IPEX PH232E-2 Series User manual

Doc No: PH232Ex2-UM-001
IPEX
(IP Electronix)
14 January 2022
USER’S MANUAL
PH232Ex2
#2 RS-232 OVER ETHERNET TERMINAL SERVER/CLIENT

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 2 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 3 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
CONTENTS
1. INTRODUCTION ........................................................................ 4
2. SPECIFICATIONS ....................................................................... 4
3. PACKAGE CHECKLIST................................................................. 5
4. TOP VIEW................................................................................. 6
5. BOTTOM VIEW ......................................................................... 6
6. FRONT VIEW............................................................................. 6
7. BACK VIEW............................................................................... 6
8. GENERAL INDICATORS .............................................................. 7
9. PORT INDICATORS .................................................................... 7
10. DEVICE POWER SUPPLY.......................................................... 7
11. RS-232 SERIAL PORTS PIN CONFIGURATION ........................... 8
12. RS-232 CONNECTING METHODS ............................................. 9
13. CONNECTION DIAGRAM....................................................... 12
14. DEVICE CONFIGURATION WEBPAGE ..................................... 14
15. DEFAULT SETTINGS .............................................................. 20
16. NETWORK CONNECTION TESTING ........................................ 21
17. CONNECTING TO DEVICE VIA TCP SOCKET ............................ 23
18. REDIRECTING ....................................................................... 25
19. GUARANTEE......................................................................... 28
20. TECHNICAL SUPPORT ........................................................... 28

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 4 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
1. INTRODUCTION
IPEX PH232Ex2 bidirectional communication terminal server/client is a simple solution for
connecting serial devices to a network which results in having 2 RS-232 serial ports over Ethernet
network. This converter uses transparent communicate protocol, so it is not required to understand
complex Ethernet TCP/IP protocol, and no modification in serial programs is needed. It operates as a
Real COM, TCP Server, TCP Client, UDP Server and UDP Client Full-Duplex converter and supports
bidirectional connection.
PH232Ex2 is designed for industrial usage and is useful for connecting any device with a serial
interface to a computer via Ethernet supported network like LAN, WAN … and can be used in
Industrial Automation, Telecommunications, SCADA Systems, DCS Systems ….
Protection against Surge, ESD and EMI is implemented in its design and it has 3kV insulation
between Ethernet and RS-232 sides. Furthermore, all the RS-232 ports are insulated from each
other too.
2. SPECIFICATIONS
Number of Ports: #2 RS-232 Serial Port, #1 Ethernet RJ45 (10/100 Mbps) Port;
Serial Standard: Meets or Exceeds the Requirements of TIA/EIA-232-F and ITU v.28 Standards;
Network Protocols: ICMP, IP, TCP, UDP, DHCP, Telnet, DNS, ARP, HTTP;
RS-232 Signal (Full Handshake Support): TxD, RxD, DTR, RTS, DSR, CTS, RI, GND;
Baud-Rates: 50, 75, 110, 150, 300, 450, 600, 900, 1200, 1800, 2400, 3600, 4800, 7200, 9600,
14400, 19200, 28800, 38400, 56000, 57600, 76800, 115200, 153600, 184320, 230400, 307200,
460800, 921600 bps; Selectable. Custom Baud-Rates are supported too;
RS-232 Parity: Even, Odd, None, Mark and Space; Selectable;
Power (Green) LED Indicator;
Transmit (Blue) and Receive (Yellow) LED Indicator for All Ports;
TCP Server (Green), TCP Client (Green) and UDP (Green) LED Indicator;
ESD Protection: RS-232 Bus-Pin ESD Protection Exceeds ±15 kV Using Human-Body Model (HBM);
Dimensions: 145mm x 118mm x 27mm (5.70in x 4.65in x 1.06in);
Operating Temperature: -20°C to +85°C (-4°F to +185°F);
1 Year Guarantee and 5 Years Support.

