INVISIBLE FENCE Indoor Micro Shields User manual

Indoor Micro Shields® Unit
My Invisible Fence® Brand Dealer:
Name:
Phone:
InvisibleFence.com | 800-578-3647
Owner’s Manual and Operating Guide

2
InvisibleFence.com
Important Precautions
• Invisible Fence®Brand pet containment systems have contained over three million pets. However, there are some
precautions you should take.
• Read and retain manuals: Read the entire Owner’s Manual before using your new Indoor Micro Shields® Solution.
• Adhere to all warnings and cautions contained in any Invisible Fence®Brand manual.
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible injury or death.
indicates a hazardous situation which, if not avoided, could result in death or serious injury.
used with the safety alert symbol, indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury
used without the safety alert symbol, indicates a hazardous situation which, if not avoided,
could result in harm to your pet.
is used to address safe use practices not related to personal injury.
WARNING
• Not every pet can be trained to avoid the established boundary. Sometimes even a properly trained pet may
cross the boundary. Therefore, Invisible Fence, Inc., as well as Invisible Fence®Distributors and Dealers, cannot
guarantee the system will, in all cases, keep a customer’s pet within the established boundary. Accordingly, if a
customer has reason to believe that their pet may pose a danger to others, or harm itself, the customer should
not rely solely upon the Invisible Fence®Brand pet containment system to keep the pet from crossing the
boundary.
• Do not install, connect, or remove your system during a lightning storm. If the storm is close enough for you to
hear thunder, it is close enough to create hazardous surges.
CAUTION
• Read and follow the important instructions on how to avoid pressure necrosis in your Invisible Fence Brand
Computer Collar®Unit manual.
• Train your pet according to the instructions in the Invisible Fence Brand training manuals. Complete all steps
before allowing your pet to run free. Do not become overly confident if your pet has become conditioned to the
Invisible Fence Brand pet containment system sooner than expected.
• Important: To ensure your pet does not receive an unintended correction, make sure your pet is not wearing the
Computer Collar unit when turning ON or adjusting the Indoor Micro Shields transmitter.
• Check the Invisible Fence Brand transmitter periodically to make sure it is operating properly. To do this, simply
bring the Computer Collar Unit to the edge of the containment field to verify function.
• The transmitter has visual and audible signals to warn of a system malfunction. The transmitter should be
installed where such signals may be easily seen and heard. If the transmitter is installed by the customer in an
enclosed box, or in a place not readily accessible to the customer, the customer will not benefit from the system’s
warning functions, for which Invisible Fence, Inc., as well as Invisible Fence Distributors and Dealers, assume no
responsibility.
• Do not attempt to service any Invisible Fence Brand equipment. Refer all service to your authorized Invisible
Fence Brand Dealer. Only your authorized Invisible Fence Brand Dealer should make adjustments to your pet
containment system.
• All Invisible Fence Brand pet containment systems are designed for domesticated animal use only. Never attempt
to use this product for any purpose not specifically described in this manual.
• The Indoor Micro Shields solution gives you control over the areas a pet or pets have access to inside your home.
It is designed to work independently or to complement your Invisible Fence® Brand 800 Series and/or Boundary
Plus® digital electronic pet containment system. The Indoor Micro Shields transmitter is designed for indoor use
only. For information on or about Outdoor Shields® products, please contact your local Invisible Fence Brand
dealer or visit us at www.invisiblefence.com. This device is not designed to operate as a containment transmitter.

3
InvisibleFence.com
Table of Contents
Important Precautions ........................................................................................................................................................2
Components .......................................................................................................................................................................... 4
How the System Works ..................................................................................................................................................... 4
Operating Guide................................................................................................................................................................5-7
Charging..................................................................................................................................................................... 5
Turning On and O ................................................................................................................................................ 5
Adjust Signal Field Range ................................................................................................................................... 6
Verify Signal Field Range..................................................................................................................................... 6
Changing the Channel Setting on the Indoor Micro Shields® Transmitter........................................ 6
Multi Area Avoidance .............................................................................................................................................7
Troubleshooting ................................................................................................................................................................... 8
Battery Disposal ................................................................................................................................................................... 9
Perchlorate Battery............................................................................................................................................................. 9
Important Recycling Advice............................................................................................................................................ 9
Compliance............................................................................................................................................................................. 9
Congratulations on your purchase of the Indoor Micro Shields® Plus. Please read and review this entire
manual to become familiar with Indoor Shields Plus solution components and its operation. It is strongly
recommended you review this information before using the product.

