iOCEAN OC-GYJ8022 User manual

OC-GYJ8022
8.0kg

2
Warning
CAUTION!
Read the instruction manual before
using this product!
1. WARNING: Regularly clean the lint
trap.
2. Do not place anything in front of the vent hole;
3. keep it clear of obstructions .
4. Only dry fabrics that have been cleaned in water.
5. Keep children away from the appliance during operation.
6. Do not hang anything on the appliance door.
7. Do not look into the vent when the dryer is running .
WARNING!
To avoid a fire hazard, do not dry flammable articles, or items containing foam, rubber or material on which you have
used a cleaning solvent or which contains flammable liquids or solids (such as petrol, kerosene, vegetable or cooking oils,
waxes, etc.).
1.This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or

3
instruction concerning use of the appliance in a safe way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user maintenance shall not be made by children without
supervision.
Children of less than 3 years should be kept away unless continuously supervised.
2. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
3 . This appliance is not intended for use by persons ( including children ) with reduced physical , sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety
Children should be supervised to ensure that they do not play with the appliance.
4. the tumble dryer is not to be used if industrial chemicals have been used for cleaning.
5. the lint trap has to be cleaned frequently.
6. lint must not to be allowed to accumulate around the tumble dryer.
7.adequate ventilation has to be provided to avoid the back flow of gases into the room from appliances
burning other fuels, including open fires
- Do not dry unwashed items in the tumble dryer .
- Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount
ofdetergent before being dried in the tumble dryer.
- Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber backed articles and
clothes or pillows fitted with foam rubber pads should not be dried in the tumble dryer.
- Fabric softeners , or similar products , should be used as specified by the fabric softener instructions .
- Remove all objects from pockets such as lighters and matches
9.WARNING:Never stop a tumble dryer before the end of the drying cycle unless all items are quickly
removed and spread out so that the heat is dissipated.
WARNING: The appliance must not be supplied through an external switching device, such as a timer, or
connected to a circuit that is regularly switched on and off by a utility.
10.
- for appliances with ventilation openings in the base, that a carpet must not obstruct the openings;
- that exhaust air must not be discharged into a flue which is used for exhausting fumes from appliances
burning gas or other fuels
- that the appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on
the opposite side to that of the tumble dryer, in such a way that a full opening of the tumble dryer door is
restricted.
11
-Oil-affected items can ignite spontaneously, especially when exposed to heat sources such as in a tumble
dryer. The items become warm, causing an oxidation reaction in the. oil . Oxidation creates heat . If the
heat cannot escape , the items can become hot enough to catch fire. Piling, stacking or storing oil-affected
items can prevent heat from escaping and so create a fire hazard.
- If it is unavoidable that fabrics that contain vegetable or cooking oil or have been
contaminated by hair care products be placed in a tumble dryer they should first be
washed in hot water with extra detergent - this will reduce, but not eliminate, the hazard.

4
To ensure the dryer correct and safe use, please read this manual carefully before installation
and use for the first time. In order to avoid unnecessary errors and accidents, every user
should be fully familiar with the operation and safety of the machine. Please keep this manual
properly and attach it to it when handling or reselling, so that each user can use the machine
correctly and safely.
The company will not be responsible for any failure and loss caused by non-compliance with
the installation instructions.
Danger! Electricity!
It is very dangerous not to use it or disassemble and assemble it by yourself.
Unless there is a person who knows the safety knowledge for supervision and guidance, who
is not familiar with the operation or lacks the operation knowledge and experience (including
children).
Be sure to remove hard objects such as keys, pins, coins, hairpins, and sand.
In order to prevent fire caused by excessive drying, please do not use this machine to dry the
following items: mattresses, quilts, etc. (highly sensitive items).
The following items, such as foam, waterproof clothes or down clothes, cotton cushion, pillow,
etc., cannot be dried in the dryer.
After finishing using, the power must be disconnected before cleaning and maintenance.
Under no circumstances can you repair the machine by yourself to avoid damage and
accidents. If you have any questions, please contact the local after-sales service.

