IP Solutions HQC-81KDB User manual

User Manual
OUTDOOR BULLET IP CAMERA
V1.0_20190808

WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS.
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
COPYRIGHT
THE TRADEMARKS MENTIONED IN THE MANUAL ARE LEGALLY REGISTERED TO
THEIR RESPECTIVE COMPANIES.

Table of Contents
1. PREFACE ..................................................................... 1
2. PRODUCT SPECIFICATIONS....................................... 1
3. PRODUCT INSTALLATION ........................................... 6
I. Monitor Settings ........................................................ 6
II. Hardware Installation .............................................. 7
Connector Instruction ............................................ 7
Wireless Antenna (Optional)................................. 8
PoE (Power Over Ethernet) .................................... 8
III. IP Assignment............................................................ 9
IV. Install Active Control ............................................. 13
For users using IE 6.0 or above ........................... 13
Another Method ................................................... 15
For Non-IE Web Browser Users ............................ 16
4. LIVE VIDEO ............................................................... 20
I. Full Screen Mode .................................................. 21
II. Live Video Panel ................................................... 21
III. Submenu ................................................................. 22
5. CAMERA CONFIGURATION .................................... 24
I. System ...................................................................... 24
System Information .............................................. 25
Server Information ............................................... 25
OSD Setting........................................................... 26
Time Setting .......................................................... 27
EasyLink (Optional).............................................. 27
User Management ............................................... 29
Anonymous User Login ....................................... 29
Universal Password .............................................. 29
Add User................................................................ 29
U s e r L i s t......................................................... 30
Default Account.................................................. 30
System Update ..................................................... 31
Firmware Upgrade .............................................. 31
Reboot System ..................................................... 31
Factory Default .................................................... 31
Setting Management ......................................... 31
II. Network.................................................................... 32
IP Settings .............................................................. 33
IP Assignment ....................................................... 33
IPv6 Assignment ................................................... 33
Port Assignment ................................................... 34
UPnP ....................................................................... 34
RTSP Setting........................................................... 36
Multicast Setting .................................................. 37
ONVIF ..................................................................... 37
Bonjour................................................................... 38
LLTD......................................................................... 38
Advanced ............................................................. 39
Https (Hypertext Transfer Protocol Secure) ..... 39
SNMP ...................................................................... 42
Access List ............................................................. 44
QoS/DSCP ............................................................. 44
IEEE 802.1x ............................................................. 45
PPPoE & DDNS ....................................................... 46
PPPoE Setting........................................................ 47
Send mail after PPPoE dialed............................ 47
DDNS Setting......................................................... 47
State ....................................................................... 47
Server Settings ...................................................... 49
Mail Setting ........................................................... 50
FTP Setting ............................................................. 50
Samba (Network Storage)................................. 51
Google Drive Setting........................................... 51
Dropbox Setting ................................................... 55
Wireless Setting ..................................................... 56
Status of Networks in Wireless Setting .............. 56
Connecting to an ad-hoc Wi-Fi network ........ 57
WEP Setting ........................................................... 61
WPA-PSK/ WPA2-PSK Setting.............................. 61
III. A/V Settings ............................................................. 63
Image Setting ....................................................... 64
Camera ................................................................. 64
Privacy Mask......................................................... 64
Image Setting....................................................... 65
Video Setting......................................................... 70
Video System ........................................................ 70
Streaming Settings ............................................... 73
Snapshot Setting .................................................. 77
3GPP Streaming Setting...................................... 77
Audio ..................................................................... 78
IP Camera to PC.................................................. 78
Adjust Volume ...................................................... 78
Sound Detection.................................................. 78
IV. Event List................................................................... 79
Event Setting ......................................................... 80
Motion Detection ................................................ 80
Tampering Detection.......................................... 81
Record File ............................................................ 83
Record Time Setting ............................................ 83
Network Dis-connected ..................................... 84
Network IP Check................................................ 84
Facial Recognition ............................................... 85
Face Detection/Recognition ............................ 86
Face Database Edit ............................................ 87
Group Setting ....................................................... 94
Face Database Manager.................................... 95
Human Data ......................................................... 95
Group and Organization.................................. 100
Log........................................................................ 101
Face Event Search ............................................. 102
Schedule ............................................................. 103
Schedule ............................................................. 103
Snapshot & Record ........................................... 104
I/O Setting ........................................................... 105
Input Setting........................................................ 105
Output Setting .................................................... 106
Log List ................................................................. 107
SD Card................................................................ 108
Playback ............................................................. 108

2
Record ................................................................. 110
SD Management ............................................... 112
SD Card Files ....................................................... 112
Copy to PC ......................................................... 113
6. NETWORK CONFIGURATION................................. 115
Configuration I ........................................................... 115
Configuration II .......................................................... 115
Configuration III ......................................................... 116
7. I/O CONFIGURATION ............................................ 117
I. I/O Connection .................................................... 117
II. I/O Setup................................................................ 118
Input Setting ........................................................ 118
Output Setting ..................................................... 118
8. FACTORY DEFAULT................................................. 120
9. UNIVERSAL PASSWORD ......................................... 121
10.PACKAGE CONTENTS ............................................ 124
11.MICRO SD CARD COMPATIBILITY (OPTIONAL) ... 125

1
1. Preface
This is a 1 / 2.8” Megapixel CMOS Starvis Sensor IP camera with a built-in
web server. The user can view real-time video via IE browser. It supports
H.264+, H.264 and M-JPEG video compression, providing smooth and high
video quality. The video can be stored in Micro SD card and playback
remotely.
With a user friendly interface, it is an easy-to-use IP camera for security
applications.
2. Product Specifications
Main Features:
2 Megapixel IR Bullet IP Camera
H.264+/ H.264/ M-JPEG Compression
Sony Starvis Sensor
Face Detection / Tracking / Capture
Facial attribute recognition
Face Recognition
Group management
Face Snapshot & Event management
True Wide Dynamic Range 120dB
ROI Function
Digital Noise Reduction
Power over Ethernet
Day & Night Manual Switch Time Control
Wide Temperature Range

2
IR Cut Filter Mechanism
Micro SD Card Backup
2-way Audio
IP66
Support iPhone/Android/Mac
SDK for Software Integration including Face Detection & Capture
Free Bundle 36 Ch Recording Software
Hardware
CPU
Multimedia SoC
VPU
Intel® Movidius™ Myriad™ 2 .
RAM
512MB
Flash
128MB
Image Sensor
1 / 2.8” Megapixel CMOS Starvis Sensor
Sensitivity
Color : 0.005 Lux (AGC ON)
B / W : 0.001 Lux (AGC ON)
Lens Type
CS Mount (suggest 5-50mm)
DC IRIS
Yes
ICR
IR cut Filter Mechanism
I/O
2 DI/ 2 DO
RS-485
Yes
Video Output
N/A
Audio
G.711(64K) and G.726(32K,24K) audio compression
Input : Microphone built-in & 3.5 Ø stereo jack (auto
switch)
Output: 3.5mm phone jack, Support 2-way.
Power over Ethernet
Yes
Power Consumption
DC 12V:4.68W
PoE Max:5.76W
Operating Temperature
*IR ON: 50°C
-20°C ~ 70°C [*IR OFF]
Wide Dynamic Range
120dB
S/N Ratio
50dB
Dimensions
65mm (W) x 58mm (H) x 132mm (L)
Weight
450g
Network

