INVT Goodrive18 Series User manual

Goodrive18 series two-in-one VFD Change history
No.
Change description
Version
Release date
1.
First release
V1.0
October 2019

Goodrive18 series two-in-one VFD Contents
i
Contents
Contents....................................................................................................................................i
1Safety Precautions ......................................................................................................1
1.1 Safety definition .......................................................................................................1
1.2 Warning symbols......................................................................................................1
1.3 Safety guidelines......................................................................................................2
1.3.1 Delivery and installation...............................................................................2
1.3.2 Commissioning and running.........................................................................3
1.3.3 Maintenance and component replacement..................................................3
1.3.4 Disposal of a scrap VFD...............................................................................3
2Product overview.........................................................................................................4
2.1 Quick startup............................................................................................................4
2.1.1 Unpacking inspection...................................................................................4
2.1.2 Checking before applying.............................................................................4
2.1.3 Environment.................................................................................................4
2.1.4 Installation confirmation................................................................................5
2.1.5 Basic commissioning....................................................................................5
2.2 Product specifications..............................................................................................6
2.3 Product nameplate...................................................................................................8
2.4 Model designation code...........................................................................................8
2.5 Product ratings.........................................................................................................9
2.6 Structural diagram....................................................................................................9
3Installing.....................................................................................................................11
3.1 Mechanical installation...........................................................................................11
3.1.1 Installation environment .............................................................................11
3.1.2 Installation direction....................................................................................12
3.1.3 Installation methods ...................................................................................12
3.1.4 Main circuit wiring diagram.........................................................................13
3.1.5 Main circuit terminal diagram .....................................................................14
3.1.6 Wiring the main circuit terminals ................................................................14
3.1.7 Control circuit wiring diagram.....................................................................15
3.1.8 Control circuit terminal diagram .................................................................15
3.1.9 Input/output signal connection diagram .....................................................17
3.2 Wiring protection....................................................................................................19
3.2.1 Protecting the VFD and input power cable in short circuit .........................19
3.2.2 Protecting the motor and motor cable........................................................19
3.2.3 Bypass connection.....................................................................................19
4Operating....................................................................................................................21
4.1 Keypad introduction ...............................................................................................21
4.2 Keypad display.......................................................................................................23
4.2.1 Displaying stopped-state parameters.........................................................23
4.2.2 Displaying running-state parameters .........................................................24
4.2.3 Displaying fault information........................................................................24
4.2.4 Editing function codes................................................................................24
4.3 Operations on the keypad......................................................................................25
4.3.1 How to switch between the P and F function groups .................................25
4.3.2 How to modify VFD function codes............................................................25

Goodrive18 series two-in-one VFD Contents
ii
4.3.3 How to set the VFD user password............................................................26
4.3.4 Viewing VFD status....................................................................................26
4.3.5 How to copy function parameters...............................................................27
5Function parameters and function terminal reuse.................................................28
5.1 Function parameter list ..........................................................................................28
5.2 Function terminal reuse .........................................................................................97
6Troubleshooting.........................................................................................................98
6.1 Fault prevention .....................................................................................................98
6.1.1 Periodical maintenance..............................................................................98
6.1.2Cooling fan...............................................................................................101
6.1.3 Capacitor..................................................................................................102
6.1.4 Power cable..............................................................................................103
6.2 Fault handling ......................................................................................................104
6.2.1 Alarm and fault indication.........................................................................104
6.2.2 Fault reset ................................................................................................104
6.2.3 Faults and solutions .................................................................................104
6.2.4 Other status..............................................................................................109
7Communication........................................................................................................110
7.1 Modbus protocol introduction...............................................................................110
7.2 Application to the VFD .........................................................................................110
7.2.1 Two-wire RS485....................................................................................... 111
7.2.2 RTU mode................................................................................................113
7.2.3 ASCII mode..............................................................................................117
7.3 Command codes and communication data .........................................................119
7.3.1 RTU mode................................................................................................119
7.3.2 ASCII mode..............................................................................................123
7.4 Data address definition........................................................................................126
7.4.1 Function code address format rules.........................................................126
7.4.2 Address description of other function codes ............................................127
7.4.3 Fieldbus scale ..........................................................................................131
7.4.4 Error messages........................................................................................132
7.5 Reading and writing examples.............................................................................134
7.5.1 Example of reading command 03H..........................................................134
7.5.2 Example of writing command 06H ...........................................................135
7.5.3 Example of continuous writing command 10H.........................................137
7.6 Common communication faults............................................................................139
Appendix A Technical data.........................................................................................140
A.1 Derated application......................................................................................................140
A.1.1 Capacity............................................................................................................140
A.1.2 Derating............................................................................................................140
A.2 CE................................................................................................................................141
A.2.1 CE marking.......................................................................................................141
A.2.2 EMC compliance declaration............................................................................141
A.3 EMC regulations..........................................................................................................141
Appendix B Dimensional drawing.............................................................................143
Appendix C Optional peripheral accessories...........................................................144
C.1 Wiring of peripheral accessories.................................................................................144
C.2 Power supply...............................................................................................................145
C.3 Cables.........................................................................................................................146