5
Danger! Explosion!
After the clothes are mixed with acetone, gasoline, detergent, turpentine, wax or dewaxing
agent, detergent should be added into hot water to wash and dehydrate before being put into
the dryer for drying.
Explosion hazard: clothes containing flammable substances (such as gasoline, alcohol,
desiccant, etc.) should not be dried in the barrel, because these substances may cause
explosion.
Danger! Fire!
Don't put the clothes with oil into the dryer.
Make sure you don't leave things like matches or lighters in your clothes and put them into
the dryer.
Do not stop the machine during drying unless the clothes can be quickly taken out of the
machine to dissipate heat and prevent fire.
INSTALLATION
Please take extra care when moving the machine. Check whether the machine is damaged
when unpacking.
If you have any questions, please do not use it and contact the local after-sales service
center.
The circuit installation of the machine must be completed by qualified electricians or electrical

6
professionals.
Make sure that the rated current of the machine power supply is greater than 10A.
Do not share the plug with other high-power appliances. Be sure not to put the machine on
the power cord.
If the machine is placed on a blanket or floor, adjust the soles of the feet to allow air to
circulate at the bottom.
After the dryer is installed, check that the machine is pressing on the power cords or
ventilation ducts.
G round
≥10A
This machine is only suitable for home use.
The machine is only suitable for clothes that can be dried by the machine. Please check the
label of clothing.
Please don't leave the drying clothes in the dryer for a long time.
Dry clothes should not exceed the rated capacity of the machine.
Before drying clothes, you need to use the washing machine to dehydrate. Do not put the
dripping clothes into the dryer.
Clothes exposed to volatile petroleum products should not be dried with this machine.
If the wiring, panel or the bottom of the machine is damaged and easy to contact the internal
components, do not use the machine.
CHILD SAFETY!
Children or people with physical or mental disabilities cannot use the machine without
supervision.
Children in need of supervision cannot play with this machine.
Prevent children or pets from crawling into the dryer barrel.
Packaging materials (such as polystyrene, plastic film, etc.) are dangerous for children to
suffocate. Do not let children touch these items.

7
INSTALLATION
1. DRYER INSTALLATION
Dryer should be installed in a well ventilated place, not in the open air or wet place.
When the back is against the wall, it is not allowed to be close to the curtain, or there are
objects floating with the wind. It is required that the distance from the wall is not less than 10
cm, so as to facilitate the installation of exhaust pipe.
Do not install in sealed rooms. (Such as bathroom, washroom, etc.)
At least 1.5 meters in front of the dryer is required. Keep clear of obstacles and keep
ventilation.
Do not install dryers where gasoline or flammable materials are stored.

DRYER HORIZONTAL ADJUSTMENT
When the dryer is installed on the ground, place the dryer on a flat surface. If one of the four
feet is uneven, you can adjust the sole of the foot. If the dryer is not placed horizontally (the
gradient of the ground is more than 2 degrees), the machine may run unsteadily or stop
halfway.

8
AIR OUTLET PIPE INSTALLATION
Align one end of the threaded nozzle with the air outlet on the back of the dryer, insert it, and
then screw it clockwise. Move the other end of the exhaust pipe to one side (2), or extend
from the window or wall opening to the outside. Install correctly, as shown in (3).
Air vent
2
3
ACCESSORIES
1
User manual
2
Air duct

9
COMPONENTS
The company reserves the right to change the product design. The product you purchased
may be improved and not completely consistent with the manual, but the performance and
use method will not be changed.
The front air outlet, rear air outlet, shoe rack, inverted rack and inverted bracket are selected
according to different models. Some models may not have them.
Roof b oard
Cont rol panel
Door
T ub
F ilt er
Box
4 pc s Adjus t ing
f oot B ac k air v ent
B ac k boar d
Temp erature
c ont r oll er
Power l ine

