IPmotion CAR-A-WAN.112 User manual

Emergency vehicle optimized 3G/4G router with
integrated WLAN hotspot and integrated WLAN client
Manual
CAR-A-WAN.112
CAWv6S7455E, CAWv6S7455PE, CAWv6S7455TE

CAR-A-WAN.112 - User Manual
September 2019
IPmotion GmbH
Ludwig-Rinn-Strasse 8-16
D - 35452 Heuchelheim, Germany
Phone: +49 (0) 641 - 350999 - 0
Fax: +49 (0) 641 - 350999 –90
Email: [email protected]
Internet: www.IPmotion.de
Responsible for the content: Florian Kempff (Managing Director)
Copyright© 2017-2019
All rights reserved.
This manual is protected by copyright. The copyright lies with IPmotion GmbH.
Trademark: All trademarks used are the property of their respective owners.
IPmotion® and CAR-A-WAN. 112® are registered trademarks.
Technical and optical changes as well as printing errors reserved.

Content
3
Content
1Visualization .................................................................................6
2Warranty terms ............................................................................7
3Limitation of liability.....................................................................9
4Safety and security......................................................................10
4.1 General safety instructions............................................................... 10
4.2 Improper installation ........................................................................ 10
4.3 12/24V connection............................................................................ 10
4.4 Mobile radio antennas...................................................................... 11
4.5 Device mounting............................................................................... 11
4.6 Risk of injury...................................................................................... 13
4.7 Risk of damage & injury during installation...................................... 14
4.8 Damage to important vehicle parts.................................................. 14
4.9 Maintenance, service and malfunctions........................................... 15
5Introductory remarks..................................................................16
6System description......................................................................18
7Device description CAR-A-WAN.112 ............................................19

Content
4
7.1 Elements on the front side................................................................19
7.2 Elements on the back ........................................................................20
7.3 SIM card holder in router housing ....................................................22
7.4 Markings and identification features of the CAR-A-WAN.112..........24
7.5 Optical signalling of the CAR-A-WAN.112 .........................................25
7.6 Acoustic messages of the CAR-A-WAN.112 ......................................25
8Storage and unpacking................................................................26
8.1 Storage of the CAR-A-WAN.112 ........................................................26
8.2 Unpacking the CAR-A-WAN.112........................................................26
9Installation and Connection.........................................................27
9.1 Power supply of the CAR-A-WAN.112...............................................28
9.2 Installation sequence.........................................................................28
Assembly............................................................................................28
Power supply .....................................................................................28
Preparation of SIM cards - preliminary consideration......................29
Deactivating the SIM pin ...................................................................29
Lay antenna cable - do not damage!.................................................30
10 Device operation and operation ..................................................31
10.1 CAR-A-WAN. 112 using Web Administration ....................................31
Launch CAR-A-WAN.112 Admin-Web ...............................................31
User settings / password change ......................................................33
Dial-up settings..................................................................................35
Modem settings.................................................................................36
Wireless settings................................................................................38
IP configuration .................................................................................39
DHCP configuration ...........................................................................40
DNS ....................................................................................................40
Port forwarding .................................................................................42

Content
5
Dynamic shutdown ........................................................................... 43
10.2 Commissioning of the CAR-A-WAN.112 ........................................... 44
11 Troubleshooting..........................................................................46
12 Service protocol..........................................................................51
13 Service hotline............................................................................52
14 Technical data.............................................................................53
14.1 Specification CAR-A-WAN.112.......................................................... 53
15 Recycling the CAR-A-WAN.112 ....................................................54
16 Identification of the CAR-A-WAN.112..........................................55
17 Declaration of conformity ...........................................................55

Visualization
6
1 Visualization
The abbreviation CAW stands for CAR-A-WAN.112 in this manual. The
version v6 is not used in this manual.
The following pictograms are used in this manual:
Indicates instructions which, if not observed,
endanger your health, functionality or safety.
Indicates additional information and tips.
Recycling label
Identification of assemblies or parts that must be
disposed of as hazardous waste. Never dispose of
these components in the trash.
This device is intended for use in vehicles. This
applies in all countries of the EU and other countries
following the EU Directive 1999/5/EC without any
exception, except France. There, WLAN outdoors
within the frequency range between 2545-2483.5
MHz shall be limited to 10mW e.i.r.p..

