INVENTOR GLXD082HP User manual
FRONT LOAD
MODEL:
GLXD082HP
DRYER MACHINE
• USER’S MANUAL
• ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΗΣ
ENGLISH | ΕΛΛΗΝΙΚΑ
3
CONTENTS
SAFETY INSTRUCTIONS
■Safety Instructions .................................................................. 4
INSTALLATION
■Product Description..............................................................11
■Installation ............................................................................. 12
OPERATIONS
■Quick Start . ............................................................................ 14
■Before Each Drying ...............................................................15
■Control Panel . ....................................................................... 17
■Option..................................................................................... 18
■Drying Programmes Tables ................................................21
MAINTENANCES
■Cleaning And Care ................................................................ 23
■Trouble Shooting...................................................................26
■Technical Specications ....................................................... 28
■Product Fiches ....................................................................... 29
4
SAFETY INSTRUCTIONS
■ Safety Instructions
For your safety,the information in this manual must be followed to
minimize the risk of re or explosion, electric shock, or to prevent
property damage, personal injury or loss of life. Explanation of the
symbols:
!
Warning!
This combination of symbol and signal word indicates a potentially
dangerous situation which may result in death or serious injuries
unless it’s avoided.
!
Caution!
This combination of symbol and signal word indicates a
potentially dangerous situation which may result in slight or
minor injuries or damage to property and the environment.
Note!
This combination of symbol and signal word indicates a
potentially dangerous situation which may result in slight or
minor injuries.
!
Warning!
To prevent any damages to your and others’ life or property, you
have to follow the safety notes.
5
SAFETY INSTRUCTIONS
Intended use
• This heat pump dryer is intended for drying typical amounts
of household laundry, which have been washed with water. It
has been designed solely for private use and is not suitable for
commercial or shared use (i.e. by several families in an apartment
building).
• Use this appliance only as described in this user manual.
• This appliance is for indoor use only.
• Any other use is deemed improper and may result in damage to
property or even personal injury.
• The manufacturer accepts no liability for damage caused by
improper use.
Safety instructions
• The appliance corresponds to protection Class I and may only be
connected to a plug with a protective conductor that has been
installed properly. When connecting the appliance to the mains,
make sure that the mains voltage is correct. You can nd more
information about this on the rating plate.
• The electrical safety of this tumble dryer can only be guaranteed
when correctly earthed. It is essential that this standard safety
requirement is met. If in any doubt, please have the household
wiring system tested by a qualied electrician. The manufacturer
cannot be held liable for the consequences of an inadequate
earthing system (e.g. electric shock).
CAUTION: RISK OF FIRE!
6
SAFETY INSTRUCTIONS
The electrical safety of this tumble dryer can only be guaranteed
when correctly earthed. It is essential that this standard safety
requirement is met. If in any doubt, please have the household
wiring system tested by a qualied electrician. The manufacturer
cannot be held liable for the consequences of an inadequate
earthing system (e.g. electric shock).
!
Warning!
Electric shock hazard
• Before connecting the tumble dryer, ensure that the connection
parameter on the rating plate (fuse rating, voltage and frequency)
match the mains electricity supply. If in any doubt, consult a
qualied electrician.
• Do not pull the power cord forcefully. Please grasp the mains plug
instead
• Do not plug/draw the mains plug with wet hands.
• Do not bend, clamp or damage the power cord and the power plug.
• If the power cable is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons in
order to avoid a hazard.
• Warning: The appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is
regularly switched on and o by a utility.
• Do not connect the appliance to the mains electricity supply by an
extension lead, multi-socket adapter or similar.
• The accessibility of the plug must always be ensured, in order to
disconnect the tumble dryer from the mains.
• If the appliance appears high temperature abnormally, please draw
the mail plug immediately.
7
SAFETY INSTRUCTIONS
Injury danger
• The appliance must not be installed behind a lockable door, a
sliding door or a door with a hinge on the opposite side to that of
the tumble dryer, in such a way that a full opening of the tumble
dryer door is restricted.
• Do not disassemble or install the dryer without any instruction or
supervision.
• Do not stack this dryer on washing machine without stacking
kits. (If you want to stack this dryer on a washing machine, please
purchase the independent parts. Installation shall be done by the
manufacturer, its service agent or similarly qualied persons to
avoid any hazards.)
• Do not lean on the opened door of the dryer.
• Condensed water is not drinking water. It can cause health
problems in both people and animals if consumed.
Damage danger
• Do not overload the machine. Follow the recommended maximun
load volume.