10
CONTROL PANEL
ON/OFF: turn on the machine and tap to turn off machine.
STENILIZATION: for a small amount of clothing disinfection.
FINE: for meticulous clothing.
UNDERWEAR: for underwear.
JEANS: for jeans.
Heavy: Large items of clothing do not include quilts or similar items.
BABY CLOTHES: for baby clothes.
SYNTHETIC: for chemical synthetic fabrics.
COTTON: for cotton-ramie fabrics.
LESS: A small amount of clothes
Standard: Clothes are suitable for wearing.
Super Dry:over dry.
START/PAUSE: Start the machine and pause the machine.
TIMING: 30, 50, 70, 90 minutes of regular drying.
CREASE-RESIST: After the automatic drying, the dry clothes can no .emitnituonekatebt
The anti-wrinkling light is on when selecting.
FILTER: After each use, the indicator light of the filter screen lights up, and clean the fil ret
screen. The warning light will be off next time.
CHILD LOCK: Child lock.

11
Guide
Machine will be off automatically after drying program
USE AND FUNCTIONS
1.FIRST USE
Please take out everything in the barrel.
Please connect the circuit according to the installation instructions.
It is recommended to clean the inner barrel with a wet cloth when using it for the first time,
because there may be some dust in the inner barrel.

12
2. TURN ON ELECTRICITY
After turn on the power and open the door.
Shake the clothes and put them into the bucket. Shake them as evenly as possible.
Close the door and check that the clothing is not stuck between the door or the filter screen,
otherwise it is easy to tear the clothes.
3. SELECT PROGRAM
Turn the program knob to the required program position, and the display will shows the
approximate time according to different programs. If the “START/PAUSE” button is not
pressed within two minutes. Then the machine will go into sleep state and can only be
activated by turning the knob again. During the working process of the machine, the ":" on the
display will keep flashing.
4. AUTOMATIC DRYING CONTROL
Select the appropriate program according to the type of clothes, and then press the
“START/PAUSE” button, the machine will automatically detect the humidity of clothes,
automatically adjust the time according to the humidity of clothes, and automatically shut
down after drying.
5. CONTROL DRYING TIME
According to your own needs, you can choose 30, 50, 70, 90 minutes of drying time. This
procedure is suitable for drying a small amount of clothing. If you want to stop the program,
you can directly tap the "ON/OFF” button.
6. PROGRAM SELECTION
According to the material and personal needs of the clothes, turn the knob to the required
program, and then press the “START/PAUSE” button to start. When the machine is working,
turning the knob again will not work. If you need to reselect the program, first press
“START/PAUSE” button to pause and then select the program.
7. “START/PAUSE” BUTTON
After selecting the program, press this button to start the machine. If you press this button
again or open the door in the process of work, the machine will enter the pause state. After
the door is closed again, you need to press this key again, and the program will continue to
run from the interrupt point.
8. “CREASE-RESIST” BUTTON
If you select this button, the clothes can't be taken out in time after drying, and it will roll
automatically. When selected, the anti wrinkle light is on. This function can be added and
selected after the program is selected by the knob. After drying, the "000" will be displayed,
and the "END" function will be displayed after 10 minutes.
9. “TIMING SELECTION”
Turn the knob, can be timed from 30 minutes, 50 minutes, 70 minutes, 90 minutes, you can

