IOGear KeyMander GE1337P User manual

Quick Start Guide
GE1337P
PART NO. Q1257-a
www.iogear.com
Controller Emulator for use with
Game Consoles
This Quick Start Guide is intended to cover basic setup and key
functions to get you up and running quickly.
For a complete explanation of setup and features, please
download the KeyMander User Manual from
www.IOGEAR.com/Product/GE1337P

1
Package Contents
System Requirements
1 x GE1337P KeyMander Controller Emulator
2 x USB A to USB Mini B Cables
1 x Quick Start Guide
1 x Warranty Card
Hardware
Game Consoles:
• PlayStation® 4
• PlayStation®3
• Xbox® 360
• Xbox® One
Console Controller:
• PlayStation® 4 Controller
• PlayStation® 3 Dual Shock 3 Controller (REQUIRED)*
• Xbox® 360 Wired Controller (REQUIRED)*
• Xbox® One Controller with Micro USB cable (REQUIRED)*
• USB keyboard & USB mouse**
Computer with available USB 2.0 port
OS
• Windows Vista®, Windows®7 and Windows®8 / 8.1
*Some aftermarket wired controllers do not function correctly with KeyMander.
It is strongly recommended to use official PlayStation/Xbox wired controllers.
**Compatible with select wireless keyboard/mouse devices.

Gamepad Mouse
Keyboard
PowerPC
Game
Reset
4
1 2 3
5
6
7 8 9
10
2
Overview
*Some gaming keyboards may have accessories that require more power than the
KeyMander can supply, requiring an external power supply. Please visit
www.shopiogear.com to order part GPA60002 1A USB power supply. Connect
supplied USB A to Mini B cable between KeyMander and power supply.
1. Gamepad port
2. Keyboard port
3. Mouse port
4. Turbo/Keyboard Mode LED
Indicator:
a. Lights solid ORANGE
when Turbo Mode is ON
b. Flashes ORANGE when
Keyboard Mode is ON
5. Setting LED indicator:
a. Lights solid BLUE when PC port
is connected to a computer.
b. Flashes (Fast) BLUE when
uploading a profile from a
computer to the KeyMander.
c. Flashes (Slow) BLUE when Direct
Mapping Mode is on.
6. Power LED indicator
7. Reset button
8. Game Console connection port
9. PC connection port
10. Power port (optional).
Connect to an optional
5VDC power supply for high
current keyboards, such as
those with built-in USB hubs
and headphone ports, etc.*

Gamepad Mouse
Keyboard PowerPC
Game
Reset
21 3
LR
SELECT START
4
3
Hardware Setup
1. Connect your console controller to the Gamepad Port.
2. Connect your USB Keyboard to the Keyboard Port.*
3. Connect your USB Mouse to the Mouse Port.
4. Using the included USB cable, connect the mini USB B plug to the
Game Port on the back of KeyMander, then connect the USB A plug to
a controller port on the console.
5. Power on the console and your KeyMander is ready to use.
*When using a wireless keyboard & mouse set, plug the receiver into the Keyboard
Port. Some wireless keyboard & mouse sets may not be supported.
Note: KeyMander is compatible with some, but not all PC gaming devices such as
keyboards, keypads and mice. When using a compatible PC configurable device,
be sure to setup/program your device on the PC before connecting it to
KeyMander. You may need to try different device settings and/or Keymander
settings to achieve best performance.

4
Keyboard / Gamepad Mode
Use the [F9] hotkey to switch between Keyboard Mode and Gamepad Mode:
Single Beep - Keyboard Mode On
Double Beep - Gamepad Mode On
Keyboard Mode activates the normal typing function of the keyboard for
operating in system menus, chatting during gameplay, or when using the
internet functions of the gaming console.
Gamepad Mode activates the controller emulation for gaming functions
using the keyboard & mouse. Gamepad Mode is the default setting. Must be
in Gamepad Mode when in game.
Hotkeys
Hotkey
[F1] ~ [F8] Switch
Profile
Switches to a Profile in the Group in Use-according to the
Profile Selection Hotkey assigned to the profile.
[F1]: Default PS Profile
[F2]: Defualt Xbox Profile
[F9] Keyboard /
Controller
Mode
Toggles between Keyboard and Controller Mode.
Keyboard Mode: Allows you to type text during gameplay.
Controller Mode: Allows you to use the keyboard as a game
controller on the PS / Xbox.
[F10] Turbo Mode Turns Turbo Mode on and off. When Turbo Mode
is on, controller buttons with Turbo settings work.
[F11] Macro Mode Turns Macro Mode on and off. When on, Macro keys that are
pressed will execute macro commands.
[F12] Play Mode Play mode allows you to use a laptop’s keyboard and touchpad
for gameplay.
Function Description

5
SELECT START
LR
1
2
1
2



Q
E
Left Shift
W
A D
S
D-Pad
L3R3
Tab




Players
Movement
Left Analog Stick
Movement
=
Basic Operation - Keyboard Layout (PS4)
OPTIONSSHARE
Spacebar
C
R
F
Backspace
Default keyboard map for PS4 controller functions:
Enter
Esc
L2 R2

6
Basic Operation - Mouse Layout (PS4)
Right Mouse click Left Mouse click
Mouse
Movement
Right Analog
Stick movement
=
LB RB
Default mouse map for PS4 controller functions:
SHARE
L1
L2
R1
R2
OPTIONS

SELECT START
LR
1
2
1
2



Backspace Enter
Esc Q
F
Spacebar
R
E
Left Shift
C
Default keyboard map for PS3 controller functions:
W
A D
S
D-Pad
L3R3
Tab




Players
Movement
Left Analog Stick
Movement
=
Basic Operation - Keyboard Layout (PS3) 7

SELECT START
LR
1
2
1
2
8
Default mouse map for PS3 controller functions:
Right Mouse click Left Mouse click
Mouse
Movement
Right Analog
Stick movement
=
Basic Operation - Mouse Layout (PS3)

9
Default keyboard map for Xbox controller functions:



Enter
Esc
1
Tab
R
C
Space Bar
Left Shift
E
Basic Operation - Keyboard Layout (Xbox)
Players
Movement
Left Analog Stick
Movement
=
RC
LC
W
A D
S




D-Pad
QG
LB RB

10
Right Mouse click Left Mouse click
Mouse
Movement
Right Analog
Stick movement
=
Basic Operation - Mouse Layout (Xbox)
LB RB
LT RT
Default mouse map for Xbox controller functions:

Note: Changes made to Direct Mapping Mode are not permanently saved
to a profile.
11
Direct Button Mapping
Direct Button Mapping Mode
Direct Button Mapping allows you to change keyboard or mouse maps
without connecting KeyMander to your PC. Direct Button Mapping requires
connection of your PS/Xbox controller to the KeyMander for basic setup.
To use Direct Mapping:
1. Connect your controller using your USB cable to the Gamepad port on
the KeyMander.
2. Press Share + Options (PS4), Select + Start (PS3), Back + Start (Xbox)
or View + Menu (Xbox One) buttons at the same time. You will hear 1
beep from KeyMander and the Setting LED will flash slowly.
3. Press PS, Xbox Guide, or Xbox button. KeyMander will beep once
again and Setting LED will now flash rapidly. You are now in Direct
Mapping Mode.
a. Press the desired PS/Xbox controller button you wish to map.
KeyMander will beep once to confirm.
b. Press any key on the keyboard or mouse and the controller button
will be mapped to that key. KeyMander will beep once to confirm.
c. Continue steps 3a & 3b until all desired buttons have been mapped
to keyboard or mouse.
4. Press Share + Options (PS4), Select + Start (PS3), Back + Start (Xbox)
or View + Menu (Xbox One) buttons at the same time to exit Direct
Mapping Mode. KeyMander will beep twice and the Setting LED will
stop flashing.
LR
2
3
OPTIONSSHARE
22
33

Note: Changes made in In-Game Mouse Sensivity Mode are not
permanently saved to a profile.
In-Game Mouse Sensitivity Adjustment
Software Installation
11
The KeyMander has the ability to have both Aim/Look and Aim Down Sight
(ADS) Sensitivity adjusted without having to use the KeyMander software
through the In-Game Mouse Sensitivity Mode feature. Set each game’s
look sensitivity and mouse DPI (if possible) to max before adjusting mouse
sensitivity on the KeyMander for optimal results.
To enter into In-Game Mouse Sensitivity Mode:
1. Press Share + Option (PS4), Select + Start (PS3), Back + Start (Xbox)
or View + Menu (Xbox One) buttons at the same time. You will hear 1
beep from KeyMander and the Setting LED will flash.
2. You are now in Mouse Sensitivity Mode.
3. To adjust Aim/Look sensitivity, Press UP or DOWN on the D-Pad. Each
press corresponds to 1 level of sensitivity.
4. To adjust ADS sensitivity, Press LEFT (to increase) or RIGHT (to
decrease) on the D-Pad.
5. Once the desired level of sensitivity has been reached press Share +
Option (PS4), Select + Start (PS3), Back + Start (Xbox) or View +
Menu (Xbox One) buttons to exit out of Mouse Sensitivity Mode. The
KeyMander will beep twice and the Setting LED will stop flashing.
CD Installation
1. Insert included CD into CD/DVD drive.
2. Follow on screen instructions.
3. Launch the software by double-clicking on the software icon.
Online Installation
To download the KeyMander software:
1. Go to www.IOGEAR.com/software/GE1337P/
2. Select the KeyMander Software link to begin download.
3. Once finished, unzip the file to your hard drive.
4. Drag the application icon to the desktop or to a desired file folder
to save the application.
5. Launch the software by double-clicking on the software icon.

12
Note: Changes made in In-Game Mouse Sensivity Mode are not
permanently saved to a profile.
Note: Please use import / export feature in system settings to save all
profiles before updating Keymander software. See user manual for complete
software update instructions.
Firmware Upgrade
Upgrading KeyMander Firmware
To upgrade the firmware on your KeyMander, follow the steps below:
1. Go to www.IOGEAR.com/software/GE1337P/
2. Select the latest firmware link and download to your PC.
3. Once finished, unzip the file and remember the saved location.
4. Connect your KeyMander to your PC:
a. Plug one of the included mini USB B cables to the PC Port located on
the back of the KeyMander.
b. Plug the other included mini USB B cable to the Power Port located on
the back of the KeyMander.
c. Connect both USB cables to your PC
5. Launch the KeyMander software and click “Connect”.
6. On the “Groups & Profiles” page, click “Menu” then “Upgrade Firmware”.
7. Locate the unzipped “firmware.exe” file and click “Open”.
8. The KeyMander software will close and the KeyMander firmware upgrade
utility will launch automatically.
9. Click “Next” to begin the upgrade process. When the firmware upgrade is
complete, click “Finish” and the utility will close.
The KeyMander has the ability to have both Aim/Look and Aim Down Sight
(ADS) Sensitivity adjusted without having to use the KeyMander software
through the In-Game Mouse Sensitivity Mode feature. Set each game’s
look sensitivity and mouse DPI (if possible) to max before adjusting mouse
sensitivity on the KeyMander for optimal results.
To enter into In-Game Mouse Sensitivity Mode:
1. Press Share + Option (PS4), Select + Start (PS3), Back + Start (Xbox)
or View + Menu (Xbox One) buttons at the same time. You will hear 1
beep from KeyMander and the Setting LED will flash.
2. You are now in Mouse Sensitivity Mode.
3. To adjust Aim/Look sensitivity, Press UP or DOWN on the D-Pad. Each
press corresponds to 1 level of sensitivity.
4. To adjust ADS sensitivity, Press LEFT (to increase) or RIGHT (to
decrease) on the D-Pad.
5. Once the desired level of sensitivity has been reached press Share +
Option (PS4), Select + Start (PS3), Back + Start (Xbox) or View +
Menu (Xbox One) buttons to exit out of Mouse Sensitivity Mode. The
KeyMander will beep twice and the Setting LED will stop flashing.
CD Installation
1. Insert included CD into CD/DVD drive.
2. Follow on screen instructions.
3. Launch the software by double-clicking on the software icon.
Online Installation
To download the KeyMander software:
1. Go to www.IOGEAR.com/software/GE1337P/
2. Select the KeyMander Software link to begin download.
3. Once finished, unzip the file to your hard drive.
4. Drag the application icon to the desktop or to a desired file folder
to save the application.
5. Launch the software by double-clicking on the software icon.

Compliance Information
FCC Statement
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential setting. This product generates, uses, and
can radiate radio frequency energy and, if not installed and used as
directed, it may cause harmful interference to radio communications.
Although this product complies with the limits for a Class B digital
device, there is no guarantee that interference will not occur in a
particular installation.
CE Compliance
This device has been tested and found to comply with the following
European Union directives: Electromagnetic Capability (2004/108/EC),
Low Voltage (2006/95/EC) and R&TTED (1999/5/EC).
The KeyMander has the ability to have both Aim/Look and Aim Down Sight
(ADS) Sensitivity adjusted without having to use the KeyMander software
through the In-Game Mouse Sensitivity Mode feature. Set each game’s
look sensitivity and mouse DPI (if possible) to max before adjusting mouse
sensitivity on the KeyMander for optimal results.
To enter into In-Game Mouse Sensitivity Mode:
1. Press Share + Option (PS4), Select + Start (PS3), Back + Start (Xbox)
or View + Menu (Xbox One) buttons at the same time. You will hear 1
beep from KeyMander and the Setting LED will flash.
2. You are now in Mouse Sensitivity Mode.
3. To adjust Aim/Look sensitivity, Press UP or DOWN on the D-Pad. Each
press corresponds to 1 level of sensitivity.
4. To adjust ADS sensitivity, Press LEFT (to increase) or RIGHT (to
decrease) on the D-Pad.
5. Once the desired level of sensitivity has been reached press Share +
Option (PS4), Select + Start (PS3), Back + Start (Xbox) or View +
Menu (Xbox One) buttons to exit out of Mouse Sensitivity Mode. The
KeyMander will beep twice and the Setting LED will stop flashing.
This Quick Start Guide is intended to cover basic setup and key
functions to get you up and running quickly.
For a complete explanation of setup and features, please
download the KeyMander User Manual from
www.IOGEAR.com/Product/GE1337P

Limited Warranty
Contact
WE’RE HERE TO HELP YOU!
NEED ASSISTANCE SETTING UP THIS PRODUCT?
Make sure you:
1. Visit www.iogear.com for more product information.
2. Visit www.iogear.com/support for live help and product support.
Warranty Information
This product carries a 3 Year Limited Warranty. For the terms and
conditions of this warranty, please go to http://www.iogear.com/sup-
port/warranty.
Register online at http://www.iogear.com/register
Important Product Information
Product Model
Serial Number
IOGEAR
iogear.custhelp.com
[e-mail]
www.iogear.com
19641 Da Vinci, Foothill Ranch, CA 92610
© 2014 IOGEAR
®