See the related chapter in the user manual.
• Do not operate the dryer without the door lter and the base lter.
• Do not dry the clothes before being spun.
• Do not expose the dryer directly under the sun.
• Do not install the dryer in humid and drenching environment.
• While cleaning and maintenance, please do remember to pull out
the power plug and do not directly clean the dryer with water.
• The appliance should not be overturned during normal use or
maintenance.
8
Explosion & Fire danger
• Please do not dry the clothes with any ammable substances such
as kerosene or alcohol. Otherwise, there may be explosion.
• The appliance contains an environmentally friendly but ammable
R290 refrigerant. Keep away from open ame and other sources of
ignition.
• The tumble dryer is not to be used if industrial chemicals have been
used for cleaning.
• Do not dry unwashed items in the tumble dryer.
• Items that have been soiled with substances such as cooking oil,
acetone, alcohol, petrol, kerosene, spot removers, turpentine,
waxes and wax removers should be washed in hot water with an
extra amount of detergent before being dried in the tumble dryer.
• Items such as foam rubber (latex foam), shower caps, waterproof
textiles, rubber backed articles and clothes or pillows tted with
foam rubber pads should not be dried in the tumble dryer.
• Fabric softeners, or similar products, should be used as specied by
the fabric softener instructions.
• Oil-aected items can ignite spontaneously, especially when
exposed to the heat inside the tumble dryer. The items become
warm, causing an oxidation reaction in the oil. Oxidation creates
heat. If the heat cannot escape, the items can become hot enough
to catch re. Piling, stacking or storing oil-aected items can
prevent heat from escaping and so create a re hazard.
• Remove all objects from pockets such as lighters and matches.
• Fabrics that contain vegetable or cooking oil or have been
contaminated by hair care products, should be avoided in the
tumble dryer. If it is not possible ,then wash them rst with hot
water and extra detergent.
• Openings must not be obstructed.
• The lint trap has to be cleaned frequently.
• Lint must not to be allowed to accumulate around the tumble dryer.
SAFETY INSTRUCTIONS
CAUTION: RISK OF FIRE!
9
SAFETY INSTRUCTIONS
!
Warning!
Never stop a tumble dryer before the end of the drying cycle
unless all items are quickly removed and spread out so that the
heat is dissipated.
Safety with children
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not
be done by children without supervision.
• Children should be supervised to ensure that they do not play with
the appliance.
• Children of less than 3 years should be kept away from the dryer,
unless continuously supervised.
• Always close the door after use. In this way you will avoid the
danger of:
1. Children climbing onto or into the dryer or hiding things in it.
2. Pets or other small animals climbing into it.
10
Correct Disposal of this product:
This marking indicates that this product should not
be disposed with other household wastes throughout
the EU. To prevent possible harm to the environment
or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse
of material resources. To return your used device, please
use the return and collection systems or contact the
retailer where the product was purchased. They can take
this product for environmental safe recycling.
Disposal of packaging material
• The packaging is designed to protect the appliance from damage
during transportation. The packaging materials are environmentally
friendly and should be recycled. Recycling the packaging can reduce
the use of raw materials in the manufacturing process and the
amount of waste in landll sites.
Model Rated capacity
GLXD082HP 8.0kg
SAFETY INSTRUCTIONS
11
INSTALLATION
■ Product Description
Note!
The product line chart is for reference only, please refer to real product as
standard.
Accessories
The following parts are optional for specic models. If your dryer
has the following parts, please ware gloves to install them as per the
instructions below,
Top board
Control panel
Door
Air inlet
Maintenance cover
Water container
Power Cord
Drum
Door lter
Connector
Condensing
Drain Hose
Hose Holder
Owner’s
manual
12
Transport
Move cautiously. Do not grasp any salient parts of machine. Do not move the machine
using the door as handle. If the dryer can’t be transported erectly, the dryer can be
tilted to right less than 30°.
Risk of injury and damage!
Improper handling of the appliance may result in injury.
• The appliance is very heavy. Never transport or carry the appliance alone; always
with the assistance of another person.
• Remove all obstacles on the transport route and from the installation location,
e.g. open doors and clear away objects lying on the oor.
• Do not use the open door as a handhold.
• Remove all package material before using the appliance.
• Before setting up the tumble dryer, check it for any externally visible damage. Do
not install or use a damaged tumble dryer.
• Do not install the tumble dryer in a room where there is a risk of frost occurring. At
temperatures around freezing point the tumble dryer may not be able to operate
properly. There is a risk of damage if the condensed water is allowed to freeze in
the pump and hoses.
