USER MANUAL
WITH WARRANTY CARD
Experience the gentle touch of care
Semi Automatic Washing Machine
AN ISO 9001:2008 COMPANY
WMS76ST
WMS76FT
SA80CR
SA80LV
COMPLIANT
SA72DB
SA72DR

Dear Customer
Congratulations on being the Proud owner of Intex Washing Machine. Your Washing
Machine comes with a intex Guarantee of Quality.
Intex takes great pride in providing its customers with perfect products that adheres to
international quality standards.
Intex is committed to international quality standards.
Intex is committed to provide the ultimate customer satisfaction as nothing brings us
greater joy than having satised customers of Intex.
At Intex, feedback and suggestions based on your product usage experience are
greatly appreciated.
CONTENTS:
1. Parts Identication ............................................................... 1
2. Safety Precaution ................................................................. 2
3. Recommended Washing Procedure ................................... 3
4. Laundry Guide ...................................................................... 4
5. Trouble Shoot Table ............................................................. 5
6. Specication & Wiring Diagram .......................................... 6
7. Warranty Card ....................................................................... 7
8. Warranty Card ....................................................................... 8
9. How to avail service ............................................................. 9
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Don’t put hands into the tub when it’s working.
The power cord of the washer is connected by Y shape. If must be replaced by the manufacturer,
its service agent or similarly qualied persons in order to avoid a hazard.
!

INTRODUCTIONS OF PARTS
1
Note : Graphics may be different with the actual machine.
4. Wash Program
Set the program to “Gentle”,“Normal”,
“Heavy” according to kinds and
quantity of the laundry.
5. Drain Selector
Select“ Wash Rinse” for washing and
rinsing and “Drain” to drain the water
out of the tub.
6. Spin Timer
Select the desired time for spinning. The
maximum limit is 5 min. Don’t rotate the knob
more than prescribed limit.
1. Water Supply Inlet
Connect here with the inlet hose from the
water tap to feed water to the tub.
2. Water Selector
Select “WASH” to supply water for
washing and rinsing and “SPIN” for spin
shower rinse.
3. Soak Timer
Select the desired time for soaking
washing or rinsing.
WASHING
COVER
WATER SUPPLY
SELECTOR
OVER FLOW
FILTER
ROTATION
FILTER-C
CABINET
PULSATOR
POWER CORD
SPIN DRYER
BASKET
SAFETY
COVER-2
SPIN DRYER
COVER
Water
Inlet
Water Selector
13 4 56
2
off
Gentle
Normal
Heavy Drain
Wash-Rinse Off
Wash Timer Wash Selector Wash Drain Spin Timer
Turbo Dry
Regular
* Model SA80CR/LV with Turbodry features of
10min Spin Timer

Safety Precautions
1. Make sure that the washing machine is plugged
to a 3 pin/5A electrical outlet and earth terminal is
provided on the outlet.
2. Unplug the power supply cord when you do not use it.
3. To disconnect the washing machine from electrical mains
completely, pull out the plug and do not pull it from the mains cord.
4. Don’t allow your kids to look inside the washing machine while
running.
5. This washing machine is meant for washing clothes with water
as a medium. Do not use petrol or other chemicals. This can
result in re and damage.
6. Do not use water with temperature exceeding 50 degree C, as
this deforms the plastic parts in the machine. If you desire to
use warm water add hot water to cold water in the wash
Do not pour hot water in an empty tub.
7. Keep the machine away from ames and inammable
material. Do not expose the washing machine to direct
sunlight or rain. Also avoid placing it in humid locations.
8. Take Precautions not to pierce the control panel membrane sheet.
9. Do not connect the earth wire to a phone wire, lightening rod.
10. Do not press the button with an awl or a pin.
11. Avoid overloading of wash and spin tub.
12. Do not use wash & spin tub for water storage.
Care & Maintenance
Be sure to remove the power plug from main power supply before cleaning the machine and lter
Net Filter Cleaning
1. Pull out the lint lter from the lock use ngers
pull out at the part of the Lint Filters side.
2. Turn the net inside out and clean with water.
3. Set back to the original position. Insert the bottom
rst as shown press down and lock as the arrow.
Cleaning the Wash Tub
1. After washing is complete, ll fresh water above the level of pulsator without adding clothes.
2. Run the machine for 1-2 minutes turn the knob to “DRAIN” position when pulsator is still rotating.
3. When water is completely drained out, turn the know to “WASH” position.
4. Finally turn off the machine.
2