4
InvisibleFence.com
How the System Works
Indoor Micro Shields® Transmitter
The transmitter is the heart of the system. It is
placed in areas you want to protect from your
pet, or protect your pet from. The lightweight,
portable design is easy to use and powered
by a rechargeable battery pack. You may use
the included AC adapter for locations near an
electrical outlet. The AC adapter is also used for
charging the transmitter. The transmitter sends
a signal field up to 4 feet in diameter or as a 2
foot radius. Your pet wears a Computer Collar®
unit that detects areas you have protected and
delivers a correction when your pet enters those areas.
The Transmitter has Three Control Buttons:
• Two for controlling the signal field range (RANGE UP & RANGE DOWN). These buttons also
control power ON and OFF during normal use.
• One for use when programming the Computer Collar unit to the Indoor Micro Shields
transmitter. The LCD display shows the signal field range and Channel A, Channel B, or
Channels A and B mode.
AC Adapter
The AC adapter (RAC00-13701) is intended for long-term use or for recharging the Micro Shields®
transmitter. Use the AC adapter to charge the battery pack for a minimum of 4 hours prior to first use.
Note: A correction is a training term used to describe an action taken to discourage unwanted pet
behavior. The Computer Collar unit delivers a correction when your pet enters a protected area or
crosses the boundary of an Invisible Fence Brand system.

5
InvisibleFence.com
Operating Guide
Important: To ensure your pet does not receive an unintended correction, make sure your pet is not wearing
the Computer Collar® unit when turning ON or adjusting the Indoor Micro Shields® transmitter.
1. Charge the Indoor Micro Shields® Transmitter
• Lift the rubber cover protecting the charging jack located on the Indoor Micro Shields transmitter.
Connect the charger connector to the charging jack with the marked side facing up.
• Plug the AC adaptor (RAC00-13701) into a standard 120 volt wall outlet
• Allow the unit to charge a full 4 hours before initial use and after prolonged storage. A charge time of
2 hours is required after the initial charge for normal charging.
• When charging is complete remove the charger connector and replace the rubber cover.
• Battery life of approximately 30 days can be expected from a fully charged battery.
Note: Ensure the charger connector is inserted correctly into the Indoor Micro Shields® transmitter.
Insert the charger connector with the marked end of the plug facing up. If the charger connector is
plugged in backwards it could permanently damage the Indoor Micro Shields® transmitter and will no
longer work.
2. Turning On and O
• Turn on by pressing RANGE UP (+) button.
• Turn o by pressing RANGE DOWN (-) button until LCD no longer displays signal field range.
Indoor Micro Shields®
Transmitter
Rubber Cover
Charger Connector
Illustration A

