Intuix S860 User manual

User guide
Manuel d’utilisation
Benutzerhandbuch
www.intuix.net
S860
TV TNT/DVB-T PORTABLE ET RADIO
S860 manuel 28/12/06 14:33 Page 2

Service Hotline [phone]*
* 1,99 /Min. vom deutschen Festnetz
Einen kostenlosen eMail-Support erhalten Sie über
www.intuix.net
(and other countries)
www.intuix.net
Service Hot line 0820 825 333*
* numéro indigo 0,15 TTC/min
www.intuix.net
www.intuix.net
S860 manuel 28/12/06 14:33 Page 1

User guide
S860
Handheld DVB-T RADIO
S860 manuel 28/12/06 14:33 Page 5

Table of Contents
Parts of the handheld TV . . . . . . . . . . . . . . . . . . . . . 1
Remote Control Operations . . . . . . . . . . . . . . . . . . . 3
Remote Control Battery Installation . . . . . . . . . . . . . 3
General Operating Instructions . . . . . . . . . . . . . . . . 4
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . 5
First Time to Setup . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Automatic Channel Searching Steps . . . . . . . . . . .13
Connection to TV Set . . . . . . . . . . . . . . . . . . . . . . . 14
Trouble Shooting Q&A . . . . . . . . . . . . . . . . . . . . . . 15
Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
S860 manuel 28/12/06 14:33 Page 6

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
Important Safety Instructions and Caution
1. Read Instructions All the safety and operating instructions should be read before the product
is operated.
2. Retain Instructions The safety and operating instructions should be retained for future reference.
3. Heed Warnings All warnings on the product and in the operating instructions should be adhered to.
4. Follow Instructions All operating and use instructions should be followed.
5. Cleaning Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
6. Attachments Do not use attachments not recommended by the product manufacturer as they may
cause hazards.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lighting flash with arrowhead symbol within
an equilateral triangle is intended to alert the
user to the presence of uninsulated dangerous
voltage within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
OR
An appliance and cart combination should be moved
with care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart
combination to overturn.
CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF POWER PLUG TO WIDE SLOT
OF AC OUTLET AND FULLY INSERT.
S3125A
Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure your personal
safety. Improper use can result in potential electrical shock or fire hazards. In order not to defeat the safeguards, observe the
following basic rules for its installation, use and servicing.
PORTABLE CART WARNING
DO NOT REMOVE THIS TAG (MARKING)
The words “WARNING, MOVE WITH CARE. THIS
CART/APPLIANCE COMBINATION SHOULD NOT BE
MOVED BY CHILDREN WITHOUT PROPER GUIDANCE
FROM AN ADULT”
S860 manuel 28/12/06 14:33 Page 7

7. Water and Moisture Do not use this product near water-for example, near a bath tub, wash bowl,
kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.
8. Accessories Do not place this product on an unstable cart, stand, tripod, bracket, or table. The
product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only
with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product.
Any mounting of the product should follow the manufacturer's instructions, and should use a mounting
accessory recommended by the manufacturer.
9. Carts and Stands The product should be used only with a cart or stand that is recommended by the
manufacturer.
9A. A product and cart combination should be moved with care. Quick stops, excessive force, and uneven
surfaces may cause the product and cart combination to overturn.
10. Ventilation Slots and openings in the cabinet are provided for ventilation and to ensure reliable
operation of the product and to protect it from overheating, and these openings must not be blocked
or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other
similar surface. This product should not be placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer's instructions have been adhered to.
11. Power Sources This product should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supply to your home, consult your product
dealer or local power company. For products intended to operate from battery power, or other
sources, refer to the operating instructions.
12. Grounding or Polarization This product may be equipped with a polarized alternating-current line plug
(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This
is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the
plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
Alternate Warnings This product is equipped with a three-wire grounding-type plug, a plug having a third
(grounding) pin. This plug will only fit into a grounding-type power outlet. This is a safety feature. If you are
unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the grounding-type plug.
13. Power-Cord Protection Power-supply cords should be routed so that they are not likely to be walked
on or pinched by items placed upon or against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the product.
14. Protective Attachment Plug The product is equipped with an attachment plug having overload
protection. This is a safety feature. See Instruction Manual for replacement or resetting of protective
device. If replacement of the plug is required, be sure the service technician has used a replacement
plug specified by the manufacturer that has the same overload protection as the original plug.
15. Outdoor Antenna Grounding If an outside antenna or cable system is connected to the product, be
sure the antenna or cable system is grounded so as to provide some protection against voltage surges
and built up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides
information with regard to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge
unit, connection to grounding electrodes, and requirements for the grounding electrode.
See Figure 131.1.
16. Lightning For added protection for this product during a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the product due to lightning and power-line surges.
17. Power Lines An outside antenna system should not be located in the vicinity of overhead power lines
or other electric light or power circuits, or where it can fall into such power lines or circuits. When
installing an outside antenna system, extreme care should be taken to keep from touching such power
lines or circuits as contact with them might be fatal.
18. Overloading Do not overload wall outlets, extension cords, or integral convenience receptacles as this
can result in a risk of fire or electric shock.
19. Object and Liquid Entry Never push objects of any kind into this product through openings as they
may touch dangerous voltage points or short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
S860 manuel 28/12/06 14:33 Page 8

