InWin RT04-01 User manual

IN WIN DEVELOPMENT
PCIe Retimer HBA
RT04-01
Supported Devices
Part Number
Description
2RAKVI003300
RT04-1 PCIe Retimer AIC
Draft Version: 0.3

History
Version
Changes
Date
0.1
First draft
2019/01/22
0.2
Added IN WIN Part Number Information
Replace PCB layout with final version
Added some more information
2019/03/25
0.3
Add the VPP usage
Replace the graphics of the layout
Adjust J7, J8, J9 location
Correct Power Consumption Information
2019/04/15

Table Of Contents
1Overview............................................................................................................................ 4
2Technical Specifications..................................................................................................... 5
3Components ...................................................................................................................... 6
3.1 Layout........................................................................................................................... 6
3.2 Connectors ................................................................................................................... 8
3.3 Jumpers ........................................................................................................................ 9
4Installation....................................................................................................................... 10
4.1 Electrostatic Discharge Sensitive (ESDS) .................................................................... 10

1Overview
The PCIe Retimer AIC is mainly designed to bridge the connections between x16 PCIe
Slot host on Motherboard to 4 x4 NVMe SSDs on backplane. Alternately, the add-in-
card supports connecting to x8 or x16 devices as PCIe signal integrator.
The link speed of the HBA can support up to PCIe Gen3 speed, says 8Gb/s.
Considering the x4 NVMe application, it provides 3.2GB/s throughput for each x4
lane NVMe device.
To facilitate 4 x4 NVMe application, the motherboards have to support PCIe
bifurcation which divides x16 slot into 4 x4.
PCIe Retimer card plays the role to re-signal the PCIe signaling between root complex
and end devices to extend the distance between root and end devices.

2 Technical Specifications
2.1 General
⚫Quad port PCI-E x16 Gen-3 Retimer
⚫Four lanes per each OCuLink port support up to 32Gbps per port
⚫Supports four physical NVMe devices
⚫Operating temperature from 10°C - 55°C
⚫Pure HBA
2.2 Dimension
⚫PCB Low Profile design
⚫6.6" x 2.71 " (L x H)
⚫1U and 2U bracket support
2.3 Power Consumption
⚫9 Watts

3Components
3.1 Layout
•TOP
•Bottom

•Physical view
•Details view

3.2 Connectors
•Connectors
Symbol
Description
J1
PCIe x16 bus
J14
NMVe0 Oculink Connector
J15
NVMe1 Oculink Connector
J16
NVMe2 Oculink Connector
J17
NVMe3 Oculink Connector
J10
VPP0
J11
VPP1

3.3 Jumpers
•Jumper settings
JN1 is used for VPP0 and VPP1 configuration. Since come of the NVMe
controller’s LED management in VPP/I2C carry 2 slots information while some
are carry 4 slots information. JN1 is designed for users to select what types of
VPP protocol will be used in the application.
JN1: 1-3, 2-4 shunted means VPP0 and VPP1 is separated. (Default)
JN1: 3-5, 4-5 shunted means VPP0 and VPP1 is paralleled.
•SMBus Address Setting
J5
J4
J3
ADDR_3
ADDR_2
ADDR_1
Default: b’111
•PCIe Mode Selection
PCIe Mode Selection (1-2)=1 (2-3)=0
Mode
J9
J8
J7
x16
1
x
x
x8x8
0
1
1
x8x4x4
0
1
0
x4x4x8
0
0
1
X4x4x4x4
0
0
0
Default: x4x4x4x4
Jumper Name
Function
J3, J4, J5
SMBus Address Configuration
J7, J8, J9
PCIe Mode Selection
JN1
VPP Bus Selector

4Installation
4.1 Electrostatic Discharge Sensitive (ESDS)
Electrostatic Discharge (ESD) might damage electronic components. To prevent
your Retimer card from being damaged, it is important to handle it with care.
The following measures are generally sufficient to protect your device from ESD.
Precautions
•Use a grounded wrist strap designed to prevent static discharge.
•Touch a grounded metal object before removing the expansion card from
the antistatic bag.
•Handle the Retimer card by its edges only. Do not touch its components or
peripheral chips.
•Put the Retimer card back into the antistatic bags when not in use.
•For grounding purposes, make sure that your system chassis provides
excellent conductivity between the power supply, the case, the mounting
fasteners and the Retimer card.