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 5 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
3. PACKAGE CHECKLIST
Before installing the PH232Ex2, verify that the package contains the following items:
1) #1 PH232Ex2 Multiport 2) #1 Quick Start Guide
3) #1 Document and Driver CD-ROM 4) #2 DB9 Female Connector
5) #1 220V AC to 12V DC Adaptor 6) #2 Din Rail Brackets with the corresponding screws
NOTE: Notify your sales representative if any of the above items is missing or damaged.

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 6 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
4. TOP VIEW
5. BOTTOM VIEW
6. FRONT VIEW
7. BACK VIEW

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 7 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
8. GENERAL INDICATORS
POWER LED (Green): It is turned ON, when the power supply connects to +VDC and GND correctly.
9. PORT INDICATORS
TCP Server LED (Green): Blinking this LED shows that the TCP Server mode for this port is selected and
device is trying to connect in this mode. If the device connects to a client, then this LED turns on
continuously.
TCP Client LED (Green): Blinking this LED shows that the TCP Client mode for this port is selected and
device is trying to connect in this mode. If the device connects to a server, then this LED turns on
continuously.
UDP LED (Green): Blinking this LED shows that the UDP mode for this port is selected and device is
trying to connect in this mode. If the network works properly, then this LED turns on continuously.
PE LED (Red): It is blinking if the device detecting a Parity Error in data.
RX LED (Yellow): It is blinking when the device receive data on serial port.
TX LED (Green): It is blinking when data is transmitting from the device serial port.
REDIRECT IN (YELLOW): It is turned on if data from other ports are redirected to this port.
REDIRECT OUT (GREEN): It is turned on if data from the port are redirected to any other port.
10.DEVICE POWER SUPPLY
To working properly, you should connect a DC Power Supply to PH232Ex2. The voltage of the Power
Supply should be from +8V to +48V. For example, this device is working with a single +12V, +15V or
+24V DC Adaptor as well.

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 8 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
11.RS-232 SERIAL PORTS PIN CONFIGURATION

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 9 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
12.RS-232 CONNECTING METHODS
-Modem Connection (to a Modem, any DCE devices)
Modem or other DCE devices
DB9-Female Pin Number
PH232Ex2 Port as DTE
DB9-Male Pin Number
Pin 1: DCD (Output)
Pin 1: DCD (Input)
Pin 2: RxD (Output)
Pin 2: RxD (Input)
Pin 3: TxD (Input)
Pin 3: TxD (Output)
Pin 4: DTR (Input)
Pin 4: DTR (Output)
Pin 5: GND (Ground)
Pin 5: GND (Ground)
Pin 6: DSR (Output)
Pin 6: DSR (Input)
Pin 7: RTS (Input)
Pin 7: RTS (Output)
Pin 8: CTS (Output)
Pin 8: CTS (Input)
Pin 9: RI (Output)
Pin 9: RI (Input)
(Modem Cable)

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 10 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
-Null Modem Connection (to PC, PLC, RTU or any other DTE devices)
PC,PLC or other DTE devices
DB9-Male Pin Number
PH232Ex2 Port as DTE
DB9-Male Pin Number
Pin 7: RTS (Output)
Pin 1: DCD (Input)
Pin 3: TxD (Output)
Pin 2: RxD (Input)
Pin 2: RxD (Input)
Pin 3: TxD (Output)
Pin 6: DSR (Input)
Pin 4: DTR (Output)
Pin 5: GND (Ground)
Pin 5: GND (Ground)
Pin 4: DTR (Output)
Pin 6: DSR (Input)
Pin 8: CTS (Input)
Pin 7: RTS (Output)
Pin 7: RTS (Output)
Pin 8: CTS (Input)
Pin 1: DCD (Input)
Pin 7: RTS (Output)
(Null Modem Cable)

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 11 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
-Simple Null Modem Connection (to PC, PLC… Without Hardware Flow control)
PC,PLC or other DTE devices
DB9-Male Pin Number
PH232Ex2 Port as DTE
DB9-Male Pin Number
Pin 3: TxD (Output)
Pin 2: RxD (Input)
Pin 2: RxD (Input)
Pin 3: TxD (Output)
Pin 5: GND (Ground)
Pin 5: GND (Ground)
(Simple Null Modem Cable (Without Hardware Handshaking))

