Invisipure Luna IP-5025 User manual

READ AND SAVE THESE INSTRUCTIONS WARNINGS
InvisiPure Luna
with Magnetic Suspension Technology
& Touch Controls
Model IP-5025
WARRANTY & SERVICE
We guarantee the unit to be free from defects in material or workmanship for a period of
one (1) year from the date of purchase.
Operating this unit with an adapter other than the one supplied or any attempts made to
service or modify the unit, will VOID THE WARRANTY.
For your convenience, please record the complete model number and the date
of purchase below, and attach your receipt as proof of purchase.
Serial No.:____________________________________________
Date of Purchase: ______________________________________
Name and address of Purchaser: __________________________
____________________________________________________
____________________________________________________
Telephone: ___________________________________________
Attach your purchase receipt here

Failure to comply with the warnings listed below may result in electric shock
or serious injury.
This product should be used only in accordance with the specifications outlined in
this manual. Usage other than what has been specified here may result in serious
injury.
● Disassembly repair or remodelling by an unauthorized person may result in serious harm and
will void the manufacturer’s warranty.
● Always place this humidifier on a firm, flat, & level surface. This humidifier may not work properly
on an uneven surface.
● Do not place this product on soft surfaces that may block the air inlet.
● This product releases mist. Do not place this humidifier directly on wood furniture, flooring, or
any surface that can be damaged by water. Manufacturer does not accept any liability for
damage caused by improper placement.
● Do not use if the plug is damaged or loose.
● Before filling or cleaning the unit, make sure it is unplugged.
● Once the humidifier has been plugged in, do not tilt or move the unit.
● Do not remove the water tank from the unit while it is on.
● Do not handle the plug with wet hands.
● Do not excessively bend, twist, pull, or damage the power cord.
● Avoid placing this product where the outlet is pointed directly at an object or person.
● Do not directly inhale the mist expelled from the product or drink water from the tank.
● Do not fill the water tank with hot or boiling water.
● Do not use this product in direct sunlight or near a heat source such as a stove, heater, or radiator.
● If the water tank becomes cracked or damaged, do not use.
● Do not keep this product running for an extended period of time.
● Unplug the cord when unit is not in use for an extended period of time and/or when no one
is home.
● Do not keep water in the tank when not in use for an extended period of time.
READ AND SAVE THESE INSTRUCTIONS WARNINGS
Failure to comply with the warnings listed below may result in electric shock or
serious injury.
• Do not clean the unit, water tank, or water reservoir with detergents or chemicals of any kind.
• The use of water additives including detergents, cleaning chemicals, water conditioners, etc. will
damage the appliance materials. Any use of such additives will void the manufactures warranty.
• Do not use this product near any other electronic device.
• Do not cover the spray spout at any time during use. Do not put anything on or in the tank.
• IMPORTANT: Neither humans nor animals can hear the high frequency vibrations.
• When unplugging from an outlet, hold humidifier securely.
• Do not place cord over objects.
• Do not get water in or on the power cord or where it connects to the product. Do not use near a sink.
• Do not touch the water tank during operation.
• Do not submerse the unit in water or pour water on the unit or in the mist outlet.
• When emptying water from water tank, pour on drain side.
• Do not cover the outlet with cloth or hand and do not use without the outlet in place.
• Use clean or distilled water in tank. Hard water will require more frequent cleaning.
E-1 E-2

PRODUCT SPECIFICATIONS AND PARTS
SPECIFICATIONS
MODEL NUMBER: CF-5025
NAME: InvisiPure Luna Top Fill Ultrasonic Cool Mist with Magnetic Suspension Technology
POWER SUPPLY: 120V, 50Hz-60Hz
POWER CONSUMPTION: 25W
TANK CAPACITY: 78oz / 2.3L
MOISTURE OUTPUT: 6.75oz/h / 200ml/h
DIMENSIONS: 7.95” x 7.95” x 10” / 202mm x 202mm x 256 mm
SET UP
Select a firm, level, and flat location at least six inches away from any wall or object for proper air
flow. Place the humidifier on a water-resistant surface, as water can damage furniture and some
flooring. Do not place unit directly on carpet, towels, blankets, or other absorbent surfaces.
We will not accept responsibility for damage caused by water spillage.
FILLING
Make sure unit is unplugged.
DIRECTIONS FOR USE
PARTS
Mist Outlet
Tank
Tank Lid
Mist Tube
Ultrasonic Disk
E-3
E-4
Control Panel
Filter
1. Remove top cover 2. Pour cool, clean water directly into the tank.
Make sure water does not drop into Mist Tube, it is
very important to ensure water is fed from tank to
basin naturally. Finally, place top cover back and turn
the air humidifier on.
Brush
Dry Air Exhaust
Base

A) Power ON/OFF
Press the power button A to turn the air humidifier ON. The power indicator A will light in blue to
indicate the unit is ON. The unit will turn on with medium mist output, night light OFF and timer
OFF. Press the power button A to turn air humidifier OFF.
Low water auto shut off
When the unit is low on water, the power indicator light A turns red and the unit including night
light will turn off.
Low water shut off condition
If the unit is low on water for over 20 seconds, you will need to refill the tank and press the power
button A to turn the humidifier off and then turn it ON again to resume mist output.
B) Night Light
For your convenience, the night light can be controlled separately even when the humidifier is not
in use. At any time, press the night light button B and the night light will light up. If the power
button A is pressed, it will turn all functions OFF including the night light.
1st press: circle through all 7 colors automatically
2nd press: Blue
3rd press: Green
4th press: Yellow
5th press: Red
6th press: Purple
7th press: Pink
8th press: Orange
9th press: Night light will turn off with two beeps
C) Timer
The machine will automatically stop operation after reaching the timer settings below:
1st press: 4 hours and the indicator will light up in blue.
2nd press: 8 hours and the indicator will light up in blue.
3rd press: 12 hours, the both indicators above the 4H and 8H will light up in blue.
D) Mist Volume
When the power is on, the unit will default to the medium mist output.
1st press: high mist output.
2nd press: low mist output.
FUNCTIONS AND FEATURES
E-5
E-6
Indicator
B
C A D