6
InvisibleFence.com
3. Adjust Signal Field Range
• Determine the desired location and the signal field range required (10 in/5 cm minimum radius up to
2ft/.61 m maximum radius)
• With the unit ON, press the RANGE UP (+) or the RANGE DOWN (-) buttons to increase or decrease
the signal field range. The first segment of the range indicator equals 10 in / 25 cm radius of signal
field. Each additional segment represents approximately 3 in / 8 cm radius of range.
• Once the range is set, place the Indoor Micro Shields® transmitter in the desired area.
2. Verify Signal Field Range
• Turn the Indoor Micro Shields transmitter ON.
• Holding the Computer Collar® unit at the height of your pet’s neck, start outside the range and move
slowly towards the Indoor Micro Shields transmitter. Do not touch the correction posts at this time.
• The Computer Collar unit will beep as it approaches the outer range of the signal field width set in Step
2. The beeping will be accompanied by a correction.
• If the Computer Collar unit fails to beep, see the troubleshooting chart found on page 10.
• Adjust range and/or relocate the Indoor Micro Shields transmitter until desired area is protected.
3. Changing the Channel Setting on the Indoor Shields® Plus Transmitter
1. Press and release the RANGE DOWN (-) button until no bars appear on the LCD.
2. Turn the unit over and remove the bottom lid by rotating counter-clockwise.
3. Locate the switch for the Channel (A), Channel (B)
and Channels (A+B).
4. Select the desired setting. Note: The Indoor
Micro Shields transmitter will not
enter into programming mode if this switch is
set to A+B. See Programming Computer Collar
unit on page 8.
5. Replace the bottom and turn clockwise until
the lid stops.
Note: Ensure the O-ring is in the top housing and seated in the
channel before replacing the bottom lid. Failure to do so may
allow moisture leakage and possible failure of the device.
(Figure 1)
Figure 1:

7
InvisibleFence.com
MULTI-AREA AVOIDANCE
Your Indoor Micro Shields® Transmitter and the Computer Collar® unit are preset to operate on
Channel A (CH.A). For homes with two or more pets, this setting is usually sucient as long as
all pets are required to avoid the same protected areas like keeping all pets away from the trash,
o the counter tops o the sofa, etc. In some multi-pet homes, it may be desired to allow one pet
access to an area while denying access to another pet.
• When set to Channel A (CH.A), the Indoor Micro Shields® transmitter denies access to pets wearing a
Computer Collar unit programmed to Channel A. (Channel A is the default setting for the Computer
Collar unit.)
• When set to Channel B (CH.B), the Indoor Micro Shields transmitter denies access to pets wearing a
Computer Collar unit programmed to Channel B.
• When set to Channel A-B (CH. A and CH.B), the Indoor Micro Shields transmitter denies access to all
pets wearing a Computer Collar unit.
Programming the Computer Collar® Unit
1. Prior to programming ensure all Computer Collar
units are removed from pets and are at least 3 feet
from the Indoor Micro Shields transmitter.
2. Follow procedure above, Changing the Channel
Setting on the Indoor Micro Shields Transmitter, to
select Channel A or Channel B for programing into
the Computer Collar unit. Note: The Indoor Micro
Shields transmitter will not enter into programming
mode if this switch is set to A+B. Turn the unit back
over and set it down on a flat surface.
3. Press and hold the PROGRAM button while lowering the Computer Collar unit from directly above
the Indoor Micro Shields transmitter.
4. Stop lowering when the Computer Collar unit begins to flicker yellow and release the PROGRAM
button on the transmitter when the Computer Collar unit begins to flash green.
5. The Computer Collar unit is now programmed to the desired channel.
6. Verify operation by turning ON the Indoor Micro Shields transmitter and listening for the Computer
Collar unit activation.
Note: Make sure any Computer Collar units you do not wish to program are more than 3 feet from the
Indoor Micro Shields transmitter or have the Power Cap® Battery removed. Do not perform this procedure
while the Computer Collar Unit is on a pet.