20. Servicing Do not attempt to service this product yourself as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
21. Damage Requiring Service Unplug this product from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions. Adjust only those
controls that are covered by the operating instructions as an improper adjustment of other controls
may result in damage and will often require extensive work by a qualified technician to restore the
product to its normal operation,
e) If the product has been dropped or damaged in any way, and
f ) When the product exhibits a distinct change in performance this indicates a need for service.
22. Replacement Parts When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.
23. Safety Check Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks to determine that the product is in proper operating condition.
24. Wall or Ceiling Mounting The product should be mounted to a wall or ceiling only as recommended by
the manufacturer.
25. Heat The product should be situated away from heat sources such as radiators, heat registers, stoves,
or other products (including amplifiers) that produce heat.
Figure 131.1
Example of antenna grounding as per
National Electrical Code, ANSI/NFPA 70
ANTENNA LEAD
IN WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
GROUND CLAMP
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC - NATIONAL ELECTRICAL CODE
S2898A
ELECTRIC
SERVICE
EQUIPMENT
S860 manuel 28/12/06 14:33 Page 9

E
N
Precautions
On Safety
• Do not use wet hands to pull out the plug. It may cause electrical shock.
• If the player does not work, please pull out the plug for safety. Contact us for further
technical support.
• Before moving the player, please make sure the power adapter is disconnected from
the wall outlet.
• Do not move the player when playing. It may cause a fire or electrical shock.
• Should any solid object or liquid fall into the cabinet, unplug the player and have it
checked by qualified personnel before operating it any further.
• If you are not going to use the player for a long while, be sure to disconnect the player
from the wall outlet. To disconnect the power adapter, grasp the plug itself; never pull
the cord.
On Placement
• Please keep a sufficient distance between the player and a radio set. A sufficient dis-
tance is also needed between the player and any other devices with electromagnetic
field.
• Please place the player in a location with adequate ventilation to prevent heat build-up
in the player.
• Do not place the player on a soft surface such as a rug that might block the ventilation
holes on the bottom.
• Do not place the player in a location near heat sources, or in places subject to direct
sunlight, excessive dust, or mechanical shock.
• Do not place the player in a location exposed to cool air. Condensation may occur and
cause the player work incorrectly.
On Operation
• The player may not work because of improper operation. The limited warranty does not
cover consequent losses that rise from improper usage.
• Turn off the player when you are watching regular TV program. It may cause a picture
distortion.
• The player will not work correctly when affected by exterior elements such as static
electricity. In such cases, pull out the power adapter and plug it back to the outlet
again.
S860 manuel 28/12/06 14:33 Page 10

EN1
Parts of the Handheld TV
Antenna
LCD panel
Infrared remote sensor
Allow remote controller to navigate this unit.
Battery LED
Battery status indicator. When the battery is getting low, the LED will glow
red. And after successfully charging, it will glow green.
Power LED
When the unit operates, the LED will glow green.
Menu/Exit button
OK/Mute button
Multi selector (CH+( )/CH-( )/VOL+( )/VOL-( ))
Speaker
Display on-off control button
: Please refer to the page 9 for more detailed
description.
1
2
3
4
5
6
7
8
9
10
6 7 8 10
▲
▲
▲
▲
S860 manuel 28/12/06 14:33 Page 1

EN2
Parts of the Handheld TV
DC power connector
Connect with the AC/DC power adapter or the car cigarette
lighter power adapter
Video out connector
Output the video signal
Earphone/Audio out connector
Output the stereo audio signal
Holder
Eyelet for TV strap
External antenna connector
Power switch
11
12
13
14
15
16
17
E
N
S860 manuel 28/12/06 14:33 Page 2

EN3
Remote Control Operations
(1) SOURCE: no function
(2) POWER: power-on/stand-by selection
(3) Channel selection up or move the cursor up
(4) MENU: enter the setup menu
(5) OK: select the highlight item
(6) Volume down or move the cursor left
(7) Channel selection down or move the cursor
down
(8) EXIT: exit the current setup
(9) Digital keys
(10) RECALL: return to the last selected channel
(11) Red button : sub-title key in the normal
operation mode or a hot key to go to the
browsed Teletextpages in teletext mode
(12) Green button : a hot key to go to the browsed
Teletext pages in the teletext mode
(13) MUTE: mute control
(14) DTV/Radio selection
(15) PIC: no function
(16) EPG: electronic program guide
(17) Volume up or move the cursor right
(18) PREVIEW: preview selected programs
(19) PLAY/PAUSE selection
(20) AUDIO: second language, and stereo selection
(21) INFO: DTV system information
(22) AUTO: automatic channel scanning
(23) MANUAL: manually select channels
(24) ENTER: enter the selected channel no.
(25) TTX: Teletext key to display Teletext (has to be supported by broadcaster)
(26) Yellow button : page up in the EPG mode or a hot key to go to the browsed Teletext pages in
the teletext mode
(27) Blue button: page down in the EPG mode or a hot key to go to the browsed Teletext pages in
the teletext mode
Remote Control Battery Installation
Before attempting to operate your remote control,
install the battery as described below.
(1) Turn the remote control face down
(2) Press down on the ridged area of
the battery cover and slide it off.
(3) Slide another battery in.
S860 manuel 28/12/06 14:33 Page 3

EN4
General Operating Instructions
Turning the unit ON or OFF
• To turn on the system, slide the Power switch
on the top side of the unit to the position labeled “ON”.
• To turn off the system, slide the Power switch
on the top side of the unit to the position labeled “OFF”.
Connecting the earphone
• Insert the earphone plug into the “ ’’
jack on the side of the unit.
Connecting to the external antenna
• Insert the antenna plug into the “Ext. ANT” jack on the top
side of the unit.
Antenna plug
Earphone
plug
E
N
S860 manuel 28/12/06 14:33 Page 4

EN5
Charging the Battery
This unit contains built-in a rechargeable battery.
When the “Battery LED” lights in red, the battery will
stop supplying power to the system. Then, you need
to charge the battery. Please follow the steps below.
1. You can watch the TV and recharge the battery
simultaneously.
2. Connect the unit to the external power source via
AC/DC power adapter or car cigarette lighter
adapter. You can refer to the diagram below and
in next page.
3. When the battery is being charged, the battery led will glow red.
4. “Battery LED” will turn green after the battery is full.
5. Charge your battery for a minimum of 4 hours to get fully charged
Connecting to the AC/DC power adapter or the cigarette lighter
• Insert the DC plug into the “ “ jack on the side of the unit.
• Attach the AC plug to the AC outlet or attach the car cigarette lighter plug to the car’s
cigarette lighter power receptacle.
NOTICE
• DO NOT, under any circumstances, use another make or model of AC adapter kit or
car cigarette lighter adapter to either charge the battery of this unit or supply power to
this unit. Failure to observe this precaution could result in overheating or damage to
this unit.
• After 300 recharging cycles, the capacity of the battery will be reduced to 70%.
Hence, after many times of recharging, please consider replacing the battery.
• The battery may become hot during playing or charging.
• Recharge the battery at room temperature between 0°C and 40°C.
DC plug
DC plug
AC plug Car cigarette lighter plug
Battery LED
S860 manuel 28/12/06 14:33 Page 5