3
Recommended washing procedure
1. Open the water tap and ll the wash tub about half way.
2. Put in the laundry detergent and allow it to disperse well.
3. Put in the clothes to be washed and add water in accordance
with the amount of cloth load.
4. Set the WASH TIMER as desired depending on the fabric type
and the degree of soiliage.
5. When washing is nished, set the Drain Selector to Drain
NOTE: Ensure that the clothes rotate freely during wash, if not,
reduce the cloth load. (By removing some clothes from the machine)
Rinsing and Drying Rinsing
There are 3 ways to rines:
1. Soak Rinse : Fill the wash tub appropriately for the number of
clothing being washed. Set wash timer for 35 Minutes.
(Soak/Rinse will begin) and clothes will Soak/Rinse for a period of 20
Minutes.
2. After 20 minutes machine will switch to wash function and clothes will be
washed for 15 Minutes. A Buzzer sound shall indicate the end of
the wash period.
3. Intermediate Spin Rinse: Put clothes inside the Spin Tub. Set Water
Supply selected to SPIN TUB. Open the water tap and keep it open for
one to two minutes and then close tap. Spin for one minute. When
rinsing is over, set the Drain Selector to DRAIN. Do not keep the water
tap open when the Spin tub is rotating, else machine will malfunction.
SPIN DRYING
Put clothes inside Spin Drum, distributing them evenly and ensure that the drain
hose is lowered otherwise the machine will malfunction. After putting clothes in
Spin Drum place spin Drum Cap over the clothes inside the tub to prevent them
from ying out. Close the Spin Drum Lid. lf the lid is not closed the Spin Drum
will not rotate. Set the SPIN TIMER from 1 to 5 minutes according to the type of
clothes. lf the spin Drum starts shaking noticeably, open the lid and wait for the
Spin Drum to stop spinning. Distribute the clothes evenly and re-start.
REFERENCE
TABLE 1. DETERGENT GUIDE
WASH LOAD
Water Level
Amount of Detergent
Amount of concentrate Detergent
Amount of Softener
Min.
25 gm
16 gm
17 ml
40 gm
25 gm
1.2 kg 1.2~2.5 kg
Low Medium High Over Flow
22 ml
50 gm
30 gm
26 ml
60 gm
38 gm
29 ml
64 gm
40 gm
35 ml
2.5~3.8 kg 3.8~5.0 kg
5.0 kg or ABOVE
* Model SA80CR/LV with Turbodry features of 10min Spin Timer

4
Notes:
If the wash load and water volume do not match, clothes may
damage/water splash may occur.
The quantity of wash load varies depending on fabric type, thickness and size
of the clothes.
Adjust the water level/wash load as required by carefully watching the
movement of the clothes in the tub.
Table 2- LAUNDRY GUIDE
Less than 1.2 kg
1.2 ~ 2.5 kg
2.5 ~ 3.8 kg
3.8 kg and above
Washing Time
Wash Selector
Washing Time
Wash Selector
Washing Time
Wash Selector
Washing Time
Wash Selector
2 minutes
Regular
2~5 minutes
REGULAR
7~10 minutes
REGULAR
Soak 20 minutes
Wash 10~15 minutes
2~5 minutes
NORMAL*/ HEAVY
7~10 minutes
NORMAL*/ HEAVY
10~15 minutes
NORMAL*/ HEAVY
Soak 20 minutes
Wash 15 minutes
REGULAR NORMAL*/ HEAVY
7~10 minutes
HEAVY
10-15 Minutes
HEAVY
#Soak 20 minutes
Wash 15 minutes
HEAVY
#Soak 20 minutes
Wash 15 minutes
HEAVY
System
Amount of Laundry Clothes Synthetic Fiber Cotton Heavy Stained
Clothes
Trouble shooting guide
Motor not working
Spin dryer basket
does not operate
Drain not drawing
ls there any cloth dropped between the basket and tub?
ls the spin dryer cover closed?
ls the laundry gathered to one side of the spin dryer
basket?
ls the lint stuck to the plunger valve?
ls the end of the drain hose guide located at an
excessive height?
TROUBLES CHECK POINTS
Check supply source.
ls the power cord rmly plugged in?
ls the timer turned to a suitable point except “OFF”?
Motor has been provided with “TOP” (Thermal overload
protector). This will protect the motor from burning due to
overheating caused by various variable factors such as
overload voltage, frequency variation, etc. In such case
motor supply will get off, thus stopping the motor. Wait for
approximate hour till motor cools to normal temperature.
Restart the M/c to see if motor functions normally.
2
/
1
System