8
InvisibleFence.com
Troubleshooting
Need additional help? Contact your local Invisible Fence® Brand dealer. Call 1-800-578-3647
or visit www.InvisibleFence.com to find your local dealer.
INDOOR MICRO SHIELDS® TRANSMITTER DOES NOT APPEAR TO WORK
• Check for low battery (audible chirp once every 10 seconds and flashing LCD). If low battery is
indicated, plug the AC adapter into the unit and charge for 2 hours.
• Check/replace the Power Cap® Battery in the Computer Collar® unit.
• The Indoor Micro Shields® transmitter power could be completely drained. Apply power to the Indoor
Shields® Plus transmitter using the AC adapter to verify operation.
• If using AC adapter for power, check connections.
• Check the Computer Collar unit fit to ensure posts have direct skin contact.
• Ensure the Computer Collar unit is programmed properly to the Indoor Micro Shields® transmitter.
LCD IS BLACK
• Operating the Micro Shields transmitter in direct sunlight may cause the LCD to overheat and turn
completely black. The LCD will return to normal when the temperature drops below 150ºF/65ºC.
Operating the transmitter when the LCD is black will not damage the device.
RANGE IS TOO LOW OR TOO HIGH
• Check for low battery (audible chirp once every 30 seconds and flashing LCD). If low battery is
indicated, plug the AC adapter into the unit and charge for 2 hours.
• Adjust the Indoor Micro Shields transmitter to increase/decrease signal field range. See Step 3 on
page 7 (Adjust signal field range).
• Metal objects may distort the transmitter’s range. Consider alternate location for the Indoor Micro
Shields transmitter.
COMPUTER COLLAR® UNIT DOES NOT SEEM TO DETER PET
• Check/replace the Power Cap Battery in the Computer Collar unit.
• Check the signal field range on the Indoor Micro Shields transmitter.
• Ensure the training posts are removed from the Computer Collar® unit after training.
COMPUTER COLLAR® UNIT FAILS TO SOUND WARNING BEEP
• Check/replace the Power Cap Battery in the Computer Collar unit.
• Ensure the Computer Collar unit is set to same Indoor Micro Shields® transmitter CHANNEL setting.
See Multi-Area Shielding Section on page 8.

9
InvisibleFence.com
Battery Disposal
Separate collection of spent batteries is required in
many regions; check the regulations in your area be-
fore discarding spent batteries. The Computer Collar®
unit operates on one (1) Lithium (Li-MnO2) battery
with a 3 Volt, 160 mAh capacity, replace only with
equivalent battery that may be obtained from your In-
visible Fence® Brand dealer. The transmitter operates
on 1 rechargeable Lithium Ion Polymer (Li-ion) battery
pack with a 3.7 Volt, 420 mAh capacity.
Perchlorate Battery
Perchlorate Material – special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Important Recycling Advice
Please respect the Waste Electrical and Electronic
Equipment regulations in your country. This
equipment must be recycled. If you no longer
require this equipment, do not place it in the normal
municipal waste system. Please return it to where it
was purchased so it can be placed in our recycling
system. If this is not possible, please contact your
Invisible Fence®Brand Dealer.
Compliance
US and Canada
FCC ID: KE3-3002563
IC: 2721A-3002563
This device complies with Industry Canada rules.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Le présent appareil est conforme aux CNR
d’Industrie Canada applicables aux appareils radio
exempts de licence. Cet appareil est conforme
à la partie 15 des régles FCC. L’exploitation est
autorisée aux deux conditions suivantes : (1)
l’appareil ne doit pas produire de brouillage, et (2)
l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
Modification or changes to this equipment not expressly
approved by Radio Systems Corporation® may void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not
occur in a specific installation. If interference does
occur to radio or television reception, which can be
determined by turning the equipment o and on, the
user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and the Computer Collar® unit.
• Connect the equipment to an outlet on a circuit
dierent from that to which the Computer
Collar® unit is connected.
• Consult the dealer, or an experienced radio/TV
technician for help.
This Class B digital apparatus complies with
Canadian RSS-210.
Cet appareil numérique de la classe B est conforme
à la norme NMB-003 du Canada.
European Union
Radio Systems Corporation® declares under its own
responsibility, that the following product(s) is (are)
in compliance with the essential requirements under
article 3 of the RED (2014/53/EU) and the RoHS
2 Directive (EU) 2015/863. Unauthorised changes
or modifications to the equipment that are not
approved by Radio Systems Corporation may violate
EU RED regulations, could void the user’s authority
to operate the equipment, and will void the warranty.
Hereby, Radio Systems Corporation®, declares
that this part is in compliance with the essential
requirements and other relevant provisions.

10
InvisibleFence.com
800-578-3647 (USA)
865-777-5404 (International)
400-1662-2
©2019 Radio Systems Corporation®
All rights reserved.
Protected by Patents:
U.S.: 7,046,152, 7,068,174, 7,117,822, 7,204,204,
7,278,376, 7,495,570 and 8,342,135
