position where
the engine operates best for the load to be handled.
2. Start the tractor in motion by moving the speed
control lever slowly forward or rearward as de¬
scribed above.
RELEASE LEVER
To push or move the tractor for a short distance,
the release lever must be held in the (up) position
and the speed control lever must be in the "N"
position.
A CAUTION! Never operate engine with re*
lease lever in (up) position. Towing or
pushing the tractor for more than a few
feet may result in transmission damage.
STOPPING THE TRACTOR
Move the speed control lever to the "N" position
or use the brake. Before dismounting always lock
the brake pedal and turn the Ignition “OFF". Also,
disengage the power take-off clutch lever.
A CAUTION! Do not carry passengers or
give rides. Keep children, pets, and
bystanders a safe distance away.
EQUIPMENT LIFT HANDLE
The lift handle is used to lift or lower equipment
used with the tractor. The equipment can be set in
multiple positions by depressing the button on the
top of the handle and releasing it when the desired
position is reached.
HEIGHT ADJUSTMENT
If a single implement height is normally used, the
handle may be adjusted to locate the desired posi¬
tion by use of the cam stop.
With lift handle in desired implement height posi¬
tion, release cam by turning locking knob counter¬
clockwise. Turn cam until it contacts tang. Lock
cam into this position by turning knob clockwise.
If free handle travel between cam stop and fully
raised position is desired (Float Position), depress
the release button on top of the handle, press in
the lock button located at the front of the handle
and release the top button.
NOTE: To disengage the lift handle from the float
position, pull lift handle back slightly and depress
top button.
NOTE: Refer to the equipment manual for proper
hitching instructions.
15

HITCHING EQUIPMENT TO THE TRACTOR
M4 A
1. Lift lever
2. Draw bar
3. Three-point hitch
Drawbar and three-point hitch shown
on International Cub Cadet 86 Tractor.
DRAWBAR
Drawbar equipment must be hitched to the tractor
only at the hitch hole in the drawbar.
THREE-POINT HITCH
When the tractor has a three-point hitch, equip¬
ment adaptable to this hitch is raised and lowered
with the lift handle or power lift control. The lift
handle can be set to hold the equipment at various
positions by use of the notches in the lift handle
quadrant or cam stop. The lower mounting bracket
has three holes which are used for additional
adjustment.
1. Release button 4. Cam lock knob
2. Lock button 5. Cam stop
3. Lift handle 6. Tang
Adjustable stop limiting handle travel.
A CAUTION! Disengage power to any
attachment when transporting or not in
use.
NOTE: Refer to the equipment manual for proper
hitching instructions.
16

REAR POWER TAKE-OFF
International Cub Cadet 86,108 and 128 Tractors
1, Power take-off guard
2. Grease fitting
If your tractor is equipped with a rear power
take-off, the following instructions should be
carefully studied and followed.
The rear power take-off is started and stopped by
the same engine clutch as the tractor. Be sure to
disengage the engine clutch before moving the
power take-off shifter lever.
CAUTION! The shifter lever should always
be in the disengaged (rearward) position
when the power take-off is not In use.
Always cover the power take-off exposed shaft
with the guard when the power take-off is not
being used.
1. Shifter lever
OPERATING THE REAR POWER TAKE OFF
WITH THE TRACTOR STANDING STILL
1. Move the throttle lever back to the "SLOW"
speed.
2. Depress the pedal and move the transmission
gearshift lever to the neutral position.
3. Move the shifter lever forward to the engaged
position.
4. Move the throttle lever forward to the "FAST"
position and slowly release the pedal.
OPERATING THE REAR POWER TAKE-OFF
WITH TRACTOR IN MOTION
Follow steps 1 thru 3 outlined above. Keep the
pedal depressed, move the transmission gearshift
lever to the speed desired and advance the throttle
lever. Slowly release the clutch pedal. This will
start the tractor in motion with the power take-off
in operation.
17