Goodrive18 series two-in-one VFD Contents
iii
C.3.1 Power cables....................................................................................................146
C.3.2 Control cables ..................................................................................................146
C.4 Breaker and electromagnetic contactor ......................................................................148
C.5 Reactors......................................................................................................................148
C.6 Filters...........................................................................................................................149
C.6.1 C3 filter model..................................................................................................149
C.6.2 C3 filter model selection...................................................................................150
Appendix D Further information................................................................................151
D.1 Product and service queries........................................................................................151
D.2 Feedback on INVT VFD manuals................................................................................151
D.3 Documents on the Internet..........................................................................................151

Goodrive18 series two-in-one VFD Safety Precautions
-1-
1 Safety Precautions
Read the manual carefully before moving, installing, running and servicing the
variable-frequency drive (VFD), and follow all safety precautions contained. Otherwise, device
damage or personal injury or even death can result.
We are not liable or responsible for any device damage or personal injury or death caused by
you or your customers due to your ignorance of the safety precautions.
1.1 Safety definition
Danger:Severe personal injury or even death can result if related requirements are not
followed.
Warning:Personal injury or device damage can result if related requirements are not
followed.
Note:Actions taken to ensure proper running.
Qualified electricians:People working on the device must have received professional
electrical and safety training and obtained the certificates, and must be familiar with all steps
and requirements of device installing, commissioning, running and maintaining and capable to
prevent any emergencies.
1.2 Warning symbols
Warnings caution you about conditions that can result in severe injury or death and/or device
damage and advice on how to prevent dangers. The following table lists the warning symbols
in this manual.
Symbol
Name
Description
Abbreviation
Danger
Danger
Severe personal injury or even
death can result if related
requirements are not followed.
Warning
Warning
Personal injury or device damage
can result if related requirements
are not followed.
Do not
Electrostatic
discharge
PCBA board damage can result if
related requirements are not
followed.
Hot sides
Hot sides
The VFD base may be hot. Do not
touch.
Note
Note
Actions to ensure proper running.
Note