13
choose the right drying time. This program does not do automatic judgment.
10.“CHILD LOCK” BUTTON
11. “LED”
12.“MANUAL TEMPERATURE CONTROL” RESET BUTTON
Manual temperature control reset button
At the same time, press and hold the " TIMING” and “CREASE-RESIST” buttons for 2
seconds, the machine enters the locking state, and the child lock light is on. Only the knob
key is available for the machine, and other buttons are out of action. At the same time, press
and hold the " TIMING” and “CREASE-RESIST” buttons for 2 seconds, the machine enters
the unlocking state, and the child lock light is off.
When the program is selected, the approximate drying time is displayed. When the program
is started, the display will show the remaining time.
When there is a fault or incorrect operation, the fault code will be displayed.
When the program ends, "END" is displayed.
Select anti wrinkle function, anti wrinkle light on.
After drying, the "FILTER” light of the clothes dryer is on to prompt cleaning, the next prompt
for cleaning, and the light will be off after the next startup.
When "ERR" is displayed at the same time, it means that the operation is invalid.
In the process of operation, if there is no heating, the manual temperature control may be
disconnected. First turn the knob to the drying program, and then start the machine. After
about 20 minutes, press the reset button.
15. END
After the end of all procedures, there is a wind-tunnel flow stage. After the completion of the
program, "END" will appear on the display screen, and six alarm sounds will sound. No
operation will be carried out. After 3 minutes, the machine will enter into sleep state. Turn off
the power and the machine is in the off state.
16. AFTER USING
After using of the machine, "Filter screen” light is on, please clean the filter.
If the process is stopped before the machine is finished, please avoid removing the clothes in

14
time.
During the drying process, if you want to reselect the program, first press the
"START/PAUSE” button to pause the original program, then turn the "PROGRAM KNOB” to
select a new program, and then press the "START/PAUSE” button to restart.
Note: Please do not worry if the clothes less than 2kg have not been dried after drying. It may be
that the clothes are too few to touch the induction device. It is recommended to use the timing
program to dry this type of clothes.
DRY GUIDE
The following types of clothing are not allowed to be placed in the dryer: special fine clothing
such as mesh curtains, wool fabrics, silk, artificial materials with metal accessories, nylon
tights, large items such as hooded windbreaker, blanket, duvet, duvet, sleeping bag and any
clothing containing sponge rubber or similar substances.
Follow the drying instructions on the clothing label.
It is usually used for machine drying.
Indicates conventional drying (high temperature).
Indicates gentle drying (low temperature).
It means that machine drying is not possible.
Button up the pillowcase and jacket to prevent small items from getting entangled inside.
Separate clothes according to the material and the degree of drying required.
To prevent wrinkles and save energy, do not over dry.
Don't put dark clothes with light colored fluffy objects, such as towels, because they will suck
fur.
Rotate and stir the clothes well before rolling to dry them.
Fine clothes such as shirts should also be simply rotated and stirred before drying.
Knitwear (knitted sweater, underwear) may shrink a little during the drying process, so do not
over dry. It is suggested that the shrinkage factor should be considered when purchasing
such clothing.
To prevent static electricity after drying, you can add softener or softener for machine drying.
After drying, please take out the clothes. If some clothes are still wet, you can continue to dry
them, but do not exceed 30 minutes. Usually, some folded clothes such as neckline need this

15
step.
Before putting clothes into the machine, please take out all metal objects (such as hairpins,
safety pins, pins, etc.)
Please remove stubborn stains before drying.
Special treatment curtain: take off the hook and tie it in the net bag.
Maintenance and cleaning
Before any maintenance and cleaning of the machine, please disconnect the power supply.
Housing cleaning: only use soap and water for cleaning and then wipe thoroughly.
Important: do not use alcohol, diluents and similar items to clean the outside of the housing.
Clean the inside of the door regularly to remove the fluff around the filter screen and in the
door seam.
Only when the filter screen is clean can the machine work normally and efficiently. During the
drying process, the filter will collect the fluff. When cleaning, please take out the filter screen
inside the machine and clean the filter screen with warm water dipped in a brush.
Warning: do not use this machine without a filter. Otherwise, it will damage the machine and
clothes, and even cause danger.
Open the door, take out the filter screen and install it as shown in the figure below. If the filter
is not installed, the machine may be damaged.
1
2 3
4
EORR
TROUBLE SHOOTING
Some faults are caused by the lack of simple maintenance and inspection, which can be
easily solved without maintenance personnel. Please read the common faults and solutions
listed below carefully before you call for repair.