EN6
Basic Operations
This section details the basic TV operations.
KEY FUNCTION
Channel selection
Press [CH+] button or [CH-] button
to select the TV/Radio channel.
Panel Control
Press this button to turn off or turn on
the panel back light.
Menu
Press this button to enter
or exit the menu mode.
Mute control
Press this button to mute
or restore the volume.
Make selection
In menu mode, press this button
to make selection.
Volume adjustment
Press [VOL-] button or [VOL+]
button to adjust the volume.
Navigating the Menu
In menu mode, press [CH+] button and [CH-]
button to move cursor up and down. Press [VOL-]
button and [VOL+] button to move cursor left
and right
.
E
N
S860 manuel 28/12/06 14:33 Page 6

EN7
MENU
There are two pages of the menu, including program and system. You can use [VOL-] button to
select each page. In the program page of the menu, you can highlight the service type,
program list, preview, audio channel, subtitle language, program info, automatic search, or
manual search to perform TV program related operation. And in the system page of the menu,
you can highlight the brightness, TV system, regional setting, osd language, time zone to adjust
the system setting. You can use [CH+] button and [CH-] button to highlight the item and press
[VOL+] button and [VOL-] button to select your choice and then press [OK] button to set the setting.
SYSTEM PAGE
Brightness
To adjust the brightness of the screen
TV System
To select the TV display format
Regional Setting
To select the region where you are located in
OSD Language
Selection of the OSD language
Time Zone
To set the time zone
S860 manuel 28/12/06 14:33 Page 7

EN8
PROGRAM PAGE
PROGRAM LIST (EPG, Electronic Program Guide)
It shows the information of all of the available channels. You can use [CH+] button and [CH-]
button to choose any channel, while [VOL-] button and [VOL+] button are the keys to show the
details of the channel.
Program List
Current program name
TV scene
Next on program name
Service Type
Selection of either TV or Radio programs
Program List
To show the information of all of the available channels
Preview
To preview up to 9 selected channels
Audio Channel
Selection of either master or secondary language
Subtitle language
To select a subtitle language available from service
providers
Program info
To provide the TV program information about the
system parameters and signal information
Automatic Search
To search the program channels automatically
Manual Search
To search the program channels manually
E
N
S860 manuel 28/12/06 14:33 Page 8

EN9
MANUAL SEARCH
You can use [VOL-] button and [VOL+] button to select the desired channel and press [OK]
button to perform program searching. The found programs will be appended to the program list.
Selected channel
Channel information
Signal information
PROGRAM INFORMATION
It provides you the TV program information about the system parameters and signal information.
Press [MENU] button to exit the screen.
System parameters
Signal information
Antenna selection information
S860 manuel 28/12/06 14:33 Page 9

EN10
First Time to Setup
When the first time this unit is turned on, please follow the following steps to finish
the initialization.
Press [MENU] button firts and then press
[VOL-] button to enter the menu for system
configuration selection
Press [VOL+] button and highlight your TV
system output and press [OK]button
Press [VOL+] button and highlight your
region and press [OK] button
Press [VOL+] button to adjust the
brightness level of the display and press
[OK] button
Press [VOL+] button and highlight your
OSD language and press [OK] button
Time will automatically set by your region.
If you need to correct it, press [CH+] button
or [CH-] button to adjust the time. E
N
S860 manuel 28/12/06 14:33 Page 10

EN11
Back to the top of the menu and press
[VOL-] button to enter program menu
screen.
Highlight the OK item ans press [OK]
button.
When the channel seraching is over, press
[CH+] button or [CH-] button to select the
program.
Highlight the automatic search item ans
press [OK] button.
Channel searching will take a few minutes.
You could press [VOL+] button or [VOL-]
button to adsjust the volume.
S860 manuel 28/12/06 14:33 Page 11

S860 manuel 28/12/06 14:33 Page 12