Goodrive18 series two-in-one VFD Safety Precautions
-2-
1.3 Safety guidelines
Only trained and qualified electricians can operate on the device.
Do not perform any wiring, inspection, or component changing when power is
applied. Ensure all input power supplies are disconnected before wiring or
checking, and always wait at least the time designated on the VFD or until the
DC bus voltage is less than 36V. The following table lists the waiting time.
VFD model
Minimum waiting time
3PH 380V
0.75kW–7.5kW
5 minutes
Do not refit the VFD unless authorized; otherwise, fire, electric shock or other
injuries may result.
The heat sink base may become hot during running. Do not touch it;
otherwise, burns may result.
The electronic components inside the VFD are electrostatic sensitive. Take
measurements to avoid electrostatic discharge during related operation.
1.3.1 Delivery and installation
Install the VFD on fire-retardant material and keep the VFD away from
combustible materials.
Do not run a damaged or incomplete VFD.
Do not touch the VFD with wet items or body parts; otherwise, electric
shock may result.
Select appropriate tools for delivery and installation to ensure proper VFD running and
prevent accidents. To ensure physical safety, take mechanical protective measures such
as wearing safety shoes and working uniforms.
Do not carry the VFD only by its front cover as the cover may fall off.
Ensure to avoid physical shock or vibration during delivery and installation.
Install the VFD far away from children and other public places.
Note that the VFD cannot meet the low voltage protection requirements in IEC61800-5-1
if the installation site altitude exceeds 2000 meters.
As leakage current during VFD running may exceed 3.5mA, apply reliable grounding and
ensure ground resistance is less than 10Ω. The PE ground conductor and phase
conductor have equal conductivity capability. For the models of 30kW or higher, the cross
section of the PE ground conductor can be slightly less than the recommended area.
R, S, T/L, and N are the power input terminals, while U1/U2, V1/V2, and W1/W2 are
output terminals for motors. Connect the input power cables and motor cables properly;
otherwise, VFD damage to may result.

Goodrive18 series two-in-one VFD Safety Precautions
-3-
1.3.2 Commissioning and running
Disconnect all power sources applied to the VFD before terminal wiring,
and wait for at least the time designated on the VFD after disconnecting
the power sources.
High voltage presents inside the VFD during running. Do not carry out
any operation on the VFD during running except for keypad setup.
The VFD may start up by itself when P01.21 (restart after power down) is
set to 1. Do not get close to the VFD and motor.
The VFD cannot be used as "Emergency-stop device". The VFD can act
as an emergency brake for the motor only after being install with a
mechanical brake device.
Do not switch on or switch off input power sources of the VFD frequently.
For VFDs that have been stored for a long time, set the capacitance and carry out inspection
and pilot run on the VFD before use.
Close the front cover before VFD running; otherwise, electric shock may occur.
1.3.3 Maintenance and component replacement
Only well-trained and qualified professionals are allowed to perform
maintenance, inspection, and component replacement on the VFD.
Disconnect all the power sources applied to the VFD before terminal
wiring, and wait for at least the time designated on the VFD after
disconnecting the power sources.
Take measures to prevent screws, cables and other conductive matters
from falling into the VFD during maintenance and component
replacement.
Use proper torque to tighten the screws.
Keep the VFD and its parts and components away from combustible materials during
maintenance and component replacement.
Do not carry out insulation voltage-endurance test on the VFD, or measure the control circuits
of the VFD with megameter.
1.3.4 Disposal of a scrap VFD
The VFD contains heavy metal. Dispose of a scrap VFD as industrial
waste.
When the life cycle ends, the VFD should enter the recycling system.
Dispose of it separately at an appropriate collection point instead of
placing it in the normal waste stream.

Goodrive18 series two-in-one VFD Product overview
-4-
2 Product overview
2.1 Quick startup
2.1.1 Unpacking inspection
Check the following after receiving the product.
Whether the packing box is damaged or dampened.
Whether the model identifier on the exterior surface of the packing box is consistent with
the purchased model.
Whether the interior surface of the packing box is abnormal, for example, in wet condition,
or whether the enclosure of the VFD is damaged or cracked.
Whether the VFD nameplate is consistent with the model identifier on the exterior surface
of the packing box.
Whether the accessories (including the manual and keypad) inside the packing box are
complete.
If any problems are found, contact the local dealer or INVT office.
2.1.2 Checking before applying
Check the following before applying the VFD.
Note: Do not carry out insulation voltage-endurance test on the VFD, or measure the control
circuits of the VFD with megameter.
1. Check the load type to verify that there is no overload of the VFD during work and check
whether the power class of the VFD needs to be modified.
2. Check whether the actual running current of the motor is less than the rated current of
the VFD.
3. Check whether the control accuracy required by the load is the same of the VFD.
4. Check whether the grid voltage is consistent with the rated voltage of the VFD.
2.1.3 Environment
Check the following before the actual installation and use:
1. Check whether the ambient temperature of the VFD exceeds 40°C. If it exceeds 40°C,
derate 1% for every increase of 1°C. It is not recommended to use the VFD if the ambient
temperature exceeds 50°C.
Note: For a cabinet VFD, the ambient temperature is the air temperature inside the cabinet.
2. Check whether the ambient temperature of the VFD in actual use is lower than -10°C. If
yes, use heating facilities.
Note: For a cabinet VFD, the ambient temperature is the air temperature inside the cabinet.