Installation Position
!
Warning!
• Children can become entangled in the packaging lm or swallow small parts
and suocate. Do not allow children to play with the packaging.
• The appliance must not be installed behind a lockable door, a sliding door or
a door with a hinge on the opposite side to that of the tumble dryer, in such a
way that a full opening of the tumble dryer door is restricted.
• Do not restrict the oor clearance through deep pile carpets, strips of wood
or similar. This might cause heat built-up which would interfere with the
operation of the appliance.
INSTALLATION
■Installation
Pull up the upper
drain hose
Connect the external
drain hose to the water
pump
Put the external drain hose into the
oor drain (be careful not to bend
the external drain hose)
13
INSTALLATION
1. It is recommended that, for your convenience, the machine is positioned close to
your washing machine.
2. Do not stack this dryer on washing machine without stacking kits. (If you want to
stack this dryer on a washing machine, please purchase the independent parts.
Installation shall be done by the manufacturer, its service agent or similarly
qualied persons to avoid any hazards.)3. The tumble dryer must be
installed in a clean place, where dirt does not accumulate. Air must be able to
circulate freely around the appliance. Do not obstruct the front air inlet or the air
intake grilles at the back of the machine. 4. To keep vibration and noise
within minimum level when the dryer is in use, it must be placed on a rm and
stable surface.
5. The feet must never be removed.
Level Adjusting
Once you have selected the operating posistion of the
machine, check that the dryer is absolutely level with the aid
of a spirit level. If it is not, adjust the feet by hand or using a
tool.
Power Supply Connection
1. Make sure that the voltage of the power supply is the same as the electric
specication.
2. Do not connect the dryer with the power connection board, a universal plug or
socket, do not use multi-plug adapters and extension cables.
14
OPERATION
■Quick Start
Note!
Before using, make sure the tumble dryer is installed correctly.
Before Drying
Plug in
Drying
After Drying
Buzzer beep and “0:00” on display.
Open the door
and take out
laundry
Pull out the
container
Pour out
condensate
water
Clean the lter Power o
Note!
If the socket with a switch is used, please press the switch to turn o the
power directly.
On Select
program
Select function
or default
Start
Load Close
the door
15
OPERATION
■Before Each Drying
Note!
• Leave it to stand for 2 hours after transporting.Before using the dryer for the
rst time, use a soft fabric to clean the drum inside.
1. Put some clean rags into the drum.
2. Plug the power, press [0n/0].
3. Select the [Refresh] Programme, press [Start/Pause] button.
4. After nishing this programme, please follow the “cleaning and care “
(refer to page 21) to clean the lter door.
• During drying, the compressor and the water will generate some noise
which is entirely normal.
I. Before drying, thoroughly spin the laundry in washing machine. High spin speed
shortens the drying time and reduces the energy consumption.
2. For uniform drying result, sort the laundry according to fabric type and select the
appropriate drying programme.
3. Before drying, please close zips, hooks and eyelets, button, tie fabric belts, etc.
4. Remove all objects from pockets such as lighters and matches.
5. Sew in or remove underwiring from bras.
6. Close duvet covers and pillow cases to prevent small items from being rolled up
inside them.
7. Leave jackets open and undo any long zips so that textiles dry evenly.
8. Do not over dry the clothes, because over dried clothes can easily get creases.
9. Do not dry the articles containing rubber or similar elastic materials.
10. Keep the area around the tumble dryer clean. Coal dust or our may cause an
explosion.
II. The door shall be opened only after the programme of the tumble dryer is
nished to avoid being scalded by hot steam or over heated drying machine.
12. Clean the lint lter and empty water container after each use to avoid extension
of drying time and increase of energy consumption.
13. Do not dry clothes after dry-clean process.
16
The reference weight of dry clothes (weight per item)
Note!
Do not put more load than recommended.
Do not dry dripping wet laundry. The dryer might get damaged
Only dry laundry suitable for tumble drying. You can advise the laundry care labels
on the clothes for the following symbols:
Suitable for tumble drying
Normal drying process: Drying in the tumbler is possible under normal load and
temperature 80°.
Mild drying process: Caution is appropriate when tumble drying. Select mild
process with reduced thermal action.
Do not tumble dry: Articles unsuitable for drying in the tumbler.