Warranty terms
7
2 Warranty terms
The receipt is considered proof of the first purchase and should be kept in
a safe place. It is required for the claiming of warranty services.
If the product is sold to another user, he is entitled to warranty services for
the rest of the warranty period. The proof of purchase, as well as this
declaration, should pass into its possession upon transfer.
We guarantee that this device is in good working order and technically
complies with the descriptions in the enclosed documentation.
The warranty period for electronic vehicle components corresponds to the
minimum period specified by the legislator.
This warranty does not apply to the following cases:
Defects caused by freight damage, accidents, natural disasters, abuse,
vandalism, improper use, incorrect maintenance or incorrect repair by
third parties.
In case of modifications, unauthorized interventions, faulty operation,
other devices or accessories, incorrect installation, or modifications not
approved by us.
Failure to follow the instructions in the documentation supplied.
Incompatibility of the product due to technical innovations or
regulations that may occur after the purchase.
When using product components which are not authorized by us or
which are incompatible and which lead to malfunctions.
For phenomena which occur in connection with the normal ageing
process of the product (wearing parts).
For defects caused by external devices.
The warranty period for parts replaced and/or repaired under this
warranty shall expire together with the original warranty for the product.
Devices sent in without accessories will be replaced without accessories. In
order to avoid damage in transit, a return of the device will only be
accepted if it is in the original packaging.

Warranty terms
8
Any travel costs incurred are generally excluded from the warranty.
IPmotion GmbH makes no warranties, express or implied, with respect to
this device and its quality, performance, merchantability or fitness for a
particular purpose.
Some jurisdictions do not allow the exclusion of implied warranties. In this
case, the validity of all explicit and / or implicit warranties is limited to the
warranty period.
With the expiration of this period, all guarantees lose their validity. Some
countries do not allow the limitation of the validity of implied warranties
by law, so the above limitation does not apply.

Limitation of liability
9
3 Limitation of liability
Claims for damages are excluded unless they are based on intent or gross
negligence on the part of IPmotion GmbH or its employees. The liability
according to the product liability law remains unaffected. We are under no
circumstances liable for:
Claims brought against you by third parties due to loss or damage.
Loss or damage to your records or data, or the cost of recovering those
records.
Economic consequential damage, including lost profits or savings or
collateral damage, also in the event that the employees of IPmotion GmbH
have been informed of the possibility of such damage.
In no event shall IPmotion GmbH be liable for any incidental, indirect,
special, consequential or other damages of any kind. This includes, without
limitation, damages for loss of profit, business interruption, loss of business
information, or any other loss resulting from the use of the CAR-A-WAN.
112 or in any relationship with the device, whether based on contract,
damages, negligence, strict liability, or other claims, even if IPmotion
GmbH has been informed in advance of the possibility of such damages.
This exclusion also includes any liability which may arise from claims of
third parties against the first purchaser.
Some countries do not allow the exclusion or limitation of incidental or
consequential damages by law, so the above statement does not apply.

Safety and security
10
4 Safety and security
4.1 General safety instructions
Please read and observe the user manual and the
safety instructions listed in this chapter carefully
before carrying out any further steps such as
transportation, storage, connection, commissioning,
etc.
Work on the router and antennas must only be
carried out by authorised specialist personnel.
4.2 Improper installation
Improper installation can lead to damage to the unit or the vehicle!
Special knowledge and skills are required for the installation of the system.
It is strongly recommended that installation be carried out by a specialist
workshop.
4.3 12/24V connection
Only use the supplied adapter plug to connect to the 12/24V DC on-
board power supply of your vehicle.
When connecting the CAR-A-WAN. 112 the power supply of the
CAR-A-WAN. 112 must be protected by a 1A slow-blow fuse (T) that cannot
be switched on again.

Safety and security
11
4.4 Mobile radio antennas
The installation of mobile radio antenna cables on vehicles is not
recommended without expert knowledge and suitable tools.
Poorly assembled or arbitrarily shortened or extended high-frequency
antenna cables can have poor reception and transmission performance and
interfere with other equipment.
Unadjusted, minimal bending radii of antenna cables can lead to breakage
of the core of antenna cables. Poor reception and transmission power can
be the result.
4.5 Device mounting
The router is intended for mounting in motor vehicles. It can be mounted
directly:
on aluminium housing (with four screws Ø 4mm arranged in square,
edge length 145mm)
145mm
145mm

Safety and security
12
or via the already installed housing bracket of the v3/v4.
Never set up or operate the device in a damp environment. Liquids
must also be kept away from the device.
The router must not be mounted near heat sources, as the aluminium
housing must be able to dissipate heat.

Safety and security
13
4.6 Risk of injury
Unsuitable installation locations, missing or insufficiently fixed
brackets can cause injuries in the event of a traffic accident.

Safety and security
14
4.7 Risk of damage & injury during installation
When removing panels, sharp or pointed tools can cause injury and
material damage.
Always loosen parts carefully. Do not apply direct pressure to the
connection cable.
4.8 Damage to important vehicle parts
When drilling mounting holes or driving in sheet metal screws, important
vehicle parts or lines can be damaged.
Ensure that there is sufficient clearance behind the screw and drill holes.