Goodrive18 series two-in-one VFD Product overview
-5-
3. When the altitude exceeds 1000m, derate by 1% for every increase of 100m. When the
altitude exceeds 2000m, configure an isolation transformer at the VFD input end. It is not
recommended that the VFD be used at the altitude higher than 5000m.
4. Check whether the humidity of the actual usage site exceeds 90% and condensation
occurs. If yes, take additional protective measures.
5. Check whether the actual use site may be exposed to direct sunlight or may have the
chance of ingress of foreign objects. If yes, take additional protective measures.
6. Check whether there is dust, explosive gas, or flammable gas in the actual use site. If yes,
take additional protective measures.
2.1.4 Installation confirmation
Check the following after the VFD installation:
1. Check whether the load ranges of the input power cable and motor cable meet the
actual load requirement.
2. Check whether correct accessories are selected for the VFD, the accessories are
correctly and properly installed, and the installation cables meet the requirements of all
components (including the reactor, input filter, output reactor, output filter, DC reactor,
braking unit and braking resistor).
3. Check whether the VFD is installed on non-flammable materials and the heat-radiating
accessories (such as the reactor) are away from flammable materials.
4. Check whether all control cables and power cables are run separately and the routing
complies with EMC requirement.
5. Check whether all grounding systems are properly grounded according to the
requirements of the VFD.
6. Check whether all the installation clearances of the VFD meet the requirements in the
operation manual.
7. Check whether the installation conforms to the instructions in the operation manual. It is
recommended that the VFD be installed uprightly.
8. Check whether the external connection terminals of the VFD are tightly fastened and the
torque is appropriate.
9. Check whether there are screws, cables, or other conductive items left in the VFD. If
yes, get them out.
2.1.5 Basic commissioning
Complete the basic commissioning as follows before the actual use of the VFD:
1. Autotune. If possible, de-couple the VFD from the motor load to start dynamic
autotuning. If the VFD cannot be de-coupled from the load, perform static autotuning.
2. Adjust the ACC/DEC time according to the actual work condition of the load.
3. Perform device commissioning by means of jogging and check whether the motor

Goodrive18 series two-in-one VFD Product overview
-6-
rotational direction is correct. If not, change the rotation direction by swapping any two
phase wires of the motor.
4. Set all control parameters and then operate.
2.2 Product specifications
Function
Specifications
Power input
Rated input
voltage (V)
For the -4 type: 3PH 380V(-15%)–440V(+10%)
Rated input
current (A)
See "Product ratings".
Rated
frequency
50Hz or 60Hz, allowable range: 47–63Hz
Power output
Rated motor
capacity (kW)
See "Product ratings".
Rated output
(kVA)
See "Product ratings".
Rated current
(A)
See "Product ratings".
Rated output
voltage (V)
Equal to the input voltage, with the deviation less than 5%
Rated output
frequency
(Hz)
0–400Hz
Technical
control
performance
Control mode
V/F control and sensorless vector control (SVC)
Motor type
Asynchronous motor (AM)
Speed ratio
1:100
Speed
control
accuracy
±0.2% (SVC)
Speed
fluctuation
±0.3% (SVC)
Torque
response
<20ms (SVC)
Torque
control
accuracy
10% (SVC)
Starting
torque
0.5Hz 150% (SVC)

