Invion GPS-7V106-IUS Assembly Instructions

GPS NAVIGATION SYSTEM
7V1 Hardware Instruction Manual

2
Congratulations on choosing a Invion product. We have every expectation that you will be
completely satised with your new purchase.
To always guarantee optimal function and performance of your product, we would ask the
following:
• Before using the appliance for the rst time, carefully read the operating
instructions and adhere to the safety precautions!
• Also read the software user manual including the End User License Agreement.
• All activities at and with this appliance may only be carried out as described in
these operating instructions.
• Please be sure to include the operating instructions in case you pass along this
product to someone else.
Packaging
This appliance is delivered in protective packaging to prevent transportation damage.
Packaging materials are raw materials and can therefore be recycled. Please recycle these
materials.
7V1 Hardware Instruction Manual

3
Contents
1. Brief introduction of hardware 4
2. Entertainment 6
3. Bluetooth operation 8
4. Specications 11
5. With reference to environmental protection 12
7V1 Hardware Instruction Manual

4
1. Brief introduction of hardware
Standard package
Before getting started with your GPS, check to see that your Invion GPS package includes the
following items. If you are missing any parts, please contact your dealer immediately.
● GPS Unit ● Car power adapter
● AC power adapter
1. BUILT-IN GPS ANTENNA
2. SD CARD SLOT
3. POWER: Press for a while to turn
the unit on and off.
4. MAP: Press to change to
Navigation mode
5. TELEPHONE: Press to change to
Bluetooth mode.
6. SOURCE: Use to shift between
AUX and Music Player mode.
7. Adjustment Button: Press
to display a setup menu, which
can be used to adjust
the brightness, and the
FM transmitting frequency.
8. MICROPHONE
9. TOUCH SCREEN
10. USB PLUG
11. VOLUME: Use to adjust the
volume.
12. HEADPHONE JACK
13. AV IN
14. DC IN
7V1 Hardware Instruction Manual

5
About the Touch Screen
• Do not touch the TOUCH SCREEN until the unit starts up completely. Otherwise,
the touch screen may not function correctly.
• The navigation device is mainly operated by touching the buttons on the touch
screen.
• If nothing happens when you touch the buttons on the touch screen, remove your
hand or the stylus from the screen and touch the button again.
• Do not touch any buttons that are grayed out.
• When cleaning the touch screen, use a soft cloth.
Connect to Car Power
• Connect the mini plug of the car adapter into the DC IN jack at the back of the
device.
• Connect the other plug of the car adapter into the car cigarette socket.
Chipset SIRF III
Operates behind athermic windshield
7V1 Hardware Instruction Manual

6
2. Entertainment
1. Insert the SD or MMC memory card to the card slot.
2. Tap on the Tap Menu to change to Media player mode.
The folder list will be displayed.
3. Tap SDMMC DISK folder to open the folder. The le list will be
displayed.
4. Select a folder and double tap to open it.
7V1 Hardware Instruction Manual

7
5. Select and double tap a le to start the playback.
The following buttons appear on the Entertainment screens.
Tap to display the entertainment interface.
Tap to scroll up the folder list or le list.
Tap to scroll down the folder list or le list.
Tap to return to the folder list.
Tap to play the mpeg4 le (*.avi) in full screen mode.
Tap to return to the le list.
Tap to play the les in the SD/MMC card in a random order.
Tap to play a le or all the les repeatedly.
Tap to return to the Top Menu.
Tap to play the previous track.
Tap to pause the playback.
Tap to play the next track.
Tap to stop the playback.
Tap to decrease the volume.
Tap to increase the volume.
7V1 Hardware Instruction Manual

8
3. Bluetooth operation
The GPS is also a Bluetooth device, and it can be paired to a mobile phone with Bluetooth
function.
1. After turning on the unit, press the TEL button on the panel to change to Bluetooth mode.
The screen shows:
2. Tap Pairing on the Bluetooth menu. The Screen shows:
3. Then use your mobile phone to search GPS and pair GPS. (For details refer to your mobile
phone’s user guide.)
When pairing you Bluetooth phone with your GPS, enter the pass code 1234 on the phone
to conrm.
7V1 Hardware Instruction Manual

9
4. When the pairing is successful, the screen shows:
Now, you can use GPS to take a telephone call.
1) Tap numbers (0~9) on the screen to enter a telephone number, and tap YES to dial it.
2) When there is a coming call, the number will be displayed, tap YES to answer it or tap NO
to cut it.
3) Tap to turn off the microphone.
4) Tap List to show the last telephone number that you have dialed, tap YES to redial it.
5) Tap Auto on the screen, when there is a coming call, the unit will answer it automatically
after 5 seconds.
6) During a telephone call, you can use to shift between through the GPS and through
your bluetooth phone.
7) In Navigation mode, when there is a coming call, the screen shows:
Tap YES to answer it, or tap NO to cut it.
7V1 Hardware Instruction Manual

10
The following buttons appear on the Bluetooth menu.
Use to turn the Bluetooth On or Off.
Tap to make the GPS discoverable.
Tap to activate the Auto Answer function.
Tap to increase the speaker volume or to scroll up the call list.
Tap to decrease the speaker volume or to scroll down the call list.
Tap to make or answer a call.
Tap to end or reject a call.
Tap to delete the entered number.
Tap to display the call list.
Tap to switch between the player and your mobile phone during a call.
Tap to turn off the microphone.
7V1 Hardware Instruction Manual

11
4. Specications
7” GPS Navigation with Bluetooth Hands-free and
MP3 Player
7” 16:9 Wide LCD Screen, 480*234 RGB
OS: Windows CE.Net 4.2
64 MB SDRAM
CPU : ARM 400 MHz
GPS: SIRF Star 3 High Sensitivity Receiver
Plays MP3 le via SD/MMC card
Bluetooth hands-free(need Mobile Phone Support)
Dimension: 198L X 101WX25H mm
Weight: 870g
Buttons and ports
MAP
Bluetooth: Switch to the Bluetooth Screen
AV
Setup
Built-in SD/MMC Slot
USB connection jack
Power charge jack
Headset jack
Accessories
12V Car Adapter
100—240V AC Adapter
Windshield Suck Mounts bracket
Package
7V1 Hardware Instruction Manual

12
5. With reference to environmental
protection
Packing materials are raw materials and can be used again.
Keep packing materials separate. For more information about recycling
contact your local administration.
Old devices do not belong in the domestic refuse!
Dispose of old devices responsibly, and contribute to environmental
protection.
Your local administration will inform you about collecting points and opening
times.
Old batteries do not belong in the domestic refuse!
Dispose of old batteries accordingly and contribute to environmental
protection. Your local administration will inform you about collecting points
and opening times.