Safety and security
15
4.9 Maintenance, service and malfunctions
Repairs may only be carried out by qualified personnel.
Only those spare parts may be used which comply with
the CAR-A-WAN.112 do not change.
The operating system is an integral part of the
certification process. When using an operating system
not released by IPmotion, there is a risk that the
certification will become invalid. If necessary, the tests
underlying the certification must be carried out again
and, if necessary, the prerequisite for this must be
reassessed.
Software updates should only be installed according to
instructions and when the power supply has been
secured. An interruption of the power supply can lead
to a total failure of the CAR-A-WAN.112.
Software updates should only be carried out with
sufficiently fast mobile phone coverage, since the
transmission time is longer than the follow-up time of
the CAR-A-WAN.112 due to the size of the updates and
could therefore be terminated prematurely.

Introductory remarks
16
5 Introductory remarks
This manual is intended to provide basic information about the router with
integrated wireless LAN hotspot to be installed in the vehicle, namely the
operating principle, the application of the various functions and what to do
in the event of malfunctions.
This manual also contains information on configuration, handling and
installation.
The contents of this device description may change due to advances in
technology. We have made every effort to ensure that the content is
correct and clear.
Should we nevertheless have made mistakes, we are grateful for any
information.
We assume no liability for errors in this description and the resulting
consequences.
The CAR-A-WAN. 112 is designed to connect computers, laptops, netbooks,
smartphones, electronic cash registers with Internet cash function and
other TCP/IP-enabled devices such as webcams from the vehicle to the
Internet:
wired via LAN
wireless via WLAN via WLAN antenna 1 (connected to W1 and W1M)
The CAR-A-WAN. 112 automatically dials up to the Internet and, if
necessary, dials up again if the connection is interrupted. Furthermore,
dial-in rules can be taken into account, such as a roaming lock or minimum
signal quality.
The WLAN antenna 2 (connected to W2 and W2M) functions as a WLAN
Ethernet client and establishes the mobile radio connections automatically
if the WPA2 connection of a stored WLAN (e.g. that of the station or other
service points) is correct.
In the Plus version, the second WAN connection can be
parallel or
alternatively

Introductory remarks
17
In the Trio version, the second or third WAN connection can be
parallel or
alternatively
to secure the availability of the connection.
Three concurrent connections are used as a parallel connection and new
connection requests are distributed across the three connections,
maintaining a path once taken to terminate the individual WAN connection
previously used.
If these WAN connections are 3G (HSPA) and a connection switches to LTE,
all traffic can be redirected to the faster, alternative connection while the
slower connection is disabled. The higher-value connection speed is
allowed to dial in.

System description
18
6 System description
The Linux router CAR-A-WAN. 112 connects local devices connected via
LAN or WLAN to the Internet using up to three data modems. System rules,
such as user-defined rules, control the dial-in behavior.
The power management controls the follow-up time and the almost
complete disconnection from the 24V DC power supply, or correct cold
starts during a manual restart or triggered watchdog of the embedded PC.
Two SIM cards are switchable, each connected with a 3G / LTE modem,
LEDs (inside the housing) signal the operating states, a speaker can emit
warning tones, an optional, tactile switch can trigger the reset of the
router.
The modems transfer their operating heat to the aluminium housing. Plug
connections for the connection of power supply and antennas facilitate
installation and allow installation and removal without tools.

Device description CAR-A-WAN.112
19
7 Device description CAR-A-WAN.112
In this chapter, the corresponding device elements are explained and you
receive the instructions for operation as well as all information on the
device connections.
7.1 Elements on the front side
WWAN means Wireless Wide Area Network, also known as
3G (UMTS), LTE, 4G.
M stands for MIMO. MIMO technology increases reliability
and data throughput.
On the front of the device you will find (from left to right) connections for
2* LAN (RJ45 10/100/1000 MBit/s), a concealed reset button that can only
be pressed with a paper clip, an LED for indicating the operating status, 2*
USB connections and the pin tray for connecting the power supply cable.

Device description CAR-A-WAN.112
20
The power supply connection contacts permanent plus 12-
24V DC (clamp 30), as well as switching plus (clamp 15) and
ground (clamp 31).
LAN connections (RJ45, Ethernet 1-2):
The Ethernet1 and WLAN interfaces are mutually bridged,
i.e. you can also connect your devices to LAN instead of
WLAN. Devices connected to the LAN can communicate
with devices connected to the WLAN. The clients are not
isolated from each other. The Ethernet2 interface is not yet
configured on delivery.
7.2 Elements on the back
On the back of the device, in the upper row, you will find the connections
for the mobile radio modems (WWAN 1-3) and their MIMO connections
WWAN 1M-3M and GPS. The lower row contains the connectors for the
WLAN antennas W1/W1M and the CAN connector.