Goodrive18 series two-in-one VFD Product overview
-7-
Function
Specifications
Overload
capacity
150% for 1min, 180% for 10s, 200% for 1s
Running
control
performance
Frequency
setting
method
Settings can be implemented through digital, analog, pulse
frequency, multi-step speed running, simple PLC, PID,
MODBUS communication, and so on.
Settings can be combined and the setting channels can be
switched.
Automatic
voltage
regulation
The output voltage can be kept constant although the grid
voltage changes.
Fault
protection
All-round protection functions, such as protection against
overcurrent, overvoltage, undervoltage, overheat, phase loss,
and overload.
External
interface
Analog input
AI2: 0–10V/0–20mA Whether the output type is voltage or
current can be selected through P05.49.
AI3: -10V–10V
AI2/AI3 min. resolution: 10mV/20mV
Analog
output
1. Output range: AO1/AO2, 0–10V/0–20mA
2. Whether the output type is voltage or current can be selected
through the control board jumper.
3. Full range deviation: ±1%, 25°C
Digital input
Eight common inputs, max. frequency 1kHz
Relay output
Two programmable relay outputs:
RO1A is NO, RO1B is NC, and RO1C is the common terminal.
RO2A is NO, RO2B is NC, and RO2C is the common terminal.
Contact capacity: 3A/AC250V
Other
Installation
method
Wall mounting
Brake unit
None
EMI filter
You can choose to use the external filter, meeting IEC61800-3
C3/C2 requirements.
Temperature
of operating
environment
-10–50°C. If the temperature exceeds 40°C, derate 1% for
every increase of 1°C.

Goodrive18 series two-in-one VFD Product overview
-8-
Function
Specifications
Altitude
When the altitude is higher than 1000m but lower than 3000m,
derate 1% for every increase of 100m.
When the altitude is higher than 2000m, configure an isolation
transformer at the VFD input end.
When the altitude is higher than 3000m but lower than 5000m,
consult INVT for technical issues.
It is not recommended that the VFD be used at the altitude
higher than 5000m.
IP rating
IP20
Pollution
class
Class 2
Safety
requirement
Compliant with CE requirements
Cooling
method
Forced air cooling
2.3 Product nameplate
IP20
Model: GD18-7R5-4-2
Power(Output1/2): 7.5kW/7.5kW
Input: AC 3PH 380V(-15%)-440V(+10%) 40A 47Hz-63Hz
Output1: AC 3PH 0-Uinput 18.5A 0Hz-400Hz
S/N: Made in China
Shenzhen INVT Electric Co.,Ltd
Output2: AC 3PH 0-Uinput 18.5A 0Hz-400Hz
Figure 2.1 Product nameplate
Note: This is a nameplate example for a standard Goodrive18 series two-in-one VFD model.
The mark such as CE/TUV/IP20 will be applied according to the actual certification situation.
2.4 Model designation code
A model designation code contains product information. You can find the model designation
code on the VFD nameplate and simplified nameplate.
GD18–7R5–
① ② ③ ④
4 2
–
Figure 2.2 Model designation code

Goodrive18 series two-in-one VFD Product overview
-9-
Field
No.
Description
Example
Abbreviation of
product series
①
Abbreviation of
product series
GD18: short for Goodrive18
Rated power
②
Power range + load
type
7R5: 7.5kW
Voltage class
③
Voltage class
4: AC 3PH 380V(-15%)–440V(+10%)
Structure
④
Number of devices
in the combination
2: Two in one, two inverting outputs
2.5 Product ratings
VFD model
Voltage
class
Output power
(kW)
Input current
(A)
Output current
(A)
GD18-0R7-4-2
3PH 380V
0.75/0.75
7
2.5/2.5
GD18-1R5-4-2
1.5/1.5
10
4.2/4.2
GD18-2R2-4-2
2.2/2.2
12
5.5/5.5
GD18-004-4-2
4/4
25
9.5/9.5
GD18-5R5-4-2
5.5/5.5
32
14/14
GD18-7R5-4-2
7.5/7.5
40
18.5/18.5
2.6 Structural diagram
The VFD structure is shown in the following figure (using the 7.5kW model as an example):