3
Ethernet
10/ 100 Base-T
Network Protocol
IPv6, IPv4, HTTP, HTTPS, SNMP, SSL, TLS , DNS , ICMP,
IGMP, ARP, SNTP, QoS/DSCP, IEEE 802.1X,
RTSP/RTP/RTCP, TCP/IP, UDP, SMTP, FTP, PPPoE,
DHCP, DDNS, NTP, UPnP, SAMBA, Bonjour, Google
drive, Drop box, Onvif profile S
Artificial Intelligence Feature
Face Detection/Tracking/Capture
Detection Frame Rate
Up to 15FPS
Maximum Faces
Number
15
Minimum Face Size
80*80 pixels
Face Orientation Angle
Yaw Angle [-60°~+60°]
Pitch Angle [-30°~+30°]
Roll Angle [-45°~+45°]
Accuracy Rate
99%
False Alarm Rate
<0.5%
Repeated capture rate
<10%
Facial Attribute Recognition
Recognition Frame
Rate
Up to 14FPS
Minimum Face Size
80*80 pixels
Face Orientation Angle
Yaw Angle [-30°~+30°]
Pitch Angle [-30°~+30°]
Roll Angle [-30°~+30°]
Accuracy Rate
Age: ±5; gender: 96%;
False Alarm Scenarios
Overexposure, Low lighting, Serious backlighting
scenarios, Exaggerated expression
Attribute Type
Gender; Age
Face Recognition
Recognition Frame
Rate
Up to 7FPS
Minimum Face Size
100*100 pixels
Face Orientation Angle
Yaw Angle [-30°~+30°]
Pitch Angle [-30°~+30°]
Roll Angle [-30°~+30°]
Accuracy Rate
Library of 1000 faces: >97%@1% FPR

4
Library of 10000 faces: >94%@1% FPR
False Alarm Scenarios
Overexposure, Low lighting, Serious backlighting
scenarios, Exaggerated expression
System
Video Resolution[16:9]
1920x1080@30fps, 1280x720@30fps,
640x480@30fps, 320x240@30fps
Video Adjust
Brightness, Contrast, Hue, Saturation, Sharpness,
AGC, Night Mode, True-WDR, Flip, Mirror, Noise
Reduction, Day&Night Adjustable
Features
ROI, Motion Detection, Privacy Mask, Anti Fog,
Tampering Detection, Push Video , P2P(Optional),
Face recognition, Face Detection & Capture, Face
attribute recognition, Face tracking
Triple Streaming
Yes
Image Snapshot
Yes
Full Screen Monitoring
Yes
Privacy Mask
Yes, 3 user defined areas
Compression Format
H.264+/ H.264/ M-JPEG
Video Bitrates Adjust
CBR, VBR
Motion Detection
Yes, 3 different areas
Event
Face Detection, Face Attribute Recognition, Face
Recognition, Face Group, Motion Detection, IP
check, Network break down (wire only), DI,
Schedule
Triggered Action
Mail, FTP, Save to SD card, DO, SAMBA , Dropbox ,
Google Drive
Security
Password protection, IP address filtering, HTTPS
encrypted data transmission, 802.1X port-based
authentication for network protection, QoS/DSCP
Firmware Upgrade
HTTP mode, can be upgraded remotely
Simultaneous
Connection
Up to 10
Integration
Hunt CMS, NVR, APP, and Recording Software; SDK
for 3rd party integration
Micro SD Card Management
Recording Trigger
Face Detection, Face Attribute Recognition, Face
Recognition, Face Group, Motion Detection, IP
check, Network break down (wire only),Schedule,
DI
Video Format
AVI , JPEG

5
Video Playback
Yes
Delete Files
Yes
Web Browsing Requirement
OS
Windows 7, 8, 10 Microsoft IE 11 or above
Mobile Support
iOS 8 or above, Android 4.4.2 or above.
Hardware Suggested
Intel Dual Core 2.8G,RAM, 4GB, Graphic card:
128MB
*SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTIFICATION.

6
3. Product Installation
I. Monitor Settings
Caution: This setting only applies to Windows 7 system users.
a. Right-Click on the desktop. Select Properties
b. Change color quality to highest (32bit).