OPERATION
Sweaters
(mixed 800g)
Jackets
( cotton 800g )
Jeans
(800g)
Bath Towels
(cotton 900g )
Single
bedsheets
(cotton 600g )
Work clothes
( 1120g)
Pyjamas
( 200g)
Shirts
(cotton 300g )
Shirts
(cotton 180g )
Underwear
(cotton 70g )
Socks
(mixed-weave
50g )
17
OPERATION
■Control Panel
Model: GLXD082HP 8kg
Jeans
Bed Linen
Synthetics
8kg
GLXD082HP
3’’3’’
Time
Special Cotton
My Cycle
Sports Iron
Cool
Warm
Refresh
Wool
Standard
Extra
Standard
Extra
Shirts
Mix
Delicate
120min
90min
60min
30min
➊On/O
Product is switched on or o.
➋Start/Pause
Press the button to start or pause the
drying cycle.
➌Option
This allows you to select an additional
function and will light when selected
➍Display
The display shows the settings,
estimated remaining time and
changes in the status of your dryer
➎Programmes
Available according to laundry type
■Display
Child lock
Remaining Time indicator/Error message
Clean lters (warning)
Empty water container (warning)
Intensity
My Cycle
18
■Option
Delay
This function is used for delaying the start of the drying programme
up to 24 hours. When the delayed programme starts, the time starts to
countdown on the display and the delay icon blinks.
1 . Load your laundry and make sure the machine door is closed.
2. Press the [On/O]button,then use the programme selector knob to
select the desired programme.
3. You can additionally select the [Anti-Crease] function according to
your need.
4. Press the [Delay] button.
5. Repeatedly to press the [Delay] button to select the desired delay
time.
6. After the [Start/Pause] button is pressed, the Dryer is at the running
condition. The drying procedure will be automatically performed
when the delay time is over.
7. If you press the [Start/Pause] button again, the delay function will be
paused.
8. If you want to cancel the “Delay” function, please press the [On/O]
button.
Time
When the [Time] programme is selected, the [Time] button can be used
to adjust the drying time in 10 min. steps.
Intensity
You can adjust the dryness level of the laundry by pressing the [intensity]
button. There are four grades.
1. The intensity function can be activated only before the programme
starts.
2. Press the [Intensity] button repeatedly to increase the drying grade.
3. Except the [Cotton Iron], [Delicate], [Wool], [Time] programme, all the
other programmes can be adjusted with the [Intensity] function.
OPERATION
19
OPERATION
Anti-Crease
At the end of the drying cycle, the anti-crease time is 60 minutes (default)
or 30min 90min 120 minutes (selected). This function prevents the laundry
from creases. The laundry can be removed during the anti-crease phase.
Except [Cool], [Wool] and [Refresh], all the other programmes have this
function.
My Cycle
Used to dene and save your favourite programme, which is used
frequently.
1. Select the desired programme and other drying functions.
2. Press and hold the [Intensity] for 3 seconds until the beep sounds and
the desired programme has been saved.
3. Turn the programme selector to the [My Cycle] position, then you can
start your favourite programme. If you want to change the [My Cycle]
settings, repeat the steps (1) and (2).
Child Lock
1. This machine incorporates a special child safety lock, which can
prevent children from carelessly pressing buttons or making the
faulty operation.
2. When the drying cycle is running, press the [Anti-Crease] and [Time]
buttons at the same time for 3 seconds to start child lock function.
3. When child lock function is set, the display will show Child lock icon
and all button are deactivated, except [On/O] button.
4. To deactivate the child lock function, the [Anti-Crease] and [Time]
buttons shall be pressed at the same time for 3 seconds.
20
■Programmes
Programme selector
1. When the LED display screen brightens up, rotate the programme knob to select
the desired programme.
2. Select the [Delay] , [Time] , [Intensity] , [Anti-Crease] functions for additional
options.
3. Press the [Start/Pause] button.
4. Press the [On/O] button after the programme has comlpeted.
Programme start
The drum will rotate after the programme starts. The cycle phase LED in the display
will light up and the remaining programme time will be displayed.
Programme end
1. The drum will stop rotating after the programme ends. The display will show
M0:00M, also the cycle phase LED showing "End" and related LED will illuminate.
The dryer will start Anti-crease function if user doesn't remove the load. (Refer to
page 17). Please press [On/O] button after unloading the tumble dryer to cut o
power and pull out the plug.
2. Deal with the problems according to "Trouble Shooting" section, if there is an
unexpected stop during the drying procedure or the dryer shows an Error Code
(Refer to page 26).
OPERATION
Table of contents
Languages:
