IP CLEANING 1250 User manual

MANUALE ISTRUZIONI PER L’USO /
OPERATOR’S MANUAL / MANUEL D’INSTRUCTIONS /
BEDIENUNGSANLEITUNG /
MANUAL DE INSTRUCCIONES / BRUKERHÅNDBOK /
GEBRUIKERSHANDLEIDING / MANUAL DE UTILIZAÇÃO /
INSTRUKTIONSBOK / МАШИНА ДЛЯ МОЙКИ И СУШКИ ПОЛОВ
/ KULLANIM KILAVUZU
Consultare attentamente questo manuale prima di procedere a qualsiasi intervento sulla macchina
Read this manual carefully before carrying out any work on the machine
Lire attentivement ce manuel avant toute intervention sur la machine
Vorliegendes Handbuch vor jedem Eingri󰀨 an der Maschine aufmerksam durchlesen
Consulte detenidamente este manual antes de llevar a cabo cualquier trabajo en la máquina
Konsulter denne håndboken nøye før du går i gang med noen som helst type inngrep på maskinen
Raadpleeg deze handleiding aandachtig alvorens met enige werkzaamheid aan de machine te beginnen
Consulte atentamente este manual antes de efectuar qualquer intervenção na máquina
Läs noggrant igenom denna handbok innan du utför något som helst ingrepp på maskinen
Внимательно ознакомьтесь с данной инструкцией до проведения любой работы с машиной
Makine ile herhangi bir işlem yapmadan önce bu kılavuzu dikkatle okuyun
1250 - 1280

ITGB
ENGLISH
(Translated instructions)
2

TECHNICAL CHARACTERISTICS ........................................................................4
MACHINE DIMENSIONS ........................................................................................7
SAFETY SYMBOLS ................................................................................................8
GENERAL INFORMATION .....................................................................................9
Purpose of this manual .................................................................................................................. 9
Identifying the machine .................................................................................................................. 9
Documentation provided with the machine ................................................................................... 10
TECHNICAL INFORMATION .................................................................................11
General description....................................................................................................................... 11
Parts of the machine ..................................................................................................................... 11
Hazard areas................................................................................................................................. 12
Accessories................................................................................................................................... 12
SAFETY INFORMATION .......................................................................................13
Safety precautions ........................................................................................................................ 13
MOVEMENT INSTALLATION ...............................................................................15
Lifting and transporting the packaged machine ............................................................................ 15
Delivery checks............................................................................................................................. 15
Unpacking ..................................................................................................................................... 15
Batteries (Battery version)............................................................................................................. 15
Batteries: preparation.................................................................................................................... 16
Batteries: installation and connection............................................................................................ 16
Batteries: removal ......................................................................................................................... 17
Choosing a battery charger........................................................................................................... 17
Preparing the battery charger ...................................................................................................... 17
Preparing the engine (Petrol and Dual Power versions).............................................................. 17
Preparing the hydraulic circuit (Petrol and Diesel versions).......................................................... 17
Fitting the side brushes................................................................................................................. 17
Lifting and transporting the machine............................................................................................. 18
PRACTICAL GUIDE FOR THE OPERATOR .........................................................19
Preparing the machine for work .................................................................................................... 19
Controls of the Battery and Dual Power versions ......................................................................... 20
Operating the Battery and Dual Power versions........................................................................... 22
Controls of the Petrol and Diesel versions.................................................................................... 22
Operating the Petrol and Diesel versions...................................................................................... 25
Emptying the bottom unloading debris bin.................................................................................... 26
Emptying the top unloading debris bin.......................................................................................... 27
Finishing work ............................................................................................................................... 27
Moving the machine when not in operation................................................................................... 27
PERIODS OF INACTIVITY ....................................................................................28
MAINTENANCE INSTRUCTIONS .........................................................................29
Maintenance - General rules......................................................................................................... 29
Replacing/installing the main brush ............................................................................................. 29
Adjusting the main brush............................................................................................................... 30
Replacing/installing the side brushes............................................................................................ 30
Adjusting the side brushes............................................................................................................ 31
Replacing/installing the suction lter............................................................................................. 31
Fuses: replacing............................................................................................................................ 33
Battery maintenance and charging ............................................................................................... 34
Changing the engine oil ................................................................................................................ 34
Top up hydraulic circuit oil on PETROL and DIESEL version ....................................................... 35
Periodic checks............................................................................................................................. 36
TROUBLESHOOTING ...........................................................................................37
DISPLAY ALARMS ................................................................................................39
TECHNICAL MENU ...............................................................................................41

GB
TECHNICAL CHARACTERISTICS
BATTERY DUAL POWER PETROL DIESEL
Cleaning width mm 1100
Cleaning capacity per hour m2/h 3800-5600 3800-5600 3800-5600 3800-5600
Main brush motor power W 600 - -
Side brush motor power W 90 - -
Drive motor power 450 W 98 Cm3/rpm
Internal combustion engine starting W-
Internal combustion engine power W-4100 3600 3500
Fuel tank capacity l - 3,1 3,1
Suction motor power W 260 - -
Panel lter shaker motor power W 90
Pocket lter shaker motor power W110
Alternator A -80 - -
Maximum forward speed Km/h 6.2 6.2 6.2 6.2
Maximum reverse speed Km/h 6.2 6.2 4.6 4.6
Maximum negotiable gradient % 12
Debris bin capacity (bottom unloading) l 61
Debris bin capacity (top unloading) l 56
4

GB
Maximum debris bin capacity (top unlo-
ading) Kg 61
Rear wheel diameter mm 250
Front wheel diameter mm 250
Main brush diameter mm 280
Side brush diameter mm 400
Panel lter surface area sq.m. 4
Pocket lter surface area sq.m. 4
Maximum bin tipping height (top unload-
ing) mm 1460
Gross weight 1250 Kg 497 456 435 465
Gross weight 1280 Kg 551 510 489 519
Transported weight 1250 Kg 215 131 75 75
Transported weight 1280 Kg 215 131 75 75
Number of batteries n° 4 2 1 1
Battery voltage V 12
Individual battery capacity Ah (5h) 180 75 45
Power system voltage V 24 24 12 12
Machine dimensions (bottom unloading) mm
X=1615
Z=905
Y=1210
Machine dimensions (top unloading) mm
X=1550
Z=905
Y1=1868
Y2=1210
Battery compartment dimensions
(length, width, height) mm 500X500 (305x185) x 2 / /
Packed size (length, width, height) mm 1740X1100X1410
5

GB
Data subject to variation without warning.
Sound pressure LpA
(dB) 70 84 82 88
Measured sound power Lwa
(dB) 82 94 94 99
Guaranteed sound power Lwa,g
(dB) 83 95 95 100
Vibration level (hand) HAV
m/sec2 2,6 32,5 3,3
Measurement uncertainty, k m/sec2 1,3 1,5 1,3 1,7
Vibration level (body) HBV
m/sec2 0,5 10,5 0,7
Measurement uncertainty, k m/sec2 0,3 0,3 0,3 0,3
6

ITGB
X-Y-Z: See “TECHNICAL CHARACTERISTICS” table
MACHINE DIMENSIONS
X
Y1
Y2
Z
X
Y
Z
7

GB
SAFETY SYMBOLS
WARNING! RISK OF CUTTING
WARNING! RISK OF CRUSHING LIMBS
WARNING! RISK OF ABRASION
WARNING! RISK OF ENTANGLEMENT
WARNING! RISK OF ACID BURNS
WARNING! RISK OF BURNS
MAXIMUM SLOPE
OPERATOR’S MANUAL, OPERATING INSTRUCTIONS
READ THE OPERATOR’S MANUAL
DIRECT CURRENT SYMBOL
INSULATION CLASS, THIS CLASSIFICATION ONLY AP-
PLIES TO MACHINES POWERED BY BATTERIES.
8

GB
GENERAL INFORMATION
Purpose of this manual
This manual has been written by the Manufacturer and is an integral part of the machine1.
It denes the purpose for which the machine has been designed and constructed and contains all
the information required by operators2.
In addition to this manual, which contains information for operators, other publications are available
providing specic information for maintenance personnel3.
The terms “right” and “left”, “clockwise” and “anti-clockwise” refer to the forward movement of the
machine.
Constant compliance with the instructions provided in this manual guarantees the safety of the op-
erator and the machine, ensures low running costs and high quality results and extends the working
life of the machine. Failure to follow these instructions may lead to injury to the operator or damage
to the machine, oor and environment.
Consult the table of contents at the beginning of the manual to nd the section you need rapidly.
Parts of the text requiring special attention are printed in bold and preceded by the symbols illus-
trated and described here.
! DANGER!
Indicates the need for attention in order to avoid a series of consequences which could cau-
se death or serious injury to personnel.
! WARNING!
Indicates the need for attention in order to avoid a series of consequences which could
cause injury to personnel or damage to the machine or work environment or nancial loss.
! IMPORTANT!
Important information.
In line with the company’s policy of constant product development and updating, the Manu-
facturer reserves the right to make modications without prior notice.
Although your machine may di󰀨er appreciably from the illustrations in this document, the
correctness and validity of the instructions contained in this manual are guaranteed.
Identifying the machine
The nameplate provides the following information:
► Model
►Battery voltage
►Total rated power
►Rated current draw
►Serial number
►Year of manufacture
► IP Index of Protection
► Dry weight
► Maximum negotiable gradient
►Name of manufacturer
1 The term "machine" replaces the trade name of the machine described in this manual.
2 Persons responsible for operating the machine but not for performing maintenance operations requiring special
technical skills.
3 Persons with technical experience, training and a knowledge of applicable legislation and standards, able to perform
all necessary operations and to recognise and avoid possible risks in handling, installing, operating and maintaining the
machine.
9

GB
Documentation provided with the machine
► Operator’s manual
► Certicate of warranty
► CE certicate of conformity