8
Wireless Antenna (Optional)
(Pictures based on another camera model)
Plug the Antenna into the connector while holding the Antenna bar.
Turn the lock nut to the right until it is totally locked.
Do not bend or try to straight the antenna bar.
PoE (Power Over Ethernet)
802.3af, 15.4W PoE Switch is recommended (Optional)
Power over Ethernet (PoE) is a technology that integrates power into a
standard LAN infrastructure. It allows providing power to a network device,
such as an IP phone or a network camera, using the same cable for network
connection. It eliminates the need for power outlets at the camera locations
and enables easier application of uninterruptible power supplies (UPS) to
ensure 24 hours a day, 7 days a week operation.

9
III. IP Assignment
i. Open the software IP Scanner to assign the IP address of the IP Camera. Find it
in Applications folder from the CD attached of the product package.
ii. Execute the English version of IP Scanner: IPScannerENG
iii. There are 3 kinds of IP configuration.
Fixed IP (Public IP or Virtual IP)
DHCP (Dynamic IP)
Dial-up (PPPoE)
iv. For Windows XP SP2 or above, a Windows Security Alert may pop up. Choose
the network type based on your surveillance environment, and click on Allow
access.

10
v. IP Scanner will search for all the IP Cameras connected on the LAN. The user
can click Search IPCam to search again.
vi. Click one of the IP Cameras listed on the left side. The network configuration
of this IP camera will be shown on the right side once you highlight the device
with your mouse. You can change the name of the IP Camera to your
preference (e.g.: Office, warehouse). Change the parameters and click
Submit.

11
You can select different network cards that you are currently connected to
from the drop-down menu at the top right corner. You can also select the
online device from a specific network card in Device lists, or choose Select All
to include all network card devices in Device lists.
vii. Please make sure the subnet of the PC IP address and the IP Camera IP
address are the same.
The same Subnet Different Subnets
IP Camera IP address: 192.168.1.200 IP Camera IP address: 192.168.2.200
PC IP address: 192.168.1.100 PC IP address: 192.168.1.100
To Change the PC IP address
Control PanelNetwork ConnectionsLocal Area Connection
PropertiesInternet Protocol (TCP/IP) Properties
Make sure your IP Camera and PC are in the same Subnet. If not, change the
IP Camera subnet or the PC IP subnet accordingly below.

12
viii. To quickly access remote monitoring, left-click the mouse twice on the
selected IP Camera listed under Device list of IP Scanner.
ix. A default network browser of the camera control interface will open. Enter
admin for both Username and Password to gain access.

13
IV. Install Active Control
For users using IE 6.0 or above
When viewing the camera video for the first time via IE, the browser will ask you
to install the ActiveX component.
Choose ‘Allow’
The ActiveX component should then be completed and user will be able to
view the live video screen.
If the installation fails, please check the security settings in the IE browser.
Follow the steps below:
1) Go to Start-Up Menu on the lower left corner of the Windows
2) Select Control Panel
3) Double-click on .
4) You will then enter the page of Internet Properties settings.
5) Starting from Internet Properties, proceeding steps as below:

14
Security Custom Level Security Settings Download unsigned
ActiveX controls Enable or Prompt (recommended).
Security Custom Level Security Settings Initialize and script
ActiveX controls not marked as safe Enable or Prompt
(recommended).
i
ii
iii
vi
v

15
When popup the following dialogue box, click Yes.
Another Method
Go to: IE→Tools → Internet Options… → Security Tab → Trusted sites → Add the
IP address and click OK.
In the site list you can key in one single IP address or a LAN address. For
example, if you add 192.168.21.*, all the IP address under 21.* on the LAN will
be regarded as trusted sites.

16
For Non-IE Web Browser Users
If you use Firefox or Google chrome to access the IP camera but fails to
watch the live video, please follow the steps to install necessary tools: (The
following pictures are based on chrome.)
i. You may see the prompt message as the picture below. Click the alink:
Firstly, please install Microsoft Visual C++ 2010 Redistributable Package
(x86).
The link will conduct you to the Microsoft official site where you can
download the tools. Please select the language and click download.
This manual suits for next models
1
Table of contents
Other IP Solutions Security Camera manuals