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 12 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
13.CONNECTION DIAGRAM
-PH232Ex2 as a Terminal Server
The below diagram is a typical connection configuration of PH232Ex2. You can connect a device with a RS-232
serial port to RS-232 serial port of the PH232Ex2, then you can connect to the device behind the network by any
application software you want by opening a TCP or UDP Socket without need of any auxiliary driver.
Any Device with a RS-232 Port
for example, a Laptop is connected to
PORT1 of PH232Ex2
Network
Switch
Network
Switch
PH232Ex2 in SERVER Mode
Any Device with a RS-232 Port
for example
a PLC, RTU, ... , is connected to
PORT2 of PH232Ex2
PH232Ex2 RJ45 LAN Port Connected to a
Network via a Switch
PC, Laptop or Server
RS-232 RS-232
LAN
LAN

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 13 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
-Client/Server, Peer to Peer Connection
If you want to connect two devices which have only RS-232 Ports to each other via Ethernet network, you can
use this connecting method. Take two PH232Ex2. Set one PH232Ex2 as Server and another one as Client with
adding Remote Server IP and Port Number on it. These two converters are connecting automatically via network
to each other, so RS-232 PORT of Server, connects to RS-232 PORT of Client via network. Now you can connect
your RS-232 devices to COM Ports as shown in the following diagram.
Any Device with a RS-232 Port
for example, a Laptop is connected to
PORT1 of PH232Ex2
Network
Switch
Network
Switch
PH232Ex2 in SERVER Mode
Any Device with a RS-232 Port
for example
a PLC, RTU, ... , is connected to
PORT2 of PH232Ex2
PH232Ex2 RJ45 LAN Port Connected to a
Network via a Switch
PH232Ex2 in CLIENT Mode
Any Device with a RS-232 Port
for example
An Industrial PC is connected to
PORT2 of PH232Ex2
Any Device with a RS-232 Port
for example a PC is connected to
PORT1 of PH232Ex2
RS-232 RS-232
RS-232 RS-232

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 14 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
14.DEVICE CONFIGURATION WEBPAGE
To open device configuration webpage, enter the device IP on your web browser address bar like this figure:
The device Default IP Address is 192.168.1.100 and the default Subnet Mask is: 255.255.255.0
Now enter user name and password to pass the authentication procedure. Default User Name is admin and
default password is admin too.
User Name: admin Password: admin

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 15 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
-Device Information Webpage
You can see some general information about the device such as MAC address, Firmware and Hardware
version and … in this page.

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 16 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
-Security
You can change device configuration webpage user name and password in this page.

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 17 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
-Network Settings
You can change all the network settings, such as device IP Address in this page.
It is important to enter valid data in this section. If you are not sure about your network settings such as DNS
address and …, you should consult to your network administrator before any changing in these settings.

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 18 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
-PORT Settings
You can see and change all the port settings in this page.

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 19 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
-Pinout Guide
RS-232 Port pinout is seen in this page.

www.ipelectronix.com
IPEX (IP Electronix) PH232Ex2: User’s Manual
Page 20 of 28 Doc No.: PH232Ex2-UM-001
14 January 2022
15.DEFAULT SETTINGS
Default IP Address: 192.168.1.100
Default Subnet Mask: 255.255.255.0
Default User Name: admin
Default Password: admin
IMPORTANT NOTICE:
If you change the device IP and forget it, you can see the new IP Address on the serial port. Whenever you turn
on the device, it sends its IP Address and Subnet Mask to the RS-232 PORT1. The ports settings for watching
device IP are fixed to 9600, 8, n, 1. You can easily see this IP Address and Subnet Mask by using a Terminal
Emulation Software such as Microsoft Hyper Terminal.
You can also Reset the device to its Factory Default Settings in this page if necessary.