Goodrive18 series two-in-one VFD Product overview
-10-
2
4
3
1
11
10
5
6
7
8
9
Figure 2.3 Structural diagram
No.
Item
Description
1
External keypad
interface
Used to connect an external keypad.
2
External keypad
interface cover
Used to protect the external keypad interface.
3
Lower cover
Used to protect the internal components.
4
Junction box
Used to fix the cables of the main and control circuits.
5
Ventilation hole
cover
Used to prevent against the ingress of dust or water.
6
Control terminals
See "Installing".
7
Barcode label
Same as the barcode on the nameplate.
Note: The barcode identified by 7 is located in the middle
of the housing and can be seen after the cover is removed.
8
Nameplate
See "Product nameplate".
9
Main circuit terminals
See "Installing".
10
Cooling fan
See "Troubleshooting".
11
Fan cover
Used to protect the fan.

Goodrive18 series two-in-one VFD Installing
-11-
3 Installing
This chapter introduces the mechanical and electrical installations of the VFD.
Only trained and qualified professionals are allowed to carry out the
operations mentioned in this chapter. Perform operations following the
instructions presented in "Safety precautions". Ignoring the safety
precautions may result in device damage or injury or even death.
Ensure the VFD power is disconnected before installation. If the VFD
has been powered on, disconnect the VFD from the power, and wait at
least the time marked on the VFD before carrying out an operation.
VFD installation must be designed and performed according to
applicable local laws and regulations. INVT is not liable or responsible
for any installation that breaches local laws and regulations. If
recommendations given by INVT are not followed, the VFD may
experience problems that the warranty does not cover.
3.1 Mechanical installation
3.1.1 Installation environment
The VFD installation environment is essential for the VFD to run with best performance in long
terms. Install the VFD in an environment compliant with the following requirements.
Environment
Condition
Installation site
Indoor
Ambient
temperature
-10–+50°C. The air temperature change rate is less than 0.5°C/min.
When the ambient temperature exceeds 40°C, derate 1% for every
temperature increase of 1°C.
It is not recommended that the VFD be used (without load) when the
ambient temperature exceeds 50°C.
In order to ensure reliability, do not use the VFD in cases where the
temperature changes rapidly.
When the VFD is used in closed space such as a control cabinet, use
the cooling fan or air conditioner to prevent the internal temperature
from exceeding the allowed temperature.
When the temperature is too low, install an external heating device
before running the VFD that has been powered off for a long time, which
eliminates the freeze inside the VFD. Otherwise, the VFD may be
damaged.
Humidity
The relative humidity (RH) of the air is less than 90%.
Condensation is not allowed.

Goodrive18 series two-in-one VFD Installing
-12-
Environment
Condition
Storage
temperature
-40°C –+70°C. The air temperature change rate is less than 1°C/min.
Operating
environment
The installation site must be:
Away from electromagnetic radiation sources.
Away from oil mist, corrosive gases and combustible gases.
Protective from foreign materials such as metal powder, dust, oil, and
water so that the foreign materials will not fall into the VFD. (Do not
install the VFD on inflammables such as wood.)
Away from radioactive substances and combustible objects.
Away from harmful gases and liquids.
With a low salt content density.
No direct sunlight.
Altitude
When the altitude is higher than 1000m but lower than 3000m, derate by
1% for every increase of 100m.
When the altitude is higher than 2000m, configure an isolation
transformer at the VFD input end.
When the altitude is higher than 3000m but lower than 5000m, consult
INVT for technical issues.
It is not recommended that the VFD be used at the altitude higher than
5000m.
Vibration
The max. vibration amplitude cannot exceed 5.8m/s2(0.6g).
Installation
direction
Install the VFD vertically to ensure good heat dissipation effect.
Note:
The VFD needs to be installed in a clean and well-ventilated environment based on the IP
rating of the VFD housing.
The cooling air must be clean enough and free from corrosive gases and conductive dust.
3.1.2 Installation direction
The VFD can be installed on the wall or in a cabinet.
The VFD must be installed vertically. Check the installation position according to following
requirements. For details about outline dimensions, see Appendix B "Dimensional drawing".
3.1.3 Installation method
Goodrive18 series 2-in-1 VFD supports wall mounting.