CLEANING
Always unplug the unit before servicing in any way.
GENERAL CLEANING
• Inside the base of the unit. Pour excess water out of the unit. Wash out the unit with fresh
water using the cleaning brush and a soft cloth as needed. Do not submerse the base of the
unit into water, or allow water to enter inside the dry air exhaust port of the unit.
• Water tank. Empty water tank. Remove top cover and clean the inside of the tank with fresh
water and vinegar solution or dishwashing liquid using a cloth or brush (a bottle cleaning brush is
recommended). Rinse after cleaning with fresh water.
• Outer surface of the unit. Wipe the surface of the unit with a soft, damp cloth if needed. If
you notice an accumulation of water during usage, reduce humidity and dry outer surface with
a cloth.
DESCALING
• Depending on usage and water type, cleaning to remove scale may be required
weekly or every other week to optimize unit performance.
• If you live in a hard water area, we recommend the use of distilled water for your
humidifier. This will help reduce the precipitation of minerals or ‘white dust’.
ULTRASONIC DISK
1. Unplug unit.
2. Remove the tank and empty all water from unit base and tank.
3. Locate the ultrasonic disk on the inside center of the base unit.
4. Use ONLY the enclosed cleaning brush to gently clean disk and remove build up and deposits.
Do not scrub or scrape the ultrasonic disk.
2. Flip over water tank and open the tank
lid, turning it to the left. Remove the filter.
*Clean the disk with the
brush only. No other
cleaning tool should be
used. BRUSH ONLY.
Ultrasonic Disk
•Do not clean the unit or water tank with
cleaning chemicals of any kind as they may
contain bleach. Use dish washing liquid or
vinegar solution ONLY.
5. Attach tank to base of unit.
6. Before turning on make sure there is water in the unit.
4. Close the tank lid, turning it to the right.
It is important to FIRMLY secure cap
before filling the tank with water.
3. Clean filter’s inner surface which
may accumulate large particles.
After cleaning, assemble it back to
tank cap.
E-8
E-7
1. Separate the tank from the base
of unit and pour out water in tank.
Brush
*Drain water in the base
according to the drainage
direction. Make sure
water doesn’t go into the
Dry Air Exhaust.

CLEANING
If scale becomes difficult to remove with brush:
1. Fill the Base with: mixture of 1 tsp. white vinegar and 1 tsp. Water.
2. Let solution stand for 5 minutes.
3. With the vinegar in the Base, clean all interior surfaces with a soft cloth or brush to help
remove scale.
4. Also check mist outlet, filter, and mist tube in water tank. Clean as needed.
5. Rinse the base thoroughly with water to remove scale and vinegar solution.
END OF SEASON STORAGE
• Follow the cleaning and descaling instructions when the humidifier will be stored away for an
extended period of time.
• Dry the humidifier completely before storing. DO NOT store with water inside the base or
water tank.
• Pack the unit in its original carton and store in a cool, dry location.
NOTE: IF YOU EXPERIENCE A PROBLEM DO NOT ATTEMPT TO OPEN THE MOTOR
HOUSING YOURSELF. DOING SO MAY VOID YOUR WARRANTY AND CAUSE DAMAGE
TO THE HUMIDIFIER OR PERSONAL INJURY.
TROUBLESHOOTING GUIDE
PROBLEM SOLUTION
Mist is
not produced.
P
ower plug: Unplug and
plug in again,
then try again.
Power Failure: When the power has returned, try again.
Tank Installation: Make sure the tank is correctly attached.
The surface of the ultrasonic disk is dirty: Clean ultrasonic
disk.
Air blows but water vapor is
not produced.
Excessive Water: Remove
water from
the
bas
e
.
Detergent residue and/or oil ingredients may be in tank or
filter; wash out tank, filter and try again.
The surface of the ultrasonic disk is dirty: Clean ultrasonic
disk.
If you use hard water, replace with softer water.
Humidity level is low.
The surface of the ultrasonic disk is dirty: Clean ultrasonic
disk.
The water in the unit is too cold: Replace with cool, but not
cold water.
The humidity has a bad
smell.
Poor maintenance or dirty water: Clean the product
thoroughly, and fill it with fresh water.
White dust is forming on
nearby furniture.
Hard
water may deposit a certain
amount
of dust. Dust in the
air also settles because of added humidity in the room. Use
distilled water if this becomes a problem.
Unit has stopped working.
No or low water. Unplug unit and refil
l
tank.
Water is accumulating
outside of unit or area
surrounding unit.
Lower mist contr
ol setting.
Unit
is not level, unplug and place
on level surface. Point outlet away from objects. Raise unit on
a water-resistant level surface 2-3 feet off of floor.
Water dripping when
refilling.
Water remaining on bottom of tank. Wipe tank or tilt to d
rain
before transporting.
Increased noise level.
Unit must be placed on a flat, level,
and firm
surface. Make
sure it is NOT placed on a soft or absorbent surface.
Red light on power dial.
Indicates low water. Unplug and refill tank.
E
-
9
E-10