16
When the machine fails, the machine will display the fault code. Please remove it according
to the following table. After troubleshooting, press the "START/PAUSE” button again to restart
the program. If the problem still exists, please contact us.
Problem Display Cause Solution
Totally no
working
No display The plug is not plugged in properly. It is
in the shutdown state
Plug the plug tightly and
press the ON/OFF button
for a long time
No display
The socket has no electricity or the fuse
is blown
Ask the electrician to check
the socket
Displays
DOP
The door is open
Power on and restart as
required
Display
normal
No press the “START/PAUSE” button Press the “START/PAUSE”
button
The drying effect
is not ideal
Display
normal Program selection error
Please reselect the
procedure according to the
drying schedule
Display
normal
Filter screen clogging Clean the filter screen
Display
normal
Unreasonable amount of dry clothes
Please check the
recommended dry weight
Display
normal
There is something attached to the
humidity sensor
Cleaning the surface of
humidity sensor
The drying cycle
ends soon after
the procedure
begins
END Too little clothes
If there is too little dry
clothes, it is recommended
to choose the regular drying
procedure
END The added clothing is too dry for the
selected procedure
Choose a higher drying
standard
For example, use extreme
dry instead of standard
The program took
too long to run
Display
normal
Too much clothes Reduce the amount of
clothing
Display
normal The clothes didn't spin-dry first
The clothes should be
spin-dried before they are
put into the dryer
Door lock failure Display
DOP
Door open
Close the door
The wiring terminal is not plugged in
properly or the wiring harness is faulty
Please have professional
maintenance personnel
overhaul.
Door lock failure
Please have professional
maintenance personnel
overhaul.
Computer board failure
Please have professional

17
maintenance personnel
overhaul.
Abnormal
temperature E1
The wiring terminal is not plugged in
properly or the wiring harness is faulty
Please have professional
maintenance personnel
overhaul.
Computer board failure
Please have professional
maintenance personnel
overhaul.
Temperature sensor failure
Please have professional
maintenance personnel
overhaul.
Heating wire
failure E2
The wiring terminal is not plugged in
properly or the wiring harness is faulty
Please have professional
maintenance personnel
overhaul.
Heating wire failure
Please have professional
maintenance personnel
overhaul.
Computer board failure
Please have professional
maintenance personnel
overhaul.
Argument
SPECIFICATION SHEET
Model DV80-WL1V
Voltage 50Hz
Capacity (kg) 8.0
Power(W) 2000
Net weight(kg) 30
Gross weight(kg) 33
Product size(mm) 598×555×845
Package size(mm) 650×580×880
Note: our company reserves the right to change the design of the product. The product you
purchased may have been improved and not completely consistent with the manual, but the
performance and use method will not be changed. Please feel free to use it.
220V / 50-60Hz
8.0
1800W
555x598x845
580x650x880

18
ENVIRONMENTAL FRIENDLY MATERIALS
PACKAGING MATERIALS
If there is a " " mark on the material, it indicates that it can be recycled.
>PE >PS >PP
Correct Disposal of this product
This marking indicates that this product should not
be disposed with other household wastes
throughout the EU. To prevent possible harm to
the environment or human health from
uncontrolled waste disposal, recycle it responsibly
to promote the sustainable reuse of material
resources. To return your used device, please use
the return and collection systems or contact the
retailer where the product was purchased. They
can take this product for environmental safe
recycling.
In order to save energy and protect the environment, we propose the following:
Try to make the machine work more load, because small load work is not economic.
To avoid wrinkling and save energy, do not dry the dry clothes.
Choose the drying procedure according to the drying procedure and type of clothes.
Clean the filter screen regularly to avoid increasing drying time and wasting power.
Keep indoor ventilation and the indoor temperature should not exceed 35 ℃.
WIRING DIAGRAM

HZH MARINE GROUP CO., LTD
Web : www.hzhmarine.com / www.huazhihang.com
Tel:[phone] Email: [e-mail]