Goodrive18 series two-in-one VFD Installing
-13-
Figure 3.1 Installation method
Step 1 Mark the positions of the installation holes. For details about the positions, see
Appendix B "Dimensional drawing".
Step 2 Mount the screws or bolts onto the marked positions.
Step 3 Place the VFD against the wall.
Step 4 Fasten the screws on the wall.
3.1.4 Main circuit wiring diagram
R
S
T
W1
V1
U1
PE
M1
Input
reactor
Input
filter
Fuse
Output
reactor
Output
filter
380V 0.75~7.5kW
3PH power
380V(-15%)~
440V(+10%)
50/60Hz
W2
V2
U2
PE
M2
Output
reactor
Output
filter
Figure 3.2 Main circuit wiring diagram
Note: The fuse, input reactor, input filter, output reactor, and output filter are optional parts. For
details, see Appendix C "Optional peripheral accessories".

Goodrive18 series two-in-one VFD Installing
-14-
3.1.5 Main circuit terminal diagram
Figure 3.3 Main circuit terminal diagram
Terminal sign
Terminal function
R, S, T
3PH AC input terminals, connected to the grid
U1, V1, W1
First channel of 3PH AC output terminal, connected to the motor
in most cases
U2, V2, W2
Second channel of 3PH AC output terminal, connected to the
motor in most cases
Protective earthing (PE) terminal for safe protection; each device
must be proper grounded.
Note:
Do not use asymmetrical motor cables. If there is a symmetrical grounding conductor in
the motor cable besides the conductive shielded layer, ground the grounding conductor on
the VFD end and motor end.
Route the motor cable, input power cable and control cables separately.
3.1.6 Wiring the main circuit terminals
Step 1 Connect the grounding line of the input power cable to the PE terminal of the VFD,
connect the 3PH input cable to the R, S and T terminals of the VFD, and tighten up.
Step 2 Connect the grounding line of the motor cable to the PE terminal of the VFD, connect
the 3PH cable of the motor to the U1/U2, V1/V2, and W1/W2 terminals of the VFD, and
tighten up.
Step 3 If allowed, fix all the cables at the outside of the VFD mechanically.

Goodrive18 series two-in-one VFD Installing
-15-
3.1.7 Control circuit wiring diagram
(External) -10V
Shield
layer
Twisted
pair
Multifunction input terminal 1
Multifunction input terminal 2
Multifunction input terminal 3
Multifunction input terminal 4
Multifunction input terminal 5
Multifunction input terminal 6
Multifunction input terminal 7
Multifunction input terminal 8
Open collector input is optional
+10V power for frequency setting
+24V
PE
AI3 multifunction analog input
AI2
GND
PE
COM
PW
Relay 1 output
Relay 2 output
RS485
communication
Analog output
0-10V/0-20mA
Analog output
0-10V/0-20mA
S1
S2
S3
S4
S5
S6
S7
S8
AO1
GND
GND
AO2
485+
485-
GND
J5
PE
RO1A
RO1B
RO1C
RO2A
RO2B
RO2C
J6
VI
J7
V I
Voltage or current
output, set through
P05.49
Figure 3.4 Control circuit wiring diagram
3.1.8 Control circuit terminal diagram
ON
AO1 AO2 485
S1 S2 S3 S4 AI2 AI3 RO1A RO1B RO1C
RO2A RO2B RO2C
PW COM COM
AO1
485+
V V
AO2
485-
GND
S5 S6 S7 S8 +24V
+10V
Figure 3.5 Control circuit terminal diagram