The pulsator
rotates too slowly
Abnormal noise
and vibration
Water leaks from
wash tub
Power out or switch off
Transmission belt burst
Pulsator is blocked by
something
Belt becomes loose
The exible screw of motor
is loose
The clothes in the spin-dry
tub are unbalanced
Something was stuck between
pulsator and wash tub
The hose is not tightened
with the wash tub
Assemble the transmission belt
Remove the blockage
Tighten the belt or replace it
Tighten the belt and the
screw
Place the clothes neatly
Remove it.
Tighten it
Usage instructions for semi-automatic washing machine
Step 1
Select the wash option (Heavy/Normal/Gentle) on the selector switch
Soak/Wash: Put clothes in the wash tub with water and detergent. Start the
Soak/Rinse function.
For the rst 20 Minutes Soak/Rinse will work and after that clothes will be washed
for the next 15 Minutes.
Step 2
Place the clothes in the spin tub.
Select spin timer for the time period required (For regular 5 mins / Turbodry 10mins)
This is required to remove excess soap
Will result in the rst drying process for the clothes.
Step 3
Transfer clothes to the wash tub.
Rinsing: Fill in water only and select wash time for 3-4 minutes.
After this is complete, select the drain mode to drain out water
Step 4
Drying : Transfer clothes to spin tub and select spin time to complete nal drying
process.
Problem
Reason Solution
The pulsator
does not rotate
Switch on plug
Trouble Shoot Table
5

6
WIRING DIAGRAM
-PT1
Red
Red
Red
Yellow
Yellow
Yellow
-M1
-XP
Brown
L
E
N
E
Blue Blue
Yellow/Green
Yellow/Green
- M2
White
Blue
Orange
Orange
Orange
-C2
White
-SQ
Gray
-PT2
Buzzer
Pink
Brown
WIRING DIAGRAM
-C1
PACKING LIST
SPECIFICATION
Name
Semi Automatic washing machine
Spin-dry safety lid
Inlet pipe
User manual
Quantity
1
1
1
1
Fuse
Spinning Input
Net Dimension in mm (WXDXH)
Package Dimension in mm (WXDXH)
Net Weight
Gross Weight
Water Capacity High
Water Capacity Low
Castor
Buzzer
Wash Timer
Soak Time
Spin Timer
190 W
805x475x935
820x520x1000
22 kg
26 kg
75 L
47 L
Yes
35 min.
Yes
20 min.
5 min.
Power Supply
W
ashing Input
SA72DB/DR
7.2 kg
520 W
Model
Max. Rated Capacity Wash
230 V AC / 50Hz
190 W
805x475x1040
820x520x1100
24 kg
29 kg
75 L
47 L
Yes
35 min.
Yes
20 min.
10 min.
SA80CR/LV
8.0 kg
540 W
230 V AC / 50Hz
6.0 kg
Max. Rated Capacity Spin
6.0 kg
190 W
805x475x995
820x520x1055
23 kg
27 kg
75 L
47 L
Yes
35 min.
Yes
20 min.
5 min.
WMS76ST/FT
7.6 kg
520 W
230 V AC / 50Hz
6.0 kg

7

8

9

10

11
